Metabo

Metabo WEV 15-125 Quick Parts

SKU: Metabo WEV15-125 Quick
€74.43
VAT included

Metabo Spare Parts for Angle Grinder WEV 15-125 Quick

Metabo genuine spare parts for replacing or repairing Angle Grinder WEV15-125 Quick - 00468001.

Angle Grinder WEV 15-125 Quick - 00468001
Metabo Angle Grinder WEV 15-125 Quick Parts
  • Metabo Angle Grinder WEV 15-125 Quick Parts
  • Metabo Angle Grinder WEV 15-125 Quick Parts Drawing
Metabo

Metabo WEV 15-125 Quick Parts

SKU: Metabo WEV15-125 Quick Condition: New
€74.43
VAT included

Metabo Spare Parts for Angle Grinder WEV 15-125 Quick

Metabo genuine spare parts for replacing or repairing Angle Grinder WEV15-125 Quick - 00468001.

Angle Grinder WEV 15-125 Quick - 00468001
settings 55 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
55 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 310010990 Armature compl., 230V €72.27
2
 photo_cameraImage coming soon 311012180 Field coil w.field coil, 230V €51.96
3
 photo_cameraImage coming soon 343410120 Switch 2-pole €10.43
6
 photo_cameraImage coming soon 343362490 Cable clip €1.77
7
 photo_cameraImage coming soon 315013520 Motor housing 2 part €10.43
8
 photo_cameraImage coming soon 339151180 Baffle €1.61
9
 photo_cameraImage coming soon 339151200 Baffle €1.61
10
 photo_cameraImage coming soon 343082890 Electronic unit, 230V 50/60Hz €46.29
11
 photo_cameraImage coming soon 143115690 Ball bearing, 6x19x6 €2.37
12
 photo_cameraImage coming soon 344097870 Rubber bushing €1.61
13
 photo_cameraImage coming soon 339133060 Washer, 8.05x17x0.4 €1.61
14
 photo_cameraImage coming soon 143115700 Ball bearing, 8x22x7 €3.11
15
 photo_cameraImage coming soon 339006390 Washer, 7.05x19.5x0.2 €1.61
16
 photo_cameraImage coming soon 341100940 Hexagon nut w.recess €1.77
17
 photo_cameraImage coming soon 343433070 Switch rod €1.61
18
 photo_cameraImage coming soon 343433030 Cap €3.85
19
 photo_cameraImage coming soon 343433100 End cap €1.61
20
 photo_cameraImage coming soon 343437100 Switch slide €1.61
21
 photo_cameraImage coming soon 341031160 Clamping flange €11.63
23
 photo_cameraImage coming soon 339204500 Wheel guard, D125 €8.93
24
 photo_cameraImage coming soon 314000970 Anti-vibration handle, M8 €14.62
26
 photo_cameraImage coming soon 342022490 Spring clip €1.61
28
 photo_cameraImage coming soon 141121430 Fill. head screw (DIN 7985) €1.61
30
 photo_cameraImage coming soon 339012430 Gasket €1.61
31
 photo_cameraImage coming soon 141121640 Fill. head screw (DIN 7985) €1.61
32
 photo_cameraImage coming soon 141116980 Self-tap. fill. h. screw €1.61
33
 photo_cameraImage coming soon 141117060 Self-tap. fill. h. screw €1.77
34
 photo_cameraImage coming soon 338060250 Rating plate €1.61
40
 photo_cameraImage coming soon 341604420 Spindle M14 €13.27
41
 photo_cameraImage coming soon 316055350 Clamping nut compl., M14 €11.63
42
 photo_cameraImage coming soon 141151120 Washer 10.2x14.8x0.2 €1.61
43
 photo_cameraImage coming soon 141152300 Washer 10.2x14.8x0.1 €1.77
44
 photo_cameraImage coming soon 141153920 Washer 10.2x14.8x0.5 €1.61
50
 photo_cameraImage coming soon 343433280 Flange compl. €18.97
51
 photo_cameraImage coming soon 341102460 Nut €2.90
52
 photo_cameraImage coming soon 316054980 Bevel gear w.pinion €19.78
53
 photo_cameraImage coming soon 316055080 Friction washer set compl. €17.45
54
 photo_cameraImage coming soon 316055100 Gear housing compl. €51.96
55
 photo_cameraImage coming soon 316054260 Safety clutch w.pinion €79.45
57
 photo_cameraImage coming soon 316054850 Fan w. dust guard €3.85
58
 photo_cameraImage coming soon 316067170 Carbon brush with brush holder Set 230V €24.66
59
 photo_cameraImage coming soon 316066040 Clamping lever compl. €11.63
61
 photo_cameraImage coming soon 141156650 Retaining ring €1.61
62
 photo_cameraImage coming soon 143196000 O-ring €1.61
63
 photo_cameraImage coming soon 342003390 Pressure spring €1.61
64
 photo_cameraImage coming soon 343433130 Push button €1.61
65
 photo_cameraImage coming soon 341515640 Bolt €1.61
70
 photo_cameraImage coming soon 343433060 Tacho disc €2.37
71
 photo_cameraImage coming soon 343433090 Pivoting switch €1.61
72
 photo_cameraImage coming soon 339007800 Washer €1.61
75
 photo_cameraImage coming soon 143192490 O-ring €1.77
92
 photo_cameraImage coming soon 143195640 O-ring €1.61
880
 photo_cameraImage coming soon 344130920 Grease 100G €40.45
885
 photo_cameraImage coming soon 344130560 Grease SF 011 50Gr 1.8oz €51.96
1005
 photo_cameraImage coming soon 316067320 Cable with sleeve €23.28

