Makita

Makita Spare Parts for Angle Grinder 9564HZ

SKU: Makita 9564HZ
€38.65
VAT included

Makita Spare Parts for Angle Grinder 9564HZ

We have the original Spares MAKITA for Angle Grinder 9564HZ the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Angle Grinder 9564HZ. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
Makita Spare Parts for Angle Grinder 9564HZ
  • Makita Spare Parts for Angle Grinder 9564HZ
  • Makita Spare Parts for Angle Grinder 9564HZ
Makita

Makita Spare Parts for Angle Grinder 9564HZ

SKU: Makita 9564HZ Condition: New
€38.65
VAT included

Makita Spare Parts for Angle Grinder 9564HZ

We have the original Spares MAKITA for Angle Grinder 9564HZ the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Angle Grinder 9564HZ. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
settings 53 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
53 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 418067-8 PLUG PLUG FOR SG1250 €1.96
2
 photo_cameraImage coming soon 233072-2 COMPRESSION SPRING 8 X 9541 €1.40
3
 photo_cameraImage coming soon 153488-4 RECEIVER INPUT. CPL FOR SG1250 €32.73
4
 photo_cameraImage coming soon 931303-0 HEXAGONAL NUT M6 €1.36
5
 photo_cameraImage coming soon 253077-6 WASHER P. 6 4300 / 01BV €1.40
6
 photo_cameraImage coming soon 226794-1 GEAR 11 X 9561CV €17.61
7
 photo_cameraImage coming soon 233901-9 STOP RING 12 X GD0800C €4.05
8
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
9
 photo_cameraImage coming soon 211142-7 BEARING 6001LLB X GD0800C €11.39
10
 Flat Washer 12 for Angle Grinder Makita GA4540 253084-9 Flat Washer 12 for Angle Grinder Makita GA4540 €1.39
11
 photo_cameraImage coming soon 317359-1 COVER BOX INPUT. X 9561 €19.04
12
 photo_cameraImage coming soon 240033-5 FAN 57 X 9561CV €8.77
13
 photo_cameraImage coming soon 515234-7 ARMATURE 9564 €71.46
14
 Armature Washer for Angle Grinders Makita 9561-9562CV 681656-4 Armature Washer for Angle Grinders Makita 9561-9562CV €1.50
15
 photo_cameraImage coming soon 253823-7 ROND. FLAT 7 X JS1600 €2.40
16
 photo_cameraImage coming soon 210027-4 BEARING 627DDW X 9561CV €6.30
17
 photo_cameraImage coming soon 421738-8 RING LABYRINTH 22 X 9561CV €14.23
21
 photo_cameraImage coming soon 413076-2 VANE X GD0800C €2.90
22
 photo_cameraImage coming soon 266258-3 SCREW 4 X 70 X 9564 €2.34
23
 photo_cameraImage coming soon 344871-8 RETAINING X GD0800C €3.24
24
 photo_cameraImage coming soon 417237-6 COVER INSULATION FOR GD0800C €2.17
25
 photo_cameraImage coming soon 626564-2 STATOR FOR 9564H €27.44
26
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
27
 photo_cameraImage coming soon 687052-4 CLAMP cable clamp X 6408 €5.40
28
 photo_cameraImage coming soon 632945-0 LOCK SWITCH X GD0800C €17.57
30
 Power Cord Protection for Angle Grinder Makita 115-125 mm 682559-5 Power Cord Protection for Angle Grinder Makita 115-125 mm €2.07
31
 Switch Makita Makita ST115A-40 651418-4 Switch Makita Makita ST115A-40 €10.80
32
 photo_cameraImage coming soon 687113-0 COVER X GD0800C €2.17
34
 photo_cameraImage coming soon 417183-3 COVER POST. X 9564 €14.31
35
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
37
 photo_cameraImage coming soon 417186-7 LEVER SWITCH X 9564 €3.28
38
 photo_cameraImage coming soon 233071-4 SPRING COMPRESSION 4 X 9541 €2.34
39
 photo_cameraImage coming soon 643760-7 BRUSH HOLDER FOR BO6040 €6.31
40
 photo_cameraImage coming soon 453276-2 HOUSING MOTOR €18.98
41
 photo_cameraImage coming soon 417813-6 CONTROL SWITCH X GD0800C €1.91
42
 Carbon Brushes CB-325 for Angle Grinder Makita 9554NB 194074-2 Carbon Brushes CB-325 for Angle Grinder Makita 9554NB €4.19
43
 photo_cameraImage coming soon 643760-7 BRUSH HOLDER FOR BO6040 €6.31
44
 photo_cameraImage coming soon 266256-7 SCREW 3 X 10 X GD0800C €2.17
45
 photo_cameraImage coming soon 862749-8 LABEL MOD. 9564H €1.79
46
 Upper Flange for Angle Grinders Makita 115-125 mm 224554-5 Upper Flange for Angle Grinders Makita 115-125 mm €8.23
47
 Inner Flange for Angle Grinder Makita 115-125 mm 224415-9 Inner Flange for Angle Grinder Makita 115-125 mm €8.23
49
 photo_cameraImage coming soon 265180-1 SCREW M5x16 €1.40
50
 photo_cameraImage coming soon 324035-0 ALBERINO X 9561CV €16.65
51
 photo_cameraImage coming soon 415300-9 DISTANCE X 9541 €2.69
52
 photo_cameraImage coming soon 265490-6 SCREW M4 X 16 X 9561CV €1.40
53
 photo_cameraImage coming soon 318334-0 BEARING BOX €24.34
54
 Bearing 6201DD NSK for Powertools Makita 211129-9 Bearing 6201DD NSK for Powertools Makita €8.41
55
 photo_cameraImage coming soon 285841-7 RETAINING BEARING X 9566CV €2.69
56
 photo_cameraImage coming soon 213673-2 RING 52 X 9561CV €2.08
57
 photo_cameraImage coming soon 227427-1 GEAR 38 €16.26
58
 photo_cameraImage coming soon 256459-1 PIN X 9561CV €2.08
59
 photo_cameraImage coming soon 213048-5 RING 6 X 9561CV €2.01
60
 photo_cameraImage coming soon 266257-5 SCREW M4 X 28 X 9561CV €2.01
61
 photo_cameraImage coming soon 213009-5 RING 4 €1.40

