Metabo Spare Parts for Hammer Drill SBE 1010 Plus

SKU: Metabo SBE 1010 Plus - 01108000
€27.50
VAT included

Metabo Spare Parts for Hammer Drill SBE 1010 Plus

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Hammer Drill SBE 1010 Plus - 01108000.

Hammer Drill SBE 1010 Plus - 01108000
Metabo Spare Parts for Hammer Drill SBE 1010 Plus
  • Metabo Spare Parts for Hammer Drill SBE 1010 Plus
  • Metabo Spare Parts for Hammer Drill SBE 1010 Plus
Metabo

Metabo Spare Parts for Hammer Drill SBE 1010 Plus

SKU: Metabo SBE 1010 Plus - 01108000 Condition: New
€27.50
VAT included

Metabo Spare Parts for Hammer Drill SBE 1010 Plus

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Hammer Drill SBE 1010 Plus - 01108000.

Hammer Drill SBE 1010 Plus - 01108000
settings 47 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
47 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
3
 Metabo SBE 705 Chuck Spindle 34160364 Metabo SBE 705 Chuck Spindle €27.50
4
 Deth Rod for Rotary Hammer Metabo BH E 6020 S 34151163 Deth Rod for Rotary Hammer Metabo BH E 6020 S €5.00
5
 photo_cameraImage coming soon 14112249 Self-tap. fill. h. screw €1.75
6
 photo_cameraImage coming soon 31603099 Gear Housing CPL. €51.31
7
 Sliding Block for Impact Drill Metabo BE 751 34000401 Sliding Block for Impact Drill Metabo BE 751 €14.94
8
 photo_cameraImage coming soon 31602771 Switch Housing Compl. €11.24
9
 photo_cameraImage coming soon 31603038 Intermediate Gear €63.68
10
 photo_cameraImage coming soon 34154001 Guide bolt €4.35
11
 photo_cameraImage coming soon 33912927 Shift fork €1.71
12
 photo_cameraImage coming soon 34409591 Seal €1.71
13
 photo_cameraImage coming soon 31603100 Gear Flange CPL. €56.60
14
 photo_cameraImage coming soon 33921083 Shaft Sealing Ring €2.42
15
 photo_cameraImage coming soon 14118168 Retaining ring €1.53
16
 photo_cameraImage coming soon 14311022 BALL BEARING, 15X32X9 €20.72
17
 photo_cameraImage coming soon 34105565 Slotted disc €3.65
18
 photo_cameraImage coming soon 31602953 Control Knob CPL. €3.12
20
 photo_cameraImage coming soon 34337604 Sealing ring €1.98
21
 photo_cameraImage coming soon 34409592 Rubber buffer €1.81
22
 photo_cameraImage coming soon 14311340 Ball bearing, 8x22x7 €11.17
23
 photo_cameraImage coming soon 31000788 Armature cpl.230V (w. tacho gen.) €87.38
24
 photo_cameraImage coming soon 14311475 Ball bearing, 6X 19X 6 €10.30
25
 Intermediate Flange for Rotary Hammer Metabo UHE 20 34337427 Intermediate Flange for Rotary Hammer Metabo UHE 20 €12.41
26
 photo_cameraImage coming soon 34307802 Temperature sensor €12.15
27
 photo_cameraImage coming soon 31400079 Support handle cpl. €19.46
28
 photo_cameraImage coming soon 33804533 Rating plate €1.34
29
 photo_cameraImage coming soon 34307878 VTC Electronic Signal, 230V €89.97
31
 Switch 230V for Hammer Metabo UHE 28 Plus 34340688 Switch 230V for Hammer Metabo UHE 28 Plus €30.94
32
 photo_cameraImage coming soon 14111706 Self-tap. fill. h. screw €1.98
33
 Motor Housing + Grip for Rotary Hammer Metabo UHE 28 Plus 31604106 Motor Housing + Grip for Rotary Hammer Metabo UHE 28 Plus €39.58
34
 photo_cameraImage coming soon 34336249 Cable clip €2.02
36
 O-Ring mm 1,98x15,08x19,06 for Percussion Drill Metabo SB 710 14319243 O-Ring mm 1,98x15,08x19,06 for Percussion Drill Metabo SB 710 €1.88
37
 photo_cameraImage coming soon 14111826 Self-tap. fill. h. screw €1.81
38
 230/240V Stator for Rotary Hammer Metabo UHE 28 Plus 31100981 230/240V Stator for Rotary Hammer Metabo UHE 28 Plus €27.59
39
 photo_cameraImage coming soon 31501265 Motor housing €14.48
40
 photo_cameraImage coming soon 33812216 M-Label,08 52x22 €1.74
41
 photo_cameraImage coming soon 33811541 Indication label €1.58
42
 Brush Contact for Hammer Metabo UHE 28 Plus 33912939 Brush Contact for Hammer Metabo UHE 28 Plus €3.43
43
 photo_cameraImage coming soon 31602879 Brush holder module €28.84
44
 photo_cameraImage coming soon 34449318 Cable with plug €23.87
46
 photo_cameraImage coming soon 34410116 Cable sleeve €2.42
47
 photo_cameraImage coming soon 31603496 Carbon brush set €14.48
49
 photo_cameraImage coming soon 14115581 Ring €1.53
50
 photo_cameraImage coming soon 34337865 supporting piece €1.34
51
 photo_cameraImage coming soon 31603574 Fan w. prot. Grid €11.57
52
 photo_cameraImage coming soon 33811788 Sticker €1.54
880
 photo_cameraImage coming soon 34413093 Grease 50Gr 1,8oz €34.48
882
 photo_cameraImage coming soon 34413097 Grease 50Gr 1,8oz €11.31

