Metabo Spare Parts for Combination Hammer KHE 56

SKU: Metabo KHE 56 - 00340000
€1.58
VAT included

Metabo Spare Parts for Combination Hammer KHE 56

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Combination Hammer KHE 56 - 00340000.

Metabo KHE 56 - 00340000
Metabo Spare Parts for Combination Hammer KHE 56
  • Metabo Spare Parts for Combination Hammer KHE 56
  • Metabo Spare Parts for Combination Hammer KHE 56
Metabo

Metabo Spare Parts for Combination Hammer KHE 56

SKU: Metabo KHE 56 - 00340000 Condition: New
€1.58
VAT included

Metabo Spare Parts for Combination Hammer KHE 56

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Combination Hammer KHE 56 - 00340000.

Metabo KHE 56 - 00340000
settings 94 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
94 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 34339440 Control knob €10.60
2
 photo_cameraImage coming soon 34409809 O-ring €1.50
3
 photo_cameraImage coming soon 14112356 Fillister head screw €1.36
4
 photo_cameraImage coming soon 31541632 Gear-box cover €75.96
5
 photo_cameraImage coming soon 34409825 Rubber cap €6.66
6
 photo_cameraImage coming soon 34339441 Sliding sleeve compl. €10.60
7
 photo_cameraImage coming soon 14115545 Circlip €1.50
8
 photo_cameraImage coming soon 34101293 Washer €10.90
9
 photo_cameraImage coming soon 34409813 O-ring €1.36
10
 photo_cameraImage coming soon 34105867 Sleeve €27.34
11
 photo_cameraImage coming soon 34101294 Washer €5.42
12
 photo_cameraImage coming soon 33913329 Guide sheet €10.90
13
 photo_cameraImage coming soon 34200351 Pressure spring €2.07
14
 photo_cameraImage coming soon 33913331 Guide plate €2.77
15
 photo_cameraImage coming soon 14115634 Retaining ring €2.07
16
 photo_cameraImage coming soon 31604270 Holder compl. €18.67
17
 photo_cameraImage coming soon 34107059 Ring €7.00
18
 photo_cameraImage coming soon 34003281 Bevel gear €23.16
19
 photo_cameraImage coming soon 34339439 Setting ring €19.21
20
 photo_cameraImage coming soon 33913318 Retaining sheet €9.67
21
 photo_cameraImage coming soon 34409817 O-ring €1.36
22
 photo_cameraImage coming soon 31604262 Piston compl. €37.38
23
 photo_cameraImage coming soon 31604258 Clutch €163.06
24
 photo_cameraImage coming soon 34101295 Washer €3.48
25
 photo_cameraImage coming soon 32005064 Needle roller and cage €6.03
26
 photo_cameraImage coming soon 34409824 Rubber ring €2.96
28
 photo_cameraImage coming soon 33913332 Carrier €13.73
29
 photo_cameraImage coming soon 34105866 Drill driving sleeve €231.89
30
 photo_cameraImage coming soon 34101296 Brake ring €22.04
32
 photo_cameraImage coming soon 31604266 Piston compl. €58.32
33
 photo_cameraImage coming soon 34101286 Stop ring €13.73
34
 photo_cameraImage coming soon 34409826 Rubber ring €3.48
35
 photo_cameraImage coming soon 34101287 Stop ring €11.64
36
 photo_cameraImage coming soon 34202209 Circlip €4.61
37
 photo_cameraImage coming soon 31604261 Striker compl. €27.80
38
 photo_cameraImage coming soon 34101288 Washer €2.07
39
 photo_cameraImage coming soon 31604260 Spindle compl.,SDS-M €278.27
40
 photo_cameraImage coming soon 33812109 Metabo label €2.96
41
 photo_cameraImage coming soon 34339434 GEAR BOX CAP €9.25
42
 photo_cameraImage coming soon 34339443 Pressure plate €5.42
43
 photo_cameraImage coming soon 34200352 Pressure spring €1.36
44
 photo_cameraImage coming soon 34409823 Seal €6.66
45
 photo_cameraImage coming soon 33913322 Retaining sheet €6.66
46
 photo_cameraImage coming soon 14112358 Fillister head screw €1.50
47
 photo_cameraImage coming soon 31604259 Bevel gear compl. €82.26
