Maruyama Brushcutter MX21 Parts

SKU: Maruyama MX21 Condition: New
€48.06
VAT included

Maruyama Brushcutter MX21 Spare Parts

Fix Your Brushcutter Maruyama MX21. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 118 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on Demand Only Call Us Before

SHIPPING IN:: ON DEMAND ONLY
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
118 spare parts
Page 1 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon 232225 232225 €51.86
2
 photo_cameraImage coming soon 221473 Clutch Case Ass'y €45.52
3
 photo_cameraImage coming soon 221474 Clutch Case €37.16
7
 photo_cameraImage coming soon 224123 Driveshaft Tube €144.08
8
 photo_cameraImage coming soon 226399 Driveshaft Ass'y €37.33
9
 photo_cameraImage coming soon 229091 Clutch Drum €32.09
10
 photo_cameraImage coming soon 223153 Throttle Trigger €64.99
11
 photo_cameraImage coming soon 215533 HOOK FOR BELT MX33 €5.47
13
 photo_cameraImage coming soon 233260 ROD LABEL MX21 €7.78
14
 photo_cameraImage coming soon 223188 Label €8.03
15
 photo_cameraImage coming soon 233477 ROD LABEL MX21 €2.48
16
 photo_cameraImage coming soon 224324 CENTRAL GRIP ASSY MX €34.79
18
 photo_cameraImage coming soon 213171 BUSHING FOR AVB HANDLE 224324 €2.48
21
 photo_cameraImage coming soon 261250 Cap Screw M €2.48
22
 photo_cameraImage coming soon 232075 CLAMP COMPLETE GUARD MX21/MX24 €34.46
23
 photo_cameraImage coming soon 231232 STONE GUARD MX21/MX24 €26.83
25
 photo_cameraImage coming soon 221580 LOWER CLAMP SCREW BC501 GUARD €2.48
29
 photo_cameraImage coming soon 231704 BC501RS WASHER €2.48
30
 photo_cameraImage coming soon 231882 String Cutter Ass'y €10.10
31
 photo_cameraImage coming soon 230747 String Cutter €6.96
32
 photo_cameraImage coming soon 261250 Cap Screw M €2.48
33
 photo_cameraImage coming soon 228325 Nut €2.46
34
 photo_cameraImage coming soon 230748 Cover Extention €11.44
35
 photo_cameraImage coming soon 220533 Hanging Strap Ass'y €19.65
Page 2 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 232070 BEVEL GEAR CPL MX21/24 231880 €153.07
2
 photo_cameraImage coming soon 226284 Gearcase €26.52
5
 photo_cameraImage coming soon 227108 BEARING 6000DDU COVER WITH, MX22 €68.59
6
 photo_cameraImage coming soon 112184 Bearing €31.32
7
 photo_cameraImage coming soon 054676 Snap Ring €2.50
8
 photo_cameraImage coming soon 225898 Collar €2.95
10
 photo_cameraImage coming soon 228477 Snap Ring €2.46
11
 photo_cameraImage coming soon 140270 Snap Ring €2.46
12
 Maruyama HT230D Cap Screw M5x25 261246 Maruyama HT230D Cap Screw M5x25 €2.48
13
 photo_cameraImage coming soon 225891 Blade Boss A €13.59
14
 photo_cameraImage coming soon 225892 Blade Boss B €8.84
15
 photo_cameraImage coming soon 225893 Nut €2.46
