Makita Recipro Saw JR3051T Parts

SKU: Makita JR3051T
€5.43
VAT included

Makita Spare Parts for Reciprocatng Saw JR3051T

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3051T.
Makita Recipro Saw JR3051T Parts
  • Makita Recipro Saw JR3051T Parts
  • Makita Recipro Saw JR3051T Parts Diagram
Makita

Makita Recipro Saw JR3051T Parts

SKU: Makita JR3051T Condition: New
€5.43
VAT included

Makita Spare Parts for Reciprocatng Saw JR3051T

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3051T.
settings 65 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
65 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
C10
 photo_cameraImage coming soon 162315-4 LATCH €2.69
C10
 photo_cameraImage coming soon 213174-0 RING 14 JR3030 €1.40
C10
 photo_cameraImage coming soon 654020-2 RING TERMINAL 94 €1.40
C20
 photo_cameraImage coming soon 654501-6 CONNECTOR P-1.25 €1.40
A04
 photo_cameraImage coming soon B-05038 RECIPRO SAW BLADE FOR METAL €19.90
A05
 photo_cameraImage coming soon B-05044 RECIPRO SAW BLADE FOR PLYW OOD €19.90
A06
 photo_cameraImage coming soon B-05153 RECIPRO SAW BLADE FOR WOO D €19.90
1
 photo_cameraImage coming soon 162704-3 SHOE €5.13
2
 photo_cameraImage coming soon 265844-7 HEX. SOCKET HEAD BOLT M6X20 €1.40
3
 photo_cameraImage coming soon 422537-1 INSULATION COVER €14.34
4
 photo_cameraImage coming soon 422223-4 PROTECTOR €1.40
5
 photo_cameraImage coming soon 257430-8 RETAINING RING(EXT)18 €1.40
6
 photo_cameraImage coming soon 310848-5 DRIVING SLEEVE €11.07
7
 photo_cameraImage coming soon 327043-0 GUIDE SLEEVE €2.08
8
 photo_cameraImage coming soon 268094-3 PIN 3 X BJR240 €3.25
9
 photo_cameraImage coming soon 234381-2 COMPRESSION SPRING 6 €1.40
10
 photo_cameraImage coming soon 256569-4 PIN 5 €1.40
11
 photo_cameraImage coming soon 458968-8 CONNECTING SLEEVE €1.40
12
 photo_cameraImage coming soon 310912-2 PUSH PIN €3.13
13
 photo_cameraImage coming soon 232472-3 COMPRESSION SPRING 2 €1.40
14
 photo_cameraImage coming soon 233594-2 TORSION SPRING 17 €1.40
15
 photo_cameraImage coming soon 961018-5 RETAINING RING E5 €3.76
16
 photo_cameraImage coming soon 256934-7 COLLARED PIN 6 €2.08
17
 photo_cameraImage coming soon 327441-8 BLOCK €2.69
18
 photo_cameraImage coming soon 911258-5 SCREW M5x35 4101R €2.58
19
 photo_cameraImage coming soon 911243-8 SCREW M5x25 HR2010 €1.40
20
 photo_cameraImage coming soon 140R13-8 GEAR HOUSING COVER COMPLE TE €18.98
21
 photo_cameraImage coming soon 214169-6 BUSH 14 JR3030 €3.97
22
 photo_cameraImage coming soon 347596-3 SLIDE PLATE €1.40
23
 photo_cameraImage coming soon 911225-0 SCREW M5X16 X JR180D €2.17
24
 photo_cameraImage coming soon 162705-1 SLIDER €18.98
25
 photo_cameraImage coming soon 341462-6 PLATE X JR3000 / V €1.40
