Makita Wall Chaser SG150 Parts

SKU: Makita SG150
€3.08
VAT included

Makita Spare Parts for Wall Chaser SG150

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wall Chaser 1800W 150 mm Makita SG150.
Makita Wall Chaser SG150 Parts
  • Makita Wall Chaser SG150 Parts
  • Makita Wall Chaser SG150 Parts Diagram
Makita

Makita Wall Chaser SG150 Parts

SKU: Makita SG150 Condition: New
€3.08
VAT included

Makita Spare Parts for Wall Chaser SG150

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wall Chaser 1800W 150 mm Makita SG150.
settings 61 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
61 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Makita SG150/2 Bolt 6x150 B47720 Makita SG150/2 Bolt 6x150 €3.07
2
 Makita SG150/2 Wrench 13/17 B03384 Makita SG150/2 Wrench 13/17 €13.07
3
 photo_cameraImage coming soon B35915 ARMATURE X SG150 €493.97
4
 photo_cameraImage coming soon 211066-7 BALL BEARING HM1301 - 6200 €11.93
5
 photo_cameraImage coming soon B32615 RING X SG150 €1.40
5
 photo_cameraImage coming soon B51003 RING 35X2.5 X SG180 €1.40
6
 photo_cameraImage coming soon B50815 GEAR BOX X SG150 €193.46
7
 photo_cameraImage coming soon B33415 SCREW M5 X 20 X SG150 €1.40
8
 photo_cameraImage coming soon B07450 SCREW M4,8 X 80 X SG150 €2.08
9
 photo_cameraImage coming soon B30361 PLATE 0.15 X SG150 €4.43
9
 photo_cameraImage coming soon B30379 PLATE 0.2X SG150 €4.43
9
 photo_cameraImage coming soon B30387 PLATE X 0.3 SG150 €5.13
13
 photo_cameraImage coming soon B30130 BEARING X SG150 €24.35
14
 photo_cameraImage coming soon B30015 SOCKET X SG150 €3.84
15
 photo_cameraImage coming soon 211281-3 BALL BEARING 6203LLU €9.89
16
 photo_cameraImage coming soon B46748 POST X SG150 €113.10
17
 photo_cameraImage coming soon B30148 RING 46X2 X SG2150 €2.69
18
 photo_cameraImage coming soon B11122 BOLT M 8 X 90 X SG150 €2.69
19
 photo_cameraImage coming soon B11189 WASHER 8.4 X SG150 €1.40
20
 photo_cameraImage coming soon B33415 SCREW M5 X 20 X SG150 €1.40
21
 Makita SG150/2 Tension Roller B10777 Makita SG150/2 Tension Roller €13.33
22
 photo_cameraImage coming soon B11247 TUBE X SG150 €9.89
23
 photo_cameraImage coming soon B18952 NUT M8 X SG150 €1.40
24
 photo_cameraImage coming soon B33407 BOLT M 8 X 55 X SG150 €1.40
25
 photo_cameraImage coming soon B10983 BOLT M 8 X 16 X SG150 €9.06
26
 photo_cameraImage coming soon B29934 EXTERNAL FLANGE X SG150 €24.35
27
 photo_cameraImage coming soon B30486 RING 3 X SG150 €3.84
28
 photo_cameraImage coming soon B10678 RING 10 X SG150 €9.89
29
 photo_cameraImage coming soon B30494 RING 18 X SG150 €12.69
30
 Wheels Security Cover for Wall Chaser 1800W 150MM SG150/2 B50831 Wheels Security Cover for Wall Chaser 1800W 150MM SG150/2 €118.10
31
 photo_cameraImage coming soon B11528 BOLT M 8 X 25 X SG150 €1.40
32
 photo_cameraImage coming soon B29884 RING 2.7X SG150 €9.89
33
 photo_cameraImage coming soon B30171 STOP BEARING X SG150 €32.73
34
 photo_cameraImage coming soon B50823 BEARING BOX X SG150 €85.14
35
 photo_cameraImage coming soon B21071 WASHER M8 X SG150 €1.40
36
 photo_cameraImage coming soon B18952 NUT M8 X SG150 €1.40
38
 photo_cameraImage coming soon B41418 VANE X SG150 €12.69
39
 photo_cameraImage coming soon B36137 SCREW M4 X 80 X SG150 €2.08
40
 photo_cameraImage coming soon B50849 STATOR 220 X SG150 €193.46
41
 photo_cameraImage coming soon B08482 HANDLE SIDE X SG150 €40.40
42
 photo_cameraImage coming soon B21030 SCREW M3,9 X 13 X SG150 €1.40
43
 photo_cameraImage coming soon B38299 CARBON BRUSHE HOLDER COVER X SG180 €3.13
44
 photo_cameraImage coming soon B32508 PORT CARBON BRUSHES X SG150 €28.56
45
 photo_cameraImage coming soon B45872 CARBON BRUSHE (1 pc) X SG150 €17.00
47
 photo_cameraImage coming soon B50807 MOTOR CASING X SG150 €76.50
48
 photo_cameraImage coming soon B31096 TUBE X SG150 €12.69
49
 Makita SG150/2 Roller 26X113 B09506 Makita SG150/2 Roller 26X113 €10.39
50
 photo_cameraImage coming soon B26948 WASHER 13 X SG150 €1.40
51
 photo_cameraImage coming soon B30981 BOLT M 7 X 12 X SG150 €2.08
52
 photo_cameraImage coming soon B31070 WASHER 7.4 X SG150 €1.40
53
 photo_cameraImage coming soon B10801 HOLDER X SG150 €68.84
54
 photo_cameraImage coming soon B48611 COMPLETE HANDLE X SG150 €68.84
55
 photo_cameraImage coming soon B14886 MUFFLER X SG150 €9.89
56
 photo_cameraImage coming soon B25221 SAVE CABLE X SG150 €2.08
58
 photo_cameraImage coming soon B17913 CLAMP X 2702 €5.13
59
 photo_cameraImage coming soon B20990 SCREW M3,9 X 16 X SG150 €1.40
60
 photo_cameraImage coming soon B31468 SWITCH X SG150 €75.83
61
 photo_cameraImage coming soon B44941 SCREW M4,8 X 38 X SG150 €1.40
62
 photo_cameraImage coming soon B42721 SCREW M3,9 X 19 X SG150 €1.40
63
 Makita SG150/2 - SG180/2 Controller B35055 Makita SG150/2 - SG180/2 Controller €210.90
Page 2 local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
A001
 photo_cameraImage coming soon B50856 MULTI STEEL CASE €100.50
A003
 photo_cameraImage coming soon P-22311 DIAMOND WHEEL F. HARD MATERIAL €128.94
A002
 photo_cameraImage coming soon P-22327 DIAMOND WHEEL F. ABRASIVE €113.44

