Makita Spare Parts for Rotary Hammer HR1841FJ

SKU: Makita HR1841FJ
€1.42
VAT included

Makita Spare Parts for Rotary Hammer HR1841FJ

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for SDS+ 18MM 2-FUNZIONI HR1841FJ.
Makita Spare Parts for Rotary Hammer HR1841FJ
  • Makita Spare Parts for Rotary Hammer HR1841FJ
  • Makita Spare Parts for Rotary Hammer HR1841FJ - Drawing
Makita

Makita Spare Parts for Rotary Hammer HR1841FJ

SKU: Makita HR1841FJ Condition: New
€1.42
VAT included

Makita Spare Parts for Rotary Hammer HR1841FJ

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for SDS+ 18MM 2-FUNZIONI HR1841FJ.
settings 82 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
82 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 286037-3 CAP 34 €1.25
2
 Makita Power Tools Ext DIN471 Circlip-17 961057-5 Makita Power Tools Ext DIN471 Circlip-17 €1.47
3
 photo_cameraImage coming soon 253470-4 FLAT WASHER 17 €1.25
4
 photo_cameraImage coming soon 457214-6 SLEEVE €1.25
5
 photo_cameraImage coming soon 257416-2 RING 21 €1.25
6
 Steel Ball 7 mm for Hammers Makita 216022-2 Steel Ball 7 mm for Hammers Makita €1.47
7
 Guide Washer for Rotary Hammer Makita HR2601 346177-0 Guide Washer for Rotary Hammer Makita HR2601 €1.41
8
 photo_cameraImage coming soon 232347-6 CONICAL COMPRESSION SPRING 21-29 €1.25
9
 photo_cameraImage coming soon 921919-9 BOLT M8X110 €5.13
10
 photo_cameraImage coming soon 194581-5 GRIP BASE €16.77
11
 photo_cameraImage coming soon 266048-4 VITE M 4 PER 40 PER 4334D €3.51
12
 photo_cameraImage coming soon 144271-0 GEAR HOUSING COMPLETE HR1841F €19.03
13
 photo_cameraImage coming soon 213278-8 RING 13 X HR2020 €1.40
14
 photo_cameraImage coming soon 161568-2 LOCK BUTTON €1.25
15
 photo_cameraImage coming soon 232344-2 COMPRESSION SPRING 3 €1.25
16
 photo_cameraImage coming soon 161569-0 CHANGE LEVER COMPLETE €1.86
17
 photo_cameraImage coming soon 158057-6 HANDLE 36 CPL HR2230 €10.01
20
 photo_cameraImage coming soon 347555-7 RETAINING RING 25 €1.25
21
 photo_cameraImage coming soon 267304-5 WASHER 25 HR1830 €1.25
22
 photo_cameraImage coming soon 232360-4 COMPRESSION SPRING 25 HR1841F €1.25
23
 photo_cameraImage coming soon 221494-8 SPUR GEAR 44 HR1841F €5.25
24
 photo_cameraImage coming soon 327039-1 DRIVING FLANGE HR1841F €3.40
25
 photo_cameraImage coming soon 216019-1 STEEL BALL 3 X 6960DW €1.42
26
 photo_cameraImage coming soon 326886-7 TOOL HOLDER HR1841F €16.77
27
 photo_cameraImage coming soon 326887-5 IMACT BOLT HR1841F €1.86
28
 photo_cameraImage coming soon 213117-2 O-O-RING 11 HR2410 €7.03
29
 photo_cameraImage coming soon 253380-5 FLAT WASHER 13 HR1841F €1.25
30
 photo_cameraImage coming soon 326888-3 RING 60 HR1841F €1.86
31
 photo_cameraImage coming soon 232357-3 COMPRESSION SPRING 10A HR1841F €1.25
32
 photo_cameraImage coming soon 327038-3 CU SLEEVE HR1841F €2.78
33
 photo_cameraImage coming soon 233942-5 O- RING 22 €1.25
34
 photo_cameraImage coming soon 267175-0 FLAT WASHER 24 6914DW €1.43
35
 photo_cameraImage coming soon 345681-6 FLANGE HR1830 €1.25
36
 photo_cameraImage coming soon 347128-6 CHANGE PLATE HR1841F €1.86
37
 photo_cameraImage coming soon 233458-0 COMPRESSION SPRING 32 HR1830 €1.25
38
 photo_cameraImage coming soon 326889-1 STRIKER HR1841F €2.78
39
 photo_cameraImage coming soon 213832-8 O-RING 13 HR1841F €1.25
40
 photo_cameraImage coming soon 326890-6 PYSTON CYLINDER HR1841F €5.86
41