27
 photo_cameraImage coming soon 422538-9 SEAL RING €2.08
28
 photo_cameraImage coming soon 911225-0 SCREW M5X16 X JR180D €2.17
29
 photo_cameraImage coming soon 911225-0 SCREW M5X16 X JR180D €2.17
30
 photo_cameraImage coming soon 347597-1 GEAR PLATE A €1.40
31
 photo_cameraImage coming soon 346715-8 GEAR PLATE €1.40
32
 photo_cameraImage coming soon 212959-1 BEARING ROLLER 708 €6.63
33
 photo_cameraImage coming soon 140R15-4 GEAR COMPLETE €24.35
34
 photo_cameraImage coming soon 267290-0 WASHER 18 X JR3050T €1.40
35
 photo_cameraImage coming soon 266459-3 SCREW 5x25 PC5000C €1.32
36
 photo_cameraImage coming soon 140R12-0 GEAR HOUSING COMPLETE €21.54
37
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
38-1
 photo_cameraImage coming soon 210105-0 BEARING 6001LLU PW5000CH €6.63
38
 Ball Bearing 6001DD for Makita 9218S 211131-2 Ball Bearing 6001DD for Makita 9218S €6.00
39
 photo_cameraImage coming soon 285036-2 BEARING RETAINER 80 €2.08
40
 photo_cameraImage coming soon 265353-6 SCREW M 4 X 12 X 4341FCT €3.76
41
 photo_cameraImage coming soon 511A03-0 ARMATURE ASS'Y 220-240V €44.84
42
 photo_cameraImage coming soon 681644-1 INSULATED WASHER for 9227CB €2.74
43
 photo_cameraImage coming soon 210029-0 BALL BEARING 608ZZ X MT601 €2.08
44
 photo_cameraImage coming soon 459919-4 BAFFLE PLATE €2.69
45
 photo_cameraImage coming soon 266056-5 SCREW M 5 X 45 X JR3060T €2.69
46
 photo_cameraImage coming soon 521894-5 FIELD ASS'Y 240V €35.76
49
 photo_cameraImage coming soon 459920-9 HOOK COVER €2.08
50
 Carbon Brushes CB-303 for Belt Sander Makita 9920X 191963-2 Carbon Brushes CB-303 for Belt Sander Makita 9920X €9.96
51
 photo_cameraImage coming soon 140R14-6 MOTOR HOUSING COMPLETE €14.34
52-1
 photo_cameraImage coming soon 265B67-9 TAPPING SCREW 4X18 €1.40
52
 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 €1.27
53
 photo_cameraImage coming soon 183N40-8 HANDLE SET €14.34
54
 photo_cameraImage coming soon 651374-8 SWITCH C3VT-2L-C-H50 €44.84
55
 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C 643750-0 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C €2.51
56-1
 photo_cameraImage coming soon 265B67-9 TAPPING SCREW 4X18 €1.40
56
 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 €1.27
57
 photo_cameraImage coming soon 687124-5 CORD CLAMP MT953 €1.47
58
 photo_cameraImage coming soon 682574-9 CABLE SLEEVE 10-90 PC5000C €1.47
59
 photo_cameraImage coming soon 665890-4 POWER SUPPLY CORD 1.0-2-4.0 €21.54
60
 photo_cameraImage coming soon 183N40-8 HANDLE SET €14.34
65
 photo_cameraImage coming soon 688165-4 FILTER LINE X AH3655 €1.44
66
 photo_cameraImage coming soon 241863-7 FAN 70 €13.60
67
 photo_cameraImage coming soon 253804-1 WASHER 6 X LS1013 €1.40

