Makita Pump PF0610 Parts

SKU: Makita PF0610
€63.38
VAT included

Makita Spare Parts for Submersible Drainage Pump PF0610

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Submersible Drainage Pump PF0610.
Makita Pump PF0610 Parts
  • Online only
  • Makita Pump PF0610 Parts
  • Makita Pump PF0610 Parts
Makita

Makita Pump PF0610 Parts

SKU: Makita PF0610 Condition: New
€63.38
VAT included

Makita Spare Parts for Submersible Drainage Pump PF0610

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Submersible Drainage Pump PF0610.
settings 54 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
54 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 609025436 POWER CABLE €63.38
3
 photo_cameraImage coming soon 609026213 SCREW €1.44
4
 photo_cameraImage coming soon 609024798 HANDLE X PF0610 €7.83
5
 photo_cameraImage coming soon 609024637 NUT €1.42
6
 photo_cameraImage coming soon 609024638 WASHER €1.42
7
 photo_cameraImage coming soon 609024650 CABLE CLAMP X EP-960DS €2.16
8
 photo_cameraImage coming soon 609026214 CABLE GLAND X EP-960DS €1.44
9
 photo_cameraImage coming soon 609024639 SCREW €1.44
10
 photo_cameraImage coming soon 609024663 PUMP FOR EP-960DS €51.66
11
 photo_cameraImage coming soon 609024641 RING 14X2.65 €1.44
12
 photo_cameraImage coming soon JH00000002 SCREW €1.42
13
 photo_cameraImage coming soon JH00000003 RING €2.13
14
 photo_cameraImage coming soon 609024642 MOTOR CASING X EP-960DS €6.14
15
 photo_cameraImage coming soon 609024588 CABLE D8.5 X EP-84 €1.44
16
 photo_cameraImage coming soon 609024664 CABLE SLEEVE FOR EP-960DS €1.42
17
 photo_cameraImage coming soon 609024590 RING X EP-84 €1.44
19
 photo_cameraImage coming soon JH00000076 CAPACITATOR FOR EP-960DS €13.04
20
 photo_cameraImage coming soon 609024592 FLANGE X EP-84 €1.44
21
 photo_cameraImage coming soon 609024593 SCREW €1.44
22
 photo_cameraImage coming soon 609024601 M4X8 SCREW €1.42
23
 photo_cameraImage coming soon 609024596 SPRING WASHER 4 €1.42
24
 photo_cameraImage coming soon JH00000004 EARTH CABLE €1.42
25
 photo_cameraImage coming soon 609024600 TOOTHED WASHER 4 €1.42
26
 photo_cameraImage coming soon 609024629 NYLON CAP FOR EP-84 €1.42
27
 photo_cameraImage coming soon 609024630 2SD CAP €1.42
28
 photo_cameraImage coming soon 609024632 CLAMP €1.42
29
 photo_cameraImage coming soon JH00000070 230V MOTOR 50HZ COMPLETE €116.38
30
 photo_cameraImage coming soon 609024595 RUBBER 10 €1.42
31
 photo_cameraImage coming soon 609024594 UPPER MOTOR HOUSING €10.16
32
 photo_cameraImage coming soon 609024602 WAVED WASHER 25 €1.42
33
 photo_cameraImage coming soon 609024603 BEARING 6201Z €6.09
34
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
35
 photo_cameraImage coming soon JH00000061 ARMOR €29.11
36
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
37
 photo_cameraImage coming soon 609024603 BEARING 6201Z €6.09
38
 photo_cameraImage coming soon JH00000062 STATOR 230V 50HZ €46.13
39
 photo_cameraImage coming soon 609024667 RING €1.42
40
 photo_cameraImage coming soon 609024607 WASHER €1.42
41
 photo_cameraImage coming soon 609024608 SEAL €1.42
42
 photo_cameraImage coming soon 609024609 BEARING BOX €5.26
43
 photo_cameraImage coming soon 609024610 RING €1.42
44
 photo_cameraImage coming soon 609024668 LOWER MOTOR HOUSING €13.04
45
 photo_cameraImage coming soon 609024608 SEAL €1.42
46
 photo_cameraImage coming soon 609024633 SEAL X EP-84 €5.29
47
 photo_cameraImage coming soon 609024634 RETAINING RING X EP-84 €1.44
48
 photo_cameraImage coming soon 609024613 GASKET X EP-84 €1.44
49
 photo_cameraImage coming soon 609024669 IMPELLER FOR EP-960DS €5.26
50
 photo_cameraImage coming soon 609024615 NUT €1.44
51
 photo_cameraImage coming soon 609024612 RING 89X5.2 €2.16
52
 photo_cameraImage coming soon JH00000058 RING €2.16
53
 photo_cameraImage coming soon 609024646 SCREW €1.44
54
 photo_cameraImage coming soon 609024654 MASS X EP-960DS €1.44
55
 photo_cameraImage coming soon 609024655 SUPPORT X EP-960DS €2.77
56
 photo_cameraImage coming soon 609024671 SEAL FOR EP-960DS €3.21
57
 photo_cameraImage coming soon 609024672 BASE FOR EP-960DS €70.84
58
 photo_cameraImage coming soon JH00000005 ANTIVIBRATION Ø40X30 MF M8X25 65SH €7.77
59
 photo_cameraImage coming soon 609024627 FITTING FOR EP-84 €3.93

