Makita

Makita Spare Parts for Rotary Hammer HR3540C

SKU: Makita HR3540C
€2.73
VAT included

Makita Spare Parts for Rotary Hammer HR3540C

We have the original Makita Spare Parts for Rotary Hammer HR3540C, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Rotary Hammer HR3540C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Makita Spare Parts for Rotary Hammer HR3540C
  • Makita Spare Parts for Rotary Hammer HR3540C
  • Makita Spare Parts for Rotary Hammer HR3540C
Makita

Makita Spare Parts for Rotary Hammer HR3540C

SKU: Makita HR3540C Condition: New
€2.73
VAT included

Makita Spare Parts for Rotary Hammer HR3540C

We have the original Makita Spare Parts for Rotary Hammer HR3540C, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Rotary Hammer HR3540C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 106 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
106 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 286269-2 TOOL HOLDER CAP HM0860C €2.29
2
 photo_cameraImage coming soon 450592-3 CHUCK COVER X HR3540C €3.09
3
 Retaining Ring for Rotary Hammer Makita HR50001C 231984-3 Retaining Ring for Rotary Hammer Makita HR50001C €2.01
4
 photo_cameraImage coming soon 331823-8 CHUCK RING HR3540C €10.16
5
 photo_cameraImage coming soon 310257-8 TOOL RETAINER X HR3540C €6.73
6
 photo_cameraImage coming soon 345928-8 GUIDE SPRING X HR3540C €6.81
7
 photo_cameraImage coming soon 234063-6 COMPRESSION SPRING 52 X Hr3540C €3.09
8
 photo_cameraImage coming soon 345976-7 SPRING HOLDER X HR3540C €3.09
9
 photo_cameraImage coming soon 424110-3 RUBBER RING 13 X HR3540C €5.32
18
 photo_cameraImage coming soon 922341-3 SCREW M6X25 €1.44
19
 photo_cameraImage coming soon 158674-2 BARREL CPL X HR3540C €22.62
20
 Seal 53 for Demolition Hammer MAKITA HM1200 213656-2 Seal 53 for Demolition Hammer MAKITA HM1200 €1.46
21
 photo_cameraImage coming soon 257294-0 O-RING 38 X HR3540C €6.07
22
 photo_cameraImage coming soon 262143-8 RING URETHANE 38 X HR3540C €2.16
23
 photo_cameraImage coming soon 267381-7 WASHER 39 X HR3540C €2.53
24
 photo_cameraImage coming soon 324900-3 TOOL HOLDER HR3540C €60.56
25
 photo_cameraImage coming soon 324901-1 IMPACT BOLT HR3540C €10.16
26
 O-Ring 19 for Power Scraper Makita HK1800 213309-3 O-Ring 19 for Power Scraper Makita HK1800 €2.12
27
 O-Ring 19 for Power Scraper Makita HK1800 213309-3 O-Ring 19 for Power Scraper Makita HK1800 €2.12
28
 photo_cameraImage coming soon 213996-8 O-RING 24 X HR3540C €4.12
29
 photo_cameraImage coming soon 324899-2 RING 13 X HR3540C €4.12
30
 photo_cameraImage coming soon 324838-2 PLATE SLIDE X HR3200C €2.91
32
 photo_cameraImage coming soon 331822-0 CYLINDER 25 X HR3540C €100.54
33
 photo_cameraImage coming soon 450243-8 SLIDE SLEEVE X HR3200C €2.45
34
 photo_cameraImage coming soon 331805-0 O-RING 29 X HR3200C €8.19
35
 photo_cameraImage coming soon 267360-5 WASHER 40 X HR3200C €2.45
36
 photo_cameraImage coming soon 234052-1 COMPRESSION SPRING 42 HR3200C €2.45
37
 photo_cameraImage coming soon 450236-5 LOCK SLEEVE HR3200C €2.45
38
