Metabo Mitre Saw KGSV 216 MC Parts

SKU: Metabo KGSV 216 MC - 15216000
€10.42
VAT included

Metabo Spare Parts for Mitre Saw KGSV 216 MC

Metabo original spare parts for to replace broken parts for to fix Mitre Saw KGSV 216 MC - 15216000.

Mitre Saw KGSV 216 MC - 15216000
Metabo Mitre Saw KGSV 216 MC Parts
  • Metabo Mitre Saw KGSV 216 MC Parts
  • Metabo Mitre Saw KGSV 216 MC Parts Drawing
  • Metabo Mitre Saw KGSV 216 MC Parts Drawing - 1
  • Metabo Mitre Saw KGSV 216 MC Parts Drawing - 2
Metabo

Metabo Mitre Saw KGSV 216 MC Parts

SKU: Metabo KGSV 216 MC - 15216000 Condition: New
€10.42
VAT included

Metabo Spare Parts for Mitre Saw KGSV 216 MC

Metabo original spare parts for to replace broken parts for to fix Mitre Saw KGSV 216 MC - 15216000.

Mitre Saw KGSV 216 MC - 15216000
settings 56 Spare parts
description 3 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
Machine Type: Mitre Saw
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
56 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 316088210 Carbon brush holder compl. €10.42
2
 photo_cameraImage coming soon 316088220 Motor cover compl. €2.36
3
 photo_cameraImage coming soon 316060610 Flange compl. €10.42
4
 photo_cameraImage coming soon 316088230 Carbon brush compl. €2.36
5
 photo_cameraImage coming soon 316088240 LED compl. €7.29
6
 photo_cameraImage coming soon 343093650 Electronic unit compl. €23.28
7
 photo_cameraImage coming soon 310014580 Stator €86.61
9
 photo_cameraImage coming soon 316088250 Gear housing €17.45
10
 photo_cameraImage coming soon 343254900 Condenser €1.61
11
 photo_cameraImage coming soon 316088260 Carry handle comp. €9.39
12
 photo_cameraImage coming soon 343413080 Switch €4.61
13
 photo_cameraImage coming soon 343090190 Power supply €7.29
14
 photo_cameraImage coming soon 316088270 Turning table comp. €79.45
15
 photo_cameraImage coming soon 316073870 base cpl. €51.95
16
 photo_cameraImage coming soon 316088280 Moving guard comp. €19.69
17
 photo_cameraImage coming soon 316088290 Foot compl. €2.36
18
 photo_cameraImage coming soon 316088300 strain relieve compl. €17.45
19
 photo_cameraImage coming soon 316088310 Wheel guard cpl. €51.95
20
 photo_cameraImage coming soon 316075410 Switch trigger compl. €1.77
23
 photo_cameraImage coming soon 316088320 Chop arm compl. €34.63
24
 photo_cameraImage coming soon 316088330 Tilting arm cpl. €46.27
25
 photo_cameraImage coming soon 316088340 Handle compl. €14.54
26
 photo_cameraImage coming soon 316075420 Detent cpl. €8.36
27
 photo_cameraImage coming soon 316073960 Handle compl. €3.85
28
 photo_cameraImage coming soon 315421110 Table side extension right €13.26
29
 photo_cameraImage coming soon 315421090 Table side extension left €15.36
30
 photo_cameraImage coming soon 316088350 Motor housing compl. €17.45
31
 Metabo Workpiece Holder Compl. for KGSV 216 MC 316075690 Metabo Workpiece Holder Compl. for KGSV 216 MC €19.78
32
 photo_cameraImage coming soon 343457630 Clamping lever €3.85
33
 photo_cameraImage coming soon 316088360 Stop compl. €28.95
34
 photo_cameraImage coming soon 316088370 Stabilizer cpl. €28.95
35
 photo_cameraImage coming soon 343457320 Table insert €3.21
37
 photo_cameraImage coming soon 316088380 DUST ETRACTION KIT COMPLETE €8.36
38
 photo_cameraImage coming soon 343435780 Cover dust collector €3.11
39
 photo_cameraImage coming soon 343436260 Extraction funnel €1.61
40
 photo_cameraImage coming soon 343457490 Cable Holder €1.61
41
 photo_cameraImage coming soon 316088390 Spindle lock comp. €2.36