Page 3 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 268608 CYLINDER MX21 €173.94
3
 photo_cameraImage coming soon 283420 Gasket €2.46
4
 photo_cameraImage coming soon 267290 Cap Screw €2.46
5
 photo_cameraImage coming soon 263772 Insulator €11.62
6
 photo_cameraImage coming soon 267049 Gasket €2.78
8
 photo_cameraImage coming soon 281524 Muf?er €27.01
10
 photo_cameraImage coming soon 280409 Gasket €4.59
11
 photo_cameraImage coming soon 282926 CYLINDER COVER MX21-24 €23.69
12
 photo_cameraImage coming soon 283983 Hook €2.46
16
 photo_cameraImage coming soon 280488 Bearing €24.24
17
 photo_cameraImage coming soon 261492 Oil Seal ISCD €5.57
18
 photo_cameraImage coming soon 261386 Oil Seal €5.89
19
 photo_cameraImage coming soon 055185 Snap Ring €13.23
21
 photo_cameraImage coming soon 261032 PISTON MS062/M22/MX21 €34.79
22
 photo_cameraImage coming soon 261158 PISTON RING MS062/M22/MX21 €9.44
23
 photo_cameraImage coming soon 261036 Piston Pin €4.59
24
 photo_cameraImage coming soon 288520 PIN BEARING MX21 €10.26
25
 photo_cameraImage coming soon 261576 CIRCLIP BC230 / M28 / MX21 €2.46
26
 photo_cameraImage coming soon 283879 CRANKSHAFT MX21 €117.29
27
 photo_cameraImage coming soon 269168 Clutch Ass'y €40.11
28
 photo_cameraImage coming soon 269169 CLUTCH SHOE BC2300 BC260 €19.71
29
 photo_cameraImage coming soon 269173 CLUTCH SHOE SPRING BC2300 BC260 €6.12
30
 photo_cameraImage coming soon 269647 Clutch Bolt €2.46
31
 photo_cameraImage coming soon 269175 CLUTCH WASHER MX21/24/27 €2.48
32
 photo_cameraImage coming soon 261777 Wave Washer €2.46
33
 photo_cameraImage coming soon 283386 Fan Cover €32.09
36
 photo_cameraImage coming soon 283397 FLYWHEEL MX21 €80.35
37
 photo_cameraImage coming soon 283645 ELECTRONIC COIL COMPLETE MX21 €207.25
43
 photo_cameraImage coming soon 261076 Woodruff Key €2.46
44
 photo_cameraImage coming soon 261417 NutRotor M €2.46
45
 photo_cameraImage coming soon 280381 Spacer €3.43
46
 photo_cameraImage coming soon 261256 COIL FIXING SCREW BK520 €2.48
47
 photo_cameraImage coming soon 262483 SPINNER MCV3100 *usa PR18Y €2.43
48
 photo_cameraImage coming soon 269722 GROUND CABLE BC/BKC5020 €4.46
50
 photo_cameraImage coming soon 264588 CLAMP KJBK50 €2.48
51
 photo_cameraImage coming soon 280419 STARTER CPL+PLATE CPL MX 563307 €34.79
52
 photo_cameraImage coming soon 269999 STARTER MX21/MX24 288685*usa273093 €28.33
53
 photo_cameraImage coming soon 280492 STARTER PULLEY BL3100 MX21 €12.75
54
 photo_cameraImage coming soon 287421 STARTER SPRING BL3110 MX22 280493 €11.92
55
 photo_cameraImage coming soon 280494 STARTER SCREW MX21 MX24 MX27E €2.48
60
 photo_cameraImage coming soon 280547 STARTER WASHER MX21 MX24 MX27E €2.48
61
 photo_cameraImage coming soon 280548 STARTER BUSHING HT2350 MX21 8712767 €3.47
63