 photo_cameraImage coming soon 234050-5 COMPRESSION SPRING 34 HR3200C €1.88
39
 photo_cameraImage coming soon 331795-7 DRIVING SLEEVE X HR3200C €27.72
41
 photo_cameraImage coming soon 324898-4 STRIKER X HR3540C €6.07
42
 photo_cameraImage coming soon 213283-5 RING 18 X HR3200C €2.45
43
 photo_cameraImage coming soon 213283-5 RING 18 X HR3200C €2.45
45
 photo_cameraImage coming soon 324918-4 PISTON X HR3200C €21.06
46
 photo_cameraImage coming soon 213262-3 O-RING 18 4100R €2.59
47
 photo_cameraImage coming soon 450235-7 ROD X HR3200C €1.88
48
 Spiral Bevel Gear 37 for Hammer Makita HR3200C 227531-6 Spiral Bevel Gear 37 for Hammer Makita HR3200C €37.21
49
 photo_cameraImage coming soon 345867-2 LEVERAGE HR3200C €5.67
64
 photo_cameraImage coming soon 266041-8 PT SCREW 5x25 €1.24
65
 photo_cameraImage coming soon 922128-3 BOLT M4x16 4300BA €1.44
66
 photo_cameraImage coming soon 450594-9 CRANK HOUSING COVER HR3540 - HR3540C €10.16
67
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
68
 photo_cameraImage coming soon 318201-9 CRANK CAP COVER HR3200C €12.33
69
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
70
 photo_cameraImage coming soon 450249-6 LEVER CPL X HR3200C €2.91
71
 photo_cameraImage coming soon 233436-0 COMPRESSION SPRING 3 HR4001C/HR4010C €1.70
72
 photo_cameraImage coming soon 450250-1 BUTTON LOCK X HR3200C €1.88
73
 photo_cameraImage coming soon 911526-6 SCREW M4 X 14 X HR2420 €3.18
74
 photo_cameraImage coming soon 450241-2 CRANK CAP €3.60
76
 photo_cameraImage coming soon 158437-6 GEAR 33 X HR3200C €2.45
78
 photo_cameraImage coming soon 345868-0 LINK PLATE HR3200C €1.88
79
 photo_cameraImage coming soon 450247-0 AIR PIPE HR3200C €2.45
80
 photo_cameraImage coming soon 263005-3 PIN RUBBER 6 €1.32
81
 Pinion for Hammers Makita HR3200C 452126-8 Pinion for Hammers Makita HR3200C €3.18
82
 photo_cameraImage coming soon 158713-8 HOUSING ROD X HR3200C €44.74
83
 photo_cameraImage coming soon 443138-2 FILTER X HR3200C €1.29
84
 photo_cameraImage coming soon 213030-4 RING 8 X RP1100C €1.42
86
 Crown for Hammers Makita HR3200C 450244-6 Crown for Hammers Makita HR3200C €3.18
88
 Crown Cover for Hammers Makita HR3200C 450237-3 Crown Cover for Hammers Makita HR3200C €3.18
89
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
90
 photo_cameraImage coming soon 324839-0 TREE ECCENTR. HR3200C €16.23
91
 photo_cameraImage coming soon 211332-2 BALL BEARING 6004 2RS HR 3000C €10.43
92
 photo_cameraImage coming soon 961060-6 RETAINING RING S20 €2.50
93
 photo_cameraImage coming soon 231991-6 SPRING CONE 21-31 X HR3000C €1.37
94
 photo_cameraImage coming soon 254239-9 4 KEY HR3000C €2.04
95
 photo_cameraImage coming soon 324848-9 CAM CLUTCH X HR3200C €5.67
96
 photo_cameraImage coming soon 227188-3 GEAR 33 X HR3200C €18.53
97
 photo_cameraImage coming soon 253197-6 WASHER 10 X LF1000 €1.22
99
 photo_cameraImage coming soon 345869-8 BELLEVILLE WASHER 18 X HR3200C €1.88
101
 photo_cameraImage coming soon 158534-8 HOUSING GEAR X HR3200C €12.33
102
 photo_cameraImage coming soon 213415-4 RING 28 X HM1100C €1.40
