Makita Spare Parts for Hammer HM1303

SKU: Makita HM1303
€146.11
VAT included

Makita Spare Parts for Demolition Hammer HM1303

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Demolition Hammer HM1303.
Makita Spare Parts for Hammer HM1303
  • Makita Spare Parts for Hammer HM1303
  • Makita Spare Parts for Hammer HM1303
Makita

Makita Spare Parts for Hammer HM1303

SKU: Makita HM1303 Condition: New
€146.11
VAT included

Makita Spare Parts for Demolition Hammer HM1303

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Demolition Hammer HM1303.
settings 95 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
95 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Switch for Polisher Makita SA7000 651922-3 Switch for Polisher Makita SA7000 €32.80
2
 photo_cameraImage coming soon 421529-7 SEAT SWITCH X HM1303 €6.06
3
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
4
 photo_cameraImage coming soon 182844-1 HANDLE CPL.X HM1303 €50.29
5
 photo_cameraImage coming soon 415805-9 BUTTON LOCK X HM1303 €2.69
6
 photo_cameraImage coming soon 415120-1 LEVER SWITCH X HR2400 €4.43
7
 photo_cameraImage coming soon 231457-6 SPRING 3 X UH4510A / 6310A €1.40
8
 photo_cameraImage coming soon 415806-7 PLATE BLOCK X HM1303 €2.69
9
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
10
 photo_cameraImage coming soon 687063-9 CABLE TIE X 4304T €3.18
11
 Cord Guard JN1601 for Angle Grinder Makita 9015B 682540-6 Cord Guard JN1601 for Angle Grinder Makita 9015B €2.72
14
 photo_cameraImage coming soon 922361-7 SCREW M6X40 X HM1303 €1.40
15
 photo_cameraImage coming soon 941152-7 FLAT WASHER 6 €1.46
16
 photo_cameraImage coming soon 941152-7 FLAT WASHER 6 €1.46
17
 photo_cameraImage coming soon 922376-4 SCREW M6x55 €1.86
18
 photo_cameraImage coming soon 344273-8 BAFFLE X HM1303 €4.72
19
 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 211228-7 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 €8.63
20
 photo_cameraImage coming soon 241128-7 FAN 92 X HM1303 €11.59
21
 photo_cameraImage coming soon 516703-1 ARMATURE 220V X HM1303 €158.19
22
 Armature Washer for Demolition Hammer Makita HR3850K 681646-7 Armature Washer for Demolition Hammer Makita HR3850K €8.71
23
 photo_cameraImage coming soon 211087-9 BALL BEARING 6200DDW €8.75
24
 photo_cameraImage coming soon 253794-8 FLAT WASHER 18 6905B / 2708 €2.08
25
 photo_cameraImage coming soon 626043-0 STATOR X HM1303 €56.20
26
 photo_cameraImage coming soon 159904-4 CASING MOTOR CPL X HM1303 €75.26
27
 Gasket 30 O-R for Cylinder Hammers Makita HR4001-2-3-10-11C 213406-5 Gasket 30 O-R for Cylinder Hammers Makita HR4001-2-3-10-11C €1.35
28
 photo_cameraImage coming soon 284069-4 COVER X HM1303 €8.92
29
 photo_cameraImage coming soon 266021-4 SCREW 5X20 €3.27
30
 photo_cameraImage coming soon 922376-4 SCREW M6x55 €1.86
31
 photo_cameraImage coming soon 941151-9 WASHER 6 X HM1303 €3.66
32
 photo_cameraImage coming soon 911221-8 SCREW M5X16 X HM1303 €1.40
33
 photo_cameraImage coming soon 344384-9 PLATE X HM1303 €2.44
34
 Rubber Ring 6 for Hammer Makita HM1303 262049-0 Rubber Ring 6 for Hammer Makita HM1303 €1.46
35
 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 643710-2 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 €2.01
36
 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders 191957-7 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders €9.15
37
 photo_cameraImage coming soon 265428-1 SCREW M5X65 X HM1303 €2.69
38
 photo_cameraImage coming soon 322894-6 CRANKSHAFT X HM1303 €56.20
39
 O-Ring 35 for Demolition Hammers Makita HR 4501-10-11C 213460-9 O-Ring 35 for Demolition Hammers Makita HR 4501-10-11C €3.29
40
 photo_cameraImage coming soon 256111-1 PIN 6 €3.13
41
 photo_cameraImage coming soon 331212-7 SEAL €6.63
42
 photo_cameraImage coming soon 211104-5 BEARING 6001 X5143R €12.69
43
 photo_cameraImage coming soon 226449-8 GEAR 34 X HM1303 €68.84
44
 photo_cameraImage coming soon 211109-5 BALL BEARING 6201 X HM1303 €7.58
45
 photo_cameraImage coming soon 316732-2 GEAR HOUSING COVER X HM1303 €56.20
47
