Makita Spare Parts for Angle Grinder GA4530R

SKU: Makita GA4530R
€16.61
VAT included

Makita Spare Parts for Angle Grinder GA4530R

Original spare parts, sourced from the manufacturer, for to make maintenance or repair damaged parts for Angle Grinder GA4530R with efficient and professional After Sales Service.
Makita Spare Parts for Angle Grinder GA4530R
  • Makita Spare Parts for Angle Grinder GA4530R
  • Makita Spare Parts for Angle Grinder GA4530R

Makita Spare Parts for Angle Grinder GA4530R

SKU: Makita GA4530R Condition: New
€16.61
VAT included

Makita Spare Parts for Angle Grinder GA4530R

Original spare parts, sourced from the manufacturer, for to make maintenance or repair damaged parts for Angle Grinder GA4530R with efficient and professional After Sales Service.
settings 47 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

45 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
220 240 V Field for Angle Grinder Makita GA4530R 633903-9 220 240 V Field for Angle Grinder Makita GA4530R €25.26
2
Baffle for Angle Grinder Makita GA4530 450796-7 Baffle for Angle Grinder Makita GA4530 €1.50
3
Ball Bearing Protection for Angle Grinder Makita GA4530 421868-5 Ball Bearing Protection for Angle Grinder Makita GA4530 €2.00
4
Ball Bearing 607 LLB for Angle Grinder Makita 9554NB 210034-7 Ball Bearing 607 LLB for Angle Grinder Makita 9554NB €3.34
5
Armature Washer for Angle Grinder Makita GA4530 681636-0 Armature Washer for Angle Grinder Makita GA4530 €2.34
6
Armature for Angle Grinder Makita GA4530-4534-5034 517649-4 Armature for Angle Grinder Makita GA4530-4534-5034 €28.43
8
Conveyor for Angle Grinder Makita GA4530 413126-3 Conveyor for Angle Grinder Makita GA4530 €1.50
9
O-Ring 26 for Powertools Makita 213445-5 O-Ring 26 for Powertools Makita €1.95
10
Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €9.01
11
Pinion Gear for Makita Angle Grinder GA4530 227545-5 Pinion Gear for Makita Angle Grinder GA4530 €6.55
12
Armature Nut M6 for Angle Grinder Makita 9554NB 252186-8 Armature Nut M6 for Angle Grinder Makita 9554NB €1.47
13
Button Pin Disc Block for Angle Grinder Makita 9554NB 417771-6 Button Pin Disc Block for Angle Grinder Makita 9554NB €3.18
14
Pin Disc Block Sping for Angle Grinder Makita GA4530 234057-1 Pin Disc Block Sping for Angle Grinder Makita GA4530 €1.83
15
photo_cameraImage coming soon 266324-6 SCREW M 4 X 22 X MT601 €2.95
16
photo_cameraImage coming soon 213032-0 RING 4 X GA4530 €2.34
17
Pin Disc Block for Angle Grinder Makita GA4530 256510-7 Pin Disc Block for Angle Grinder Makita GA4530 €2.51
18
Gears Box for Angle Grinder Makita GA4530 318335-8 Gears Box for Angle Grinder Makita GA4530 €14.96
19
Rubber Pin for Hammer SDS-Max Makita HR4000C 263002-9 Rubber Pin for Hammer SDS-Max Makita HR4000C €1.47
20
Bearing 696ZZ FOR Angle Grinder Makita GA4530 210033-9 Bearing 696ZZ FOR Angle Grinder Makita GA4530 €3.35
21
Ring 11 for Angle Grinder Makita GA4530 233950-6 Ring 11 for Angle Grinder Makita GA4530 €1.43
22
Retaining Ring R26 for Angle Grinder and Milling Machines Makita 962105-3 Retaining Ring R26 for Angle Grinder and Milling Machines Makita €1.47
23
Crown Gear for Makita Angle Grinder GA4530 227546-3 Crown Gear for Makita Angle Grinder GA4530 €11.60
24
Retaining Ring R32 for Powertools Makita 962151-6 Retaining Ring R32 for Powertools Makita €1.43
25
Bearing 6201DD NSK for Powertools Makita 211129-9 Bearing 6201DD NSK for Powertools Makita €8.41
26
Flat Washer 12 for Rotary Hammer Makita HR4000C 267113-2 Flat Washer 12 for Rotary Hammer Makita HR4000C €2.51
27
O-Ring 42 for Angle Grinder and Milling Machines Makita 213561-3 O-Ring 42 for Angle Grinder and Milling Machines Makita €1.30
28
Bearings Box for Angle Grinder Makita GA4530 318336-6 Bearings Box for Angle Grinder Makita GA4530 €11.60
29
photo_cameraImage coming soon 265099-4 SCREW M4x14 FOR 9554NB €1.43
30
photo_cameraImage coming soon 345464-4 RING FOR DUST 9554NB €1.40
32
Spindle for Angle Grinder Makita GA4530 324954-0 Spindle for Angle Grinder Makita GA4530 €8.23
34
Disc Protection for Angle Grinder Makita 9554NB 123098-1 Disc Protection for Angle Grinder Makita 9554NB €16.64
35
Inner Flange for Angle Grinder Makita 115-125 mm 224415-9 Inner Flange for Angle Grinder Makita 115-125 mm €8.23
36
Upper Flange for Angle Grinders Makita 115-125 mm 224554-5 Upper Flange for Angle Grinders Makita 115-125 mm €8.23
37
photo_cameraImage coming soon 266325-4 SCREW M 4 TO 70 PER MT952 €1.36
40
Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 643839-4 Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 €3.18
41
Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 194722-3 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 €5.37
43
photo_cameraImage coming soon 650769-2 SWITCH €21.54
44
Strain Relief for Angle Grinder Makita GA4530 687681-3 Strain Relief for Angle Grinder Makita GA4530 €2.51
45
Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 €1.47
46
photo_cameraImage coming soon 638739-1 CAPACITOR X JS1000 €3.75
47
Power Cord Protection for Angle Grinder Makita 115-125 mm 682559-5 Power Cord Protection for Angle Grinder Makita 115-125 mm €2.07
50
photo_cameraImage coming soon 456380-6 HOUSING MOTOR €9.57
52
Lever Switch Spring for Angle Grinder Makita 9554NB 233121-5 Lever Switch Spring for Angle Grinder Makita 9554NB €1.30
53
Switch Lever for Angle Grinder Makita GA4530 450797-5 Switch Lever for Angle Grinder Makita GA4530 €6.55
56
photo_cameraImage coming soon 266492-5 SCREW M4X25-9527PB 9528PB €2.47

