Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000

SKU: Metabo W 12-125 Quick 00398000
€77.26
VAT included

Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000

We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 12-125 Quick - 00398000.

Angle Grinder W 12-125 Quick - 00398000
Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000
  • Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000
  • Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000
Metabo

Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000

SKU: Metabo W 12-125 Quick 00398000 Condition: New
€77.26
VAT included

Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000

We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 12-125 Quick - 00398000.

Angle Grinder W 12-125 Quick - 00398000
settings 54 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
54 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 31001098 Complete armature, 230V €58.13
2
 photo_cameraImage coming soon 31101198 Field (Stator) 230 V €42.19
3
 Switch for Angle Grinder Metabo WQ 1000 34341111 Switch for Angle Grinder Metabo WQ 1000 €24.97
4
 photo_cameraImage coming soon 34410097 Cable sleeve €1.79
5
 photo_cameraImage coming soon 34449956 Power Cord with CEE plug €11.58
6
 photo_cameraImage coming soon 34336249 Cable clip €2.02
7
 photo_cameraImage coming soon 31501352 Motor housing 2 part €10.67
8
 photo_cameraImage coming soon 33915118 Baffle €1.76
9
 photo_cameraImage coming soon 33915120 Baffle €1.76
10
 photo_cameraImage coming soon 34343314 Cover €1.28
11
 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 14311517 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 €7.95
12
 photo_cameraImage coming soon 34409787 Rubber bushing €1.76
13
 photo_cameraImage coming soon 33913306 Washer,8,05x17x0,4 €1.76
14
 photo_cameraImage coming soon 14311518 Ball bearing,8x22x7 €3.92
15
 photo_cameraImage coming soon 33900639 Washer,7,05x19,5x0,2 €1.76
16
 photo_cameraImage coming soon 34110094 Hexagon nut w.recess €2.02
17
 Metabo Rod for Angle Grinder W12-125 34343307 Metabo Rod for Angle Grinder W12-125 €2.50
18
 photo_cameraImage coming soon 34343303 Cap €3.94
19
 photo_cameraImage coming soon 34343311 koncovka €1.28
20
 photo_cameraImage coming soon 34343710 Switch slide €1.76
21
 photo_cameraImage coming soon 34103116 Clamping flange €13.19
23
 photo_cameraImage coming soon 33920450 Protective cover, D125 €13.58
24
 photo_cameraImage coming soon 31400097 Anti-vibration handle,M 8 €15.03
26
 photo_cameraImage coming soon 34202249 Torsion spring €1.71
30
 photo_cameraImage coming soon 33901197 Gasket €1.75
31
 photo_cameraImage coming soon 14112164 Fill. head screw(DIN 7985) €1.76
32
 photo_cameraImage coming soon 14111698 Self-tap. fill. h. screw €1.76
33
 photo_cameraImage coming soon 14111706 Self-tap. fill. h. screw €1.98
34
 photo_cameraImage coming soon 33805993 Data plate €1.28
40
 photo_cameraImage coming soon 34160442 Spindle M14 €13.76
41
 photo_cameraImage coming soon 31605535 Clamping nut compl.,M14 €11.94
42
 photo_cameraImage coming soon 14115112 Washer 10,2 X 14,8X 0,2 €1.74
43
 photo_cameraImage coming soon 14115230 Washer 10,2 X 14,8X 0,1 €1.91
44
 photo_cameraImage coming soon 14115392 Washer 10,2 X 14,8X 0,5 €1.79
50
 Flange Complete for Angle Grinder Metabo W 9-115 34343328 Flange Complete for Angle Grinder Metabo W 9-115 €19.52
51
 Nut EW 6114 S for Wall Chaser Metabo MFE 40 34110246 Nut EW 6114 S for Wall Chaser Metabo MFE 40 €2.76
52
 Crown Gear and Pinion Bevel for Angle Grinder Metabo W 9-115 31605496 Crown Gear and Pinion Bevel for Angle Grinder Metabo W 9-115 €20.37
53
 Friction Washer Set Complete for Wall Chaser Metabo MFE 40 31605508 Friction Washer Set Complete for Wall Chaser Metabo MFE 40 €17.95
54
 photo_cameraImage coming soon 31605510 Gear housing compl. €54.65
55
 photo_cameraImage coming soon 31605422 Safety clutch w.pinion €63.94
56
 photo_cameraImage coming soon 31605524 Carbon Brush support compl. €10.56
57
 photo_cameraImage coming soon 31605485 Fan w. dust guard €3.94
58
 Metabo Grinder W 12-125 Quick Carbon Brush Set 31605521 Metabo Grinder W 12-125 Quick Carbon Brush Set €13.15
59
 photo_cameraImage coming soon 31606604 Clamping lever compl. €11.60
61
 photo_cameraImage coming soon 14115665 Retaining ring €1.76
63
 photo_cameraImage coming soon 34200339 Pressure spring €1.76
64
 photo_cameraImage coming soon 34343313 Push button €1.76
65
 photo_cameraImage coming soon 34151564 Bolt €1.76
71
 photo_cameraImage coming soon 34343309 Pivoting switch €1.76
72
 photo_cameraImage coming soon 33900780 Washer €1.76
75
 photo_cameraImage coming soon 14319249 O-ring €1.94
92
 photo_cameraImage coming soon 14319564 O-ring €1.76
880
 photo_cameraImage coming soon 34413092 Grease 100G €40.13
885
 photo_cameraImage coming soon 34413056 Grease SF 011 50Gr 1,8oz €37.66