 photo_cameraImage coming soon 287399 PLATE W/CRICK AND SPRING MX24/27 €17.71
64
 photo_cameraImage coming soon 269833 STARTER SCREW MX22E M4X16 €2.48
65
 photo_cameraImage coming soon 280489 STARTER SCREW MX22E M4X201 €2.48
66
 photo_cameraImage coming soon 288689 STARTER LABEL MX21 €4.14
67
 photo_cameraImage coming soon 286122 CYLINDER HOUSING LABEL MX €2.48
68
 photo_cameraImage coming soon 284587 CYLINDER HOUSING LABEL MX €2.48
69
 photo_cameraImage coming soon 267561 Label €2.46
70
 photo_cameraImage coming soon 288500 STARTER PLATE MX24E €4.80
Page 4 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 283893 Carburetor Ass'y €44.53
2
 photo_cameraImage coming soon 8472046 MX21 CARBURETOR VALVE ONLY *59-132 €45.05
4
 photo_cameraImage coming soon 262991 Purge Body €26.36
5
 photo_cameraImage coming soon 262992 Cover Plate €8.68
6
 photo_cameraImage coming soon 261874 Primer Bulb €18.01
7
 photo_cameraImage coming soon 283905 Diaphragm Meterring €34.38
8
 photo_cameraImage coming soon 262993 Gasket €7.53
9
 photo_cameraImage coming soon 262994 Diaphragm,Fuel Pump €12.94
10
 photo_cameraImage coming soon 282576 Gasket €7.21
12
 photo_cameraImage coming soon 261871 O-RING JET *16-104 AE320 AE500 €5.47
13
 photo_cameraImage coming soon 261876 E-Ring €2.62
14
 photo_cameraImage coming soon 261658 Swivel €7.69
16
 photo_cameraImage coming soon 261117 BC450 TANK CLAMP €2.46
17
 photo_cameraImage coming soon 261864 Gasket €3.44
18
 photo_cameraImage coming soon 264691 O-Ring €2.46
19
 photo_cameraImage coming soon 266420 Cleaner Ass'y €27.83
20
 Maruyama MX21 Filter Cover 277554 Maruyama MX21 Filter Cover €15.46
21
 photo_cameraImage coming soon 266433 Case Ass'y €29.47
22
 Maruyama BC2300RS Air Filter 264695 Maruyama BC2300RS Air Filter €7.31
23
 photo_cameraImage coming soon 269834 CARBURETOR SCREW MX21 M5x60 €2.48
24
 photo_cameraImage coming soon 280020 Swivel Ring €2.46
25
 photo_cameraImage coming soon 285728 TANK COMPLETE MX21 €70.57
26
 photo_cameraImage coming soon 285664 ONLY TANK MX24 €30.14
27
 photo_cameraImage coming soon 281564 Fuel Tank Cap Ass'y €9.33
28
 photo_cameraImage coming soon 269377 Gasket €2.46
29
 photo_cameraImage coming soon 261696 Breather Ass'y €14.41
30
 photo_cameraImage coming soon 265752 Fuel Pipe PickXup Ass'y €23.86
31
 photo_cameraImage coming soon 264031 Fuel Pipe Ass'y €9.11
32
 photo_cameraImage coming soon 261115 Grommet €7.21
35
 photo_cameraImage coming soon 264653 FUEL FILTER €7.86
36
 photo_cameraImage coming soon 261117 BC450 TANK CLAMP €2.46
38
 photo_cameraImage coming soon 281208 Screw €3.78
Page 5 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
6
 Alpina Brushcutter TR 250 J Nylon Head 118801753/0 Alpina Brushcutter TR 250 J Nylon Head €14.93
6
 photo_cameraImage coming soon 232226 Semi-Auto Head (L) €52.54

