Makita

Makita Spare Parts for Angle Grinder 9609NB

SKU: Makita 9609NB
€1.47
VAT included

Makita Spare Parts for Angle Grinder 9609NB

We have the original MAKITA parts and tool repair help you need to get your tools running like new again.

Fix Your Angle Grinder 9609NB. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Makita Spare Parts for Angle Grinder 9609NB
  • Makita Spare Parts for Angle Grinder 9609NB
  • Makita Spare Parts for Angle Grinder 9609NB
Makita

Makita Spare Parts for Angle Grinder 9609NB

SKU: Makita 9609NB Condition: New
€1.47
VAT included

Makita Spare Parts for Angle Grinder 9609NB

We have the original MAKITA parts and tool repair help you need to get your tools running like new again.

Fix Your Angle Grinder 9609NB. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 53 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
53 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 911263-2 HEAD SCREW CILIND. €1.47
2
 photo_cameraImage coming soon 962062-5 RETAINING RING R12 €1.36
3
 photo_cameraImage coming soon 256615-3 PIN 6 9609HB 9607 / 09GA €1.36
4
 photo_cameraImage coming soon 231037-8 SPRING 7 9607/09 / GA / 3612BR €1.36
5
 photo_cameraImage coming soon 421156-0 TOOL REST, GA7910 9609NB / HB €4.24
7
 photo_cameraImage coming soon 156451-6 GEAR HOUSING, 9607NB 9609NB / HB / GA €82.66
8
 photo_cameraImage coming soon 263005-3 PIN RUBBER 6 €1.32
9
 photo_cameraImage coming soon 961051-7 RETAINING RING S11 €1.36
10
 photo_cameraImage coming soon 257062-1 RING 11 9609NB / HB / 07HB €2.62
11
 photo_cameraImage coming soon 221322-7 SPIRAL B. GEAR, GA7911 9609NB / HB / GA €27.49
12
 Ball Bearing 6301DD for Angle Grinders Makita 211132-0 Ball Bearing 6301DD for Angle Grinders Makita €13.46
13
 photo_cameraImage coming soon 341403-2 PLATE, 9607NB 9609NB / HB / GA €9.61
14
 photo_cameraImage coming soon 254001-2 KEY CRESCENT 4 €1.44
16
 photo_cameraImage coming soon 514937-0 ARMATURE ASSìY 9609NB / HBS / NBS €115.04
17
 Armature Washer for Planer Makita 1100 681623-9 Armature Washer for Planer Makita 1100 €2.00
18
 photo_cameraImage coming soon 211087-9 BALL BEARING 6200DDW €8.75
22
 photo_cameraImage coming soon 911290-9 SCREW M5X65 €1.53
23
 Carbon Brush Holder Cover for Electric Chainsaw Makita UC3041A 643650-4 Carbon Brush Holder Cover for Electric Chainsaw Makita UC3041A €2.43
24
 Carbon Brushes CB-153 for Miter Saws Makita LS1016-1040-1216F 181044-0 Carbon Brushes CB-153 for Miter Saws Makita LS1016-1040-1216F €9.91
25
 Rubber Pin for Hammer SDS-Max Makita HR4000C 263002-9 Rubber Pin for Hammer SDS-Max Makita HR4000C €1.32
26
 photo_cameraImage coming soon 156452-4 MOTOR HOUSING, 9607NB 9609NB / HB €50.68
27
 photo_cameraImage coming soon 654020-2 RING TERMINAL 94 €1.40
28
 photo_cameraImage coming soon 911248-8 CYLINDER HEAD SCREW. M5X28 €1.36
29
 photo_cameraImage coming soon 181908-8 HANDLE ASS'Y, 9607GB 9609NB / HB €43.55
30
 photo_cameraImage coming soon 651142-9 SWITCH C3D-15CS €39.23
32
 Power Cord Protection for Portable Cut-Off Machine Makita 2412N 682506-6 Power Cord Protection for Portable Cut-Off Machine Makita 2412N €3.84
34
 photo_cameraImage coming soon 687001-1 CLAMP cable tie €1.47
35
 photo_cameraImage coming soon 911126-2 SCREW M4x16 €1.47
36
 photo_cameraImage coming soon 421279-4 DUST COVER, 4110C 9609B / NB / HB €3.04
37
 photo_cameraImage coming soon 911111-5 HEAD SCREW CILIND. M4X10 €3.76
38
 photo_cameraImage coming soon 911143-2 SCREW M4FOR22 €1.40
39
 photo_cameraImage coming soon 911248-8 CYLINDER HEAD SCREW. M5X28 €1.36
40
 photo_cameraImage coming soon 911136-9 HEAD SCREW CILIND. M4x20 €1.47
41
 Upper Flange for Angle Grinder Makita 180-230 mm 224543-0 Upper Flange for Angle Grinder Makita 180-230 mm €5.45
42
 Inner Flange 42 for Angle Grinder Makita 9524NB 224490-5 Inner Flange 42 for Angle Grinder Makita 9524NB €2.94
43
 photo_cameraImage coming soon 164392-2 WHEEL COVER 9609B / NB / HB / S €31.77
44
 photo_cameraImage coming soon 342555-2 WHEEL COVER HOLDER €3.04
45
 photo_cameraImage coming soon 942101-7 SPRING WASHER 5 €1.36
46
 photo_cameraImage coming soon 911223-4 HEAD SCREW CILIND. M5X16 €1.44
47
 photo_cameraImage coming soon 321218-3 SPINDLE 9609NB / HB / S / GA €34.73
48
 photo_cameraImage coming soon 254001-2 KEY CRESCENT 4 €1.44
49
 photo_cameraImage coming soon 256047-4 PIN 6 84DW / 9609B / GA €1.36
50
 photo_cameraImage coming soon 911226-8 HEAD SCREW CILIND. M5X18 €1.47
51
 photo_cameraImage coming soon 315003-4 HOUSING W/O BEARING, 9607NB 9609N / HB / S €20.92
52
 photo_cameraImage coming soon 443036-0 FELT RING 25, GA7001L 9609N / HB €1.36
53
 photo_cameraImage coming soon 253772-8 FLAT WASHER 28, GA7001L €1.36
54
 Ball Bearing 6203LLU for Makita SG150-2 211490-4 Ball Bearing 6203LLU for Makita SG150-2 €10.49
55
 photo_cameraImage coming soon 962157-4 RETAINING RING R40 €2.85
56
 photo_cameraImage coming soon 221323-5 SPIRAL B. GEAR 58, GA7001L 9609B / HB / GA €48.74
57
 Makita Power Tools Ext DIN471 Circlip-17 961057-5 Makita Power Tools Ext DIN471 Circlip-17 €1.47
58
 photo_cameraImage coming soon 322465-9 SHAFT LOCK BUSH, 9000BL 9609B / HBS €9.61
59
 photo_cameraImage coming soon 253214-2 FLAT WASHER 9 €1.40
60
 Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €9.01
61
 photo_cameraImage coming soon 273404-1 SIDE HANDLE €7.80
62
 photo_cameraImage coming soon 643556-6 BRUSH HOLDER , 4301BV €5.47

