Makita

Makita Spare Parts for Angle Grinder GA9012C

SKU: Makita GA9012C
€33.44
VAT included

Makita Spare Parts for Angle Grinder GA9012C

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9012C.
Makita Spare Parts for Angle Grinder GA9012C
  • Makita Spare Parts for Angle Grinder GA9012C
  • Makita Spare Parts for Angle Grinder GA9012C
Makita

Makita Spare Parts for Angle Grinder GA9012C

SKU: Makita GA9012C Condition: New
€33.44
VAT included

Makita Spare Parts for Angle Grinder GA9012C

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9012C.
settings 49 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
49 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 418517-3 KEY LOCK-DISC X GA9010C €3.41
2
 photo_cameraImage coming soon 231037-8 SPRING 7 9607/09 / GA / 3612BR €1.36
3
 photo_cameraImage coming soon 416972-3 CAP 9079S €1.79
4
 photo_cameraImage coming soon 318817-0 GERS HOUSING X GA9010C €20.58
5
 photo_cameraImage coming soon 266553-1 SCREW 5X30 GA7012C-9012C €1.79
7
 photo_cameraImage coming soon 210043-6 BALL BEARING 608LLB FOR LF1000 €4.95
8
 Ext DIN471 Circlip-15 for Makita Power Tools 961055-9 Ext DIN471 Circlip-15 for Makita Power Tools €1.47
9
 photo_cameraImage coming soon 227457-2 GEAR 43 X GA9010C €41.63
10
 photo_cameraImage coming soon 285809-3 CUSHION PORTABLE 23-36 €4.18
11
 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 211228-7 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 €8.63
12
 photo_cameraImage coming soon 267215-4 WASHER 15 X BTD200 €3.41
13
 photo_cameraImage coming soon 213720-9 GASKET 67 €3.41
14
 photo_cameraImage coming soon 318376-4 BEARING BOX FOR GA9010C €10.34
15
 photo_cameraImage coming soon 922221-3 Screw M5X16 X HM1303 €3.41
16
 photo_cameraImage coming soon 153785-8 SPINDLE X GA9010C €14.96
17
 Woodruf Key mm 4x7,95x4,97 for Angle Grinder Makita 9554NB 254011-9 Woodruf Key mm 4x7,95x4,97 for Angle Grinder Makita 9554NB €1.38
18
 photo_cameraImage coming soon 654532-5 TERMINAL BLOCK 6E / 1DS €3.76
19
 photo_cameraImage coming soon 122847-3 HEADSET BLADE X GA9010C €23.74
20
 Inner Flange for Angle Grinder Makita 115-125 mm 224415-9 Inner Flange for Angle Grinder Makita 115-125 mm €8.23
21
 Upper Flange for Angle Grinder Makita 180-230 mm 224543-0 Upper Flange for Angle Grinder Makita 180-230 mm €5.45
22
 photo_cameraImage coming soon 213026-5 RING 7 X GA9010C €2.64
23
 photo_cameraImage coming soon 256483-4 PIN 7 X GA7010C €3.41
24
 photo_cameraImage coming soon 931303-0 HEXAGONAL NUT M6 €1.36
25
 photo_cameraImage coming soon 227456-4 GEAR 9 X GA9010C €15.51
26
 Ball Bearing 6201LLB NSK for Sander Makita SA7000 211106-1 Ball Bearing 6201LLB NSK for Sander Makita SA7000 €8.69
27
 photo_cameraImage coming soon 253759-0 WASHER P.12 JN / JS3200 €3.41
28
 photo_cameraImage coming soon 317753-7 HOUSING COVER GEAR X GA9010C €10.34
29
 photo_cameraImage coming soon 240070-9 FAN 76 X GA9010C €3.41
30
 photo_cameraImage coming soon 513568-2 ARMATURE X GA9010C €44.14
31
 photo_cameraImage coming soon 681660-3 INSULATOR X PV7000C €13.42
32
 photo_cameraImage coming soon 267281-1 WASHER 8 X GA9010C €3.41
33
 Ball Bearing 608DDW for Jigsaw Makita 4327 210005-4 Ball Bearing 608DDW for Jigsaw Makita 4327 €5.16
34
 photo_cameraImage coming soon 421720-7 RUBBER RING 5604R €15.56
35
 photo_cameraImage coming soon 266386-4 5X75 SCREW FOR GA7012C-GA9012C €1.79
36
 photo_cameraImage coming soon 418516-5 DEFLECTOR X GA9010C €2.88
37
 photo_cameraImage coming soon 625824-9 STATOR GA7012C-GA9012C €39.37
38
 photo_cameraImage coming soon 153786-6 HOUSING MOTOR GA9012C €23.74
40
 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders 191957-7 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders €9.15
41
 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 643710-2 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 €2.01
43
 photo_cameraImage coming soon 631950-4 REGULATOR GA7012C-GA9012C €53.56
44
 photo_cameraImage coming soon 418518-1 COMPASS X GA9010C €3.41
45
 Switch for Polisher Makita SA7000 651922-3 Switch for Polisher Makita SA7000 €32.80
46
 photo_cameraImage coming soon 451637-0 SWITCH HOLDER GA7012C €1.79
47
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
49
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
50
 photo_cameraImage coming soon 687124-5 CORD CLAMP MT953 €1.47
51
 photo_cameraImage coming soon 682573-1 CORD ARMOR 10 X GA9010C €3.41
53
 photo_cameraImage coming soon 233117-6 COMPRESSION SPRING 6 X GA7010C €1.32
54
 photo_cameraImage coming soon 140358-6 LEVER SWITCH CPL GA7012C €8.35