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Maruyama Brushcutter MX21 Spare Parts

Fix Your Brushcutter Maruyama MX21. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Brushcutter Maruyama MX21

Maruyama Brushcutter MX21 Spare Parts Pag.1
# Part Num. Description
1 363905
1 363916
2 221473 CLUTCH DRUM SUPPORT COMPLETE MX24
3 221474 CLUTCH COVER CASE MX2
4 016405
5 013825
6 261612
7 224123 OUTER ROD BCL2250RS/MX21
8 226399 INNER ROD MX21/BC2300RS
9 229091 CLUTCH DRUM MX21/33/BC2600
10 223153 THROTTLE LEVER ASSY BC350/BC280
11 215533 HOOK FOR BELT MX33
12 261762
13 233260 ROD LABEL MX21
14 223188 ROD ATTACHMENT LABEL BC5021RS
15 233477 ROD LABEL MX21
16 224324 CENTRAL GRIP ASSY MX
17 222520
18 213171 BUSHING FOR AVB HANDLE 224324
19 215608
20 089846
21 261250 MUFFLER SCREW BC350 M5x20
22 232075 CLAMP COMPLETE GUARD MX21/MX24
23 231232 STONE GUARD MX21/MX24
24 227819
25 221580 LOWER CLAMP SCREW BC501 GUARD
26 232076
27 227820
28 220632
29 231704 BC501RS WASHER
30 231882 MX WIRE CUTTING BLADE SET
31 230747 MX/BC WIRE CUTTING BLADE
32 261250 BC350 MUFFLER SCREW M5x20
33 228325 SQUARE NUT FOR WIRE CUTTING BLADE
34 230748 BC/BKC GUARD EXTENSION *Ex 227812
35 220533 MX33 SHOULDER 560229
36 231657
Maruyama Decespugliatore MX21 Ricambi Pag.2
# Part Num. Description
1 232070 BEVEL GEAR CPL MX21/24 231880
2 226284 BEVEL GEAR COVER BC2300RS
3 225897
4 226285 SHAFT+BEVEL GEAR SET 232070
5 227108 BEARING 6000DDU COVER WITH, MX22
6 112184
7 054676
8 225898 BEVEL GEAR COLLAR BC2300RS
9 226286
10 228477 SEEGER COVER WITH MX27/MX33
11 140270 SEEGER MC-PS
12 261246 ALLEN SCREW MX BC
13 225891 DISC SUPPORT WASHER BC2300RS
14 225892 DISC FIXING WASHER BC2300 MX21
15 225893 FLANGE NUT M8x1.25Sx BC2300 MX21
16 219087
Maruyama Decespugliatore MX21 Ricambi Pag.3
# Part Num. Description
1 858975 EE200 ENGINE SET CPL MX21
2 268608 CYLINDER MX21
3 283420 CYL. GASKET BCL2250/MX21 267178
4 267290 CYLINDER SCREW MX24
5 263772 INTAKE MANIFOLD BC2300RS
6 267049 COLL. GASKET BCL2250 MX21
7 269826
8 281524 MUFFLER MX24
9 266264
10 280409 MUFFLER GASKET MX24
11 282926 CYLINDER COVER MX224
12 283983 ACC. CABLE STOP MX
13 283984
14 280144
15 280341
16 280488 BEARING ALB.M.BC2300 HT 261491
17 261492 ENGINE OIL SEAL MCV3100 ISCD12287
18 261386 OIL SEAL BC350 262197 ISCD12227
19 055185
20 261612
21 261032 PISTON MS062/M22/MX21
22 261158 PISTON RING MS062/M22/MX21
23 261036 PISTON PIN HT230D/M22/MX21
24 288520 PIN BEARING MX21
25 261576 PIN STOPPER BC230/M28/MX21
26 283879 CRANKSHAFT MX21
27 269168 CLUTCH COMPLETE BC2300/BC2600 248058
28 269169 CLUTCH SHOE BC2300 BC260
29 269173 CLUTCH SHOE SPRING BC2300 BC260
30 269647 CLUTCH FIXING SCREW BC2600
31 269175 CLUTCH WASHER MX21/24/27
32 261777 WAVED CLUTCH WASHER BC320
33 283386 CLUTCH CASING MX24
34 269831
35 283567
36 283397 FLYWHEEL MX21
37 283645 ELECTRONIC COIL COMPLETE MX21
38 283722
39 283646
40 283647
41 283178
42 283270
43 261076 FLYWHEEL KEY BKC5020RS
44 261417 FLYWHEEL NUT BC3021S
45 280381
66 288689 STARTER LABEL MX21
67 286122 CYLINDER HOUSING LABEL MX
68 284587 CYLINDER HOUSING LABEL MX
69 267561 CYLINDER HOUSING LABEL
70 288500 STARTER PLATE MX24E
