Makita

Makita Multi-Tool TM3010C Parts

SKU: Makita TM3010C
€6.29
VAT included

Makita Multi-Tool TM3010C Parts

Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Multi-Tool TM3010C.

Features
- Ergonomic soft grip coating
- Regulator speed
- Constant speed under load
- Slow start
Makita Multi-Tool TM3010C Parts
  • Makita Multi-Tool TM3010C Parts
  • Makita Multi-Tool TM3010C Parts Diagram
Makita

Makita Multi-Tool TM3010C Parts

SKU: Makita TM3010C Condition: New
€6.29
VAT included

Makita Multi-Tool TM3010C Parts

Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Multi-Tool TM3010C.

Features
- Ergonomic soft grip coating
- Regulator speed
- Constant speed under load
- Slow start
settings 85 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
85 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
A01
 photo_cameraImage coming soon 142257-8 TOOL BOX COMPLETE €8.11
A7
 photo_cameraImage coming soon 196550-2 DUST ATTACHMENT SET €6.00
A07-1
 photo_cameraImage coming soon 199624-8 DUST ATTACHMENT SET €6.00
C60
 photo_cameraImage coming soon 422362-0 FELT RING 47 €2.08
C10
 photo_cameraImage coming soon 453974-8 Makita Latch €6.66
C70
 photo_cameraImage coming soon 459362-7 SPACER €1.40
A03-1
 photo_cameraImage coming soon 821550-0 CONNECTOR PLASTIC CASE (TYPE2) €55.51
A03
 photo_cameraImage coming soon 821550-0 CONNECTOR PLASTIC CASE (TYPE2) €55.51
A04
 photo_cameraImage coming soon 837773-0 INNER TRAY €7.45
A09
 photo_cameraImage coming soon B-21325 SEGMENT SAW BLADE 85 TMA00 6 €23.25
A10
 photo_cameraImage coming soon B-21331 SEGMENT SAW BLADE 85 TMA00 €17.17
A11
 photo_cameraImage coming soon B-21353 PLUNGE CUT SAW BLADE 28 TM A009 €17.17
A12
 photo_cameraImage coming soon B-21369 PLUNGE CUT SAW BLADE 32 TM A010 €17.17
A13
 photo_cameraImage coming soon B-21381 PLUNGE CUT SAW BLADE 32 TM A012 €13.45
A14
 photo_cameraImage coming soon B-21428 PLUNGE CUT SAW BLADE 20 TM A016 €13.45
A15
 photo_cameraImage coming soon B-21434 PLUNGE CUT SAW BLADE 10 TM A017 €10.32
A16
 photo_cameraImage coming soon B-21456 SCRAPER 52 FLEXIBLE TMA019 €10.32
A17
 photo_cameraImage coming soon B-21490 HM SEG SAW BLADE 85 TMA023 €33.45
A18
 photo_cameraImage coming soon B-21509 HM SEG SAW BLADE 65 TMA024 €27.76
A19
 photo_cameraImage coming soon B-21537 SANDING PAD €13.45
A20
 photo_cameraImage coming soon B-21624 ABRASIVEPAPER DELTA RED 60 €3.06
A22
 photo_cameraImage coming soon B-21630 ABRASIVEPAPER DELTA RED 80 €3.06
A21
 photo_cameraImage coming soon B-21668 ABRASIVEPAPER DELTA RED 240 €3.06
A23
 photo_cameraImage coming soon B-22947 ABRASIVEPAPER DELTA RED 100 €3.06
A24
 photo_cameraImage coming soon B-22953 ABRASIVEPAPER DELTA RED 150 €3.06
A19-3
 photo_cameraImage coming soon B-46202 SANDING PAD €13.45
A19-1
 photo_cameraImage coming soon B-46202 SANDING PAD €13.45
A09-1
 photo_cameraImage coming soon B-64799 STARLOCK SEGMENTSAW 85 TM A045 €23.94
A11-1
 photo_cameraImage coming soon B-64814 STARLOCK CUTSAW 32 TMA047 BIM €18.68
A10-1
 photo_cameraImage coming soon B-64836 STARLOCK SEGMENTSAW 85 TM A049 €17.68
A10-2
 photo_cameraImage coming soon B-64842 STARLOCK CUTSAW 24 TMA050 €10.61
A11-1
 photo_cameraImage coming soon B-64842 STARLOCK CUTSAW 24 TMA050 €10.61
A13-1
 photo_cameraImage coming soon B-64858 STARLOCK CUTSAW 32 TMA051 HCS €13.85
A12-1
 photo_cameraImage coming soon B-64870 STARLOCK CUTSAW 32 TMA053 €17.68
A15-1
 photo_cameraImage coming soon B-64917 STARLOCK CUTSAW 10 TMA057 BIM €10.61
A15-2
 photo_cameraImage coming soon B-64917 STARLOCK CUTSAW 10 TMA057 BIM €10.61
A14-1
 photo_cameraImage coming soon B-64923 STARLOCK CUTSAW 20 TMA058 BIM €13.85
A14-2
 photo_cameraImage coming soon B-64923 STARLOCK CUTSAW 20 TMA058 BIM €13.85
A16-1
 photo_cameraImage coming soon B-64995 STARLOCK SCRAPERFLEXIBLE TM A66 €10.61
A17-1
 photo_cameraImage coming soon B-65028 STARLOCK SEGMENTSAW 85 TM A069 €34.46