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Angle Grinder W 12-125 Quick 00398000

We are METABO original spare parts Worldwide Dealers

 at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 12-125 Quick - 00398000.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
W 12-125 Quick 00398000

Angle Grinder Metabo W 12-125 Quick 00398000
# Part Num. Description
1 31001098 Complete armature, 230V
2 31101198 Field (Stator) 230 V
3 34341111 Switch, FPCe 230 V
4 34410097 Cord Armor
5 34449956 Power Cord with CEE plug
6 34336249 Power Cord holder
7 31501352 2-part motor casing
8 33915118 Air conveyor
9 33915120 Air conveyor
10 34343314 Cover
11 14311517 Bearing, 6x19x6
12 34409787 Rubber bushing
13 33913306 Washer, 8,05x17x0,4
14 14311518 Bearing, 8x22x7
15 33900639 Washer, 7,05x19,5x0,2
16 34110094 Hexagon nut with Collar
17 34343307 Gear shift rod
18 34343303 Cover
19 34343311 Terminal
20 34343710 Switch slider
21 34103116 Clamping flange
23 33920450 Protective cover, D125
24 31400097 Anti-vibration handle, M 8
26 34202249 Torsion spring
30 33901197 flat gasket
31 14112164 Screw (DIN 7985)
32 14111698 Screw
33 14111706 Screw
34 33805993 Data plate
36 39999999 NOT NECESSARY
40 34160442 Grinding wheel shaft M14
41 31605535 Complete tightening nut, M14
42 14115112 Washer 10.2 X 14.8X 0.2
43 14115230 Washer 10.2 X 14.8X 0.1
44 14115392 Washer 10.2 X 14.8X 0.5
50 34343328 Flange compl.
51 34110246 Nut
52 31605496 Bevel Gear + pinion gear
53 31605508 Friction Washer Set compl.
54 31605510 Gear case compl.
55 31605422 Safety clutch with pinion
56 31605524 Carbon Brush support compl.
57 31605485 Fan with dust cover
58 31605521 Carbon brushe set
59 31606604 Clamping lever compl.
61 14115665 Safety ring
62 14319600 Ring-O
63 34200339 Spring
64 34343313 Yellow button
65 34151564 Pin
71 34343309 Switch Components
72 33900780 Washer
75 14319249 Ring-O
90 39999999 Partic. UNNECESSARY
92 14319564 Ring-Or
880 34413092 100G GREASE TUBE
885 34413056 FAT TUBE SF 011 50Gr 1,8oz
1001 33850581 Data plate