42
 photo_cameraImage coming soon 316075470 Saw head lock comp. €1.61
43
 photo_cameraImage coming soon 316088400 Depth stop compl. €3.11
44
 photo_cameraImage coming soon 316088410 tipping axis compl. €10.42
46
 photo_cameraImage coming soon 344113030 Plug in buffer €1.61
48
 photo_cameraImage coming soon 316056820 SET SCREW COMPLETE €1.61
49
 photo_cameraImage coming soon 316088420 Scale set compl. €3.85
50
 photo_cameraImage coming soon 316088430 Motor compl. €216.28
52
 photo_cameraImage coming soon 316075550 End stop cpl. €3.11
53
 photo_cameraImage coming soon 316075520 Bevel clamping comp. €3.11
55
 photo_cameraImage coming soon 341722210 Stop screw €1.61
57
 photo_cameraImage coming soon 344113040 Rubber bushing €1.61
58
 photo_cameraImage coming soon 316075510 Tool holder col. €1.61
61
 photo_cameraImage coming soon 338084780 Rating plate 15216000 KGSV 216 MC €1.77
62
 photo_cameraImage coming soon 341113050 Star grip screw €1.61
63
 photo_cameraImage coming soon 343457560 Clamping cap €1.61
66
 photo_cameraImage coming soon 320054880 Ball bearing €2.36
67
 photo_cameraImage coming soon 339146080 Sliding sheet €1.61
68
 photo_cameraImage coming soon 316088440 Screw set €3.11
880
 photo_cameraImage coming soon 344130970 Grease 50Gr 1,8oz €11.62
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
3
 photo_cameraImage coming soon 316060610 Flange compl. €10.42
5
 photo_cameraImage coming soon 316088240 LED compl. €7.29
10
 photo_cameraImage coming soon 343254900 Condenser €1.61
11
 photo_cameraImage coming soon 316088260 Carry handle comp. €9.39
12
 photo_cameraImage coming soon 343413080 Switch €4.61
13
 photo_cameraImage coming soon 343090190 Power supply €7.29
16
 photo_cameraImage coming soon 316088280 Moving guard comp. €19.69
20
 photo_cameraImage coming soon 316075410 Switch trigger compl. €1.77
25
 photo_cameraImage coming soon 316088340 Handle compl. €14.54
34
 photo_cameraImage coming soon 316088370 Stabilizer cpl. €28.95
37
 photo_cameraImage coming soon 316088380 DUST ETRACTION KIT COMPLETE €8.36
38
 photo_cameraImage coming soon 343435780 Cover dust collector €3.11
39
 photo_cameraImage coming soon 343436260 Extraction funnel €1.61
42
 photo_cameraImage coming soon 316075470 Saw head lock comp. €1.61
43
 photo_cameraImage coming soon 316088400 Depth stop compl. €3.11
44
 photo_cameraImage coming soon 316088410 tipping axis compl. €10.42
55
 photo_cameraImage coming soon 341722210 Stop screw €1.61
62
 photo_cameraImage coming soon 341113050 Star grip screw €1.61
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 316088210 Carbon brush holder compl. €10.42
2
 photo_cameraImage coming soon 316088220 Motor cover compl. €2.36
4
 photo_cameraImage coming soon 316088230 Carbon brush compl. €2.36
6
 photo_cameraImage coming soon 343093650 Electronic unit compl. €23.28
7
 photo_cameraImage coming soon 310014580 Stator €86.61
9
 photo_cameraImage coming soon 316088250 Gear housing €17.45
19
 photo_cameraImage coming soon 316088310 Wheel guard cpl. €51.95
30
 photo_cameraImage coming soon 316088350 Motor housing compl. €17.45
41
 photo_cameraImage coming soon 316088390 Spindle lock comp. €2.36
50
 photo_cameraImage coming soon 316088430 Motor compl. €216.28
57
 photo_cameraImage coming soon 344113040 Rubber bushing €1.61
61
 photo_cameraImage coming soon 338084780 Rating plate 15216000 KGSV 216 MC €1.77
66
 photo_cameraImage coming soon 320054880 Ball bearing €2.36
880
 photo_cameraImage coming soon 344130970 Grease 50Gr 1,8oz €11.62