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Angle Grinder 9564HZ

We have the original Spares MAKITA for Angle Grinder 9564HZ the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Angle Grinder 9564HZ. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita 9564HZ

Angle Grinder 9564HZ
# Part Num. Description
1 418067-8 PLUG PLUG FOR SG1250
2 233072-2 SPRING COMPRESSION 8 X 9541
3 153488-4 RECEIVER INPUT. CPL FOR SG1250
4 931303-0 HEX NUT M6
5 253077-6 ROND.P. 6 4300 / 01BV
6 226794-1 GEAR 11 X 9561CV
7 233901-9 RING OF ARREST 12 X GD0800C
8 961052-5 RETAINING RING S12
9 211142-7 BEARING 6001LLB X GD0800C
10 253084-9 ROND.P.12 8419B / 5016NB
11 317359-1 COVER BOX INPUT. X 9561
12 240033-5 FAN 57 X 9561CV
13 515234-7 ARMATURE 9564
14 681656-4 INSULATOR X GD0810C
15 253823-7 ROND. FLAT 7 X JS1600
16 210027-4 BEARING 627DDW X 9561CV
17 421738-8 RING LABYRINTH 22 X 9561CV
21 413076-2 BAFFLEX GD0800C
22 266258-3 SCREW 4 X 70 X 9564
23 344871-8 RETAINING X GD0800C
24 417237-6 COVER INSULATION X GD0800C
25 626564-2 STATOR FOR 9564H
26 265995-6 SCREW M4X18 X 6408 / 6221DW
27 687052-4 CLAMP ties X 6408
28 632945-0 LOCK SWITCH X GD0800C
30 682559-5 SAVE CABLE X 6822
31 651418-4 SWITCH ST115A-40 X 9541
32 687113-0 COVER X GD0800C
34 417183-3 COVER POST. X 9564
35 265995-6 SCREW M4X18 X 6408 / 6221DW
37 417186-7 LEVER SWITCH X 9564
38 233071-4 SPRING COMPRESSION 4 X 9541
39 643760-7 BRUSH HOLDER X BO6040
40 453276-2 HOUSING MOTOR
41 417813-6 CONTROL SWITCH X GD0800CP02
42 194074-2 CARBON BRUSHES CB-325 X 9554NB
43 643760-7 BRUSH HOLDER X BO6040
44 266256-7 SCREW 3 X 10 X GD0800C
45 862749-8 LABEL MOD. 9564H
46 224554-5 EXTERNAL FLANGE 14-45 X 9541
47 224415-9 FLANGE INTERNAL 42 GA95010
48 122894-4 HEADSET WHEEL ATT.RAP.9564C
49 265180-1 SCREW M5X16
50 324035-0 ALBERINO X 9561CV
51 415300-9 DISTANCE X 9541
52 265490-6 SCREW M4 X 16 X 9561CV
53 318334-0 BEARING BOX
54 211129-9 BALL BEARING NSK 6201DD
55 285841-7 RETAINING BEARING X 9566CV
56 213673-2 RING 52 X 9561CV
57 227427-1 GEAR 38
58 256459-1 PIN X 9561CV
59 213048-5 RING 6 X 9561CV
60 266257-5 SCREW M4 X 28 X 9561CV
61 213009-5 RING 4

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
