Makita

Makita Drill DHP453 Parts

SKU: Makita DHP453
€2.20
VAT included

Makita Spare Parts for Cordless Hammer Drill DHP453

MAKITA service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Hammer Diver Drill DHP453.
Makita Drill DHP453 Parts
  • Makita Drill DHP453 Parts
  • Makita Drill DHP453 Parts Drawing
Makita

Makita Drill DHP453 Parts

SKU: Makita DHP453 Condition: New
€2.20
VAT included

Makita Spare Parts for Cordless Hammer Drill DHP453

MAKITA service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Hammer Diver Drill DHP453.
settings 15 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
15 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 125310-5 SPEED SHIFT LEVER. FOR BDF440 €2.14
2
 photo_cameraImage coming soon 187363-2 HOUSING MOTOR BDF453-BHP453 €30.38
3
 photo_cameraImage coming soon 815J03-9 — €1.43
4
 photo_cameraImage coming soon 266130-9 SCREW 3X16 X 6203/13 / 6313DW €1.46
5
 photo_cameraImage coming soon 232182-2 SPRING PLATE X 6096DW €1.43
6
 Change Lever for Makita Cordless BDF343RHE 419250-0 Change Lever for Makita Cordless BDF343RHE €2.51
7
 photo_cameraImage coming soon 632A23-2 SWITCH BDF453-BHP453 €51.67
8
 photo_cameraImage coming soon 643852-2 TERMINAL X BVC350Z €4.56
9
 Chuck Screw M 6x22 for Cordless Drill Makita MT064SK 251468-5 Chuck Screw M 6x22 for Cordless Drill Makita MT064SK €1.43
10
 Keyless Chuck S13 for Cordless Drill Makita 8391D 196306-3 Keyless Chuck S13 for Cordless Drill Makita 8391D €18.02
11
 photo_cameraImage coming soon 125485-0 GROUP GEARS X 8391D €63.40
12
 Motor for Cordless Makita 6390 DWAE 629937-8 Motor for Cordless Makita 6390 DWAE €26.79
13
 photo_cameraImage coming soon 911108-4 SCREW M4X8 X 5103R €3.18
14
 photo_cameraImage coming soon 187363-2 HOUSING MOTOR BDF453-BHP453 €30.38
15
 photo_cameraImage coming soon 424476-1 RUBBER BHR242RFE €1.43
16
 photo_cameraImage coming soon 421940-3 COVER FOR MOTOR DC 8390D €2.86

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Cordless Hammer Drill DHP453

MAKITA service center and original spare parts Worldwide Distributor

. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Hammer Diver Drill DHP453.
In the following table, look for the model of the Cordless Drill and the respective parts of the code.
Makita DHP453

MAKITA DHP453
# Part Num Description
1 125310-5 SPEED GEAR LEVER FOR BDF440
2 187363-2 BDF453-BHP453 MOTOR CASING
3 815J03-9 —
4 266130-9 3X16 SCREW X 6203/13/6313DW
5 232182-2 PLATE SPRING X 6096DW
6 419250-0 F/R CHANGE LEVER /BHP451/BDF441/BHP441
7 632A23-2 BDF453-BHP453 SWITCH
8 643852-2 TERMINAL FOR BVC350Z
9 251468-5 FLAT HEAD SCREW M6X22 /MT065SK2/BDF441
10 196306-3 8391D 15 KEYLESS CHUCK
11 125485-0 GEAR GROUP FOR 8391D
12 629937-8 DC MOTOR FOR 6390D
13 911108-4 M4X8 SCREW X 5103R
14 187363-2 BDF453-BHP453 MOTOR CASING
15 424476-1 BHR242RFE RUBBER
16 421940-3 COVER DC MOTOR FOR 8390D
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita DHP453
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita DHP453 Parts Drawing

Makita DHP453 Parts Drawing

Download (309.39KB)