103
 Spiral Bevel Gear 9 for Rotary Hammer Makita HR3200C 227533-2 Spiral Bevel Gear 9 for Rotary Hammer Makita HR3200C €19.64
104
 photo_cameraImage coming soon 254239-9 4 KEY HR3000C €2.04
105
 photo_cameraImage coming soon 210105-0 BEARING 6001LLU PW5000CH €6.63
106
 photo_cameraImage coming soon 125421-6 TORQUE X HR3200C €60.56
107
 photo_cameraImage coming soon 257291-6 RING 10 X HR3200C €1.88
108
 Ball Bearing 608DDW for Jigsaw Makita 4327 210005-4 Ball Bearing 608DDW for Jigsaw Makita 4327 €5.16
109
 photo_cameraImage coming soon 450251-9 BAFFLE HR3200C €2.91
110
 photo_cameraImage coming soon 213133-4 SEAL OIL 12 HR2800 €8.52
112
 photo_cameraImage coming soon 210105-0 BEARING 6001LLU PW5000CH €6.63
113
 Flat Washer 12 for Angle Grinder Makita GA4540 253084-9 Flat Washer 12 for Angle Grinder Makita GA4540 €1.39
114
 photo_cameraImage coming soon 241863-7 FAN 70 €13.60
115
 photo_cameraImage coming soon 513748-0 ARMATURE HR3200C €67.67
116
 Armature Washer for Demolition Hammers Makita HR4000C 681650-6 Armature Washer for Demolition Hammers Makita HR4000C €8.76
117
 Ball Bearing 608DDW for Jigsaw Makita 4327 210005-4 Ball Bearing 608DDW for Jigsaw Makita 4327 €5.16
118
 photo_cameraImage coming soon 266056-5 SCREW M 5 X 45 X JR3060T €2.69
119
 photo_cameraImage coming soon 625813-4 STATOR X HR3200C €30.62
120
 photo_cameraImage coming soon 450252-7 MOTOR HOUSING X HR3200C €23.81
122
 Carbon Brushes CB-350 for Hammers Makita HR4001C 194160-9 Carbon Brushes CB-350 for Hammers Makita HR4001C €8.80
123
 photo_cameraImage coming soon 450253-5 REAR COVER HR3200C €6.36
124
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
125
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
126
 photo_cameraImage coming soon 638519-5 BRUSHE HOLDER HR3200C €12.33
127
 photo_cameraImage coming soon 631784-5 CONTROLLER PER HR3200C €60.56
128
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
129
 photo_cameraImage coming soon 638406-8 CABLE HARNESS X HR4011C €2.27
130
 photo_cameraImage coming soon 450246-2 CORD CLAMP BASE HR3200C €2.16
131
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
132
 photo_cameraImage coming soon 687169-3 STRAIN RELIEF HP1620 €1.46
133
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
134
 photo_cameraImage coming soon 450240-4 LENS X HR3200C €1.69
135
 Power Cord Protection for Angle Grinder Makita 1800-2000-2200W 682560-0 Power Cord Protection for Angle Grinder Makita 1800-2000-2200W €3.18
137
 photo_cameraImage coming soon 266041-8 PT SCREW 5x25 €1.24
141
 photo_cameraImage coming soon 911233-1 HEAD SCREW M5X20 3600H €1.32
148
 photo_cameraImage coming soon 450262-4 HANDLE €13.31
149
 photo_cameraImage coming soon 419025-7 SWITCH X HR4011C €4.08
150
 photo_cameraImage coming soon 154626-1 SWITCH HOLDER HR4001C €4.08
151
 photo_cameraImage coming soon 650676-9 SWITCH TG73B-1 HR4001C €12.55
152
 photo_cameraImage coming soon 450257-7 COVER HANDLE X HR3200C €11.46
153
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
154