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Angle Grinder 9609NB

Fix Your Angle Grinder 9609NB. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita 9609NB

9609NB - SMERIGLIATRICE 1800W 230 MM
# Part Num. Description
1 911263-2 Pan Hdscrew M5x40 W/cp
2 962062-5 INTERNAL INVERTED RING-12*
3 256615-3 PIN 6 9609HB 9607 / 09GA
4 231037-8 COMPRESSION SPRING 7 9607/09 / GA / 3612BR
5 421156-0 TOOL REST, GA7910 9609NB / HB
7 156451-6 GEAR HOUSING, 9607NB 9609NB / HB / GA
8 263005-3 RUBBER PIN 6
9 961051-7 RETAINING RING S-11, DP4000
10 257062-1 RING 11 9609NB / HB / 07HB
11 221322-7 SPIRAL B. GEAR, GA7911 9609NB / HB / GA
12 211132-0 BALL BEARING 6301DD
13 341403-2 PLATE, 9607NB 9609NB / HB / GA
14 254001-2 WOODRUFF KEY 4, HM1810
16 514937-0 ARMATURE ASSìY 9609NB / HBS / NBS
17 681623-9 INS. WASHER, 2012NB
18 211087-9 BALL BEARING 6200DDW NSK
22 911290-9 P.H. SCREW M5X65, GA7911
23 643650-4 BRUSH HOLDER CAP, 5007NK
24 181044-0 CARBON BRUSH CB-153 (CB-22)/94 (150/52/54)
25 263002-9 RUBBER PIN 4
26 156452-4 MOTOR HOUSING, 9607NB 9609NB / HB
27 654020-2 GARTER SPRING 94, 5007NK
28 911248-8 P.H. SCREW M5X28, HM1500
29 181908-8 HANDLE ASS'Y, 9607GB 9609NB / HB
30 651142-9 SWITCH C3D-15CS
32 682506-6 CORD GUARD 12/90, 6922NB
34 687001-1 STRAIN RELIEF, 6013BR
35 911126-2 P.H. SCREW M4X16, 5402NA
36 421279-4 DUST COVER, 4110C 9609B / NB / HB
37 911111-5 P.H. SCREW M4X10, LS1011
38 911143-2 P.H. SCREW M4X22, 6211D
39 911248-8 P.H. SCREW M5X28, HM1500
40 911136-9 P.H. SCREW M4X20, N9501B
41 224543-0 LOCK NUT 14-45 9047F 9049F 9049SF
42 224490-5 INNER FLANGE 42 DGA452
43 164392-2 WHEEL COVER 9609B / NB / HB / S
44 342555-2 WHEEL COVER HOLDER
45 942101-7 SPRING WASHER 5, 9005B
46 911223-4 P.H. SCREW M5X16, 5007NK
47 321218-3 SPINDLE 9609NB / HB / S / GA
48 254001-2 WOODRUFF KEY 4
49 256047-4 PIN 6 84DW / 9609B / GA
50 911226-8 P.H. SCREW M5X18, GA7911
51 315003-4 HOUSING W/O BEARING, 9607NB 9609N / HB / S
52 443036-0 FELT RING 25, GA7001L 9609N / HB
53 253772-8 FLAT WASHER 28, GA7001L
54 211490-4 BALL BEARING 6203LLU X SG150-2
55 962157-4 RETAINING RING R-40, GA7911
56 221323-5 SPIRAL B. GEAR 58, GA7001L 9609B / HB / GA
57 961057-5 RETAINING RING S-17, LS1016L
58 322465-9 SHAFT LOCK BUSH, 9000BL 9609B / HBS
59 253214-2 FLAT WASHER 9
60 211092-6 BALL BEARING 629DD
61 273404-1 SIDE HANDLE 37, 6013BR-T1
62 643556-6 BRUSH HOLDER , 4301BV
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita 9609NB
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita 9609NB

Diagram Makita 9609NB

Download (301.95KB)
