| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
photo_cameraImage coming soon | 30101380 Seal ring | €2.26 | |
|
2
|
photo_cameraImage coming soon | 32501250 Bearing 17x40x12 (6203) | €10.54 | |
|
3
|
photo_cameraImage coming soon | 6FC44200 Pinion | €61.27 | |
|
4
|
photo_cameraImage coming soon | 32501010 Ball bearing 12x32x10 | €5.12 | |
|
6
|
photo_cameraImage coming soon | 6FC44100 Reverse gear | €40.58 | |
|
7
|
photo_cameraImage coming soon | 32101200 Needle bearing | €5.69 | |
|
9
|
photo_cameraImage coming soon | 30102400 Seal ring | €2.64 | |
|
10
|
photo_cameraImage coming soon | 32501750 Ball bearing | €9.62 | |
|
12
|
photo_cameraImage coming soon | 6CT28100 Spacer | €7.08 | |
|
13
|
photo_cameraImage coming soon | 6FC44000 Engagement collar | €25.10 | |
|
14
|
photo_cameraImage coming soon | 6CT19600 Spacer | €7.08 | |
|
15
|
photo_cameraImage coming soon | 6FC37700 Sliding gear z-59 | €73.45 | |
|
18
|
photo_cameraImage coming soon | 31901200 Needle roller bushing | €3.65 | |
|
19
|
photo_cameraImage coming soon | 6CO15300 Gearbox cover | €79.67 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
12
|
photo_cameraImage coming soon | 6CM00700 Right angled blade | €8.50 | |
|
14
|
photo_cameraImage coming soon | 5FV00400 Blade holder hub | €9.87 | |
|
16
|
photo_cameraImage coming soon | 6CM00600 Left angled blade | €8.50 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Fix your Tiller RT401- 03/2018 - From serial number 9101497 (891HD04), all spare parts are available at discounted prices. Our spare parts are original and come with a full warranty.
In the table below to find the position, code and detailed description corresponding to each spare part.![]()
| TAV 1 - TRASMISSION GROUP Pag.1 | ||
| # | Code | Description |
| 1 | 3930520T | M12x90 Hex Socket Head Cap Screw |
| 2 | 3940276T | M6x22 Hex Socket Head Cap Screw |
| 3 | 6CO028T0 | Dust Cover |
| 4 | 30102300 | Sealing Ring |
| 5 | 38011520 | Seeger I 52 |
| 6 | 6HP04460 | Shifter |
| 7 | 32501600 | Ball Bearing 25x52x15 |
| 8 | 6CL17600 | Right Central Body |
| 9 | 3940295T | M6x40 Hex Socket Head Cap Screw |
| 10 | 31001080 | Cutter Drive Chain |
| 11 | 3930330T | M8x45 Hex Socket Head Cap Screw |
| 12 | 6HC04110 | Z-16 Cutter Drive Pinion |
| 13 | 6GF00400 | Chain Tensioner |
| 14 | 3940360T | M8x18 Hex Socket Head Cap Screw |
| 15 | 3730105T | Ø8 Groove Washer |
| 16 | 3322104T | M8 Self-Locking Nut |
| 17 | 3700106T | Ø8 Chamfered Washer |
| 18 | 6HT092T0 | Directional Knife Support |
| 19 | 5CM002C0 | Directional Knife |
| 20 | 3931300T | M8x30 Hex Socket Head Cap Screw |
| 21 | 6LD013T0 | 16x1.5 Oil Cap |
| 22 | 37460010 | 16x22x1.5 Aluminum Washer |
| 23 | 6BB00100 | Cutter Shaft |
| 24 | 38311300 | Ø6x16 Cylindrical Pin |
| 25 | 6GR07000 | Rod Holder Plate |
| 26 | 38191030 | Pin |
| 27 | 6HP00680 | Shift Ø12-Ø20-0.8 |
| 28 | 6BF15000 | Pin |
| 29 | 30101050 | Sealing ring 12-19-5 |
| 30 | 6FU176T0 | Spring |
| 31 | 6FL087T0 | Lever |
| 32 | 37101080 | Corrugated washer Ø8 |
| 33 | 3290106T | M8 nut |
| 34 | 6DT007T0 | Wire guide |
| 35 | 3420106T | Red fiber washer |
| 36 | 6BO010T01 | Barrel |
| 37 | 30601040 | Breather cap |