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Angle Grinder WEV15-125 Quick

Metabo genuine spare parts for replacing or repairing Angle Grinder WEV 15-125 Quick - 00468001.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Metabo WEV 15-125 Quick - 00468001
WEV 15-125 Quick - 00468001
# Part Num Description
1 310010990 Armature compl., 230V
2 311012180 Field coil w.field coil, 230V
3 343410120 Switch 2-pole
4 399999990 Part not needed
5 399999990 Part not needed
6 343362490 Cable clip
7 315013520 Motor housing 2 part
8 339151180 Baffle
9 339151200 Baffle
10 343082890 Electronic unit, 230V 50/60Hz
11 143115690 Ball bearing, 6x19x6
12 344097870 Rubber bushing
13 339133060 Washer, 8.05x17x0.4
14 143115700 Ball bearing, 8x22x7
15 339006390 Washer, 7.05x19.5x0.2
16 341100940 Hexagon nut w.recess
17 343433070 Switch rod
18 343433030 Cap
19 343433100 End cap
20 343437100 Switch slide
21 341031160 Clamping flange
23 339204500 Wheel guard, D125
24 314000970 Anti-vibration handle, M8
26 342022490 Spring clip
28 141121430 Fill. head screw (DIN 7985)
30 339012430 Gasket
31 141121640 Fill. head screw (DIN 7985)
32 141116980 Self-tap. fill. h. screw
33 141117060 Self-tap. fill. h. screw
34 338060250 Rating plate
36 399999990 Part not needed
40 341604420 Spindle M14
41 316055350 Clamping nut compl., M14
42 141151120 Washer 10.2x14.8x0.2
43 141152300 Washer 10.2x14.8x0.1
44 141153920 Washer 10.2x14.8x0.5
50 343433280 Flange compl.
51 341102460 Nut
52 316054980 Bevel gear w.pinion
53 316055080 Friction washer set compl.
54 316055100 Gear housing compl.
55 316054260 Safety clutch w.pinion
57 316054850 Fan w. dust guard
58 316067170 Carbon brush with brush holder Set 230V
59 316066040 Clamping lever compl.
61 141156650 Retaining ring
62 143196000 O-ring
63 342003390 Pressure spring
64 343433130 Push button
65 341515640 Bolt
70 343433060 Tacho disc
71 343433090 Pivoting switch
72 339007800 Washer
75 143192490 O-ring
92 143195640 O-ring
880 344130920 Grease 100G
885 344130560 Grease SF 011 50Gr 1.8oz
1001 338505780 Diagram
1005 316067320 Cable with sleeve