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Hammer Drill SBE 1010 Plus

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Hammer Drill SBE 1010 Plus - 01108000.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Metabo SBE 1010 Plus - 01108000

Hammer Drill SBE 1010 Plus 01108000
# Part Num. Description
3 34160364 Drill Spindle
4 34151163 Depth Stop
5 14112249 Self-Tap. Fill. H. Screw
6 31603099 Gear Housing CPL.
7 34000401 Cursor lock
8 31602771 Switch Housing Compl.
9 31603038 Intermediate Gear
10 34154001 Guide Bolt
11 33912927 Shift fork
12 34409591 Seal
13 31603100 Gear Flange CPL.
14 33921083 Shaft Sealing Ring
15 14118168 Retaining Ring
16 14311022 Ball Bearing 15x 32x 9
17 34105565 Slotted Disc
18 31602953 Control Knob CPL.
20 34337604 Sealing ring
21 34409592 Rubber Buffer
22 14311340 Ball Bearing 8x 22x 7
23 31000788 Armature compl. 230 V
24 14311475 Ball bearing 8x 22x 6
25 34337427 Intermediate flange
26 34307802 Temperature sensor
27 31400079 Support Handle CPL.
28 33804533 Rating plate
29 34307878 VTC Electronic Signal, 230V
31 34340688 Poti switch
32 14111706 Screw
33 31604106 Pistol grip, 2 piece, rubber
34 34336249 Cable clip
36 14319243 O-ring
37 14111826 Self-Tap. Fill. H. Screw
38 31100981 Field Coil 230 V
39 31501265 Motor Housing
40 33812216 Metabo label, 08 52x22
41 33811541 Iindication Label
42 33912939 Brush contact
43 31602879 Brush holder Module
44 34449318 Cord with CEE plug
46 34410116 Cable sleeve
47 31603496 carbon Brush set
49 14115581 ring
50 34337865 supporting piece
51 31603574 Fan with prot. Grid
52 33811788 Self adhesive
880 34413093 Grease in tube 50gr 1,8oz
882 34413097 Grease in tube 50gr 1,8oz
1001 33850225 Data plate
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo SBE 1010 Plus - 01108000
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Drawing Metabo SBE 1010 Plus

Drawing Metabo SBE 1010 Plus

Download (196.38KB)
