Fix Your Hedge Cutter Maruyama HT237D. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.![]()
| Maruyama Hedge Cutter HT237D Parts | ||
| Main Body Pag.1 | ||
| # | Part. Num. | Description |
| 1-1 | 362426 | HT237D |
| 1-2 | 271226 | Guide Plate |
| 1-3 | 270682 | Blade |
| 1-4 | 274877 | Blade Guard |
| 1-5 | 991914 | Screw |
| 1-6 | 271229 | Screw |
| 1-7 | 991913 | Washer |
| 1-8 | 991941 | U-Nut |
| 1-9 | 217677 | Cover of Blade |
| 1-10 | 271396 | Rear Handle Ass'y Incl.11-29 |
| 1-11 | 271278 | Rear Handle (L) |
| 1-12 | 271279 | Rear Handle (R) |
| 1-13 | 271280 | Lever,Throttle |
| 1-14 | 271281 | Stop Lever |
| 1-15 | 271282 | Lock Lever |
| 1-16 | 271283 | Lock Lever Stopper |
| 1-17 | 271284 | Rod |
| 1-18 | 271285 | Switch |
| 1-19 | 271398 | Cable Comp |
| 1-20 | 271287 | Spacer |
| 1-21 | 271288 | Spring |
| 1-22 | 271289 | Spring |
| 1-23 | 270400 | Spring |
| 1-24 | 271276 | Screw |
| 1-25 | 271274 | Handle Stay (L) |
| 1-26 | 271275 | Handle Stay (R) |
| 1-27 | 271276 | Screw |
| 1-28 | 270424 | Spacer |
| 1-29 | 271277 | Spacer |
| 1-30 | 270566 | Label |
| 1-31 | 287394 | Label |
| 1-32 | 271221 | Tube |
| 1-33 | 271908 | Screw |
| 1-34 | 277400 | Screw |
| 1-35 | 271909 | Screw |
| 1-36 | 271911 | Screw |
| 1-37 | 270843 | Washer |
| 1-38 | 271222 | Upper Case |
| 1-39 | 271410 | Pinion |
| 1-40 | 270021 | Clutch Drum |
| 1-41 | 270423 | Bearing |
| 1-42 | 580767 | Bearing |
| 1-43 | 266959 | Label |
| 1-44 | 266960 | Label |
| 1-45 | 991937 | Grease Nipple |
| 1-46 | 271223 | Lower Case |
| 1-47 | 271224 | Plate |
| 1-48 | 991924 | Screw |
| 1-49 | 270423 | Bearing |
| 1-50 | 270552 | Crank Comp |
| 1-51 | 271225 | Rod Ass'y |
| 1-52 | 271227 | Felt |
| 1-53 | 271895 | Screw |
| 1-54 | 271910 | Screw |
| 1-55 | 991941 | U-Nut |
| 1-56 | 580777 | Snap Ring |
| 1-57 | 278303 | Front Handle Ass'y |
| 1-58 | 266957 | Label |
| Engine Pag.2 | ||
| 2-1 | 875089 | Engine |
| 2-2 | 278641 | Cylinder |
| 2-3 | 289643 | Gasket |
| 2-4 | 267290 | Cap Screw |
| 2-5 | 272744 | Insulator |
| 2-6 | 267049 | Gasket |
| 2-7 | 265924 | Cap Screw |
| 2-8 | 278263 | Muffler Comp |
| 2-9 | 266402 | Cap Screw |
| 2-10 | 278273 | Gasket |
| 2-11 | 278264 | Tail Pipe Comp |
| 2-12 | 278288 | Cylinder Cover Ass'y Incl.13-15 |
| 2-13 | 277793 | Cylinder Cover |
| 2-14 | 286399 | Knob |
| 2-15 | 286270 | Washer |
| 2-16 | 278210 | Muffler Cover Comp |
| 2-17 | 261607 | Cap Screw |
| 2-18 | 278208 | Crankcase |
| 2-19 | 261181 | Bearing |
| 2-20 | 262712 | Oil Seal |
| 2-21 | 262713 | Oil Seal |
| 2-22 | 054676 | Snap Ring |
| 2-23 | 261246 | Cap Screw |
| 2-24 | 272204 | Piston |
| 2-25 | 264891 | Piston Ring |
| 2-26 | 261036 | Piston Pin |