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Reciprocatng Saw JR3051T

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3051T.

In the following table, look for the model of Saw and the respective parts of the code.
Makita JR3051T

MAKITA JR3051T RECIPRO SAW
# Part Num. Description
1 162704-3 SHOE
2 265844-7 HEX. SOCKET HEAD BOLT M6X20
3 422537-1 INSULATION COVER
4 422223-4 PROTECTOR
5 257430-8 RETAINING RING(EXT)18
6 310848-5 DRIVING SLEEVE
7 327043-0 GUIDE SLEEVE
8 268094-3 PIN 3
9 234381-2 COMPRESSION SPRING 6
10 256569-4 SHOULDER PIN 5
11 458968-8 CONNECTING SLEEVE
12 310912-2 PUSH PIN
13 232472-3 COMPRESSION SPRING 2
14 233594-2 TORSION SPRING 17
15 961018-5 STOP RING E-5
16 256934-7 COLLARED PIN 6
17 327441-8 BLOCK
18 911258-5 PAN HEAD SCREW M5X35
19 911243-8 PAN HEAD SCREW M5X25
20 140R13-8 GEAR HOUSING COVER COMPLE TE
C10 213174-0 X RING 14
21 214169-6 PLANE BEARING 14
22 347596-3 SLIDE PLATE
23 911225-0 PAN HEAD SCREW M5X16
23-1 265C32-4 P.H.SCREW M5X16 WITH WM
24 162705-1 SLIDER
25 341462-6 PLATE
26 136188-1 GEAR HOUSING COVER ASS'Y
26 INC. 4-17,20-25
26-1 136962-7 GEAR HOUSING COVER ASS'Y
26-1 INC. 4-17,20-25
27 422538-9 SEAL RING
28 911225-0 PAN HEAD SCREW M5X16
28-1 265C32-4 P.H.SCREW M5X16 WITH WM
29 911225-0 PAN HEAD SCREW M5X16
29-1 265C32-4 P.H.SCREW M5X16 WITH WM
30 347597-1 GEAR PLATE A
31 346715-8 GEAR PLATE
32 212959-1 NEEDLE BEARING 708
33 140R15-4 GEAR COMPLETE
34 267290-0 FLAT WASHER 18
35 266459-3 TAPPING SCREW 5X25
35-1 265D56-6 TAPPING SCREW 5X25
36 140R12-0 GEAR HOUSING COMPLETE
37 961052-5 RETAINING RING (EXT) S-12
38 211131-2 BALL BEARING 6001DDW
38-1 210105-0 BALL BEARING 6001LLU
39 285036-2 BEARING RETAINER 80
40 265353-6 HEX. SOCKET HEAD BOLT M4X12
41 511A03-0 ARMATURE ASS'Y 220-240V
41 INC. 37-39,42,43,66
42 681644-1 INSULATION WASHER
43 210029-0 BALL BEARING 608ZZ
44 459919-4 BAFFLE PLATE
45 266056-5 TAPPING SCREW 5X45
46 521894-5 FIELD ASS'Y 240V
C10 654020-2 RING TERMINAL
C20 654501-6 CONNECTOR P-1.25
49 459920-9 HOOK COVER
50 191963-2 CARBON BRUSH CB-303
50-1 194996-6 CARBON BRUSH SET CB-303
51 140R14-6 MOTOR HOUSING COMPLETE
C10 644501-4 BRUSH HOLDER 5X11
52 266326-2 TAPPING SCREW 4X18
52-1 265B67-9 TAPPING SCREW 4X18
53 183N40-8 HANDLE SET
53 INC. 60
53-1 183N41-6 HANDLE SET
53-1 INC. 60
54 651374-8 SWITCH C3VT-2L-C-H50
54-1 650068-2 SWITCH C3VT-2-C-H50
55 643750-0 BRUSH HOLDER CAP 7-11
56 266326-2 TAPPING SCREW 4X18
56-1 265B67-9 TAPPING SCREW 4X18
57 687124-5 STRAIN RELIEF
58 682574-9 CORD GUARD 10-90
59 665890-4 POWER SUPPLY CORD 1.0-2-4.0
60 183N40-8 HANDLE SET
60 INC. 53
60-1 183N41-6 HANDLE SET
60-1 INC. 53
61 856M49-4 JR3051T NAME PLATE
62 807G78-4 CLEAR LABEL
63 856M54-1 JR3051T SERIAL NO. LABEL
64 8010T0-1 CLEAR LABEL
65 688165-4 LINE FILTER
66 241863-7 FAN 70
67 253804-1 FLAT WASHER 6
A02 821795-0 PLASTIC CASE
C10 162315-4 LATCH
A03 8007C1-9 JR3051TK MODEL NO. LABEL
A04 B-05038 RECIPRO SAW BLADE FOR METAL
A05 B-05044 RECIPRO SAW BLADE FOR PLYW OOD
A06 B-05153 RECIPRO SAW BLADE FOR WOO D
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita JR3051T
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita JR3051T Parts Diagram

Makita JR3051T Parts Diagram

Download (380.49KB)