 photo_cameraImage coming soon 922371-4 HEX SCREW M6x50 €1.42
48
 photo_cameraImage coming soon 266140-6 BOLT M10X113 X HM1303 €8.92
49
 photo_cameraImage coming soon 416228-4 BASE HANDLE X HM1303 €3.13
50
 photo_cameraImage coming soon 416228-4 BASE HANDLE X HM1303 €3.13
51
 photo_cameraImage coming soon 252633-9 KNOB X HM1500 €12.69
52
 photo_cameraImage coming soon 253194-2 WASHER 5 X HM1303 €1.40
53
 photo_cameraImage coming soon 922221-3 Screw M5X16 X HM1303 €3.41
54
 photo_cameraImage coming soon 322986-1 TOOL RETAINER X HM1303 €29.13
55
 photo_cameraImage coming soon 421567-9 DUST COVER X HM1303 €15.40 Not available for order
56
 photo_cameraImage coming soon 322987-9 RETAINING RING X HM1303 €5.30
57
 photo_cameraImage coming soon 233142-7 COMPRESSION PRING. 14 X HM1303 €1.58
58
 photo_cameraImage coming soon 266010-9 BOLT M8x30 X HM1303 €2.08
59
 photo_cameraImage coming soon 322875-0 TOOL HOLDER HM1303 €158.19
60
 photo_cameraImage coming soon 322874-2 GUIDE RING X HM1303 €11.59
61
 photo_cameraImage coming soon 213707-1 SEAL 65 X HR1800 €3.84
62
 photo_cameraImage coming soon 322873-4 IMPACT BOLT X HM1303 €19.78
63
 photo_cameraImage coming soon 952257-8 PIN 3.0-20 HR5000K €1.29
65
 photo_cameraImage coming soon 345233-3 SIDE HANDLE HM1303 €15.40
66
 photo_cameraImage coming soon 211214-8 BALL BEARING 6302 €8.50
67
 photo_cameraImage coming soon 226450-3 GEAR 57 X HM1303 €75.83
68
 photo_cameraImage coming soon 257196-0 RING 25 X HM1303 €3.84
69
 photo_cameraImage coming soon 159806-4 GEAR HOUSING CPL X HM1303 €114.34
70
 photo_cameraImage coming soon 421731-2 O-RING 112 X HM1303 €3.48
71
 photo_cameraImage coming soon 211373-8 BALL BEARING 6205 €14.77
72
 photo_cameraImage coming soon 316730-6 HEAD BEARING X HM1303 €12.69
73
 photo_cameraImage coming soon 265366-7 BOLT M5 X 22 X HM1500 €3.13
74
 photo_cameraImage coming soon 254001-2 KEY CRESCENT 4 €1.44
75
 photo_cameraImage coming soon 256238-7 PIN 12 X HM1303 €5.67
76
 photo_cameraImage coming soon 322919-6 CYLINDER HM1303 €126.74
77
 photo_cameraImage coming soon 213519-2 PISTON RING OR 36 HM1303 €6.06
78
 photo_cameraImage coming soon 322871-8 PISTON X HM1303 €69.54
79
 photo_cameraImage coming soon 213520-7 PISTON RING Y 36 HM1303 €7.96
80
 photo_cameraImage coming soon 322812-4 ROD HM1303 €40.95
81
 photo_cameraImage coming soon 212260-4 ROLLER BEARING 1716 €32.82
82
 photo_cameraImage coming soon 321825-2 REDUCTION ROD XHM1300 €13.16
83
 photo_cameraImage coming soon 942251-8 SPRING WASHER 10 €1.33
84
 photo_cameraImage coming soon 922557-0 BOLT M10x35 €1.98
86
 photo_cameraImage coming soon 256111-1 PIN 6 €3.13
87
 photo_cameraImage coming soon 316832-8 CRANK HOUSING HM1303 €126.74
88
 photo_cameraImage coming soon 442009-0 SEAL HOUSING €2.48
89
 photo_cameraImage coming soon 341397-1 COVER HOUSING €2.48
90
 photo_cameraImage coming soon 911211-1 SCREW M5X12 €1.36
91
 photo_cameraImage coming soon 213707-1 SEAL 65 X HR1800 €3.84
92
 photo_cameraImage coming soon 265367-5 BOLT M 8 X 40 X HM 1500 €2.91
93
 photo_cameraImage coming soon 316831-0 CYLINDER CASE X HM1303 €142.94
94
 photo_cameraImage coming soon 262068-6 RING 59 X HM1303 €15.40
95
 photo_cameraImage coming soon 267146-7 WASHER 58 HM1303 €6.82
96
 photo_cameraImage coming soon 322815-8 RING X HM1303 €84.03
97
 photo_cameraImage coming soon 262536-9 RUBBER 64 HM1303 €4.72
98
 photo_cameraImage coming soon 213707-1 SEAL 65 X HR1800 €3.84
99
 photo_cameraImage coming soon 213390-4 O-RING 25 X HM1303 €4.06
100
 photo_cameraImage coming soon 322872-6 SEAL HOLDER X HM1303 €36.56
101
 photo_cameraImage coming soon 213383-1 XRING 25 NEW HR3520 €25.08
102
 photo_cameraImage coming soon 262072-5 URETHANE RING 49 HM1303 €13.49
103
 Noise Suppressor for Cut-Off Machine Makita 2412N 645006-7 Noise Suppressor for Cut-Off Machine Makita 2412N €2.14
104
 photo_cameraImage coming soon 643711-0 CARBON BRUSHE HOLDER HM1500-HM1303 €18.98
105
 photo_cameraImage coming soon 654020-2 RING TERMINAL 94 €1.40
999
 photo_cameraImage coming soon 193393-3 SERVICE KIT HM1303 €45.71