A18-1
 photo_cameraImage coming soon B-65040 STARLOCK SEGMENTSAW 70 TM A071 €28.59
A19-4
 photo_cameraImage coming soon B-65115 STARLOCK SANDING PAD 93 TM A078 €13.85
A19-2
 photo_cameraImage coming soon B-65115 STARLOCK SANDING PAD 93 TM A078 €13.85
1
 photo_cameraImage coming soon 454634-5 FRONT COVER €5.94
1-1
 photo_cameraImage coming soon 455272-6 UPPER HEAD COVER €5.94
2
 photo_cameraImage coming soon 319059-9 LEVER €4.43
3
 photo_cameraImage coming soon 313268-2 FREEZE €3.13
4
 photo_cameraImage coming soon 911102-6 SCREW M4X6 €1.32
5
 photo_cameraImage coming soon 232282-8 PLATE €1.40
6
 photo_cameraImage coming soon 266424-2 SCREW 4X20 TM 3000 €1.40
7
 photo_cameraImage coming soon 268306-4 PIN 5 €1.40
8
 photo_cameraImage coming soon 326346-9 SCREW €6.63
8-1
 photo_cameraImage coming soon 327176-1 HOLDER BOLT €6.63
9
 photo_cameraImage coming soon 266424-2 SCREW 4X20 TM 3000 €1.40
10
 photo_cameraImage coming soon 454635-3 COVER LOWER €1.44
12
 photo_cameraImage coming soon 326347-7 BEARING BOX €7.58
13
 photo_cameraImage coming soon 961003-8 RETAINING RING S7 €1.47
14-1
 photo_cameraImage coming soon 210164-4 SPHERE BEARING 706 €2.69
14
 photo_cameraImage coming soon 211392-4 BALL BEARING 706 TM3000C €44.84
15
 photo_cameraImage coming soon 253133-2 PLAIN WASHER 7 €1.40
16
 photo_cameraImage coming soon 313245-4 ECCENTRIC TM3000C €1.40
17
 Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €9.01
18
 photo_cameraImage coming soon 285857-2 RETAINING BEARING TM3000C €1.40
19
 photo_cameraImage coming soon 240140-4 FAN 46 TM3000 €1.40
20
 photo_cameraImage coming soon 517683-4 ARMATURE TM3000 €44.84
21
 Armature Washer for Angle Grinder Makita GA4530 681636-0 Armature Washer for Angle Grinder Makita GA4530 €2.34
22
 photo_cameraImage coming soon 267426-1 WASHER 7 TM3000C €1.40
23
 photo_cameraImage coming soon 210023-2 9910/11 BEARING €7.16
24
 photo_cameraImage coming soon 267756-0 WAVY WASHER X BO6040 €3.76
25-1
 Magnet Sleeve for Angle Grinder Makita GA4540C 688117-5 Magnet Sleeve for Angle Grinder Makita GA4540C €4.20
25
 photo_cameraImage coming soon 688174-3 MAGNETIC WASHER RT0700CX3 €3.84
26
 photo_cameraImage coming soon 259039-2 LOCKING 6 X 9566CV €3.76
27
 photo_cameraImage coming soon 453828-9 BAFFLE TM3000C €1.40
28
 photo_cameraImage coming soon 266415-3 SCREW 4FOR55 HR2230 €1.40
29
 Stator (FIELD) for Multi-Tool Makita TM3010CX2J 623558-8 Stator (FIELD) for Multi-Tool Makita TM3010CX2J €37.93
30
 photo_cameraImage coming soon 453823-9 HOUSING MOTOR TM3000C €18.98
31
 photo_cameraImage coming soon 453761-5 BUTTON SWITCH TM3000C €1.40
32
 photo_cameraImage coming soon 453825-5 LEVER SWITCH TM3000C €1.40
33
 photo_cameraImage coming soon 234263-8 SPRING COMPRESSION 5 TM3000C €1.40
34
 photo_cameraImage coming soon 651609-7 SWITCH-SS106A 7-1 TM3000 €14.34
35
 Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 643839-4 Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 €3.18
36
 photo_cameraImage coming soon 266492-5 SCREW M4X25-9527PB 9528PB €2.47
37
 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 194722-3 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 €5.37
38
 photo_cameraImage coming soon 654532-5 TERMINAL BLOCK 6E / 1DS €3.76
39
 Strain Relief for Angle Grinder Makita GA4530 687681-3 Strain Relief for Angle Grinder Makita GA4530 €2.51
40-1
 photo_cameraImage coming soon 265B67-9 TAPPING SCREW 4X18 €1.40
40
 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 €1.27
42
 photo_cameraImage coming soon 682569-2 CORD ARMOR MT601 €2.77
44
 photo_cameraImage coming soon 620234-5 REGULATOR €75.83
45
 photo_cameraImage coming soon 453824-7 BACK COVER TM3000C €5.94
46
 photo_cameraImage coming soon 266424-2 SCREW 4X20 TM 3000 €1.40
47
 photo_cameraImage coming soon 142208-1 CRANK HOUSING COMPLETE €139.89
47-1
 photo_cameraImage coming soon 143249-0 GEAR BOX €103.61