| 38 | 6GP10100 | M8 x 32 stud |
| 39 | 6CI17500 | LH central body |
| 40 | 6GS14000 | Sealing ring |
| 41 | 30201270 | Shift 20x35x0.3 |
| 42 | 6HP02970 | Cutter control crown z-16 |
| 43 | 6CC01700 | Quick release |
| 44 | 38311010 | Centering pin |
| 45 | 3292108T | M12 x 1.75 medium nut |
| 46 | 3700108T | Beveled washer Ø12 |
| 47 | 6BF151T0 | Crankcase adjustment rod |
| TAV 2 - WHEEL GEAR CHANGE GROUP Pag.2 | ||
| 1 | 6FL022T0 | Gear shift lever |
| 2 | 6HG007A0 | Gear indicator |
| 3 | 3290107T | M10 nut |
| 4 | 6CO048T0 | Dust cover |
| 5 | 30201240 | Sealing ring |
| 6 | 6GH02400 | Pin with eccentric |
| 7 | 6CL03200 | Gearbox |
| 8 | 3940405T | TCEI screw M8x60 |
| 9 | 3322104T | Self-locking nut M8 |
| 10 | 6DT011T0 | Wire guide |
| 11 | 3945102T | TE screw M8x25 flanged |
| 15 | 5CB009T0 | Long chain guard |
| 16 | 6DS01040 | Gasket |
| 17 | 3295109T | M14x1.5-h8 nut |
| 18 | 37101110 | Corrugated washer Ø14 |
| 19 | 6CC01900 | Wheel drive chain |
| 20 | 31001720 | Wheel drive chain |
| 21 | 6DL022B0 | Wheel axle support |
| 22 | 37301040 | Chamfered washer Ø7 |
| 23 | 3931716T | TE screw M7x14 |
| 24 | 32501350 | Ball bearing |
| 25 | 6CT04200 | Spacer |
| 26 | 38011420 | Internal circlip I 42 |
| 27 | 30102100 | Sealing ring |
| 28 | 6BA00600 | Wheel shaft |
| 29 | 5HD08500 | Wheel 4.00.4 complete |
| 32 | 3945105T | TE screw M8x20 flanged |
| 33 | 30701100 | Inner ring |
| 34 | 30111020 | Seal ring |
| 35 | 31901550 | Needle roller cup |
| 36 | 6FC16600 | Idler gear z-10 |
| 37 | 6DS01140 | Seal |
| 38 | 38001120 | Seeger E 12 |
| 39 | 6HP00650 | Shift 12-20-0.8 |
| 40 | 31911100 | Needle roller cup |
| 41 | 6FC16400 | Sliding gear z-18 |
| 42 | 6FC16700 | Double gear z-9-14 |
| 43 | 31911050 | Needle roller cup |
| 44 | 6FC37800 | Central shaft z-12 |
| 45 | 6HP02970 | Shift 20x35x0.3 |
| 46 | 30101600 | Seal ring |
| 47 | 6DS06940 | Seal |
| 48 | 6GL01200 | Fork carrier pin |
| 49 | 6DF02500 | Gear shift fork |
| 50 | 3931275T | M8x10 hex head screw |
| 51 | 39112800 | M6x25 grub screw |
| 52 | 6HC03630 | Washer |
| 53 | 6FU03700 | Spring |
| 54 | 38101100 | Ball |
| 55 | 3972103T | Self-tapping screw |
| 56 | 36601080 | Knob diam. 12 |
| TAV 3 - TRASMISSION MOTOR Pag.3 | ||
| 1 | 30101380 | Seal ring |
| 2 | 32501250 | Ball bearing |
| 3 | 6FC44200 | Pinion |
| 4 | 32501010 | Ball bearing |
| 5 | 6GL05700 | Pinion |
| 6 | 6FC44100 | Reverse gear |
| 7 | 32101200 | Needle bearing |
| 8 | 6HP00970 | Shift 010-021-0.3 |
| 9 | 30102400 | Seal ring |
| 10 | 32501750 | Ball bearing |
| 11 | 38011550 | Seeger I 55 |
| 12 | 6CT28100 | Spacer |
| 13 | 6FC44000 | Engagement collar |
| 14 | 6CT19600 | Spacer |
| 15 | 6FC37700 | Sliding gear z-59 |
| 16 | 6HP02650 | Shift 020-030-0.8 |
| 17 | 38001190 | Seeger E 19 |
| 18 | 31901200 | Needle roller bushing |
| 19 | 6CO15300 | Gearbox cover |
| 20 | 3945103T | M8x35 flanged hex head screw |
| 22 | 3970390T | M6x10 cap screw |
| 23 | 6HC00150 | Washer |
| 24 | 3294107T | M10 low nut |
| 25 | 37101090 | Ø10 wave washer |
| TAV 4 - HANDLEBAR AND SUPPORT Pag.4 | ||
| 1 | 3540137P | Pre-assembled engagement lever |
| 2 | 35601060 | Grip |