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Demolition Hammer HM1303

We are MAKITA original spare parts Worldwide Dealers, at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Demolition Hammer HM1303.


In the following table, look for the model of Hammer and the respective parts of the code.
Makita HM1303

Demolition Hammer HM1303
# Part Num. Description
1 651922-3 TG71B SWITCH
2 421529-7 SEAT SWITCH X HM1303
3 265995-6 SCREW M4X18 X 6408 / 6221DW
4 182844-1 HANDLE CPL.X HM1303
5 415805-9 BUTTON LOCK X HM1303
6 415120-1 LEVER SWITCH X HR2400
7 231457-6 SPRING 3 X UH4510A / 6310A
8 415806-7 PLATE BLOCK X HM1303
9 265995-6 SCREW M4X18 X 6408 / 6221DW
10 687063-9 CABLE CLAMP X 4304T
11 682540-6 CORD GUARD JN1601
14 922361-7 SCREW M6x40 X HM1303
15 941152-7 FLAT WASHER 6
16 941152-7 FLAT WASHER 6
17 922376-4 SCREW M6x55
18 344273-8 BAFFLE X HM1303
19 211228-7 BALL BEARING 6202DD
20 241128-7 FAN 92 X HM1303
21 516703-1 ARMATURE 220V X HM1303
22 681646-7 WASHER ISOLATED HM1200 / 3612BR
23 211087-9 BALL BEARING NSK 6200DDW
24 253794-8 FLAT WASHER 18 6905B / 2708
25 626043-0 STATOR X HM1303
26 159904-4 CASING MOTOR CPL X HM1303
27 213406-5 SEAL 30 58NB / SB / HM1200
28 284069-4 COVER X HM1303
29 266021-4 5X20 SCREW
30 922376-4 SCREW M6x55
31 941151-9 WASHER 6 X HM1303
32 911221-8 SCREW M5X16 X HM1303
33 344384-9 PLATE X HM1303
34 262049-0 RUBBER RING 6 X N500
35 643710-2 BRUSH HOLDER CAP X HM1500
36 191957-7 CARBON BRUSHE SET CB-204 (201.202)
37 265428-1 SCREW M5X65 X HM1303
38 322894-6 CRANKSHAFT X HM1303
39 213460-9 O-RING 35 HK / HR1800 / HM12
40 256111-1 PIN 6
41 331212-7 SEAL X HM1400
42 211104-5 BALL BEARING 6001 X5143R
43 226449-8 GEAR 34 X HM1303
44 211109-5 BALL BEARING 6201 X HM1303
45 316732-2 GEAR HOUSING COVER X HM1303
47 922371-4 HEX SCREW M6x50
48 266140-6 BOLT M10X113 X HM1303
49 416228-4 BASE HANDLE X HM1303
50 416228-4 BASE HANDLE X HM1303
51 252633-9 KNOB X HM1500
52 253194-2 WASHER 5 X HM1303
53 922221-3 SCREW M5X16 X HM1303
54 322986-1 TOOL RETAINER X HM1303
55 421567-9 DUST COVER X HM1303
56 322987-9 RETAINING RING X HM1303
57 233142-7 COMPRESSION PRING. 14 X HM1303
58 266010-9 BOLT M8X30 X HM1303
59 322875-0 TOOL HOLDER HM1303
60 322874-2 GUIDE RING X HM1303
61 213707-1 O-RING 65 X HR1800
62 322873-4 IMPACT BOLT X HM1303