Shipping and delivery information will be available shortly.

Metabo Spare Parts for Mitre Saw KGSV 216 MC

Metabo original spare parts for to replace broken parts for to fix Mitre Saw KGSV 216 MC - 15216000.

In the following table, look for the model of the Mitre Saw and the respective parts of the code.
METABO KGSV 216 MC - 15216000

KGSV 216 MC - 15216000
# Part Num Description
1 316088210 Carbon brush holder compl.
2 316088220 Motor cover compl.
3 316060610 Flange compl.
4 316088230 Carbon brush compl.
5 316088240 LED compl.
6 343093650 Electronic unit compl.
7 310014580 Stator
8 310014590 Armature
9 316088250 Gear housing
10 343254900 Condenser
11 316088260 Carry handle comp.
12 343413080 Switch
13 343090190 Power supply
14 316088270 Turning table comp.
15 316073870 base cpl.
16 316088280 Moving guard comp.
17 316088290 Foot compl.
18 316088300 strain relieve compl.
19 316088310 Wheel guard cpl.
20 316075410 Switch trigger compl.
23 316088320 Chop arm compl.
24 316088330 Tilting arm cpl.
25 316088340 Handle compl.
26 316075420 Detent cpl.
27 316073960 Handle compl.
28 315421110 Table side extension right
29 315421090 Table side extension left
30 316088350 Motor housing compl.
31 316075690 Workpiece holder compl.
32 343457630 Clamping lever
33 316088360 Stop compl.
34 316088370 Stabilizer cpl.
35 343457320 Table insert
37 316088380 Dust etraction kit compl.
38 343435780 Cover dust collector
39 343436260 Extraction funnel
40 343457490 Cable Holder
41 316088390 Spindle lock comp.
42 316075470 Saw head lock comp.
43 316088400 Depth stop compl.
44 316088410 tipping axis compl.
46 344113030 Plug in buffer
48 316056820 Set screw compl.
49 316088420 Scale set compl.
50 316088430 Motor compl.
52 316075550 End stop cpl.
53 316075520 Bevel clamping comp.
55 341722210 Stop screw
57 344113040 Rubber bushing
58 316075510 Tool holder col.
61 338084780 Rating plate 15216000 KGSV 216 MC
62 341113050 Star grip screw
63 343457560 Clamping cap
65 320054870 Ball bearing
66 320054880 Ball bearing
67 339146080 Sliding sheet
68 316088440 Screw set
880 344130970 Grease 50Gr 1,8oz
1001 338511350 Diagram
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo KGSV 216 MC - 15216000
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
Machine Type
Mitre Saw
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Metabo KGSV216MC Parts Drawing

Metabo KGSV216MC Parts Drawing

Download (576.05KB)

You might also like

Auxiliary Guide Complete for Mitre Saw Metabo KS 254 Plus
Metabo SKU: 1010737210
Auxiliary Guide Complete for Mitre Saw Metabo KS 254 Plus
Auxiliary Guide Complete for Mitre Saw Metabo KS 254 Plus Original Spare Part Metabo, Auxiliary Guide Complete for Mitre Saws KS 254 Plus - KS 305 Plus - KGS 315 Plus. Part for the following products: - Mitre Saw KS 254...
AVAILABLE €48.72
Details
Work Clamp Ass'y for Mitre Saw Metabo KS 254 Plus
Metabo SKU: 1010737440
Work Clamp Ass'y for Mitre Saw Metabo KS 254 Plus
Work Clamp Ass'y for Mitre Saw Metabo KS 254 Plus Original Spare Part Metabo, Work Clamp Ass'y Complete for Mitre Saws KS 254 Plus - KS 305 Plus - KGS 315 Plus. Part for the following products: - Mitre Saw KS 254 Plus/0102540100 -...
AVAILABLE €68.26
Details
Rip Fence for Mitre Saw Metabo KS 254 Plus
Metabo SKU: 1010736427
Rip Fence for Mitre Saw Metabo KS 254 Plus
Rip Fence for Mitre Saw Metabo KS 254 Plus Original Spare Part Metabo, Rip Fence for Mitre Saws KS 254 Plus - KS 305 Plus - KGS 315 Plus. Part for the following products: -  Mitre Saw KS 254 Plus/0102540100 -  Mitre Saw KS 305...
on 7/10 Business Days Approx €70.00
Details
Carbon Brush Set for Mitre Saw Metabo KS 254 Plus
Metabo SKU: 1010737385
Carbon Brush Set for Mitre Saw Metabo KS 254 Plus
Carbon Brush Set for Mitre Saw Metabo KS 254 Plus Original Spare Part Metabo, Carbon Brush Set 230V for Mitre Saws KS 254 Plus - KS 305 Plus. Part for the following products: -  Mitre Saw KS 254 Plus - 0102540100 -  Mitre Saw KS 305...
on 7/10 Business Days Approx €27.17
Details
Metabo KS 254 Plus Switch
Metabo SKU: 8111737712
Metabo KS 254 Plus ON-OFF Switch
Metabo KS 254 Plus ON-OFF Switch Original Spare Parts Metabo, ON-OFF Switch for Mitre Saws KS 254 Plus - KS 305 Plus - KGS 315 Plus.s. Part for the following aproducts: - Mitre Saw KS 254 Plus - 0102540100 10 - Mitre Saw KS 305...
on 7/10 Business Days Approx. €26.02
Details
Metabo Workpiece Holder Compl. for KGSV 216 MC
Metabo SKU: 316075690
Metabo Workpiece Holder Compl. for KGSV 216 MC
Metabo Workpiece Holder Complete for KGSV 216 MC Genuine Spare Parts Metabo, Workpiece Holder Complete for Metabo Mitre Saws KGSV 72 Xact SYM - KGSV 216 MC - KGSV 254 MC. Part for the following products: -  Metabo...
Usually Ships in: 7/10 Business Days Approx. €19.78
Details
Comments (0)
No customer reviews for the moment.
