Metabo

Metabo Spare Parts for Angle Grinder W 6-115

SKU: Metabo W6-115 - 06111000
€1.66
VAT included

Metabo Spare Parts for Angle Grinder W 6-115

Metabo original spare parts for to make Maintenance or repair electrical or mechanical parts for Angle Grinder W 6-115 - 06111000.

Angle Grinder W 6-115 - 06111000
Metabo Spare Parts for Angle Grinder W 6-7-8/115W
  • Metabo Spare Parts for Angle Grinder W 6-7-8/115W
  • Metabo Spare Parts for Angle Grinder W 6-115
Metabo

Metabo Spare Parts for Angle Grinder W 6-115

SKU: Metabo W6-115 - 06111000 Condition: New
€1.66
VAT included

Metabo Spare Parts for Angle Grinder W 6-115

Metabo original spare parts for to make Maintenance or repair electrical or mechanical parts for Angle Grinder W 6-115 - 06111000.

Angle Grinder W 6-115 - 06111000
settings 34 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
34 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 31400054 Handle cpl. €12.25
2
 photo_cameraImage coming soon 31604061 Spindle stop compl. €3.40
3
 photo_cameraImage coming soon 31603962 Gear housing cpl. €20.92
4
 photo_cameraImage coming soon 34110094 Hexagon nut w.recess €2.02
5
 photo_cameraImage coming soon 31603959 Bevel gear €18.92
6
 photo_cameraImage coming soon 14111046 Fillister head screw €1.66
7
 photo_cameraImage coming soon 14311518 Ball bearing,8x22x7 €3.92
8
 photo_cameraImage coming soon 31520231 Flange €1.32
9
 Armature Sealing Washer for Angle Grinder Metabo W 6-115 34339274 Armature Sealing Washer for Angle Grinder Metabo W 6-115 €5.18
10
 photo_cameraImage coming soon 14311504 Ball bearing, 6x19x6 €4.61
11
 photo_cameraImage coming soon 31603960 Armature w. ball bearing,230V €41.87
12
 Armature Bearing Rubber Holder for Angle Grinders Metabo 115 mm 34409526 Armature Bearing Rubber Holder for Angle Grinders Metabo 115 mm €2.08
14
 photo_cameraImage coming soon 34339207 Motor cap €3.56
15
 Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
16
 photo_cameraImage coming soon 34409755 O-ring 48 x 1 €1.62
17
 photo_cameraImage coming soon 34116101 Spindle €5.66
19
 photo_cameraImage coming soon 31604059 Flange compl.,M14 €27.80
20
 photo_cameraImage coming soon 14112007 Fill. head screw €1.66
21
 photo_cameraImage coming soon 34110690 Flange nut €9.91
22
 photo_cameraImage coming soon 34103116 Clamping flange €13.19
23
 photo_cameraImage coming soon 14112164 Fill. head screw(DIN 7985) €1.76
24
 photo_cameraImage coming soon 31603963 Wheel guard cpl. €11.25
28
 photo_cameraImage coming soon 34336249 Cable clip €2.02
31
 photo_cameraImage coming soon 31101046 Field coil assembly w.field coil, 230V €18.67
33
 photo_cameraImage coming soon 31501316 Motor housing €7.00
34
 photo_cameraImage coming soon 33812216 M-Label,08 52x22 €1.74
35
 Metabo W6-115 Carbon Brush Set 31604063 Metabo W6-115 Carbon Brush Set €23.59
36
 photo_cameraImage coming soon 34300086 Brush holder €2.37
37
 photo_cameraImage coming soon 34325429 Condenser €1.66
39
 Switch for Angle Grinders Metabo W 820-720-6-115 34340826 Switch for Angle Grinders Metabo W 820-720-6-115 €8.15
40
 photo_cameraImage coming soon 34409736 Cable sleeve €1.66
41
 photo_cameraImage coming soon 34449842 Cable with plug €7.34
42
 photo_cameraImage coming soon 34416392 Pin spanner €5.32
880
 photo_cameraImage coming soon 34413097 Grease 50Gr 1,8oz €11.31

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Angle Grinder W 6-115

Metabo original spare parts for to make Maintenance or repair electrical or mechanical parts for Angle Grinder W 6-115 - 06111000.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Angle Grinder W 6-115/06111000

Angle Grinder W 6-115/06111000
# Part Num. Description
1 31400054 Handle cpl.
2 31604061 Spindle stop compl.
3 31603962 Gear housing cpl.
4 34110094 Hexagon nut w.recess
5 31603959 Bevel gear
6 14111046 Fillister head screw
7 14311518 Ball bearing,8x22x7
8 31520231 Flange
9 34339274 Sealing washer
10 14311504 Ball bearing, 6x19x6
11 31603960 Armature w. ball bearing,230V
12 34409526 Rubber bushing
13 34339210 Baffle
14 34339207 Motor cap
15 14111602 Self-tap fill h screw
16 34409755 O-ring 48 x 1
17 34116101 Spindle
18 34100567 Bush
19 31604059 Flange compl.,M14
20 14112007 Fill. head screw
21 34110690 Flange nut
22 34103116 Clamping flange
23 14112164 Fill. head screw(DIN 7985)
24 31603963 Wheel guard cpl.
25 33804780 Rating plate
26 34339208 Switch slide
27 34339209 Switch rod
28 34336249 Cable clip
29 34170414 Self-tap. fill. h. screw
31 31101046 Field coil assembly w.field coil, 230V
32 33812068 Indication label 52X22
33 31501316 Motor housing
34 33812216 M-Label,08 52x22
35 31604063 Carbon brush,230V
36 34300086 Brush holder
37 34325429 Condenser
39 34340826 Switch
40 34409736 Cable sleeve
41 34449842 Cable with plug
42 34416392 Pin spanner
43 33901158 Insulation
880 34413097 Grease 50Gr 1,8oz
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo W6-115 - 06111000
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Diagram Metabo W 6-115

Diagram Metabo W 6-115

Download (186.12KB)