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Angle Grinder GA9012C

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9012C.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita GA9012C

Angle Grinder GA9012C
# Part Num. Description
1 418517-3 KEY LOCK-DISC X GA9010C
2 231037-8 SPRING 9607 7/09 / GA / 3612BR
3 416972-3 CAP 9079S
4 318817-0 CARCASS ING. X GA9010C
5 266553-1 SCREW 5X30 GA7012C-9012C
7 210043-6 BEARING FOR 608LLB LF1000
8 961055-9 RETAINING RING S15
9 227457-2 GEAR 43 X GA9010C
10 285809-3 BEARING 23-36
11 211228-7 BALL BEARING 6202DD
12 267215-4 WASHER 15 X BTD200
13 213720-9 SEAL 67 X HR2400
14 318376-4 BEARING BOX X GA9010C
15 922221-3 SCREW M5X16 X HM1303
16 153785-8 POST X GA9010C
17 254011-9 KEY 4
18 654532-5 TERMINAL BLOCK 6E / 1DS
19 122847-3 HEADSET BLADE X GA9010C
20 224415-9 FLANGE INTERNAL 42 GA95010
21 224543-0 FLANGE 9047F 9049F 9049SF
22 213026-5 RING 7 X GA9010C
23 256483-4 PIN 7 X GA7010C
24 931303-0 HEX NUT M6
25 227456-4 GEAR 9 X GA9010C
26 211106-1 BALL BEARING 6201LLB
27 253759-0 ROND.P.12 JN / JS3200
28 317753-7 COVER CARC.INGR. X GA9010C
29 240070-9 FAN 76 X GA9010C
30 513568-2 ARMATURE X GA9010C
31 681660-3 INSULATOR X PV7000C
32 267281-1 WASHER 8 X GA9010C
33 210005-4 BALL BEARING 608 DDW
34 421720-7 RING RUBBER 5604R
35 266386-4 5X75 SCREW FOR GA7012C-GA9012C
36 418516-5 DEFLETTORE X GA9010C
37 625824-9 STATOR GA7012C-GA9012C
38 153786-6 HOUSING MOTOR GA9012C
40 191957-7 CARBON BRUSCHES CB-204 (201.202)
41 643710-2 BRUSH HOLDER X HM1500
43 631950-4 REGULATOR GA7012C-GA9012C
44 418518-1 COMPASS X GA9010C
45 651922-3 SWITCH TG71B
46 451637-0 SWITCH HOLDER GA7012C
47 265995-6 SCREW M4X18 X 6408 / 6221DW
48 188826-1  REAR HANDLE GA7012CP12
49 265995-6 SCREW M4X18 X 6408 / 6221DW
50 687124-5 CLAMP ties MT953
51 682573-1 CABLE 10 X GA9010C
53 233117-6 SPRING COMP. 6 X GA7010C
54 140358-6 LEVER SWITCH CPL GA7012C
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita GA9012C
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita GA9012C

Diagram Makita GA9012C

Download (305.94KB)