 photo_cameraImage coming soon 347127-8 GUIDE PLATE HR1841F €1.25
42
 photo_cameraImage coming soon 324612-8 PISTON PIN X X HR1830 €1.86
43
 photo_cameraImage coming soon 232361-2 COMPRESSION SPRING 6-13 HR1841F €1.25
44
 photo_cameraImage coming soon 347130-9 SPRING GUIDE HR1841F €1.25
45
 photo_cameraImage coming soon 211016-2 BALL BEARING 626DD €7.03
46
 photo_cameraImage coming soon 221495-6 SPUR GEAR 12 HR1841F €2.78
47
 photo_cameraImage coming soon 326892-2 CAM SHAFT HR1841F €3.40
48
 photo_cameraImage coming soon 326891-4 CLUTCH CAM HR1841F €3.92
49
 photo_cameraImage coming soon 219029-7 SEASH BEARING 9 HR1841F €19.03
50
 photo_cameraImage coming soon 253733-8 FLAT WASHER 9 X 2708 €1.36
51
 photo_cameraImage coming soon 251510-2 HSH BOLT M3X12 €1.25
52
 photo_cameraImage coming soon 253381-3 FLAT WASHER 3 HR1841F €1.25
53
 photo_cameraImage coming soon 347129-4 SPRING PLATE HR1841F €1.86
54
 photo_cameraImage coming soon 221496-4 HELICAL GEAR 23 HR1841F €4.54
55
 photo_cameraImage coming soon 211016-2 BALL BEARING 626DD €7.03
56
 photo_cameraImage coming soon 232359-9 COMPRESSION SPRING 7 HR1841F €1.25
57
 photo_cameraImage coming soon 213833-6 O-RING 60 HR1841F €1.25
58
 photo_cameraImage coming soon 144270-2 INNER HOUSING COMPLETE HR1841F €21.50
59
 photo_cameraImage coming soon 213118-0 O-RING 12 X HR5210C €1.42
60
 photo_cameraImage coming soon 326893-0 RING 9 HR1841F €1.86
61
 photo_cameraImage coming soon 210162-8 BALL BEARING 609LLU HR1841F €5.25
62
 photo_cameraImage coming soon 267231-6 FLAT WASHER 9 X HR2020 €1.36
63
 photo_cameraImage coming soon 513989-8 ARMATURE ASSY HR1841F €39.60
64
 photo_cameraImage coming soon 681670-0 INSULATION WASHER X JR180D €1.34
65
 photo_cameraImage coming soon 210193-7 BALL BEARING 627DDW, RT0700C €4.54
66
 photo_cameraImage coming soon 267804-5 WAVY WASHER 15 HR2230 €1.25
67
 photo_cameraImage coming soon 457350-8 BAFFLE PLATE A HR1841F €1.25
68
 photo_cameraImage coming soon 266425-0 SCREW 4X45 MT924 €1.43
69
 photo_cameraImage coming soon 633994-0 FIELD HR1841F €11.22
70
 photo_cameraImage coming soon 256347-2 ROD 5 HR1841F €1.25
71
 photo_cameraImage coming soon 457352-4 MOTOR HOUSING A HR1841 €7.51
72
 photo_cameraImage coming soon 232358-1 COMPRESSION SPRING 10B HR1841F €1.25
73
 photo_cameraImage coming soon 424951-7 BELLOWS HR1841F €2.39
74
 photo_cameraImage coming soon 457355-8 HANDLE COMPLETE HR1841F €8.74
75
 photo_cameraImage coming soon 257417-0 SLEEVE 8 HR1841F €1.25
76
 photo_cameraImage coming soon 251530-6 TAPPING SCREW 4X18 HR1841F €1.25
77
 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 194722-3 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 €5.37
78
 photo_cameraImage coming soon 632K41-0 BRUSH HOLDER UNIT HR1841F €9.79
79
 photo_cameraImage coming soon 631937-6 CIRCUIT LIGHT HR2611FT €8.74
80
 photo_cameraImage coming soon 265620-9 TAPPING SCREW 4X18 €1.44
81
 photo_cameraImage coming soon 457354-0 HANDLE COVER HR1841F €7.51
82
 photo_cameraImage coming soon 266385-6 SCREW 4x14 GA9020 €1.44
83
 photo_cameraImage coming soon 687682-1 CLAMP Cable tie X JS1000 €2.95
84
 photo_cameraImage coming soon 682566-8 CORD GUARD X HR2450 €2.15
86
 photo_cameraImage coming soon 651086-3 SWITCH HR1841F €16.77

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Rotary Hammer HR1841FJ

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for SDS+ 18MM 2-FUNZIONI HR1841FJ.