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Multi-Tool TM3010C Parts

Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Multi-Tool TM3010C.

In the following table, look for the model of the Multi-Tool and the respective parts of the code.
Makita TM3010C
Multi-Tool TM3010C Parts
# Part Num. Description
1 454634-5 UPPER HEAD COVER
1-1 455272-6 UPPER HEAD COVER
2 319059-9 LEVER
3 313268-2 TURN BLOCK
4 911102-6 PAN HEAD SCREW M4X6
5 232282-8 LEAF SPRING
6 266424-2 TAPPING SCREW 4X20
6-1 265D38-8 TAPPING SCREW 4X20
7 268306-4 PIN 5
8 326346-9 HOLDER BOLT
8-1 327176-1 HOLDER BOLT
9 266424-2 TAPPING SCREW 4X20
9-1 265D38-8 TAPPING SCREW 4X20
10 454635-3 LOWER HEAD COVER
11 213343-3 O RING 35
11-1 213A08-3 O RING 35
12 326347-7 BEARING BOX
13 961003-8 RETAINING RING S-7
14 211392-4 SPHERE BEARING 706
14-1 210164-4 SPHERE BEARING 706
15 253133-2 FLAT WASHER 7
16 313245-4 BALANCER
17 211092-6 BALL BEARING 629DDW
18 285857-2 BEARING RETAINNER
19 240140-4 FAN 46
20 517683-4 ARMATURE ASSEMBLY 220-240V
20 INC. 19,21-26
21 681636-0 INSULATION WASHER
22 267426-1 FLAT WASHER 7
23 210023-2 BALL BEARING 627DDW
24 267756-0 WAVE WASHER 6
25 688174-3 MAGNET SLEEVE
25-1 688117-5 MAGNET SLEEVE
26 259039-2 SELF LOCK 6
27 453828-9 BAFFLE PLATE
28 266415-3 TAPPING SCREW 4X55
28-1 265D37-0 TAPPING SCREW 4X55
29 623558-8 STATOR FIELD TM3000C
30 453823-9 MOTOR HOUSING
31 453761-5 SWITCH KNOB
32 453825-5 SWITCH LEVER
33 234263-8 COMPRESSION SPRING 5
34 651609-7 SWITCH SS106A-7-1
35 643839-4 BRUSH HOLDER 6X9
36 266492-5 TAPPING SCREW 3X8
36-1 265D33-8 TAPPING SCREW 3X8
37 194722-3 CARBON BRUSH CB-459
37-1 195026-6 CARBON BRUSH SET CB-459
38 654532-5 TERMINAL BLOCK 1P
39 687681-3 STRAIN RELIEF
40 266326-2 TAPPING SCREW 4X18
40-1 265B67-9 TAPPING SCREW 4X18
41 665399-6 POWER SUPPLY CORD 1.0-2-5.0
42 682569-2 CORD GUARD 8-85
43 814T82-4 TM3010C NAME PLATE
44 620234-5 CONTROLLER
45 453824-7 REAR COVER
46 266424-2 TAPPING SCREW 4X20
46-1 265D38-8 TAPPING SCREW 4X20
47 142208-1 CRANK HOUSING COMPLETE
47-1 143249-0 CRANK HOUSING COMPLETE
A01 142257-8 TOOL BOX COMPLETE
C10 454652-3 LATCH
A01-1 143308-0 TOOL BOX COMPLETE WITH LABEL
C10 454652-3 LATCH
A02 454247-2 PIN 4
A03 821550-0 CONNECTOR PLASTIC CASE (TYP E2)
C10 453974-8 LATCH
A03-1 821550-0 CONNECTOR PLASTIC CASE (TYP E2)