48
 photo_cameraImage coming soon 34101291 Washer €1.36
49
 photo_cameraImage coming soon 34151531 Bearing bolt €22.04
50
 photo_cameraImage coming soon 32005068 Bearing €4.89
51
 photo_cameraImage coming soon 31510473 Gear housing compl. €185.50
52
 Carbon Brushe Set for Hammers Metabo MHE-KHE 56-76 31604265 Carbon Brushe Set for Hammers Metabo MHE-KHE 56-76 €41.44
53
 photo_cameraImage coming soon 33901165 Shaft sealing ring €13.73
54
 photo_cameraImage coming soon 34449740 Lead Wire (Switch) €1.70
55
 photo_cameraImage coming soon 33804933 NAME PLATE €1.32
56
 photo_cameraImage coming soon 34409809 O-ring €1.50
57
 photo_cameraImage coming soon 34339432 Motor cap cpl. €23.16
58
 photo_cameraImage coming soon 14112355 Fillister head screw €1.36
59
 photo_cameraImage coming soon 33000187 Fan €4.19
60
 photo_cameraImage coming soon 31000931 Armature compl.,220-240 V €175.03
61
 photo_cameraImage coming soon 34409807 Dust seal €9.67
62
 photo_cameraImage coming soon 32005065 Ball bearing €12.13
63
 photo_cameraImage coming soon 34339431 Tacho disc €22.04
64
 photo_cameraImage coming soon 34409822 Rubber bushing €3.48
65
 photo_cameraImage coming soon 34170427 Screw,L5x35 T2025 €1.36
66
 photo_cameraImage coming soon 34339433 Handle 2 part €54.74
67
 photo_cameraImage coming soon 34339429 Cover cap €1.54
68
 photo_cameraImage coming soon 34409808 Sealing ring €22.04
69
 photo_cameraImage coming soon 34202207 Retaining ring €1.50
70
 photo_cameraImage coming soon 32005067 Ball bearing €18.43
71
 photo_cameraImage coming soon 31530063 Gear cover €54.74
72
 photo_cameraImage coming soon 31604252 Armature w.flange €209.44
73
 photo_cameraImage coming soon 33901164 Damping ring €13.73
74
 Electronic Unit for Hammer Metabo MHE 56 34308135 Electronic Unit for Hammer Metabo MHE 56 €98.10
75
 photo_cameraImage coming soon 34339435 Pressure plate €4.89
77
 photo_cameraImage coming soon 34340767 On-off switch €55.06
78
 photo_cameraImage coming soon 34339438 Light transmitter €4.89
79
 photo_cameraImage coming soon 33915111 Baffle €5.66
80
 photo_cameraImage coming soon 34170421 Screw,4x64 €1.50
81
 photo_cameraImage coming soon 31101085 Field coil w.field coil,220-240 V €46.36
82
 photo_cameraImage coming soon 31501326 Motor housing €37.38
84
 photo_cameraImage coming soon 14112354 Fillister head screw €1.36
85
 photo_cameraImage coming soon 34170424 Screw, €1.50
86
 photo_cameraImage coming soon 34300092 Brush holder €7.41
87
 photo_cameraImage coming soon 34170424 Screw, €1.50
88
 photo_cameraImage coming soon 34339421 Cable clip €1.50
89
 photo_cameraImage coming soon 34409821 Cable sleeve €3.48
90
 photo_cameraImage coming soon 34449743 Cable w.CEE plug €36.55
91
 photo_cameraImage coming soon 33913319 Clamping holder €11.64
92
 photo_cameraImage coming soon 14113102 Square nut €1.32
93
 photo_cameraImage coming soon 34170422 Screw,K5x45 T20 €1.50
94
 photo_cameraImage coming soon 31604254 Body compl. €20.92
96
 photo_cameraImage coming soon 31400107 Anti-vibration handle compl. €46.36
97
 photo_cameraImage coming soon 33105075 Depth stop €7.00
98
 photo_cameraImage coming soon 31604263 Shift element compl. €5.42
99
 photo_cameraImage coming soon 31604264 Maintenance kit €152.59
100
 photo_cameraImage coming soon 34170426 Screw, €1.36
880
 photo_cameraImage coming soon 34413117 Tube Grease,45 g Urethyn €24.54

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Combination Hammer KHE 56

We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Combination Hammer KHE 56 - 00340000.