In the following table, look for the model of the Cordless Rotary Hammer Drill and the respective parts of the code.
Makita HR1841FJ

MAKITA ROTARY HAMMER SDS+ 18MM 2-FUNZIONI HR1841FJ
# Part Num. Description
1 286037-3 CAP 34
2 961057-5 RETAINING RING S17
3 253470-4 FLAT WASHER 17
4 457214-6 SLEEVE
5 257416-2 RING 21
6 216022-2 STEEL BALL 7
7 346177-0 GUIDE WASHER HR2601
8 232347-6 CONICAL COMPRESSION SPRING 21-29
9 921919-9 HEX HEAD BOLT M8X110
10 194581-5 GRIP BASE
11 266048-4 TAPPING SCREW M 4 X 40 X 4334D
12 144271-0 GEAR HOUSING COMPLETE HR1841F
13 213278-8 O-RING 13 X HR2020
14 161568-2 LOCK BUTTON
15 232344-2 COMPRESSION SPRING 3
16 161569-0 CHANGE LEVER COMPLETE
17 158057-6 GRIP 36 CPL HR2230
20 347555-7 SPIRAL RETAINING RING 25
21 267304-5 FLAT WASHER 25 HR1830
22 232360-4 COMPRESSION SPRING 25 HR1841F
23 221494-8 SPUR GEAR 44 HR1841F
24 327039-1 DRIVING FLANGE HR1841F
25 216019-1 STEEL BALL 3 X DHR24 * / HR26 **
26 326886-7 TOOL HOLDER HR1841F
27 326887-5 IMPACT BOLT HR1841F
28 213117-2 O RING 11 HR2410
29 253380-5 FLAT WASHER 13 HR1841F
30 326888-3 RING 60 HR1841F
31 232357-3 COMPRESSION SPRING 10A HR1841F
32 327038-3 CUP SLEEVE HR1841F
33 233942-5 RING SPRING 22
34 267175-0 FLAT WASHER 24 6914DW
35 345681-6 JOINT PLATE HR1830
36 347128-6 CHANGE PLATE HR1841F
37 233458-0 COMPRESSION SPRING 32 HR1830
38 326889-1 STRIKER HR1841F
39 213832-8 O-RING 13 HR1841F
40 326890-6 PISTON CYLINDER HR1841F
41 347127-8 GUIDE PLATE HR1841F
42 324612-8 PIN X PISTON X HR1830
43 232361-2 SPRING COMPRESSION 6-13 HR1841F
44 347130-9 SPRING GUIDE HR1841F
45 211016-2 BALL BEARING 626DD
46 221495-6 SPUR GEAR 12 HR1841F
47 326892-2 CAM SHAFT HR1841F
48 326891-4 CLUTCH CAM HR1841F
49 219029-7 SW ASH BEARING 9 HR1841F
50 253733-8 FLAT WASHER 9 X 2708
51 251510-2 HSH BOLT M3X12 W/WRM
52 253381-3 FLAT WASHER 3 HR1841F
53 347129-4 SPRING PLATE HR1841F
54 221496-4 HELICAL GEAR 23 HR1841F
55 211016-2 BALL BEARING 626DD
56 232359-9 COMPRESSION SPRING 7 HR1841F
57 213833-6 O-RING 60 HR1841F
58 144270-2 INNER HOUSING COMPLETE HR1841F
59 213118-0 O-RING 12 X HR5210C
60 326893-0 RING 9 HR1841F
61 210162-8 BALL BEARING 609LLU HR1841F
62 267231-6 FLAT WASHER 9 X HR2020
63 513989-8 ARMATURE ASSY HR1841F
64 681670-0 INSULATION WASHER
65 210193-7 BALL BEARING 627DDW
66 267804-5 WAVE WASHER 15 HR2230
67 457350-8 BAFFLE PLATE A HR1841F
68 266425-0 TAPPING SCREW 4X45 MT924
69 633994-0 FIELD HR1841F
70 256347-2 ROD 5 HR1841F
71 457352-4 MOTOR HOUSING A HR1841
72 232358-1 COMPRESSION SPRING 10B HR1841F
73 424951-7 BELLOWS HR1841F
74 457355-8 HANDLE COMPLETE HR1841F
75 257417-0 SLEEVE 8 HR1841F
76 251530-6 TAPPING SCREW 4X18 HR1841F
77 194722-3 CARBON BRUSH CB 459 2 PC/SET GA4530
78 632K41-0 BRUSH HOLDER UNIT HR1841F
79 631937-6 LIGHT CIRCUIT HR2611FT
80 265620-9 TAPPING SCREW 4X18
81 457354-0 HANDLE COVER HR1841F
82 266385-6 TAPPIMG SCREW 4X14 GA9020
83 687682-1 STRAIN RELIEFE JS1000
84 682566-8 CORD GUARD HR2450
86 651086-3 SWITCH HR1841F

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HR1841FJ
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Drawing Makita HR1841FJ

