Fix Your Hedge Trimmer Maruyama HT230D-R-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Fix Your Hedge Trimmer Maruyama HT230D-R-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
No spare parts mapped to this page.
Check the other pages for available parts.
Shipping and delivery information will be available shortly.
Fix Your Hedge Trimmer Maruyama HT230D-R-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Maruyama Hedge Trimmer HT230D-R-01 Spare Parts Pag.1 |
||
| # | Part Num. | Description |
| 3 | 271602 | Handle Ass'y |
| 4 | 270468 | Rear Handle (R) |
| 5 | 270469 | Rear Handle (L) |
| 6 | 270397 | Handle Stay (R) |
| 7 | 270398 | Handle Stay (L) |
| 8 | 270470 | Lock Lever |
| 9 | 270400 | Spring |
| 10 | 270401 | Spring |
| 11 | 270402 | Spring |
| 13 | 271390 | Cable Comp. |
| 14 | 270472 | Lever |
| 15 | 270406 | Stop Lever |
| 16 | 270407 | Stopper |
| 18 | 271392 | Screw |
| 22 | 270424 | Spacer |
| 29 | 581912 | Guide Plate |
| 31 | 580767 | Bearing |
| 32 | 270423 | Bearing |
| 33 | 584666 | Pinion |
| 34 | 591443 | Crank Comp |
| 35 | 271466 | ConRod |
| 36 | 580777 | Snap Ring |
| 37 | 991931 | Screw |
| 39 | 991924 | Screw |
| 40 | 991919 | Plate,Rod Slide |
| 41 | 270758 | Felt |
| 43 | 270756 | Lower Case |
| 46 | 991913 | Washer |
| 47 | 991914 | Screw |
| 50 | 270120 | Bolt |
| 53 | 217677 | Cover of Blade |
| 54 | 270021 | Clutch Drum |
| 55 | 270760 | Upper Case |
| 56 | 581910 | Bolt |
| 57 | 270241 | Front Handle |
| 58 | 991912 | Screw |
| 59 | 270759 | Reinforcing Plate |
| 61 | 270757 | Plate |
| Pag.3 | ||
| 2 | 264981 | Cylinder |
| 3 | 263770 | Gasket |
| 4 | 267290 | Cap Screw |
| 5 | 265802 | Insulator |
| 6 | 265794 | Air Duct |
| 7 | 261171 | Gasket |
| 12 | 261607 | Cap Screw |
| 14 | 280747 | Top Cover |
| 19 | 054676 | Snap Ring |
| 20 | 261246 | Cap Screw |
| 21 | 283265 | Piston |
| 22 | 263789 | Piston Ring |
| 23 | 281185 | Piston Pin |
| 24 | 261037 | Bearing,Needle |
| 25 | 261576 | Clip,Piston |
| 26 | 264643 | Shaft Comp |
| 28 | 261607 | Cap Screw |
| 29 | 280404 | Clutch Ass'y 264959 |
| 32 | 280570 | Spring |
| 34 | 261250 | Cap Screw |
| 35 | 267384 | Magneto Ass'y |
| 37 | 267400 | Ignition Coil Ass'y |
| 42 | 261075 | Connector |
| 43 | 261072 | Cap |
| 45 | 261076 | Woodruff Key |
| 50 | 267492 | Lead |
| 51 | 261202 | Grommet |
| 52 | 265175 | Fuel Tank Ass'y |
| 53 | 264545 | Fuel Tank |
| 54 | 265176 | Tank Cap Ass'y |
| 56 | 269417 | Gasket |
| 58 | 265929 | Fuel Pipe Ass'y |
| 59 | 265869 | Grommet |
| 62 | 264653 | Filter Ass'y |
| 63 | 261117 | Clip |
| 64 | 261117 | Clip |
| 65 | 263824 | Pad |
| 66 | 264318 | Pad |
| 69 | 261181 | Bearing |
| Pag.4 | ||
| 1 | 281489 | Carburetor Ass'y |
| 4 | 282576 | Gasket |
| 5 | 262994 | Diaphragm,Fuel Pump |
| 7 | 262993 | Gasket |
| 8 | 283905 | Diaphragm, Meterring |
| 9 | 262991 | Purge Body |
| 10 | 261874 | Primer Bulb |
| 11 | 262992 | Cover Plate |
| 14 | 261876 | E-Ring |
| 15 | 261658 | Swivel |
| 18 | 261864 | Gasket |
| 19 | 265973 | Baffle Plate |
| 21 | 265575 | Cleaner Ass'y |
| 22 | 265576 | Housing |
| 23 | 264695 | Filter |
| 24 | 264709 | Cover |
| 26 | 264534 | Recoil Starter Ass'y |
| 27 | 264083 | Starter Ass'y |
| 29 | 261725 | Starter Grip |
| 31 | 261622 | Spiral Spring |
| 32 | 261621 | Pulley |
| 34 | 264085 | Starter Pawl Ass'y |
| 35 | 261630 | Pawl |
| 36 | 261631 | Return Spring |
| 38 | 020299 | E-Ring |