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Submersible Drainage Pump PF0610

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Submersible Drainage Pump PF0610.

In the following table, look for the model of Submersible Drainage Pump and the respective parts of the code.
Makita Spare Parts for Submersible Drainage Pump PF0610

Makita PF0610 - SUBMERSIBLE PUMP
# Part Num Description
1 609025436 POWER CABLE
2 JH00000198 SWITCH FOR PF0300
3 609026213 SCREW
4 609024798 HANDLE FOR PF0610
5 609024637 NUT
6 609024638 WASHER
7 609024650 CABLE CLAMP FOR EP-960DS
8 609026214 CABLE GLAND FOR EP-960DS
9 609024639 SCREW
10 609024663 PUMP FOR EP-960DS
11 609024641 RING 14X2.65
12 JH00000002 SCREW
13 JH00000003 RING
14 609024642 MOTOR HOUSING FOR EP-960DS
15 609024588 CABLE SLEEVE D8.5 FOR EP-84
16 609024664 CABLE SLEEVE FOR EP-960DS
17 609024590 RING NUT FOR EP-84
18 609024589
19 JH00000076 CAPACITATOR FOR EP-960DS
20 609024592 FLANGE FOR EP-84
21 609024593 SCREW
22 609024601 M4X8 SCREW
23 609024596 SPRING WASHER 4
24 JH00000004 EARTH CABLE
25 609024600 TOOTHED WASHER 4
26 609024629 NYLON CAP FOR EP-84
27 609024630 2SD CAP
28 609024632 CLAMP
29 JH00000070 230V MOTOR 50HZ COMPLETE
30 609024595 RUBBER 10
31 609024594 UPPER MOTOR HOUSING
32 609024602 WAVED WASHER 25
33 609024603 BEARING 6201Z
34 961052-5 RETAINING RING S12
35 JH00000061 ARMOR
36 961052-5 RETAINING RING S12
37 609024603 BEARING 6201Z
38 JH00000062 STATOR 230V 50HZ
39 609024667 RING
40 609024607 WASHER
41 609024608 SEAL
42 609024609 BEARING BOX
43 609024610 RING
44 609024668 LOWER MOTOR HOUSING
45 609024608 SEAL
46 609024633 SEAL FOR EP-84
47 609024634 RETAINING RING FOR EP-84
48 609024613 GASKET FOR EP-84
49 609024669 IMPELLER FOR EP-960DS
50 609024615 NUT
51 609024612 RING 89X5.2
52 JH00000058 RING
53 609024646 SCREW
54 609024654 GROUND FOR EP-960DS
55 609024655 SUPPORT FOR EP-960DS
56 609024671 SEAL FOR EP-960DS
57 609024672 BASE FOR EP-960DS
58 JH00000005 BASE
59 609024627 FITTING FOR EP-84
60 JH00000121 RING 37.5X3
61 JH00000121 RING 37.5X3
62 609024626 ELBOW FOR EP-84 3.02
58 JH00000005 BASE 6.05