Drawing Makita HR1841FJ

Download (318.93KB)

You might also like

Carbon Brushes for Angle Grinders Makita GA4530-4534-5034
Makita SKU: 194722-3
Carbon Brushes for Angle Grinders Makita GA4530-4534-5034
Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 Makita genuine spare parts, Carbon Brusches for Angle grinders GA4530 - GA4534 - GA5034. Part for the following products: - GA4530 - GA4534 - GA5034 CUTTERS - JS1000 - JS1602...
AVAILABLE €5.37
Details
Steel Ball 7 mm for Hammers Makita
Makita SKU: 216022-2
Steel Ball 7 mm for Hammers Makita
Steel Ball 7 mm for Hammers Makita Genuine spare part Makita, Steel Ball 7 mm diameter for Hammers SDS Plus and Cordless, BHR162RFE - BHR200SFE - BHR240RFE - BHR241RFE - BHR261DP1 - DHR263Z - HR1830 -  HR2420 - HR2611FT....
build View Spare Parts
Bearing for Angle Grinder Makita 9524NB
Makita SKU: 211012-0
Bearing for Angle Grinder Makita 9524NB
Bearing for Angle Grinder Makita 9524NB Genuine spare Makita, Ball Bearing 606 2Z for Angle Grinder 9524NB. Part for the following products: - CIRCULAR SAW 165 MM 5604R - CIRCULAR SAW 165 MM-18V 2.2Ah Ni-MH 5621RDWBE - KEYLESS DRILL...
AVAILABLE €8.23
Details
Spring 21-29 for 20 mm Hammer Makita HR2020
Makita SKU: 233916-6
Spring 21-29 for 20 mm Hammer Makita HR2020
Spring 21-29 for 20 mm Hammer Makita HR2020 Original spare Makita, 21-29 Spring for 20 mm Hammerdrill SDS Plus 710 W Makita HR2020. Part for the following products: - Hammer SDS-PLUS 18MM 1830 - Hammer 24MM 750W 2450 - Hammer 720W...
AVAILABLE €3.18
Details
Ring 21 for Chuck Hammer Makita HR2020
Makita SKU: 257241-1
Ring 21 for Chuck Hammer Makita HR2020
Ring 21 for Chuck Hammer Makita HR2020 Genuine part Makita, Ring 21 for Hammers HR1830 - HR2020 - HR2230 - BHR162-202-240-241-261-262RFE - DHR164Z. Parts for the following products: - BHR162RFE - Cordless Hammer 14.4V LITHIUM BATTERY...
AVAILABLE €3.31
Details
Cover Cap Bits for Rotary Hammer MAKITA HR2020
Makita SKU: 286263-4
Cover Cap Bits for Rotary Hammer MAKITA HR2020
Cover Cap Bits for Rotary Hammer MAKITA HR2020 Original parts Makita, Cover Cap for Rotary Hammers BHR162RFE - BHR202RFE - BHR240RFE - BHR241RFE - BHR243RFE - BHR261DP1 - BHR261TDP1 - BHR262RDE - BHR262TRDE - DHR164Z - DHR165Z -...
Last items in stock €4.86
Details
Elastic Ring 19 for HAMMER Makita HR2020
Makita SKU: 233940-9
Elastic Ring 19 for HAMMER Makita HR2020
Elastic Ring 19 for HAMMER Makita HR2020 Genuine spare Makita, Elastic Ring 19 for Hammers HK1820 - HR1830 - HR2020 - HR2230 - HR2432 - HR2440 - HR2450 - HR2450F - HR2450FT - HR2450X - HR2460 - HR2470 - HR2470F - HR2470FT - HR2610T -...
AVAILABLE €1.50
Details
Compression Spring 3 for Rotary Hammer Makita HR1830
Makita SKU: 233459-8
Compression Spring 3 for Rotary Hammer Makita HR1830
Compression Spring 3 for Rotary Hammer Makita HR1830 Genuine spare part Makita, Compression Spring 3 for Rotary Hammer SDS PLUS 18 mm Makita HR1830 For the Following Items : -  HR1830 - ROTARY HAMMER SDS+18MM 2 FUNCTIONS -  BHR162 -...
AVAILABLE €1.43
Details
Guide Washer for Rotary Hammer Makita HR2601
Makita SKU: 346177-0
Guide Washer for Rotary Hammer Makita HR2601
Guide Washer for Rotary Hammer Makita HR2601 Genuine spare part Makita, Guide Washer for Rotary Hammers Makita HR2600 - HR2601 - HR2611F - HR2630 - HR2631F. Parts for the following products: -  HR2300 - ROTARY HAMMER SDS.+ 720W -...
on 7/10 Business Days Approx. €1.41
Details
Comments (0)