 photo_cameraImage coming soon 267383-3 WASHER 22 HR3200C €1.69
155
 photo_cameraImage coming soon 267721-9 WASHER Ondul. 19 FOR HM1202 €1.25
999
 photo_cameraImage coming soon 195192-9 SERVICE KIT HR3540C €19.45
1001
 photo_cameraImage coming soon 181573-3 BIT GREASE HR2400 €5.57
1002
 photo_cameraImage coming soon 135209-6 GRIP 36 ASSY HR3540/3541/4001C €22.50
1003
 photo_cameraImage coming soon 824819-1 PLASTIC CARRYING CASE €70.67
1004
 photo_cameraImage coming soon 443122-7 CLOTH BHR262/HR4011C/4001C €5.13
5001
 photo_cameraImage coming soon 654091-9 NON INSULATED TERMINAL HM0870 HM0871-TD0101F-N910-RP0900- GA5020 - GA5021-JR-LC1230-HR2432-HM1810-SMA40 €1.40

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Rotary Hammer HR3540C

Fix Your Rotary Hammer HR3540C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
Makita HR3540C
Makita HR3540C Sds Max Rotary Hammer
# Part Num. Description
1 286269-2 TOOL HOLDER CAP HM0860C/HR3540
2 450592-3 CHUCK COVER HR3540/HR3541
3 231984-3 RING SPRING 25 HR5001C/HM1202C
4 331823-8 CHUCK RING HR3540/3541
5 310257-8 TOOL RETAINER HR3540/HR3541
6 345928-8 SPRING GUIDE HR3540/HR3541
7 234063-6 COMPRESSION SPRING 52 HR3540/4
8 345976-7 SPRING HOLDER HR3540/HR3541
9 424110-3 RUBBER SPRING 13 HR3540/3541
18 922341-3 CAP HD SCREW M6X25
19 158674-2 BARREL COMP HR3540/HR3541
20 213656-2 O RING 53 HM1200
21 257294-0 RING 38 HR3540/3541
22 262143-8 URETHANE RING 38 HR3540/3541
23 267381-7 FLAT WAHSER 39 HR3540/3541
24 324900-3 TOOL HOLDER HR3540/HR3541
25 324901-1 IMPACT BOLT HR3540/3541
26 213309-3 O RING 19 HK1800/HR3540*41
27 213309-3 O RING 19 HK1800/HR3540*41
28 213996-8 FLOURO CARBON RESIN RING 24 HR
29 324899-2 RING 13 HR3540/3541
30 324838-2 SLIDE PLATE HR3210/3540/3541
31 256266-2 PIN 6 HR3210CT/FCT/HK1820/L
32 331822-0 CYLINDER 25 HR3540/HR3541
33 450243-8 SLIDE SLEEVE HR3210/3540/3541
34 331805-0 RING 29 HR3210CT/FCT HR3200C
35 267360-5 FLAT WASHER 40 HR3210/3540/41 HR3200C
36 234052-1 COMPRESSION SPRING 42 HR3210CT HR3200C
37 450236-5 LOCK SLEEVE HR3210/3540/3541 HR3200C
38 234050-5 COMPRESSION SPRING 34 HR3210FC HR3200C
39 331795-7 DRIVING SLEEVE HR3210CT/3540 HR3200C
40 213434-0 O RING 26 5621RD/HR3540*41 5621RDW
41 324898-4 STRIKER HR3540/HR3541 HR3540C
42 213283-5 O RING 18 HR3210CT/FCT/HK1800   HR3200C
43 213283-5 O RING 18 HR3210CT/FCT/HK1800 HR3200C
44 256087-2 PIN 7 HR3210CT/FCT/HK1820/L   HR3200C
45 324918-4 PISTON HR3210CT/3540/3541 HR3200C
46 213262-3 O RING 18 BFS440/AN942/BFR540   4100R
47 450235-7 CONNECTING ROD HR3210CT/3540 HR3200C
48 227531-6 SPIRAL BEVEL GEAR 37 HR3210CT/ HR3200C
49 345867-2 LINK ARM HR3210CT/3540/3541 HR3200C
64 266041-8 PT SCREW 5X25
65 922128-3 HEX SOCKET BOLT M4x16* 4300BA
66 450594-9 CRANK HOUSING COVER HR3540 - HR3540C
67 266192-7 TAPPING SCREW 4X14 6837 HR4001C / HR4010C
68 318201-9 CRANK CAP COVER HR3210CT/3440/ HR3200C
69 265995-6 PT SCREW 4X18 KP0810C*
70 450249-6 CHANGE LEVER HR3210CT/3450/34 HR3200C
71 233436-0 COMPRESSION SPRING 3 X HR4001C / HR4010C
72 450250-1 LOCK BUTTON X HR3200C
73 911526-6 PAN HEAD SCREW M4 X 14 X HR2420