| 3 | 3322103T | M6 self-locking nut |
| 4 | 35701460 | Throttle and stop control |
| 5 | 6FB07400 | Engine stop wire with faston |
| 6 | 3322104T | M8 self-locking nut, low |
| 7 | 37101080 | Wave washer 08 |
| 8 | 6DT041T0 | Adjuster |
| 9 | 5FL074PX | Complete lever |
| 10 | 3930320T | M8x35 hex head screw |
| 11 | 6HB013T0 | Adjuster |
| 12 | 6DG23300 | Clamp engagement wire |
| 13 | 3931225T | M6x16 hex head screw |
| 14 | 3701120T | Ø6 washer |
| 15 | 5BS00600 | Tool bag |
| 16 | 6GQ109A0 | Support guard |
| 20 | 6HZ012T0 | Sprocket sector |
| 21 | 5HT466A0 | Handlebar support |
| 22 | 3325101T | M8 smooth flange nut |
| 23 | 6HC025T0 | Washer |
| 24 | 6CS008T0 | Threaded bushing |
| 25 | 6FU008T0 | Lever spring |
| 26 | 6DG02800 | Throttle wire |
| 27 | 3290103T | M5 h 5 nut |
| 28 | 33801210 | Cable clamp |
| 29 | 3970335T | M5x20 TCCI screw |
| 30 | 5HR170C0 | Handlebar |
| TAV 5 - ENGINE DETAILS Pag.5 | ||
| 1 | 31001690 | Belt, section 5L |
| 2 | 6GV045T0 | Gearbox pulley |
| 3 | 3946102T | M8x16 flanged hex head screw |
| 4 | 3730105T | Ø8 grower washer |
| 6 | 3700106T | Ø8 chamfered washer |
| 7 | 6HQ068T0 | Double belt guide |
| 8 | 6CO154T0 | Belt cover |
| 9 | 3934215T | 5/16 - 24 x 3/4 hex head screw |
| 10 | 39103350 | M8 grub screw |
| 11 | 6GV04600 | Motor pulley |
| 12 | 31401200 | Key |
| 13 | 3946101T | M8x40 flanged hex head screw |
| 14 | 3325101T | M8 flanged self-locking nut |
| 15 | 6GG003C0 | Bumper |
| 16 | 3701130T | 8-24 washer |
| 17 | 6HT093B0 | Motor mount |
| 18 | 3945102T | M8x25 flanged hex head screw |
| 19 | 3930367T | M8x85 hex head screw |
| 20 | 3930320T | M8x35 hex head screw |
| 21 | 5BT092T0 | Belt tensioner arm |
| 22 | 6CT256T0 | Spacer |
| 23 | 6BU004PX | Pulley with bearing |
| 26 | 3322104T | M8 self-locking nut |
| 27 | 3930335T | M8 x 50 hex head screw |
| 28 | 37101080 | Ø8 corrugated washer |
| 29 | 32201160 | Sintered bushing |
| 30 | 6CT282T0 | Bushing spacer |
| 31 | 6BR015T0 | Spacer bushing |
| 32 | 6HT099T0 | Belt cover support |
| 33 | 6CB024A0 | Belt cover |
| 34 | 3324102T | M12 self-locking nut |
| 35 | 37101100 | Ø12 washer |
| 36 | 31401150 | 5 x 5 x 15 key |
| TAV 6 - MILLING GROUP Pag.6 | ||
| HOOD 16 / 24 cm. | ||
| 1 | 5CH139A0 | Right-hand movable hood |
| 2 | 5BN021A0 | Right-hand movable vane |
| 3 | 5CH138A0 | Central fixed hood |
| 4 | 5BN022A0 | Left-hand movable vane |
| HOOD 32 / 40 / 50 cm | ||
| 1.1 | 5CH136A0 | Right-hand movable hood |
| 2.1 | 5BN019A0 | Right-hand movable vane |
| 3.1 | 5CH141A0 | Central fixed hood |
| 4.1 | 5BN020A0 | Left-hand movable vane |
| 5.1 | 5CH137A0 | Left-hand movable hood |
| GENERAL PARTS | ||
| 6 | 3296101T | M12 x 1.5 h8 nut |
| 7 | 6HC04500 | Special washer |
| 8 | 935062/63/64 | Pin (Various sizes: 15, 31.6, 48.3 cm) |
| 9 | 3931295T | M8 x 25 hex head screw |
| 10 | 3730105T | Grower washer 8 |
| 11 | 3290106T | M8 nut |
| 12 | 6CM00700 | Right angled blade |
| 13 | 93505515 | L53 spacer |
| 14 | 5FV00400 | Blade holder hub |
| 16 | 6CM00600 | Left angled blade |
| 17 | 3325101T | M8 self-locking nut, smooth flange |
| 18 | 3700106T | Ø8 beveled washer |
| 19 | 3946102T | M8 x 16 hex head screw, smooth flange |
