| Makita SG181 - WALL CHASER 2150W 180MM | ||
| # | Part Num. | Description |
| 1 | B09172 | ARMATURE |
| 2 | B22681 | BALL BEARING 6000 2RS |
| 3 | B08306 | SCREW 5X20 |
| 4 | B08890 | GEAR BOX |
| 5 | B33415 | SCREW M5 X 20 X SG150 |
| 6 | B07450 | SCREW M4.8 X 80 X SG150 |
| 7 | B30387 | PLATE 0.3 X SG150 |
| 8 | B30148 | RING 46X2 X SG2150 |
| 9 | B09171 | SPINDLE CPL |
| 17 | B07756 | SCREW 4X90 |
| 20 | B11122 | BOLT M 8 X 90 X SG150 |
| 21 | B11189 | WASHER 8.4 X SG150 |
| 22 | B10777 | ROLLER X SG150 |
| 23 | B11247 | TUBE X SG150 |
| 24 | B18952 | NUT M8 X SG150 |
| 25 | B10983 | BOLT M 8 X 16 X SG150 |
| 26 | B29934 | OUTER FLANGE X SG150 |
| 27 | B30486 | RING 3 X SG150 |
| 29 | B08845 | FLANGE B |
| 30 | B08847 | FLANGE A |
| 31 | B06879 | SCREW M8X70 |
| 32 | B07692 | DISC GUARD |
| 33 | B08482 | SIDE HANDLE X SG150 |
| 35 | B21071 | WASHER M8 X SG150 |
| 37 | B08042 | BAFFLE |
| 38 | B73536 | FIELD ASSY |
| 39 | B50807 | MOTOR CASING X SG150 |
| 41 | B45872 | CARBON BRUSH X SG150 (single) |
| 42 | B52894 | CARBON BRUSH HOLDER X SG150 |
| 43 | B38299 | CARBON BRUSH HOLDER COVER X SG180 |
| 44 | B21030 | SCREW M3.9 X 13 X SG150 |
| 45 | B30981 | BOLT M 7 X 12 X SG150 |
| 46 | B31070 | WASHER 7.4 X SG150 |
| 47 | B10801 | SUPPORT X SG150 |
| 48 | B26948 | WASHER 13 X SG150 |
| 49 | B09506 | TENSION ROLLER X SG150 |
| 50 | B31096 | TUBE X SG150 |
| 51 | B48611 | COMPLETE HANDLE X SG150 |
| 53 | B44941 | SCREW M4.8 X 38 X SG150 |
| 54 | B71787 | ELECTRONIC BOARD |
| 55 | B31468 | SWITCH X SG150 |
| 57 | B17913 | CLAMP X 2702 |
| 58 | B25221 | CORD GUARD SG150 |
