Metabo

Metabo Spare Parts for Jig Saw STE 70

SKU: Metabo STE 70 - 05700000
€3.37
VAT included

Metabo Spare Parts for Jig Saw STE 70

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 70 - 05700000.

Jig Saw STE 70
Metabo Spare Parts for Jig Saw STE 70
  • Metabo Spare Parts for Jig Saw STE 70
  • Metabo Spare Parts for Jig Saw STE 70
Metabo

Metabo Spare Parts for Jig Saw STE 70

SKU: Metabo STE 70 - 05700000 Condition: New
€3.37
VAT included

Metabo Spare Parts for Jig Saw STE 70

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 70 - 05700000.

Jig Saw STE 70
settings 52 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
52 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 34220057 Protective strap €3.10
3
 Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
4
 photo_cameraImage coming soon 31603045 Housing cpl. €35.49
5
 photo_cameraImage coming soon 33803790 Rating Plate €1.62
6
 photo_cameraImage coming soon 34307741 Electronic Unit 230 V €36.73
7
 photo_cameraImage coming soon 14111697 Fillister head screw €1.87
8
 Switch for Rotorbital Sander Metabo SXE 450 Turbo Tec 34340892 Switch for Rotorbital Sander Metabo SXE 450 Turbo Tec €14.81
9
 photo_cameraImage coming soon 34151386 Cylindrical pin €1.65
11
 photo_cameraImage coming soon 33912050 Sliding sheet €1.46
12
 photo_cameraImage coming soon 34407004 Felt €1.46
13
 photo_cameraImage coming soon 34202168 Pressure spring €1.65
14
 photo_cameraImage coming soon 33912932 Guide plate €1.46
15
 photo_cameraImage coming soon 34100261 Needle bearing €12.76
16
 photo_cameraImage coming soon 33912549 Washer €1.65
17
 photo_cameraImage coming soon 31603008 Spur gear cpl. €41.99
18
 photo_cameraImage coming soon 14311143 Needle sleeve €5.07
19
 photo_cameraImage coming soon 33912929 Balancing plate €8.92
20
 photo_cameraImage coming soon 33912936 Pressure spring €9.86
21
 photo_cameraImage coming soon 31603009 Bearing support cpl. €17.90
22
 photo_cameraImage coming soon 34338006 Cover brush €1.52
23
 photo_cameraImage coming soon 14311340 Ball bearing, 8x22x7 €11.17
24
 photo_cameraImage coming soon 31000789 Armature Cpl. 230 V €73.34
25
 photo_cameraImage coming soon 14311566 Ball bearing, 6x19x6 €2.48
26
 photo_cameraImage coming soon 34409255 Rubber stopper €1.45
27
 photo_cameraImage coming soon 31603010 Field Coil 230 V €43.39
28
 Carbon Brushes for Jigsaw Metabo STE 65 SP 31603396 Carbon Brushes for Jigsaw Metabo STE 65 SP €17.98
29
 photo_cameraImage coming soon 31603256 Oscillating guide €5.86
30
 photo_cameraImage coming soon 34107031 Cover plate €2.40
31
 photo_cameraImage coming soon 14319470 O-Ring €1.46
32
 photo_cameraImage coming soon 33901052 Sealing washer €1.46
33
 photo_cameraImage coming soon 14111916 Cap Screw €1.62
34
 photo_cameraImage coming soon 34460034 Clamping Piece €4.78
35
 photo_cameraImage coming soon 14116081 Tightening pin €1.79
37
 Metabo STE 65 SP Connecting Link 33912945 Metabo STE 65 SP Connecting Link €3.06
38
 photo_cameraImage coming soon 14112055 Countersunk screw €1.46
40
 photo_cameraImage coming soon 34339548 Anti-splintering insert €1.52
41
 photo_cameraImage coming soon 31602962 Base plate cpl. €13.50
42
 photo_cameraImage coming soon 33912931 position plate €1.52
43
 photo_cameraImage coming soon 14113137 Square nut €1.47
44
 photo_cameraImage coming soon 34416153 Hexagonal key €1.79
45
 photo_cameraImage coming soon 14112230 Cap screw €1.55
46
 photo_cameraImage coming soon 33900562 Champing claw €2.22
47
 photo_cameraImage coming soon 34105586 Shift axle €5.86
48
 photo_cameraImage coming soon 31603014 Shift lever €5.28
49
 photo_cameraImage coming soon 33811483 Metabo Label €1.62
50
 photo_cameraImage coming soon 34409142 Rubber plug €1.53
52
 photo_cameraImage coming soon 34410114 Cable sleeve €2.55
53
 Power Cord for Angle Grinder Metabo W 7-115 34448588 Power Cord for Angle Grinder Metabo W 7-115 €19.80
54
 photo_cameraImage coming soon 14118181 Circlip €1.52
56
 photo_cameraImage coming soon 34409758 Rubber plug €1.46
57
 photo_cameraImage coming soon 31602958 Brush Holder Module €15.92
880
 photo_cameraImage coming soon 34413093 Grease 50Gr 1,8oz €34.48

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Jig Saw STE 70

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 70 - 05700000.

In the following table, look for the model of the Jig Saw and the respective parts of the code.
Metabo STE 70 - 05700000

Metabo STE 70 - 05700000
# Part Num. Description
1 34337459 Eye Shield
2 34220057 Protective Strap
3 14111602 Self-tap. Fill. H. Screw
4 31603045 Housing Cpl.
5 33803790 Rating Plate
6 34307741 Electronic Unit 230 V
7 14111697 Fillister Head Screw
8 34340892 Pressure switch black
9 34151386 Cylindrical Pin
10 31602988 Supporting Lever
11 33912050 Sliding Sheet
12 34407004 Felt
13 34202168 Pressure Spring
14 33912932 Guide Plate
15 34100261 Needle Bearing
16 33912549 Washer
17 31603008 Spur Gear Cpl.
18 14311143 Needle Sleeve
19 33912929 Balancing Plate
20 33912936 Pressure Spring
21 31603009 Bearing Support Cpl.
22 34338006 Cover Brush
23 14311340 Ball Bearing, 8x22x7
24 31000789 Armature Cpl. 230 V
25 14311566 Ball bearing, 6x19x6
26 34409255 Rubber Stopper
27 31603010 Field Coil 230 V
28 31603396 Carbon Brush Cpl.
29 31603256 Oscillating Guide
30 34107031 Cover Plate
31 14319470 O-ring
32 33901052 Sealing Washer
33 14111916 Cap Screw
34 34460034 Clamping Piece
35 14116081 Tightening Pin
36 34105612 Ram
37 33912945 Connecting Link
38 14112055 Countersunk Screw
39 31603026 Ram With Guide
40 34339548 Anti-splintering insert
41 31602962 Base Plate Cpl.
42 33912931 Position Plate
43 14113137 Square Nut
44 34416153 Hexagonal Key
45 14112230 Cap Screw
46 33900562 Champing Claw
47 34105586 Shift Axle
48 31603014 Shift Lever
49 33811483 Metabo Label
50 34409142 Rubber Plug
52 34410114 Cable Sleeve
53 34448588 Cable With Plug
54 14118181 Circlip
55 99999999 Part not needed
56 34409758 Rubber Plug
57 31602958 Brush Holder Module
880 34413093 Grease 50gr 1,80z
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo STE 70 - 05700000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Diagram Metabo STE 70

Diagram Metabo STE 70

Download (312.7KB)