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Wall Chaser SG150

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wall Chaser 1800W 150 mm Makita SG150.

In the following table, look for the model of Groover and the respective parts of the code.
Makita SG150
Wall Chaser Makita SG150
Pag.1
#
Part Num.
 Description
1
 BOLT X SG150
2
 WRENCH 13/17 X SG150
3
B35915
 ARMATURE ASS`Y
4
211066-7
 BALL BEARING 6200LLB
5
B51003
 O-RING 35x2,5
5
B32615
 O-RING 31x2,5
6
B50815
 GEAR HOUSING
7
B33415
 TAPTITE SCREW M5x20
8
B07450
 SCREW 4,8x80
9
B30361
 SHIM 0,15
9
B30379
 SHIM 0,2
9
B30387
 SHIM 0,3
13
B30130
 BALL BEARING 6003LLU
14
B30015
 SLEEVE
15
211281-3
 BALL BAERING 6203LLU
16
B46748
 SPINDLE
17
B30148
 O-RING 46x2
18
B11122
 HEX. BOLT M8x90
19
B11189
 WASHER 8,4
20
B33415
 TAPTITE SCREW M5x20
21
 TENSION ROLLER X SG150
22
B11247
 PIPE
23
B18952
 HEX.NUT M8
24
B33407
 HEX.BOLT M8X55
25
B10983
 HEX.BOLT M8X16
26
B29934
 OUTER FLANGE
27
B30486
 RING 3
28
B10678
 RING 10
29
B30494
 RING 18
30
 SAFETY COVER X SG150
31
B11528
 HEX. BOLT M8X25
32
B29884
 RING 2,7
33
B30171
 BEARING RETAINER
34
B50823
 BEARING BOX
35
B21071
 WASHER 8
36
B18952
 HEX.NUT M8
38
B41418
 BAFFLE PLATE
39
B36137
 SCREW 4X80
40
B50849
 FIELD ASS`Y
41
B08482
 SIDE GRIP
42
B21030
 PAN HEAD SCREW 3,9X13
43
B38299
 BRUSH HOLDER COVER
44
B32508
 BRUSH HOLDER
45
B45872
 CARBON BRUSH
46
B47721
 NAME PLATE
47
B50807
 MOTOR HOUSING
48
B31096
 PIPE
49
 TENSION ROLLER X SG150
50
B26948
 WASHER 13
51
B30981
 HEX. BOLT M7X12
52
B31070
 WASHER 7,4
53
B10801
 HOLDER
54
B48611
 HANDLE SET
55
B14886
 NOISE SUPPRESSOR
56
B25221
 CORD GUARD
57
P-12918
 POWER SUPPLY CORD 1.50-2-5M
58
B17913
 STRAIN RELIEF
59
B20990
 PAN HEAD SCREW 3,9X16
60
B31468
 SWITCH
61
B44941
 PAN HEAD SCREW 4,8X38
62
B42721
 PAN HEAD SCREW 3,9X19
63
 CONTROLLER X SG150
Accessories Pag.2
A001 B50856 MULTI STEEL CASE
A002 P-22327 DIAMOND WHEEL F. ABRASIVE
A003 P-22311 DIAMOND WHEEL F. HARD MATERIAL
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita SG150
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita SG150 Parts Diagram

Makita SG150 Parts Diagram

Download (486.93KB)
