Makita

Makita Drill HP1300S Parts

SKU: Makita HP1300S
€1.47
VAT included

Makita Spare Parts for Percussion Drill HP1300S

We supply original Makita spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Percussion Drill HP1300S.
Makita Drill HP1300S Parts
  • Makita Drill HP1300S Parts
  • Makita Drill HP1300S Parts Diagram
Makita

Makita Drill HP1300S Parts

SKU: Makita HP1300S Condition: New
€1.47
VAT included

Makita Spare Parts for Percussion Drill HP1300S

We supply original Makita spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Percussion Drill HP1300S.
settings 31 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
CODICE ARTICOLO
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
31 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 251425-3 M6X22 SCREW €1.40
3
 photo_cameraImage coming soon 192877-8 DRILL CHUCK 1/2 X 20 S13 €55.38
4
 photo_cameraImage coming soon 323785-4 SPINDLE €21.54
5
 Woodruf Key mm 4x7,95x4,97 for Angle Grinder Makita 9554NB 254011-9 Woodruf Key mm 4x7,95x4,97 for Angle Grinder Makita 9554NB €1.38
6
 Steel Ball 4,8 mm for Stonecutter Makita HK1820 216002-8 Steel Ball 4,8 mm for Stonecutter Makita HK1820 €1.50
7
 photo_cameraImage coming soon 211206-7 BEARING 6202V €9.76
8
 photo_cameraImage coming soon 253070-0 FLAT WASHER 15 €1.40
9
 photo_cameraImage coming soon 226495-1 HELICAL GEAR 62 €32.73
10
 photo_cameraImage coming soon 153120-0 CAM COMPLETE €50.21
11
 photo_cameraImage coming soon 232053-3 LEAF SPRING €1.40
12
 photo_cameraImage coming soon 411623-3 KNOB €2.69
13
 photo_cameraImage coming soon 321111-1 SHIFTER PIN €11.07
14
 photo_cameraImage coming soon 182400-7 HOUSING SET €44.84
17
 photo_cameraImage coming soon 911124-6 SCREW M4FOR14FOR HM1301 €1.40
18
 photo_cameraImage coming soon 633183-7 FIELD 220V €28.31
19
 photo_cameraImage coming soon 211028-5 BEARING BALLS 627 €10.09
20
 Armature Insulation Washer for Planer Makita N1923B 681614-0 Armature Insulation Washer for Planer Makita N1923B €2.00
21
 photo_cameraImage coming soon 511958-3 ARMATURE ASS'Y 220V €61.62
22
 photo_cameraImage coming soon 241812-4 FAN 58 €8.50
23
 photo_cameraImage coming soon 211033-2 BEARING 608LB €9.89
24
 photo_cameraImage coming soon 191950-1 CARBON BRUSH CB-415 €11.07
26
 photo_cameraImage coming soon 342460-3 HOOK €2.69
28
 photo_cameraImage coming soon 651256-4 SWITCH, JR3000V €44.84
29
 photo_cameraImage coming soon 651478-6 SWITCH VTX11 €16.65
30
 photo_cameraImage coming soon 911133-5 SCREW M4X18 €1.46
31
 photo_cameraImage coming soon 687053-2 CLAMP cable tie €2.21
32
 photo_cameraImage coming soon 682504-0 CORD GUARD 10/85 €3.84
35
 photo_cameraImage coming soon 911143-2 SCREW M4FOR22 €1.40
37
 photo_cameraImage coming soon 911143-2 SCREW M4FOR22 €1.40
39
 photo_cameraImage coming soon 182400-7 HOUSING SET €44.84
400
 photo_cameraImage coming soon 763432-9 CHUCK KEY S13 €5.95
401
 photo_cameraImage coming soon 410102-8 KEY HOLDER €1.53
403
 photo_cameraImage coming soon 152491-2 HANDLE 36 X GV7000C €3.84

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Percussion Drill HP1300S

We supply original Makita spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Percussion Drill HP1300S.

In the following table, look for the model of Drill and the respective parts of the code.
MAKITA HP1300S
MAKITA HP1300S
# Part. Num. Description
1 251425-3 FLAT HEAD SCREW M6X22
3 192877-8 DRILL CHUCK S13
4 323785-4 SPINDLE
5 254011-9 WOODRUFF KEY 4
6 216002-8 STEEL BALL 4.8
7 211206-7 BALL BEARING 6202LLB
8 253070-0 FLAT WASHER 15
9 226495-1 HELICAL GEAR 62
10 153120-0 CAM COMPLETE
11 232053-3 LEAF SPRING
12 411623-3 KNOB
13 321111-1 SHIFTER PIN
14 182400-7 HOUSING SET
INC. 39
17 911124-6 PAN HEAD SCREW M4X14
18 633183-7 FIELD 220V
19 211028-5 BALL BEARING 627LB
20 681614-0 INSULATION WASHER
21 511958-3 ARMATURE ASS'Y 220V
INC. 19,20,22,23
22 241812-4 FAN 58
23 211033-2 BALL BEARING 608LB
24 191950-1 CARBON BRUSH CB-415
26 342460-3 HOOK
28 651256-4 SWITCH SGEL106CV-1A
29 651478-6 SWITCH VTX11
30 911133-5 PAN HEAD SCREW M4X18
31 687053-2 STRAIN RELIEF
32 682504-0 CORD GUARD 10-85
33 691005-7 POWER SUPPLY CORD 0.75-2-2.0
35 911143-2 PAN HEAD SCREW M4X22
36 815559-2 NAME PLATE HP1300S
37 911143-2 PAN HEAD SCREW M4X22
39 182400-7 HOUSING SET
INC. 14
400 763432-9 CHUCK KEY S13
401 410102-8 KEY HOLDER
402 824700-6 PLASTIC CARRYING CASE
403 152491-2 GRIP 36 COMPLETE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HP1300S
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita HP1300S Parts Diagram

Makita HP1300S Parts Diagram

Download (443.23KB)
