Hedge Cutter Maruyama HT234D

Maruyama Hedge Cutter HT234D Parts
Main Body Pag.1
# Part. Num. Description
1-1 362417 HT234D
1-2 277418 Guide Plate
1-3 271888 Spacer Plate
1-4 271889 Spacer
1-5 277421 Spacer
1-6 271890 Washer
1-7 271891 Upper Blade
1-8 271892 Lower Blade
1-9 274878 Blade Guard
1-10 271894 Bush
1-11 271895 Screw
1-12 277530 Screw
1-13 271897 Screw
1-14 277531 Screw
1-15 271899 Nut
1-16 271901 Cover of Blade
1-17 271902 Rear Handle Ass'y Incl.18-36
1-18 271278 Rear Handle (L)
1-19 271279 Rear Handle (R)
1-20 271280 Lever,Throttle
1-21 271281 Stop Lever
1-22 271282 Lock Lever
1-23 271283 Lock Lever Stopper
1-24 271284 Rod
1-25 271285 Switch
1-26 271904 Cable Comp
1-27 271287 Spacer
1-28 271288 Spring
1-29 271289 Spring
1-30 270400 Spring
1-31 271276 Screw
1-32 271274 Handle Stay (L)
1-33 271275 Handle Stay (R)
1-34 271276 Screw
1-35 270424 Spacer
1-36 271277 Spacer
1-37 271905 Front Handle
1-38 270566 Label
1-39 271906 Tail Pipe Cover
1-40 271907 Tail Pipe Comp
1-41 271221 Tube
1-42 270843 Washer
1-43 271908 Screw
1-44 271909 Screw
1-45 271910 Screw
1-46 271911 Screw
1-47 271912 Screw
1-48 271914 Rod Ass'y
1-49 271918 Upper Case
1-50 271919 Pinion
1-51 271920 Plate
1-52 270021 Clutch Drum
1-53 271921 Bearing
1-54 580767 Bearing
1-55 991937 Grease Nipple
1-56 271923 Lower Case
1-57 271924 Plate
1-58 270423 Bearing
1-59 271925 Bearing
1-60 271926 Crank Comp
1-61 271927 Felt
1-62 271910 Screw
1-63 266957 Label
1-64 266960 Label
1-65 269433 Label
Engine Pag.2
2-1 859995 Engine
2-2 288499 Cylinder
2-3 286074 Gasket
2-4 261250 Cap Screw
2-5 265802 Insulator - New gasket required
2-6 267049 Gasket
2-7 265924 Cap Screw
2-8 275641 Muffler Ass'y Incl.9-11
2-9 288503 Muffler Tail
2-10 289382 Gasket
2-11 288542 Screw
2-12 266959 Label
2-13 266402 Cap Screw
2-14 275562 Muffler Guard
2-15 288542 Screw
2-16 275561 Gasket
2-17 275560 Under Cover
2-18 267191 Cap Screw
2-19 276563 Top Cover Ass'y Incl.20-22
2-20 276564 Top Cover Comp
2-21 286399 Knob
2-22 286270 Washer
2-23 288537 Crankcase
2-24 280488 Bearing
2-25 261492 Oil Seal
2-26 261386 Oil Seal
2-27 055185 Snap Ring
2-28 261246 Cap Screw
2-29 283379 Piston
2-30 282177 Piston Ring
2-31 261036 Piston Pin
2-32 263957 Bearing, Needle
2-33 261576 Clip,Piston
2-34 288511 Crankshaft/Conn.Rod Ass'y
2-35 280404 Clutch Ass'y Incl.36-38
2-36 280568 Clutch Shoe
2-37 280569 Clutch Boss
2-38 280570 Spring
2-39 275557 Fan Cover
2-40 261250 Cap Screw
2-41 271998 Magneto Ass'y Incl.42-49
2-42 288515 Rotor/Fan
2-43 271999 Ignition Coil Ass'y Incl.44-49
2-44 272000 Spark Plug Wire Ass'y Incl.45-47
2-45 289485 Spark Plug Wire
2-46 277856 Connector
2-47 272001 Plug Boot
2-48 283271 Cap
2-49 289486 Insulator
2-50 277567 Label
2-51 261076 Woodruff Key
2-52 261417 Nut,Rotor
2-53 280381 Spacer
2-54 261256 Cap Screw
2-55 288264 Spark Plug
2-56 261772 Lead
2-57 283140 Grommet
2-58 283171 Recoil Starter Ass'y Incl.59-73
2-59 283172 Starter Ass'y Incl.60-68
2-60 286363 Reel
2-61 286364 Cam Plate
2-62 283290 Spring
2-63 280931 Spiral Spring
2-64 267213 Screw
2-65 283291 Rope Ass'y Incl.66-68
2-66 283292 Starter Rope
2-67 261725 Starter Grip
2-68 283293 Rope Stopper
2-69 283173 Starter Pulley Ass'y Incl.70-73
2-70 283294 Starter Pulley
2-71 280936 Ratchet
2-72 283295 Spring
2-73 020299 E-Ring
2-74 264535 Screw
2-75 280144 Tapping Screw
Carburetor - Recoil Starter Pag.3
3-1 277126 Carburetor Ass'y Incl.2-15
3-2 268499 Pump Body
3-3 262991 Purge Body
3-4 262992 Cover Plate
3-5 261874 Primer Bulb
3-6 283905 Diaphragm, Meterring
3-7 262993 Gasket
3-8 262994 Diaphragm,Fuel Pump
3-9 282576 Gasket
3-10 289396 Main Jet
3-11 261871 O-Ring
3-12 261876 E-Ring
3-13 261658 Swivel
3-14 264682 Screw
3-15 262996 Screw
3-16 288517 Gasket
3-17 283773 Stay
3-18 283771 Gasket
3-19 289048 Case Ass'y Incl.20-26
3-20 269050 Case Body
3-21 289019 Valve
3-22 284803 Lever
3-23 284816 Washer
3-24 269032 Screw
3-25 126993 Nut
3-26 269051 Sleeve
3-27 269030 Element
3-28 262720 Cap Screw
3-29 283772 Cleaner Cover
3-30 281438 Knob
3-31 276555 Fuel Tank Ass'y Incl.32-42
3-32 275559 Fuel Tank
3-33 283438 Tank Cap Ass'y Incl.34,35
3-34 283727 Gasket
3-35 283764 Breather Ass'y
3-36 265752 Fuel Pipe Pick-up Ass'y Incl.37-42
3-37 264031 Fuel Pipe Ass'y Incl.38-40
3-38 261115 Grommet
3-39 261690 Fuel Pipe
3-40 263038 Return Pipe
3-41 264653 Filter Ass'y
3-42 261117 Clip
3-43 261117 Clip
3-44 269690 Cap Screw
Accessories Pag.4
4-1 264606 Tool Set
4-2 264607 Box Spanner
4-3 219431 Wrench
4-4 219432 Wrench
4-5 271825 Instruction Manual
4-6 271827 Instruction Manual
4-7 271830 Instruction Manual
4-8 524271 Parts List
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Maruyama websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Maruyama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Maruyama HT234D
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
[email protected]
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Maruyama HT234D Parts Diagram