74 450241-2 CRANK CAP HR3210CT/3540/41
75 213223-3 O RING 16 9036/AG125/HR3540/4 HR3200C
76 158437-6 SPUR GEAR 33 COMP HR3210/3540 HR3200C
77 424064-4 SEAL RING B HR3520CT/3540/3541 HR3200C
78 345868-0 LINK PLATE HR3210/3540/3541 HR3200C
79 450247-0 AIR PIPE HR3200C
80 263005-3 RUBBER PIN 6
81 452126-8 GEAR SHAFT HR32103540/3541 - HR3200C
82 158713-8 CRANK HOUSING CO HR3540 HR3200C
83 443138-2 FILTER HR3210CT/3540/3541 - HR3200C
84 213030-4 O RING 8 BTM40/50/HM0871C RP1100C
85 450238-1 FILTER CAP HR3210/3540/3541 HR3200C
86 450244-6 CRANK GEAR HR3210CT/3540/3541 HR3200C
87 213176-6 O RING 14 AN942/HR3210 - AN901
88 450237-3 CAP HOLDER HR3210CT/3450/3451 - HR3200C
89 266192-7 TAPPING SCREW 4X14 6837 HR4001C / HR4010C
90 324839-0 CRANK SHAFT HR3210/3540/3541 -   HR3200C
91 211332-2 BALL BEARING 6004LLU HR3000C
92 961060-6 EXT DIN471 CIRCLIP S20
93 231991-6 CONICAL COMP SPRING 21-31 HR30 - HR3000C
94 254239-9 KEY 4 X HR3000C
95 324848-9 CLUTCH HR3210CT/3540/3541 - HR3200C
96 227188-3 SPUR GEAR 33 HR3210CT/3540/41 - HR3200C
97 253197-6 FLAT WASHER 10 7104L/LF1000
98 961036-3 RETAINING RING WR-10 HR3210/35 - HR3200C
99 345869-8 CUP WASHER 18 HR3210CT/3541 - HR3200C
100 424063-6 SEAL RING A HR3210/3540/3541 - HR3200C
101 158534-8 GEAR HOUSING COMP HR3210/3540T - HR3200C
102 213415-4 O RING 28 HM1110/1111/1110C - HM1100C
103 227533-2 SPIRAL BEVEL GEAR 9 HR3210/354 - HR3200C
104 254239-9 KEY 4 X HR3000C
105 210105-0 BALL BEARING 6001LLU PW5000C - PW5000CH
106 125421-6 TORQUE LIMITER ASSY HR3210CT/FC HR3200C
107 257291-6 RING 10 HR3210CT/FCT - HR3200C
108 210005-4 BALL BEARING 608DDW GA5020
109 450251-9 BAFFLE PLATE HR3210C/3540/3541
110 213133-4 OIL SEAL 12 X HR2800
112 210105-0 BALL BEARING 6001LLU PW5000C - PW5000CH
113 253084-9 FLAT WASHER 12 8419B / 5016NB
114 241863-7 FAN 70 HR3000C/JR3060T/3070/3540
115 513748-0 ARMATURE ASSY 240V HR3210/3540 HR3200C
116 681650-6 INSULATION WASHER HM0870/71C - HR4000C
117 210005-4 BALL BEARING 608 DDW
118 266056-5 PT SCREW 5X45 9046 - JR3060T
119 625813-4 FIELD 240V HR3210CT/3540/3541 - HR3200C
120 450252-7 MOTOR HOUSING HR3210/3540 - HR3200C
122 194160-9 CARBON BRUSH CB-350 HR4011C - HR4001C
123 450253-5 REAR COVER HR3210CT/FCT - HR3200C
124 265995-6 PT SCREW 4X18 KP0810C* 6408 / 6221DW SCREW
125 265995-6 PT SCREW 4X18 KP0810C* 6408 / 6221DW SCREW
126 638519-5 BRUSH HOLDER UNIT HR3210CT/FCT - HR3200C
127 631784-5 CONTROLLER 240V HR32103540 - HR3200C
128 266192-7 TAPPING SCREW 4X14 6837 HR4001C / HR4010C
129 638406-8 LEAD UNIT HR4011C/3210/3540/41 - HR4011C
130 450246-2 CORD CLAMP BASE HR3210CT/3540 - HR3200C
131 266192-7 TAPPING SCREW 4X14 6837 HR4001C / HR4010C
132 687169-3 STRAIN RELIEF GA7050/GA9050/ HP1620
133 266192-7 TAPPING SCREW 4X14 6837 - HR4001C / HR4010C
134 450240-4 LENS HR3210CT/3540/3541 - HR3200C
135 682560-0 CORD GUARD 10 HM1317C/CB/HR300 - HM1202C / 9079S
137 266041-8 PT SCREW 5X25
140 865375-2 NAME PLATE HR3540 - HR3540C
141 911233-1 PAN HD SCREW 5X20 W/CP 3600H
148 450262-4 HANDLE HR3450 /3541 - HR3200C
149 419025-7 SWITCH LEVER HR4011C/HR4511C - HR4011C