| 2-27 | 288520 | Bearing, Needle |
| 2-28 | 261576 | Clip,Piston |
| 2-29 | 283155 | Shaft Comp |
| 2-30 | 280404 | Clutch Ass'y Incl.31-33 |
| 2-31 | 280568 | Clutch Shoe |
| 2-32 | 280569 | Clutch Boss |
| 2-33 | 280570 | Spring |
| 2-34 | 278161 | Magneto Ass'y Incl.35-41 |
| 2-35 | 278176 | Rotor/Fan |
| 2-36 | 278293 | Ignition Coil Ass'y Incl.37-41 |
| 2-37 | 278367 | Spark Plug Wire Ass'y Incl.38,39 |
| 2-38 | 282292 | Plug Boot |
| 2-39 | 261075 | Connector |
| 2-40 | 261072 | Cap |
| 2-41 | 280080 | Insulator |
| 2-42 | 280936 | Ratchet |
| 2-43 | 285552 | Spring |
| 2-44 | 020299 | E-Ring |
| 2-45 | 267492 | Lead |
| 2-46 | 261076 | Woodruff Key |
| 2-47 | 261077 | Nut,Rotor |
| 2-48 | 280381 | Spacer |
| 2-49 | 278831 | Cap Screw |
| 2-50 | 288264 | Spark Plug |
| 2-51 | 278294 | Grommet |
| 2-52 | 278207 | Starter Ass'y Incl.53-59 |
| 2-53 | 278693 | Pulley |
| 2-54 | 280931 | Spiral Spring |
| 2-55 | 262922 | Screw |
| 2-56 | 283291 | Rope Ass'y Incl.57-59 |
| 2-57 | 283292 | Starter Rope |
| 2-58 | 261725 | Starter Grip |
| 2-59 | 283293 | Rope Stopper |
| 2-60 | 267290 | Cap Screw |
| 2-61 | 278300 | Label |
| 2-62 | 267191 | Cap Screw |
| Carburetor - Fuel Tank Pag.3 | ||
| 3-1 | 278297 | Carburetor Ass'y Incl.2-15 |
| 3-2 | 268499 | Pump Body |
| 3-3 | 262991 | Purge Body |
| 3-4 | 262992 | Cover Plate |
| 3-5 | 261874 | Primer Bulb |
| 3-6 | 283905 | Diaphragm, Meterring |
| 3-7 | 262993 | Gasket |
| 3-8 | 262994 | Diaphragm,Fuel Pump |
| 3-9 | 282576 | Gasket |
| 3-10 | 289396 | Main Jet |
| 3-11 | 261871 | O-Ring |
| 3-12 | 261876 | E-Ring |
| 3-13 | 261658 | Swivel |
| 3-14 | 264682 | Screw |
| 3-15 | 262996 | Screw |
| 3-16 | 268535 | Stay |
| 3-17 | 278750 | Gasket |
| 3-18 | 278090 | Cleaner Ass'y Incl.19-21 |
| 3-19 | 265576 | Housing |
| 3-20 | 264695 | Filter |
| 3-21 | 278760 | Cleaner Cover |
| 3-22 | 261117 | Clip |
| 3-23 | 268963 | Gasket |
| 3-24 | 280102 | Screw |
| 3-25 | 278209 | Fuel Tank Ass'y Incl.26-36 |
| 3-26 | 277791 | Fuel Tank |
| 3-27 | 283438 | Tank Cap Ass'y Incl.28,29 |
| 3-28 | 283727 | Gasket |
| 3-29 | 283764 | Breather Ass'y |
| 3-30 | 265752 | Fuel Pipe Pick-up Ass'y Incl.31-36 |
| 3-31 | 264031 | Fuel Pipe Ass'y Incl.32-34 |
| 3-32 | 261115 | Grommet |
| 3-33 | 261690 | Fuel Pipe |
| 3-34 | 263038 | Return Pipe |
| 3-35 | 264653 | Filter Ass'y |
| 3-36 | 261117 | Clip |
| 3-37 | 269690 | Cap Screw |
| Accessories Pag.4 | ||
| 4-1 | 278278 | Instruction Manual |
| 4-2 | 278279 | Instruction Manual I |
| 4-3 | 278280 | nstruction Manual |
| 4-4 | 524392 | Parts List |
| 4-5 | 264606 | Tool Set Incl.6-8 |
| 4-6 | 264607 | Box Spanner |
| 4-7 | 219431 | Wrench |
| 4-8 | 219432 | Wrench |