Maruyama HT234D Parts Diagram

Download (1.26MB)

You might also like

Maruyama SKU: 280404
Maruyama HT230D Clutch Assembly Genuine replacement part Makita, Clutch Assembly for Hedgetrimmers HT230D-R-01 - HT230DS-R-01 - GK761PL. Part for the following products: - Hedgetrimmer Maruyama HT230D-R-01 - Hedgetrimmer...
Usually Ships in: 10/15 Business Days Approx. €41.92
Maruyama SKU: 270021
Maruyama HT230D Clutch Drum Genuine replacement part Makita, Clutch Drum for Hedgetrimmers HT230D-R-01 - HT230DS-R-01 - GK761PL. Part for the following products: - Hedgetrimmer Maruyama HT230D-R-01 - Hedgetrimmer...
AVAILABLE €57.29
Maruyama SKU: 265802
Maruyama HT230D Insulator Genuine replacement part Makita, Carburator Insulator for Hedgetrimmers HT230D-R-01 - HT230DS-R-01. Part for the following products: - Hedgetrimmer Maruyama HT230D-R-01 - Hedgetrimmer...
Usually Ships in: 10/15 Business Days Approx. €34.26
Maruyama SKU: 271905
Maruyama Front Handle for Hedge Cutter HT234D Genuine spare part Maruyama, Front Handle for Hedge Cutter HT234D. Part for the following products: -  Hedge Cutter Maruyama HT234D - Code : 271905
Last items in stock €31.99
Comments (0)