C10 453974-8 LATCH
A04 837773-0 INNER TRAY
A05 802B42-0 TM3010CJ INDICATION LABEL
A05 802B46-2 TM3010CX2J INDICATION LABEL
A05 802B52-7 TM3010CX5J INDICATION LABEL
A06 802B43-8 TM3010CJ PLASTIC CASE LABEL
A06 802B47-0 TM3010CX2J PLASTIC CASE LABE L
A6 8007F7-8 TM3010CX5J PLASTIC CASE LABE L
A7 196550-2 DUST ATTACHMENT SET
C10 443177-2 FELT RING 37
C20 453832-8 JOINT
C30 453835-2 NOZZLE BAND A
C40 454636-1 DUST ATTACHMENT
C50 454637-9 DUST NOZZLE D
A07-1 199624-8 DUST ATTACHMENT SET
C10 443177-2 FELT RING 37
C20 453832-8 JOINT
C30 453835-2 NOZZLE BAND A
C40 454636-1 DUST ATTACHMENT
C50 454637-9 DUST NOZZLE D
C60 422362-0 FELT RING 47
C70 459362-7 SPACER
A08 196272-4 ADAPTER A SET
A08-1 196271-6 ADAPTER A SET
A09 B-21325 SEGMENT SAW BLADE 85 TMA00 6
A09-1 B-64799 STARLOCK SEGMENTSAW 85 TM A045
A10 B-21331 SEGMENT SAW BLADE 85 TMA00
A10-1 B-64836 STARLOCK SEGMENTSAW 85 TM A049
A10-2 B-64842 STARLOCK CUTSAW 24 TMA050
A11 B-21353 PLUNGE CUT SAW BLADE 28 TM A009
A11-1 B-64814 STARLOCK CUTSAW 32 TMA047 BIM
A11-1 B-64842 STARLOCK CUTSAW 24 TMA050 HCS
A12 B-21369 PLUNGE CUT SAW BLADE 32 TM A010
A12-1 B-64870 STARLOCK CUTSAW 32 TMA053
A13 B-21381 PLUNGE CUT SAW BLADE 32 TM A012
A13-1 B-64858 STARLOCK CUTSAW 32 TMA051 HCS
A14 B-21428 PLUNGE CUT SAW BLADE 20 TM A016
A14-1 B-64923 STARLOCK CUTSAW 20 TMA058 BIM
A14-2 B-64923 STARLOCK CUTSAW 20 TMA058 BIM
A15 B-21434 PLUNGE CUT SAW BLADE 10 TM A017
A15-1 B-64917 STARLOCK CUTSAW 10 TMA057 BIM
A15-2 B-64917 STARLOCK CUTSAW 10 TMA057 BIM
A16 B-21456 SCRAPER 52 FLEXIBLE TMA019
A16-1 B-64995 STARLOCK SCRAPERFLEXIBLE TM A66
A17 B-21490 HM SEG SAW BLADE 85 TMA023
A17-1 B-65028 STARLOCK SEGMENTSAW 85 TM A069
A18 B-21509 HM SEG SAW BLADE 65 TMA024
A18-1 B-65040 STARLOCK SEGMENTSAW 70 TM A071
A19 B-21537 SANDING PAD
A19-1 B-46202 SANDING PAD
A19-2 B-65115 STARLOCK SANDING PAD 93 TM A078
A19-3 B-46202 SANDING PAD
A19-4 B-65115 STARLOCK SANDING PAD 93 TM A078
A20 B-21624 ABRASIVEPAPER DELTA RED 60
A21 B-21668 ABRASIVEPAPER DELTA RED 240
A22 B-21630 ABRASIVEPAPER DELTA RED 80
A23 B-22947 ABRASIVEPAPER DELTA RED 100
A24 B-22953 ABRASIVEPAPER DELTA RED 150
A25 821591-6 TOOL BOX
C10 454652-3 LATCH
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita TM3010C
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita TM3010C Parts Diagram

