Metabo Hammer KHA 18 LTX Parts

SKU: METABO KHA18LTX - 00210000
€3.21
VAT included

Metabo Parts for Cordless Rotary Hammer Drill KHA 18 LTX

Fix Your Cordless SDS-Plus Rotary Hammer Drill KHA 18 LTX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

KHA 18 LTX 18v
Metabo Hammer KHA 18 LTX Parts
  • Metabo Hammer KHA 18 LTX Parts
  • Metabo Hammer KHA 18 LTX Parts Diagram

Metabo Hammer KHA 18 LTX Parts

SKU: METABO KHA18LTX - 00210000 Condition: New
€3.21
VAT included

Metabo Parts for Cordless Rotary Hammer Drill KHA 18 LTX

Fix Your Cordless SDS-Plus Rotary Hammer Drill KHA 18 LTX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

KHA 18 LTX 18v
settings 69 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

68 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 34409939 Rubber cap €3.21
2
photo_cameraImage coming soon 34202234 Circlip €1.61
3
photo_cameraImage coming soon 34343292 Adjusting ring €5.27
4
photo_cameraImage coming soon 33900765 Washer €1.61
5
photo_cameraImage coming soon 34200389 Pressure spring €1.61
6
photo_cameraImage coming soon 14311533 Ball €1.61
7
photo_cameraImage coming soon 31605295 Gear housing compl. €26.12
8
photo_cameraImage coming soon 34170481 Screw €1.61
9
photo_cameraImage coming soon 34101321 Supporting disc €1.61
10
photo_cameraImage coming soon 14118129 Circlip €1.61
11
photo_cameraImage coming soon 34207034 Cup spring €3.11
12
photo_cameraImage coming soon 33900487 Friction washer €1.77
13
photo_cameraImage coming soon 34000409 Spur gear €7.29
14
photo_cameraImage coming soon 33900638 friction slice €1.61
15
photo_cameraImage coming soon 34105923 coupling sleeve €17.45
16
photo_cameraImage coming soon 31605303 Drill driving sleeve compl. €57.78
17
photo_cameraImage coming soon 34121061 Piston €5.20
18
photo_cameraImage coming soon 34116156 O-ring,11.9X2.62 €1.61
19
photo_cameraImage coming soon 34121060 Damping ring €2.36
20
photo_cameraImage coming soon 14319464 O-ring €1.77
21
photo_cameraImage coming soon 34105931 Catching sleeve €4.61
22
photo_cameraImage coming soon 14319392 O-ring €5.95
23
photo_cameraImage coming soon 14118184 Circlip €1.81
24
photo_cameraImage coming soon 34409314 Sealing ring €5.17
25
photo_cameraImage coming soon 31604801 Striker compl. €13.26
26
photo_cameraImage coming soon 34121080 exciter sleeve compl. €11.62
27
photo_cameraImage coming soon 34202235 sealing ring €1.61
28
photo_cameraImage coming soon 31605304 Gear flange compl. €34.63
29
photo_cameraImage coming soon 34407067 Felt seal €1.81
30
photo_cameraImage coming soon 34409592 Rubber buffer €1.81
32
photo_cameraImage coming soon 14311530 Thrust washer €1.61
33
photo_cameraImage coming soon 14311550 Axial needle bearing €3.11
34
photo_cameraImage coming soon 31606108 Intermediate gear compl. €79.45
35
photo_cameraImage coming soon 14115492 Cup spring €1.77
36
photo_cameraImage coming soon 33900768 Washer €1.61
37
Control Knob Complete for Rotary Hammer Metabo KHE 2444 31605299 Control Knob Complete for Rotary Hammer Metabo KHE 2444 €8.15
38
photo_cameraImage coming soon 34339834 Seal €1.61
39
photo_cameraImage coming soon 31604561 Shift element compl. €7.29
40
photo_cameraImage coming soon 31604570 safety clutch cpl. €34.63
41
Deth Rod for Rotary Hammer Metabo BH E 6020 S 34151163 Deth Rod for Rotary Hammer Metabo BH E 6020 S €5.00
42
photo_cameraImage coming soon 31400114 Side support handle compl. €13.26
43
photo_cameraImage coming soon 34339831 Sealing washer €1.61
44
photo_cameraImage coming soon 14311589 Ball bearing, 8X 22X 7 €4.61
45
photo_cameraImage coming soon 31001130 Armature €57.78
46
photo_cameraImage coming soon 31606109 Armature compl. €86.61
47
Magnet for Cordless Mitre Saw Metabo KS 18 LTX 216 31101188 Magnet for Cordless Mitre Saw Metabo KS 18 LTX 216 €68.55
48
photo_cameraImage coming soon 34409874 Rubber bushing €1.61
50
photo_cameraImage coming soon 31605321 Brush holder compl.,18 V €15.66
51
photo_cameraImage coming soon 34341057 Switch slide €1.61
52
photo_cameraImage coming soon 34344014 Press button €1.61
53
photo_cameraImage coming soon 34308338 LED lense €2.36
54
photo_cameraImage coming soon 34344015 Pressure plate €1.61
55
photo_cameraImage coming soon 34200177 Pressure spring €1.61
56
photo_cameraImage coming soon 33914751 hook €1.77
57
photo_cameraImage coming soon 34344013 Motor housing €23.28
58
photo_cameraImage coming soon 34344016 Cover left €1.61
59
photo_cameraImage coming soon 34170471 Screw,ST2,9x13 €1.75
60
photo_cameraImage coming soon 34308445 Electronic switch €93.94
61
photo_cameraImage coming soon 34341056 Switch slide,R+L €1.61
62
Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
63
photo_cameraImage coming soon 34344017 Cover right €1.61
64
photo_cameraImage coming soon 33812994 Information plate €1.79
65
photo_cameraImage coming soon 31606107 Maintenance kit €121.87
66
Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
67
photo_cameraImage coming soon 33806259 Rating plate €1.61
68
photo_cameraImage coming soon 14311601 Ball bearing, 5X 13X 4 €3.11
95
photo_cameraImage coming soon 34343968 Battery cover €1.62
880
Grease Tube GF 126 for All Metabo Power Tools 34413080 Grease Tube GF 126 for All Metabo Power Tools €22.39