You might also like

Reciprocating Saw - Makita JR3050T -20% Sale
HiKOKI Power Tools Italia S.p.a. SKU: Makita JR3050T
Reciprocating Saw - Makita JR3050T
Reciprocating Saw - Makita JR3050T Features - Bearings with double seal protection against dust - Ergonomic - Blade engagement fast - Stop carbon brushes
Last items in stock €265.83 €332.29
Details
Needle Bearing for Belt Saw Makita 2106W Sale
Makita SKU: 212115-3
Needle Bearing for Belt Saw Makita 2106W
Needle Bearing for Belt Saw Makita 2106W Genuine spare Makita, Needles Bearing HK121816 for Belt Saw 115 mm 2106W - Reciprocating JR3000 - JR3000V - JR3000VT - JR3020. Part for the following article: - Belt Saw 115MM MAKITA 2106W -...
AVAILABLE €11.60
Details
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C
Makita SKU: 643750-0
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C Genuine part MAKITA, Carbon Brush Holder Cap for Hammers HM1100 - HM1100C - Angle Grinder  GA6021C - GA6020 - Circular Saw 5703R. Parts for the following products: - 2107FK -...
AVAILABLE €2.51
Details
Compression Spring 6 for Reciprocating Saw Makita BJR2240 Sale
Makita SKU: 233345-3
Compression Spring 6 for Reciprocating Saw Makita BJR2240
Compression Spring 6 for Reciprocating Saw Makita BJR2240 Original spare parts Makita, Compression Spring 6 for Reciprocating Saws Makita BJR141RFE - BJR141RFE - BJR181SFE - BJR240SFE - DJR182Z - JR100DWE Part for the following...
AVAILABLE €1.37
Details
Ball Bearing 6001DDW for Makita JR3050T Sale
Makita SKU: 210102-6
Ball Bearing 6001DDW for Makita JR3050T
Ball Bearing 6001DDW for Makita JR3050T Genuine part Makita, Ball Bearing 6001DDW for JR3050T. Part for the following products: - BJR181RFE - Reciprocating Saw 18V-Litio - BJR181SFE - Reciprocating Saw 18V-Litio - BJR182RFE -...
AVAILABLE €3.32
Details
Carbon Brushes CB-303 for Belt Sander Makita 9920X
Makita SKU: 191963-2
Carbon Brushes CB-303 for Belt Sander Makita 9920X
Carbon Brushes CB-303 for Belt Sander Makita 9920X Original spare part Makita, Carbon Brushes CB-303 for Belt Sanders 9920X - 9404X - 9403 - 9902 - 9903. Part for the following products: - 2107FK - BAND SAW - 4100KB - DIAMOND SAW...
AVAILABLE €9.96
Details
Ball Bearing 6001DD for Makita 9218S
Makita SKU: 211131-2
Ball Bearing 6001DD for Makita 9218S
Ball Bearing 6001DD for Makita 9218S Genuine part Makita, Ball Bearing 6001DD for 9218S. Part for the following products: - Reciprocating Saw JR3070CT - Reciprocating Saw JR3060T...
AVAILABLE €6.00
Details
Retaining Ring S12 for Power Tools Makita
Makita SKU: 961052-5
Retaining Ring S12 for Power Tools Makita
Retaining Ring S12 for Power Tools Makita Genuine replacement part Makita, Retaining Ring S12 for Power Tools Makita. Part for the following products: - 2012 12" PLANER - 2030 12" PLANER-JOINTER - 2030N 12-1/2" PLANER-JOINTER WITH...
AVAILABLE €1.40
Details
Retaining Ring for Reciprocating Saw Makita JR3050T
Makita SKU: 257952-8
Retaining Ring for Reciprocating Saw Makita JR3050T
Retaining Ring for Reciprocating Saw Makita JR3050T Original spare parts Makita, Retaining Ring for Reciprocating Saw Makita JR3050T - JR3060T - JR3070CT - BJR182 - DJR187RTE - DJR360ZK. Part for the following products: -  JR3050T -...
on 7/10 Business Days Approx €1.30
Details
Protector for Reciprocating Saw Makita JR3050T
Makita SKU: 424147-0
Protector for Reciprocating Saw Makita JR3050T
Protector for Reciprocating Saw Makita JR3050T Original spare parts Makita, Protector for Reciprocating Saw Makita JR3050T - JR3060T - JR3070CT - BJR182 - DJR187RTE - DJR360ZK. Part for the following products: -  JR3050T -...
on 7/10 Business Days Approx €1.42
Details
Comments (0)
