Fix Your Hedge Trimmer Maruyama HT230D. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Maruyama Hedge Trimmer HT230D Parts | ||
| Main Body Pag.1 | ||
| # | Part Num. | Description |
| 1-1 | 362064 | |
| 1-2 | 270239 | |
| 1-3 | 270240 | Kit Handle |
| 1-4 | 997258 | Screw |
| 1-5 | 997259 | Plate |
| 1-6 | 997260 | Pin |
| 1-7 | 270145 | Cap |
| 1-8 | 997262 | Lever |
| 1-9 | 997263 | Seeger |
| 1-10 | 270274 | Pin |
| 1-11 | 270233 | Nut |
| 1-12 | 270085 | Plate |
| 1-13 | 270083 | Lever |
| 1-14 | 270370 | Stop |
| 1-15 | 270098 | Left Handle |
| 1-16 | 997268 | Screw |
| 1-17 | 997269 | Screw |
| 1-18 | 270099 | Right Handle |
| 1-19 | 266960 | Plate |
| 1-20 | 217677 | Blade Cover |
| 1-21 | 270021 | Clutch Drum |
| 1-22 | 584661 | Gear Box |
| 1-23 | 581910 | Screw |
| 1-24 | 270241 | Central Handle |
| 1-25 | 266957 | Plate |
| 1-26 | 997244 | Nut |
| 1-27 | 991941 | Nut |
| 1-28 | 270030 | Screw |
| 1-29 | 581912 | |
| 1-30 | 991937 | Pin |
| 1-31 | 580767 | Bearing |
| 1-32 | 270423 | Bearing |
| 1-33 | 584666 | Shaft |
| 1-34 | 591443 | Gear |
| 1-35 | 997282 | Connecting Rod |
| 1-36 | 580777 | Seeger |
| 1-37 | 991931 | |
| 1-38 | 570687 | Blade |
| 1-39 | 991924 | |
| 1-40 | 991919 | Plate |
| 1-41 | 997286 | Felt |
| 1-42 | 570688 | Blade |
| 1-43 | 997288 | Gear Box Cover |
| 1-44 | 580791 | Screw |
| 1-45 | 270023 | Tube |
| 1-46 | 991913 | Washer |
| 1-47 | 991914 | |
| 1-48 | 270119 | |
| 1-49 | 997253 | Nut |
| 1-50 | 270120 | Stop |
| 1-51 | 270371 | |
| 1-52 | 991912 | Support Bar |
| 1-53 | 991973 | Plate |
| 1-54 | 269426 | |
| Accessories Pag.2 | ||
| 2‐1 | 264606 | Accessory set |
| 2‐2 | 264607 | Spark plug wrench |
| 2‐3 | 219431 | Hex wrench |
| 2‐4 | 219432 | Hex wrench |
| 2‐5 | 270181 | User manual |
| 2‐6 | 521158 | Spare parts list |
| Engine Pag.3 | ||
| 3-1 | 850393 | |
| 3-2 | 263768 | Cylinder |
| 3-3 | 263770 | Gasket |
| 3-4 | 261250 | Screw |
| 3-5 | 267924 | Collector |
| 3-6 | 265794 | Gasket |
| 3-7 | 261171 | Gasket |
| 3-8 | 265924 | Screw |
| 3-9 | 263776 | Muffler |
| 3-10 | 264736 | Pin |
| 3-11 | 266959 | Label |
| 3-12 | 265925 | Screw |
| 3-13 | 263777 | Heat shield |
| 3-14 | 264223 | Screw |
| 3-15 | 263802 | Cover |
| 3-16 | 261607 | Screw |
| 3-17 | 264670 | Cylinder cover |
| 3-18 | 265742 | Screw |
| 3-19 | 264542 | Complete shaft |
| 3-20 | 261181 | |
| 3-21 | 262712 | |
| 3-22 | 262713 | Rubber |
| 3-23 | 054676 | |
| 3-24 | 261246 | Cap Screw |