150 154626-1 SWITCH HOLDER COMP HR4011C/451 - HR4001C
151 650676-9 SWITCH TG73B-1 HR4001C
152 450257-7 HANDLE COVER HR3210/3540/3541 - HR3200C
153 265995-6 PT SCREW 4X18 KP0810C* 6408 / 6221DW SCREW
154 267383-3 FLAT WASHER 22 HR3210C/FCT - HR3200C
155 267721-9 WAVE WAHER 15 HR3210CT/3540 - HM1202
156 213083-3 O RING 9 HR3210 - HR3200C
999 195192-9 SERVICE KIT HR3540C
1001 181573-3 GREASE VESSEL 93G
1002 135209-6 GRIP 36 ASSY HR3540/3541/4001C
1003 824819-1 PLASTIC CARRYING CASE
1004 443122-7 CLOTH BHR262/HR4011C/4001C
1005 810409-6 CAUTION CARD HR3210CT/FCT
5001 654091-9 NON INSULATED TERMINAL MT814/1
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HR3540C
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita HR3540C

Diagram Makita HR3540C

Download (244.92KB)

You might also like

Elastic Ring for Demolition Hammers Makita HR 4001-2-10-11C
Valex s.p.a. SKU: 233937-8
Elastic Ring for Demolition Hammers Makita HR 4001-2-10-11C
Elastic Ring for Demolition Hammers Makita HR 4001-2-10-11C Genuine spare part Makita SDS Max Rotary Demolition Hammers eg, Elastic Ring for, HR4001C - HR 4002 - HR4010C - HR4011C Part for the following products: - ROTARY HAMMER SDS...
AVAILABLE €4.19
Details
Sliding Bushing for Hammers Makita HR4001-2-10-11C
Valex s.p.a. SKU: 419003-7
Sliding Bushing for Hammers Makita HR4001-2-10-11C
Sliding Bushing for Hammers Makita HR4001-2-10-11C Genuine spare part Makita, Sliding Bushing for Hammers eg, HR4001C - HR 4002 - HR4003C - HR4010C - HR4011C. Part for the following products: - ROTARY HAMMER SDS MAX HR4001C - ROTARY...
AVAILABLE €6.55
Details
Gear Pletine for Hammers SDS-MAX Makita HR4001-4002-4010-4011C
Makita SKU: 419018-4
Makita HR4001-4002-4010-4011C Change Plate
Makita HR4001-4002-4010-4011C Change Plate Genuine spare Makita, Change Plate for Demolition Hammers SDS Max, HR4001C - HR 4002 - HR4010C - HR4011C and compatible. For the following articoili: -  Rotary Hammer SDS-MAX HR4001C -...
on 7/10 Business Days Approx €4.19
Details
Carbon Brushes CB-350 for Hammers Makita HR4001C
Makita SKU: 194160-9
Carbon Brushes CB-350 for Hammers Makita HR4001C
Carbon Brushes CB-350 for Hammers Makita HR4001C Genuine Part Makita, Carbon Brushes for Hammers HK1820 - HM0870C - HR3200C - HR3210FCT - HR4001C - HR4002 - HR4010-11-13C. Part for the following items: - STONECUTTER 3.3kg 550W HK1820...
AVAILABLE €8.80
Details
Pinion for Hammers Makita HR3200C
Makita SKU: 452126-8
Pinion for Hammers Makita HR3200C
Pinion for Hammers Makita HR3200C Genuine spare part Makita, Pinion for Rotary Hammers, HR3200C - HR3210C - HR3210FCT - HR3540C - HR3541FC Part for the following products: - ROTARY HAMMER SDS-PLUS 32MM HR3200C - ROTARY HAMMER...
AVAILABLE €3.18
Details
Crown for Hammers Makita HR3200C
Makita SKU: 450244-6
Crown for Hammers Makita HR3200C
Crown for Hammers Makita HR3200C Genuine spare part Makita, Crown for Rotary Hammers, HR3200C - HR3210C - HR3210FCT - HR3540C - HR3541FC Part for the following products: -  ROTARY HAMMER SDS-PLUS 32MM HR3200C -  ROTARY...