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Parts for Cordless Rotary Hammer Drill KHA 18 LTX

Metabo genuine spare parts or replacement parts for to repair Cordless SDS-Plus Rotary Hammer Drill 00210000 KHA 18 LTX 18v SDS-Plus

Fix Your Cordless SDS-Plus Rotary Hammer Drill KHA 18 LTX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Cordless Hammer Drill and the respective parts of the code.
METABO KHA 18 LTX - 00210000

METABO 00210000 KHA 18 LTX 18v
# Part Num Description
1 34409939 Rubber cap
2 34202234 Circlip
3 34343292 Adjusting ring
4 33900765 Washer
5 34200389 Pressure spring
6 14311533 Ball
7 31605295 Gear housing compl.
8 34170481 Screw
9 34101321 Supporting disc
10 14118129 Circlip
11 34207034 Cup spring
12 33900487 Friction washer
13 34000409 Spur gear
14 33900638 friction slice
15 34105923 coupling sleeve
16 31605303 Drill driving sleeve compl.
17 34121061 Piston
18 34116156 O-ring, 11.9X2.62
19 34121060 Damping ring
20 14319464 O-ring
21 34105931 Catching sleeve
22 14319392 O-ring
23 14118184 Circlip
24 34409314 Sealing ring
25 31604801 Striker compl.
26 34121080 exciter sleeve compl.
27 34202235 sealing ring
28 31605304 Gear flange compl.
29 34407067 Felt seal
30 34409592 Rubber buffer
32 14311530 Thrust washer
33 14311550 Axial needle bearing
34 31606108 Intermediate gear compl.
35 14115492 Cup spring
36 33900768 Washer
37 31605299 Control knob compl.
38 34339834 Seal
39 31604561 Shift element compl.
40 31604570 safety clutch cpl.
41 34151163 Depth stop
42 31400114 Side support handle compl.
43 34339831 Sealing washer
44 14311589 Ball bearing, 8X 22X 7
45 31001130 Armature
46 31606109 Armature compl.
47 31101188 Field coil compl., 2 pol.
48 34409874 Rubber bushing
49 39999999 Part not needed
50 31605321 Brush holder compl., 18 V
51 34341057 Switch slide
52 34344014 Press button
53 34308338 LED lense
54 34344015 Pressure plate
55 34200177 Pressure spring
56 33914751 hook
57 34344013 Motor housing
58 34344016 Cover left
59 34170471 Screw, ST2,9x13
60 34308445 Electronic switch
61 34341056 Switch slide, R+L
62 14111602 Self-tap fill h screw
63 34344017 Cover right
64 33812994 Indication label
65 31606107 Maintenance kit
66 14111602 Self-tap fill h screw
67 33806259 Rating plate
68 14311601 Ball bearing, 5X 13X 4
95 34343968 Cover cap
880 34413080 Grease FG 126
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