| 3-25 | 263569 | Piston |
| 3-26 | 263789 | Piston ring |
| 3-27 | 261036 | |
| 3-28 | 263957 | |
| 3-29 | 261576 | |
| 3-30 | 264643 | |
| 3-31 | 264585 | Support |
| 3-32 | 264959 | Clutch |
| 3-33 | 264960 | Shoe |
| 3-34 | 264963 | Plate |
| 3-35 | 264964 | Spring |
| 3-36 | 264646 | Washer |
| 3-37 | 263799 | Cover |
| 3-38 | 265972 | |
| 3-39 | 264588 | Plate |
| 3-40 | 267386 | Coil |
| 3-41 | 263570 | Flywheel |
| 3-42 | 267173 | |
| 3-43 | 267174 | |
| 3-44 | 267403 | Complete spark plug cap |
| 3-45 | 267404 | Cable |
| 3-46 | 261074 | Cable |
| 3-47 | 261075 | |
| 3-48 | 261072 | |
| 3-49 | 269418 | |
| 3-50 | 261076 | |
| 3-51 | 261077 | Nut |
| 3-52 | 261078 | Rubber |
| 3-53 | 261256 | Screw |
| 3-54 | 262483 | Spark plug |
| 3-55 | 267492 | Cable |
| 3-56 | 261202 | Rubber |
| 3-57 | 265081 | Cover |
| 3-58 | 265175 | |
| 3-59 | 264545 | Fuel Tank |
| 3-60 | 265176 | Tank cap |
| 3-61 | 269415 | Cap filter |
| 3-62 | 269417 | Cap rod |
| 3-63 | 265928 | Pipe/filter kit |
| 3-64 | 265929 | Pipe kit |
| 3-65 | 265869 | Rubber pipe |
| 3-66 | 262649 | Tube |
| 3-67 | 263038 | Tube |
| 3-68 | 264653 | Filter |
| 3-69 | 261117 | Or |
| 3-70 | 264318 | Rubber |
| 3-71 | 263824 | Rubber |
| 3-72 | 261117 | Lock |
| 3-73 | 265199 | Plate |
| 3-74 | 261878 | |
| Carburetor - Recoil Starter Pag.4 | ||
| 4-1 | 265635 | |
| 4-2 | 261871 | Or |
| 4-3 | 262121 | Pin |
| 4-4 | 262995 | Diaphragm |
| 4-5 | 262994 | Diaphragm |
| 4-6 | 264155 | Base |
| 4-7 | 262993 | Diaphragm |
| 4-8 | 261873 | Diaphragm |
| 4-9 | 262991 | Base |
| 4-10 | 261874 | Pump |
| 4-11 | 262992 | Support |
| 4-12 | 262996 | Screw |
| 4-13 | 264681 | Base |
| 4-14 | 261876 | Lock |
| 4-15 | 261658 | Screw |
| 4-16 | 264682 | Pin |
| 4-17 | 261652 | Nut |
| 4-18 | 261864 | Gasket |
| 4-19 | 265973 | Plate |
| 4-20 | 264691 | O-ring |
| 4-21 | 265575 | |
| 4-22 | 265576 | Filter plate |
| 4-23 | 264695 | Filter |
| 4-24 | 264709 | Filter cover |
| 4-25 | 264016 | Screw |
| 4-26 | 264534 | Starter kit |
| 4-27 | 264083 | Starter Ass'y |
| 4-28 | 115096 | |
| 4-29 | 261725 | Handle |
| 4-30 | 261627 | Rope |
| 4-31 | 261622 | Spiral Spring |
| 4-32 | 261621 | Pulley |
| 4-33 | 262922 | Screw |
| 4-34 | 264085 | Starter Pawl Ass'y |
| 4-35 | 261630 | Pawl |
| 4-36 | 261631 | Spring |
| 4-37 | 264086 | Base |
| 4-38 | 020299 | Lock |
| 4-39 | 264535 | |
| 4-40 | 264807 | Screw |
| 4-41 | 265736 | |
| 4-42 | 264604 | Cable |