AVAILABLE €3.18
Details
Crown Cover for Hammers Makita HR3200C Sale
Makita SKU: 450237-3
Crown Cover for Hammers Makita HR3200C
Crown Cover for Hammer Makita HR3200C Genuine spare part Makita, Crown Cover for Rotary Hammers, HR3200C - HR3210C - HR3210FCT - HR3540C - HR3541FC. Part for the following products: -  ROTARY HAMMER SDS-PLUS 32MM HR3200C -  ROTARY...
AVAILABLE €3.18
Details
Rubber Ring 25 for Hammers Makita HR4000C
Makita SKU: 213392-0
Rubber Ring 25 for Hammers Makita HR4000C
Rubber Ring 25 for Hammers Makita HR4000C Original spare Makita, Rubber ring 25 mm for Rotary Hammers SDS Max, HR4001C - HR 4002 - HR4003C - HR4010C - HR4011C - HR4013C - HR4500C - HR5201C - HR5210C and compatible. - Code: 213392-0
Last items in stock €9.24
Details
Lock Sleeve for Rotary Hammer Makita HR4001C
Makita SKU: 165633-9
Lock Sleeve for Rotary Hammer Makita HR4001C
Lock Sleeve for Rotary Hammer Makita HR4001C Genuine spare Makita, Lock Sleeve for Rotary Hammers SDS-MAX Makita HR4001C - HR4001C - HR4002 - HR4010C - HR4011C. Parts for the following products: -  Rotary Hammer SDS-MAX HR4001C...
AVAILABLE €28.33
Details
Armature for Demolition Hammers Makita HR 4001-10-11C
Makita SKU: 513633-7
Armature for Demolition Hammers Makita HR 4001-10-11C
Armature for Demolition Hammers Makita HR 4001-10-11C Original spare Makita, Armature Ass'y 220-240V for SDS-Max Rotary Hammers, HR4001C - HR4010C - HR4011C. Part for the Following products: -  Rotary Hammer SDS-MAX HR4001C -...
Usually Ships in: 7/10 Business Days Approx. €76.12
Details
Power Cord for Angle Grinder Makita 1800-2000-2200W
Makita SKU: Cavo 230
Power Cord for Angle Grinder Makita 1800-2000-2200W
Power Cord for Angle Grinder Makita 1800-2000-2200W Original spare Makita, Power cord for Angle Grinders 1800-2000-2200 Watts and compatible. Part for the following products: - For Angle Grinder Makita 230 mm - Code :
AVAILABLE €31.79
Details
Eccentric Shaft for Hammers Makita HR4001-10-11C
Makita SKU: 324550-4
Crankshaft for Hammers Makita HR4001-10-11C
Crankshaft for Hammers Makita HR4001-10-11C Original replacement part Makita, Crankshaft for SDS-Max Rotary Hammers, HR4001C - HR4002 - HR4010C - HR4011C. Part for the following products: - ROTARY HAMMER SDS-MAX...
Last items in stock €25.21
Details
Service Pack for Hammers Makita HR4001C-4002-4010-11C
Makita SKU: 195195-3
Service Pack for Hammers Makita HR4001C-4002-4010-11C
Service Pack for Hammers Makita HR4001C-4002-4010-11C Genuine spare parts Makita, Service Pack for Rotary Hammers SDS-Max, HR4001C - HR4002 - HR4010C - HR4011C Part for the following items: - ROTARY HAMMER SDS-MAX Makita HR4001C -...
Last items in stock €33.48
Details
Armature Washer for Demolition Hammers Makita HR4000C
Makita SKU: 681650-6
Armature Washer for Demolition Hammers Makita HR4000C
Armature Washer for Demolition Hammers Makita HR4000C Genuine spare part Makita, Armature Protection Washer for SDS-Max Rotary Hammers, HM0860C - HM0870C - HM1100C - HM1140C - HR3000C - HR3200C - HR3541FC - HR4000C. Part for the...
