Metabo Spare Parts for Percussion Drill SBE 610
€1.92
VAT included
Metabo Spare Parts for Percussion Drill SBE 610
METABO service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Percussion Drill SBE 610 - 06101000.
Metabo Spare Parts for Percussion Drill SBE 610
€1.92
VAT included
Metabo Spare Parts for Percussion Drill SBE 610
METABO service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Percussion Drill SBE 610 - 06101000.
settings
17 spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
17 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 10 BUSYNESS DAYS
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Metabo Spare Parts for Percussion Drill SBE 610
METABO service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Percussion Drill SBE 610 - 06101000.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Percussion Drill SBE 610/06101000 | ||
| 1 | 34151163 | Depth stop |
| 2 | 34335978 | Clamping piece |
| 3 | 14111616 | Hexagon head screw |
| 4 | 31400055 | Handle |
| 5 | 31400084 | Support handle cpl. |
| 6 | 34170194 | Cheese-head screw |
| 7 | 34170147 | Self-tap. fill. h. screw |
| 8 | 31604116 | Gear housing compl. |
| 9 | 34339276 | Switch slide |
| 10 | 34101279 | Spacer sleeve |
| 11 | 34160401 | Spindle |
| 12 | 34001255 | Spur gear |
| 13 | 14319193 | O-ring |
| 14 | 32005026 | Ball holder |
| 15 | 33900693 | Washer |
| 16 | 31604113 | Gear flange cpl. |
| 17 | 14112007 | Fill. head screw |
| 18 | 14115059 | Cup spring |
| 19 | 14311488 | Ball bearing, 8x22x7 |
| 20 | 31000992 | Armature compl. |
| 21 | 34157012 | Self-tap. fill. h. screw |
| 22 | 14311475 | Ball bearing, 6X 19X 6 |
| 23 | 14319243 | O-ring |
| 24 | 34339275 | Baffle |
| 25 | 31101076 | Field coil 230 V |
| 26 | 31604173 | Brush compl. w.bearing clamp,230V |
| 27 | 31700328 | Motor compl. |
| 28 | 33804857 | Rating plate |
| 32 | 34449666 | Strand compl., |
| 33 | 34449667 | Strand compl., |
| 36 | 34449731 | Interf. suppr.,230V |
| 37 | 34449732 | Interf. suppr.,230V |
| 38 | 34339162 | switch |
| 40 | 33812041 | Metabo Label 99 |
| 41 | 14111602 | Self-tap fill h screw |
| 42 | 34336249 | Cable clip |
| 43 | 34409786 | Cable sleeve |
| 44 | 34449318 | Cable with plug |
| 45 | 34339295 | retaining plate |
| 46 | 33904093 | Cable sleeve |
| 47 | 31605120 | Switch set |
| 880 | 34413065 | Grease GL 402 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo SBE 610 - 06101000
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
Specific References