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Angle Grinder GA4530R

Original spare parts, sourced from the manufacturer, for to make maintenance or repair damaged parts for Angle Grinder GA4530R with efficient and professional After Sales Service.

In the following table, look for the model of Angle Grinder and the respective parts of the code.
Makita GA4530R

Angle Grinder GA4530R
# Part Num. Description
1 633903-9 FIELD ASSY 220-240V
2 450796-7 BAFFLE GA4530
3 421868-5 RING RUBBER X 9554NB
4 210034-7 BEARING 607LLB X 9554NB
5 681636-0 INSULATING WASHER
6 517649-4 ARMATURE FOR GA4530
7 240139-9 FAN 56
8 413126-3 CONVEYOR FOR GA4530
9 213445-5 RING 26 X 9554NB
10 211092-6 BALL BEARING 629DD
11 227545-5 SPIRAL BEVEL GEAR 10 GA4530
12 252186-8 NUT M6 X 9554NB
13 417771-6 BUTTON X 9554NB
14 234057-1 SPRING 6 GA5021C
15 266324-6 SCREW M 4 X 22 X MT601
16 213032-0 RING 4 X GA4530
17 256510-7 SHOULDER PIN 4 GA4530
18 318335-8 GEAR CASE GA4530
19 263002-9 RUBBER PIN 4
20 210033-9 BALL BEARING 696ZZ X 2107FK
21 233950-6 RING 11 X GA5010
22 962105-3 RETAINING RING R26
23 227546-3 37 GEAR FOR GA4530
24 962151-6 RETAINING RING R32
25 211129-9 BALL BEARING NSK 6201DD
26 267113-2 FLAT WASHER 12 X 8412DWH
27 213561-3 RING 42 FOR GA4530
28 318336-6 BEARING HAUSING GA4530
29 265099-4 SCREW M4 X 14 X 9554NB
30 345464-4 RING X 9554NB
32 324954-0 SHAFT GA4530
34 123098-1 DISC COVER 115AK
35 224415-9 RECIEVE WASHER 42 GA95010
36 224554-5 CLAMP WASHER 14-45 X 9541
37 266325-4 SCREW M 4 X 70 X MT952
40 643839-4 BRUSH HOLDER GA4530
41 194722-3 CARBON BRUSCHE SET CB 459 X GA4530
43 650769-2 SWITCH
44 687681-3 CABLE CLAMP GA4530
45 266326-2 SCREW 4x18 X MT601
46 638739-1 CAPACITOR
47 682559-5 SAVE CABLE X 6822
49 418016-5 KEY SWITCH X MT952
50 456380-6 HOUSING MOTOR
51 643839-4 BRUSH HOLDER GA4530
52 233121-5 COMPRESSION SPRING 4 X 9554NB
53 450797-5 SWITCH LEVER GA4530
55 266326-2 SCREW 4x18 X MT601
56 266492-5 SCREW M4x25-9527PB 9528PB
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita GA4530R
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita GA4530R

Diagram Makita GA4530R

Download (357.53KB)