63 952257-8 PIN 3.0-20 HR5000K
65 345233-3 SIDE HANDLE HM1303
66 211214-8 BALL BEARING 6302
67 226450-3 GEAR 57 X HM1303
68 257196-0 RING 25 X HM1303
69 159806-4 GEAR HOUSING CPL X HM1303
70 421731-2 O-RING 112 X HM1303
71 211373-8 BALL BEARING 6205 X HM1303
72 316730-6 HEAD BEARING X HM1303
73 265366-7 BOLT M5 X 22 X HM1500
74 254001-2 WOODRUFF KEY 4
75 256238-7 PIN 12 X HM1303
76 322919-6 CYLINDER HM1303
77 213519-2 PISTON RING OR 36 HM1303
78 322871-8 PISTON X HM1303
79 213520-7 PISTON RING Y 36 HM1303
80 322812-4 ROD HM1303
81 212260-4 ROLLER BEARING 1716
82 321825-2 REDUCTION ROD XHM1300
83 942251-8 WASHER 10
84 922557-0 BOLT M10x35
86 256111-1 PIN 6
87 316832-8 CRANK HOUSING HM1303
88 442009-0 MOTOR HOUSING PACKING HM1303B
89 341397-1 MOTOR HOUSING COVER HM1303B HM1300
90 911211-1 SCREW M5x12
91 213707-1 O-RING 65 X HR1800
92 265367-5 BOLT M 8 X 40 X HM 1500
93 316831-0 CYLINDER CASE X HM1303
94 262068-6 RING 59 X HM1303
95 267146-7 WASHER 58 HM1303
96 322815-8 RING X HM1303
97 262536-9 RUBBER 64 HM1303
98 213707-1 O-RING 65 X HR1800
99 213390-4 O-RING 25 X HM1303
100 322872-6 SEAL HOLDER X HM1303
101 213383-1 XRING 25 NEW HR3520
102 262072-5 URETHANE RING 49 HM1303
103 645006-7 NOISE SUPPRESSOR X LS1013
104 643711-0 CARBON BRUSHE HOLDER HM1500-HM1303
105 654020-2 RING TERMINAL 94
999 193393-3 SERVICE KIT HM1303
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HM1303
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita HM1303

Diagram Makita HM1303

Download (328.97KB)

You might also like

Armature Washer for Demolition Hammer Makita HR3850K
Makita SKU: 681646-7
Armature Washer for Demolition Hammer Makita HR3850K
Armature Washer for Demolition Hammer Makita HR3850K Genuine spare part Makita, Armature Protection Washer for Demolition Hammers HM1200 - HM1200K - HM1300 - HM1303 - HM1304 - HM1800 - HM1810 - HR3850 - HR3850K Part for the following...
AVAILABLE €8.71
Details
Rubber Ring 6 for Hammer Makita HM1303
Makita SKU: 262049-0
Rubber Ring 6 for Hammer Makita HM1303
Rubber Ring 6 for Hammer Makita HM1303 Genuine spare part Makita, Rubber Ring 6 for 14KG 1300W Hammer HM1303 Part for the following products: - 5621RDWBE - CIRCULAR SAW 165MM18V-2,2AH NI-MH - BSS610RFE - CIRCULAR SAW 165MM 18V LITIO -...
on 7/10 Business Days Approx €1.46
Details
Comments (0)