61 280548 STARTER BUSHING HT2350 MX21 8712767
62 269423
63 287399 PLATE W/CRICK AND SPRING MX24/27
64 269833 STARTER SCREW MX22E M4X16
65 280489 STARTER SCREW MX22E M4X201
56 280495
57 283616
58 280497
59 280550
60 280547 STARTER WASHER MX21 MX24 MX27E
51 280419 STARTER CPL+PLATE CPL MX 563307
52 269999 STARTER MX21/MX24 288685*usa273093
53 280492 STARTER PULLEY BL3100 MX21
54 287421 STARTER SPRING BL3110 MX22 280493
55 280494 STARTER SCREW MX21 MX24 MX27E
46 261256 COIL FIXING SCREW BK520
47 262483 SPINNER MCV3100 *usa PR18Y
48 269722 GROUND CABLE BC/BKC5020
49 282880
50 264588 CLAMP KJBK50
Maruyama Decespugliatore MX21 Ricambi Pag.4
# Part Num. Description
1 283893 CARBURETOR MX21 BC2300RS KJBL21
2 8472046 MX21 CARBURETOR VALVE ONLY *59-132
3 262996
4 262991 CARBURETOR PRIMER BODY BC520
5 262992 BC350 PUMP COVER
6 261874 BC350/BC520 PRIMER KK21017AA013
7 283905 MCV3100 CE500 DIAPHRAGM 268501
8 262993 WA DIAPHRAGM GASKET +8102
9 262994 BC350 BC520 BC5021
10 282576 DIAPHRAGM GASKET MEMBRANE BKC5020 BC5021
11 262730
12 261871 O-RING JET *16-104 AE320 AE500
13 261876 SEEGER VALVE CARBURETOR BC350
14 261658 PAWL GAS VALVE BKC520
15 264682
16 261117 FUEL PIPE CLAMP
17 261864 CARBURETOR GASKET BC230/350
18 264691 O-RING HT230
19 266420 FILTER COMPLETE HT233/MX24 277926
20 277554 FILTER COVER HT230/MX21 264709
21 266433 FILTER BOX AHT235 MX21 MX22E
22 264695 FILTER ELEMENT BC350/BC2300RS
23 269834 CARBURETOR SCREW MX21 M5x60
24 280020 PAWL CAP VALVE MX
25 285728 TANK COMPLETE MX21
26 285664 ONLY TANK MX24
27 281564 CPL CAP BC5020 *usa 275306
28 269377 MEMBRANE CAP BC5020 *usa 287058
29 261696 BREATHER VALVE 122805 *usa 289352
30 265752 TANK TUBES KIT BC350
31 264031 TANK TUBES SET 261688
32 261115 TANK TUBES GASKET BC450
33 261690
34 263038
35 264653 TANK FILTER DRAG FILTER
36 261117 FUEL PIPE CLAMP
37 269828
38 281208
Maruyama Decespugliatore MX21 Ricambi Pag.5
# Part Num. Description
1 210418
2 022865
3 210181
4 219432
5 219433
6 232226 HEAD Z4 8x1.25SxF *usa 232226
6 118801753/0 HEAD Z4 8x1.25SxF ECO
7 233234
8 233326
9 233336
10 523264
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Maruyama websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Maruyama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Maruyama MX21
6 Items

Data sheet

SHIPPING IN:
ON DEMAND ONLY
MORE INFO:
[email protected]
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Maruyama MX21 Parts Diagram

Maruyama MX21 Parts Diagram

Download (1.14MB)

You might also like

Maruyama MX21 Filter Cover
Maruyama SKU: 277554
Maruyama MX21 Filter Cover
Maruyama MX21 Filter Cover Genuine spare part Maruyama, Filter Cover for Brushcutter Maruyama HT230 - MX21. Part for the following products: -  Brushcutter Maruyama HT230 - MX21 - Code : 277554
AVAILABLE €15.46
Details
Maruyama BC2300RS Air Filter
Maruyama SKU: 264695
Maruyama BC2300RS Air Filter
Maruyama BC2300RS Air Filter Genuine spare part Maruyama, Air Filter for Brushcutter Maruyama BC2300RS - MX21. Part for the following products: -  Maruyama BC2300RS -  Maruyama HT230D-R-01 -  Maruyama MX21...
Usually Ships in: 10/15 Business Days Approx. €7.31
Details
Comments (0)