AVAILABLE €8.76
Details
Cilynder 28.5 for Rotary Hammer Makita HR4001C Sale
Makita SKU: 324570-8
Cilynder 28.5 for Rotary Hammer Makita HR4001C
Cilynder 28.5 for Rotary Hammer Makita HR4001C Genuine parts MAKITA: Cilynder 28.5 for Rotary Hammers SDS MAX HR4001C - HR4010C - HR4011C Parts for the following products:  - HR4001C - ROTARY HAMMER SDS-MAX 40MM - HR4010C - ROTARY...
AVAILABLE €53.67
Details
Rear Handle for Demolition Hammer Makita HR4011C Sale
Makita SKU: 419038-8
Rear Handle for Demolition Hammer Makita HR4011C
Rear Handle for Demolition Hammer Makita HR4011C Genuine part MAKITA, Rear Handle for Demolition Hammer Makita HR4011C Parts for the following products: - Demolition Hammer Makita HR4011C - Code: 419038-8
AVAILABLE €14.24
Details
Srew M4X14 for Hammers Makita HR4001C-HR4010C
Makita SKU: 266192-7
Srew M4X14 for Hammers Makita HR4001C-HR4010C
Srew M4X14 for Hammers Makita HR4001C-HR4010C Original spare Makita, Srew M4X14 for Demolition Hammers Makita HR4001C - HR4010C Parts for the following products: - Demolition Hammer HR4001C -...
AVAILABLE €1.46
Details
Compression Spring 11 mm for Hammer Makita HR4011C Sale
Makita SKU: 233434-4
Compression Spring 11 mm for Hammer Makita HR4011C
Compression Spring 11 mm for Hammer Makita HR4011C Genuine spare Makita, Compression Spring 11 mm for Hammers HM0871C - HM1111C - HM1213C - HR4011C - HR4511C - HR5211C Parts for the following products: - HM0871C - HAMMER 1100W SDS-MAX...
AVAILABLE €3.03
Details
Spiral Bevel Gear 37 for Hammer Makita HR3200C
Makita SKU: 227531-6
Spiral Bevel Gear 37 for Hammer Makita HR3200C
Spiral Bevel Gear 37 for Hammer Makita HR3200C Genuine spare part Makita, Spiral Bevel Gear 37 for Rotary Hammers, HR3200C - HR3210C - HR3210FCT - HR3540C - HR3541FC Part for the following products: - HR3200C - ROTARY HAMMER SDS+32MM...
AVAILABLE €37.21
Details
Retaining Ring for Rotary Hammer Makita HR50001C
Makita SKU: 231984-3
Retaining Ring for Rotary Hammer Makita HR50001C
Retaining Ring for Rotary Hammer Makita HR50001C Genuine spare part Makita, Retaining Ring for Rotary Hammers HR50001C - HR4001C - HR4002 - HR4010C - HR4011C - Hammer HM0860C - HM0870C. Part for the following products: - HR4001C -...
AVAILABLE €2.01
Details
Seal 53 for Demolition Hammer MAKITA HM1200
Makita SKU: 213656-2
Seal 53 for Demolition Hammer MAKITA HM1200
Seal 53 for Demolition Hammer MAKITA HM1200 Genuine replacement part Makita, Seal 53 Demolition Hammers HM1200 - HM1200K - HM0870C - HM0870C - HM0871C. Part for the following products: -...
AVAILABLE €1.46
Details
Spiral Bevel Gear 9 for Rotary Hammer Makita HR3200C
Makita SKU: 227533-2
Spiral Bevel Gear 9 for Rotary Hammer Makita HR3200C
Spiral Bevel Gear 9 for Rotary Hammer Makita HR3200C Genuine spare part Makita, Spiral Bevel Gear 9 for Rotary Hammers, HR3200C - HR3210C. Part for the following products: -  ROTARY HAMMER SDS-PLUS 32MM HR3200C -  ROTARY HAMMER...
Last items in stock €19.64
Details
O-Ring 19 for Power Scraper Makita HK1800
Makita SKU: 213309-3
O-Ring 19 for Power Scraper Makita HK1800
O-Ring 19 for Power Scraper Makita HK1800 Genuine Spare Part Makita, O-Ring 19 for Hex Shank Power Scraper 3,2KG 505W HK1800 - HK1810 Part for the following products: -  HK1800 - HEX SHANK POWER SCRAPER 3,2KG 505W -  HK1810 - HEX...
on 7/10 Business Days Approx €2.12
Details
Comments (0)