In the following table, look for the model of the Drill and the respective parts of the code.
Metabo KHE 56 - 00340000
Combination Hammer KHE 56/00340000
# Part Num. Description
1 34339440 Control knob
2 34409809 O-ring
3 14112356 Fillister head screw
4 31541632 Gear-box cover
5 34409825 Rubber cap
6 34339441 Sliding sleeve compl.
7 14115545 Circlip
8 34101293 Washer
9 34409813 O-ring
10 34105867 Sleeve
11 34101294 Washer
12 33913329 Guide sheet
13 34200351 Pressure spring
14 33913331 Guide plate
15 14115634 Retaining ring
16 31604270 Holder compl.
17 34107059 Ring
18 34003281 Bevel gear
19 34339439 Setting ring
20 33913318 Retaining sheet
21 34409817 O-ring
22 31604262 Piston compl.
23 31604258 Clutch
24 34101295 Washer
25 32005064 Needle roller and cage
26 34409824 Rubber ring
27 34101289 Supporting disc
28 33913332 Carrier
29 34105866 Drill driving sleeve
30 34101296 Brake ring
32 31604266 Piston compl.
33 34101286 Stop ring
34 34409826 Rubber ring
35 34101287 Stop ring
36 34202209 Circlip
37 31604261 Striker compl.
38 34101288 Washer
39 31604260 Spindle compl.,SDS-M
40 33812109 Metabo label
41 34339434 GEAR BOX CAP
42 34339443 Pressure plate
43 34200352 Pressure spring
44 34409823 Seal
45 33913322 Retaining sheet
46 14112358 Fillister head screw
47 31604259 Bevel gear compl.
48 34101291 Washer
49 34151531 Bearing bolt
50 32005068 Bearing
51 31510473 Gear housing compl.
52 31604265 Carbon brush set
53 33901165 Shaft sealing ring
54 34449740 Lead Wire (Switch)
55 33804933 NAME PLATE
56 34409809 O-ring
57 34339432 Motor cap cpl.
58 14112355 Fillister head screw
59 33000187 Fan
60 31000931 Armature compl.,220-240 V
61 34409807 Dust seal
62 32005065 Ball bearing
63 34339431 Tacho disc
64 34409822 Rubber bushing
65 34170427 Screw,L5x35 T2025
66 34339433 Handle 2 part
67 34339429 Cover cap
68 34409808 Sealing ring
69 34202207 Retaining ring
70 32005067 Ball bearing
71 31530063 Gear cover
72 31604252 Armature w.flange
73 33901164 Damping ring
74 34308135 Electronic unit,220-240 V
75 34339435 Pressure plate
77 34340767 On-off switch
78 34339438 Light transmitter
79 33915111 Baffle
80 34170421 Screw,4x64
81 31101085 Field coil w.field coil,220-240 V
82 31501326 Motor housing
84 14112354 Fillister head screw
85 34170424 Screw,
86 34300092 Brush holder
87 34170424 Screw,
88 34339421 Cable clip
89 34409821 Cable sleeve
90 34449743 Cable w.CEE plug
91 33913319 Clamping holder
92 14113102 Square nut
93 34170422 Screw,K5x45 T20
94 31604254 Body compl.
95 31400108 Side support handle compl.
96 31400107 Anti-vibration handle compl.
97 33105075 Depth stop
98 31604263 Shift element compl.
99 31604264 Maintenance kit
100 34170426 Screw,
880 34413117 Tube Grease,45 g Urethyn
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo KHE 56 - 00340000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Diagram Metabo KHE 56

Diagram Metabo KHE 56

Download (314.96KB)

You might also like

Carbon Brushe Set for Hammers Metabo MHE-KHE 56-76
Metabo SKU: 31604265
Carbon Brushe Set for Hammers Metabo MHE-KHE 56-76
Carbon Brushe Set for Hammers Metabo MHE-KHE 56-76 Genuine Spare Parts Metabo, Carbon Brushe Set for Hammers MHE 56/00366000 - KHE 56/00340000 - KHE 76/00341000. Part for the following article : - Hammer METABO MHE 56/00366000 -...
AVAILABLE €41.44
Details
Spacer Sleeve for Rotary Hammer Metabo KHE 3250
Metabo SKU: 34100605
Spacer Sleeve for Rotary Hammer Metabo KHE 3250
Spacer Sleeve for Rotary Hammer Metabo KHE 3250 Original Spare Parts Metabo, Spacer Sleeve for Rotary Hammer Metabo KHE 3250/00637000 Part for the following article : - METABO KHE 3250/00637000 - METABO...
AVAILABLE €4.32
Details
Electronic Unit for Hammer Metabo MHE 56
Metabo SKU: 34308135
Electronic Unit for Hammer Metabo MHE 56
Electronic Unit for Combination Hammer Metabo MHE 56 Genuine part Metabo, Electronic Unit 220/240V for Combination Hammers MHE 56 - KHE 56. Parts for the following products: -  Combination Hammer MHE 56 - 00366000 -  Combination...
on 7/10 Business Days Approx €98.10
Details
Comments (0)