Makita TM3010C Parts Diagram

Download (281.09KB)

You might also like

Carbon Brushes for Angle Grinders Makita GA4530-4534-5034
Makita SKU: 194722-3
Carbon Brushes for Angle Grinders Makita GA4530-4534-5034
Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 Makita genuine spare parts, Carbon Brusches for Angle grinders GA4530 - GA4534 - GA5034. Part for the following products: - GA4530 - GA4534 - GA5034 CUTTERS - JS1000 - JS1602...
AVAILABLE €5.37
Details
Bearing 629DD FOR Angle Grinder Makita GA4530
Makita SKU: 211092-6
Bearing 629DD FOR Angle Grinder Makita GA4530
Bearing 629DD FOR Angle Grinder Makita GA4530 Genuine part Makita, Ball Bearing 629DD for Angle Grinders GA4530 - GA4530R - GA4534 - GA5034 - GA9000 - 9541-9542. Parts for the following products: - GA4530 - ANGLE GRINDER 115MM -...
AVAILABLE €9.01
Details
Armature Washer for Angle Grinder Makita GA4530
Makita SKU: 681636-0
Armature Washer for Angle Grinder Makita GA4530
Armature Washer for Angle Grinder Makita GA4530 Genuine spare Makita, Armature Protection Washer for Angle Grinders GA4530 - GA4530R - GA4534 - GA5034 - 9521NB - 9554HN - 9557HN...
AVAILABLE €2.34
Details
Strain Relief for Angle Grinder Makita GA4530 Sale
Makita SKU: 687681-3
Strain Relief for Angle Grinder Makita GA4530
Strain Relief for Angle Grinder Makita GA4530 Genuine part Makita, Strain Relief for Angle GrinderS GA4530 - GA4530R - GA4534 -  GA5034 - Plate Joiner PJ7000. Parts for the following products: - GA4530 - ANGLE GRINDER 115MM 720W -...
AVAILABLE €2.51
Details
Magnet Sleeve for Angle Grinder Makita GA4540C
Makita SKU: 688117-5
Magnet Sleeve for Angle Grinder Makita GA4540C
Magnet Sleeve for Angle Grinder Makita GA4540C Genuine Replacement Part Makita, Magnet Sleeve for Angle Grinders GA4540C - GA4541C - GA5040C - GA4541C - 9561CVH -  9561CVR. Part for the following products: - 3707FC - TRIMMER 6MM 500W...
AVAILABLE €4.20
Details
Stator (FIELD) for Multi-Tool Makita TM3010CX2J
Makita SKU: 623558-8
Stator (FIELD) for Multi-Tool Makita TM3010CX2J
Stator (FIELD) for Multi-Tool Makita TM3010CX2J Genuine replacement part Makita, Stator 220-240V (FIELD) for Multi-Tool 320W + Accessories TM3010CX2J. Part for the following products: - TM3000C...
on 7/10 Business Days Approx. €37.93
Details
Comments (0)
