Metabo

Metabo Spare Parts for Angle grinder WX 2400-230

SKU: Metabo WX 2400-230 00379000
€1.92
VAT included

Metabo Spare Parts for Angle grinder WX 2400-230

Metabo original spare parts for to replace broken parts for to fix Angle Grinder WX 2400-230/00379000.

Metabo WX 2400-230 00379000
Metabo Spare Parts for Angle grinder WX 2400-230
  • Metabo Spare Parts for Angle grinder WX 2400-230
  • Metabo Spare Parts for Angle grinder WX 2400-230
Metabo

Metabo Spare Parts for Angle grinder WX 2400-230

SKU: Metabo WX 2400-230 00379000 Condition: New
€1.92
VAT included

Metabo Spare Parts for Angle grinder WX 2400-230

Metabo original spare parts for to replace broken parts for to fix Angle Grinder WX 2400-230/00379000.

Metabo WX 2400-230 00379000
settings 45 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
45 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 31400028 Handle €16.95
2
 photo_cameraImage coming soon 34337644 Push button €2.54
3
 photo_cameraImage coming soon 34200173 Pressure spring €1.65
4
 photo_cameraImage coming soon 34100397 Guide bush €3.85
5
 photo_cameraImage coming soon 31603172 Gear housing cpl. €59.73
6
 photo_cameraImage coming soon 34151381 Thrust bolt €1.80
7
 photo_cameraImage coming soon 34110066 Self locking nut €3.12
8
 Bevel Gear Set for Angle Grinder Metabo W 21-230 31602529 Bevel Gear Set for Angle Grinder Metabo W 21-230 €73.40
9
 photo_cameraImage coming soon 34101151 Spacer ring €5.07
10
 photo_cameraImage coming soon 14319244 elt ring €3.12
11
 photo_cameraImage coming soon 33907008 Cover washer €1.71
12
 photo_cameraImage coming soon 14311523 ball Bearing 12x 37x 12 €6.97
13
 photo_cameraImage coming soon 33900728 Fixed bearing cover €2.99
14
 Armature 230V Assy for Grinder Metabo WX 2400-230 31001221 Armature 230V Assy for Grinder Metabo WX 2400-230 €148.97
15
 photo_cameraImage coming soon 14311340 Ball bearing, 8x22x7 €11.17
16
 Armature Bearing Rubber Holder for Angle Grinders Metabo 230 mm 34409408 Armature Bearing Rubber Holder for Angle Grinders Metabo 230 mm €2.08
17
 photo_cameraImage coming soon 34343775 Intermediate flange €7.13
18
 photo_cameraImage coming soon 14112444 Fillister head screw €1.70
19
 photo_cameraImage coming soon 31101265 Field coil w.field coil,230V €64.98
20
 photo_cameraImage coming soon 14112445 Fillister head screw €1.70
21
 photo_cameraImage coming soon 14112202 Fillister head screw €1.53
22
 photo_cameraImage coming soon 14111985 Fillister head screw €1.53
23
 photo_cameraImage coming soon 33906014 Sealing ring €1.71
24
 photo_cameraImage coming soon 31604747 Complete gearbox flange, D 230 €25.02
25
 photo_cameraImage coming soon 14112164 Fill. head screw(DIN 7985) €1.76
26
 photo_cameraImage coming soon 34160416 Grinding shaft €12.74
27
 photo_cameraImage coming soon 34110690 Flange nut €9.91
28
 photo_cameraImage coming soon 34103116 Clamping flange €13.19
29
 photo_cameraImage coming soon 31604500 Complete protection cap, D 230 €22.39
30
 photo_cameraImage coming soon 34170205 Screw €1.53
31
 photo_cameraImage coming soon 34337643 Cover €1.80
32
 photo_cameraImage coming soon 31604748 Carbon Brush set €14.92
33
 photo_cameraImage coming soon 34300077 Brush guide €5.76
34
 Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
35
 photo_cameraImage coming soon 34339826 Upper and lower handle 22 €11.17
36
 Switch 230V Ass'y for Grinder Metabo WX 2400-230 31604541 Switch 230V Ass'y for Grinder Metabo WX 2400-230 €66.49
37
 photo_cameraImage coming soon 33912773 Cable clip €1.53
38
 photo_cameraImage coming soon 14111680 Self-tap. fill. h. screw €1.70
39
 photo_cameraImage coming soon 34409455 Cable sleeve €2.42
40
 Power Cord with CEE Plug for Grinder Metabo W 22-230 MVT 34448780 Power Cord with CEE Plug for Grinder Metabo W 22-230 MVT €40.51
41
 photo_cameraImage coming soon 33811734 Indication label €1.61
42
 photo_cameraImage coming soon 34416084 Pin spanner €5.07
43
 photo_cameraImage coming soon 31501276 Motor housing €23.77
44
 photo_cameraImage coming soon 33812208 Metabo plate 14 €3.10
880
 photo_cameraImage coming soon 34413091 Grease 100G €15.35

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Angle grinder WX 2400-230

Metabo original spare parts for to replace broken parts for to fix Angle Grinder WX 2400-230/00379000.

Open PDF Diagram, check your spare part number position and then select it in the following table.
Metabo WX 2400-230 00379000
Angle Grinder WX 2400-230/00379000
# Part Num. Description
1 31400028 Handle cpl.
2 34337644 Push button
3 34200173 Pressure spring
4 34100397 Guide bush
5 31603172 Gear housing cpl.
6 34151381 Thrust bolt
7 34110066 Self locking nut
8 31602529 Bevel gear Set
9 34101151 Spacer ring
10 14319244 elt ring
11 33907008 Cover washer
12 14311523 Ball bearing, 12x37x12
13 33900728 Fixed bearing cover
14 31001221 Armature compl.,230V
15 14311340 Ball bearing, 8x22x7
16 34409408 Rubber bearing
17 34343775 Intermediate flange
18 14112444 Fillister head screw
19 31101265 Field coil w.field coil,230V
20 14112445 Fillister head screw
21 14112202 Fillister head screw
22 14111985 Fillister head screw
23 33906014 Sealing ring
24 31604747 Gear flange compl.,D 230
25 14112164 Fill. head screw(DIN 7985)
26 34160416 Spindle
27 34110690 Flange nut
28 34103116 Clamping flange
29 31604500 Wheel guard compl.,D 230
30 34170205 Screw
31 34337643 Cover
32 31604748 Carbon brush set
33 34300077 Brush guide
34 14111602 Self-tap fill h screw
35 34339826 Handle (upper+under part)
36 31604541 Switch compl.,230V
37 33912773 Cable clip
38 14111680 Self-tap. fill. h. screw
39 34409455 Cable sleeve
40 34448780 Cable with plug
41 33811734 Indication label
42 34416084 Pin spanner
43 31501276 Motor housing
44 33812208 Metabo label
880 34413091 Grease 100G
