Makita

Makita Spare Parts for Rotary Hammer HR2000

SKU: Makita HR2000
€1.43
VAT included

Makita Spare Parts for Rotary Hammer HR2000

Makita genuine spare parts or replacement parts for to repair Rotary Hammer SDS-PLUS HR2000.

Fix Your Rotary Hammer SDS-PLUS HR2000. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Makita Spare Parts for Rotary Hammer HR2000
  • Makita Spare Parts for Rotary Hammer HR2000
  • Makita Spare Parts for Rotary Hammer HR2000
Makita

Makita Spare Parts for Rotary Hammer HR2000

SKU: Makita HR2000 Condition: New
€1.43
VAT included

Makita Spare Parts for Rotary Hammer HR2000

Makita genuine spare parts or replacement parts for to repair Rotary Hammer SDS-PLUS HR2000.

Fix Your Rotary Hammer SDS-PLUS HR2000. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 60 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
60 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 267022-5 SPECIAL WASHER 13.5 HR200 5PK HR2000 €3.09
3
 photo_cameraImage coming soon 262038-5 Rubber Ring 17 Hr2000/hr160dwh Hr2400 €2.69
4
 photo_cameraImage coming soon 321915-1 Idler Hr2000/hr160dwh Hr2400 €18.98
6
 photo_cameraImage coming soon 213063-9 GASKET 10 X HR2000 €5.24
7
 photo_cameraImage coming soon 213063-9 GASKET 10 X HR2000 €5.24
8
 photo_cameraImage coming soon 322516-8 TOOL HOLDER HR2000 (TIB136)* €196.30
11
 photo_cameraImage coming soon 213068-9 O Ring 10 Hr2000 Tib136 Hr2400 €1.39
12
 photo_cameraImage coming soon 221924-9 SPUR GEAR 39 HR2000 €35.82
13
 photo_cameraImage coming soon 231408-9 COMPRESSION SPRING 35 HR2000 €3.09
15
 photo_cameraImage coming soon 231936-4 RING SPRING 30.5 HR3000C/HR200 €1.43
16
 photo_cameraImage coming soon 213418-8 OIL SEAL 28 HR2000 €6.63
17
 photo_cameraImage coming soon 211323-3 BALL BEARING 6904 €21.53
18
 photo_cameraImage coming soon 157611-3 GEAR HOUSING COMPLETE HR2000 €82.12
20
 photo_cameraImage coming soon 154404-9 Change Ring Comp Hr2000/hr160d Hr2400 €44.42
21
 photo_cameraImage coming soon 286234-1 Cap 37 Hr2000 Hr160dw Hr2400 €12.57
22
 photo_cameraImage coming soon 261067-5 WASHER 28 HR2000 €28.57
25
 photo_cameraImage coming soon 321911-9 STRIKER HR2000 / 8015DW €13.31
26
 Seal 16 O-R for Cylinder Stonecutter HK0500 213214-4 Seal 16 O-R for Cylinder Stonecutter HK0500 €2.51
27
 photo_cameraImage coming soon 331282-6 PISTON CYLINDER HR2000 €54.98
28
 photo_cameraImage coming soon 321916-9 PISTON JOINT HR2000/HR160DWH €16.65
32
 photo_cameraImage coming soon 442087-0 GEAR HOUSING PACKING €2.53
33
 photo_cameraImage coming soon 157612-1 GEAR HOUSING COVER COMPLETE H €35.82
35
 photo_cameraImage coming soon 213407-3 SEAL 26 X 3901 €2.18
36
 Ball Bearing 6000DD NSK for Cordless Drill Makita 6221DW 211061-7 Ball Bearing 6000DD NSK for Cordless Drill Makita 6221DW €8.69
37
 Oil Seal for Hammer SDS-Max Makita HR4000C 213112-2 Oil Seal for Hammer SDS-Max Makita HR4000C €7.72
38
 photo_cameraImage coming soon 241832-8 FAN 62 HR2000 €7.92
39
 photo_cameraImage coming soon 515128-6 ARMATURE HR2000 €111.69
42
 Stator for Percussion Drills Makita HP2010N/HR2000 528147-3 Stator for Percussion Drills Makita HP2010N/HR2000 €53.67
46
 photo_cameraImage coming soon 651470-2 REVERSING STE210N-1 €26.15
47
 photo_cameraImage coming soon 213105-9 SEAL 11 43 / 65SB / HP201N €1.42
48
 photo_cameraImage coming soon 682504-0 CORD GUARD 10/85 €3.84
50
 photo_cameraImage coming soon 687001-1 CLAMP cable tie €1.47
51
 photo_cameraImage coming soon 911133-5 SCREW M4X18 €1.46
52
 photo_cameraImage coming soon 685722-9 SPONGE 4302C €1.36
54
 photo_cameraImage coming soon 150315-6 HANDLE COVER COMPLETE HR2000 €19.45
55
 photo_cameraImage coming soon 911124-6 SCREW M4FOR14FOR HM1301 €1.40
56
 Carbon Brush Holder for Percussion Drills Makita HP2000-HP2010N 643605-9 Carbon Brush Holder for Percussion Drills Makita HP2000-HP2010N €3.18
58
 photo_cameraImage coming soon 651256-4 SWITCH, JR3000V €44.84
59
 photo_cameraImage coming soon 411900-3 COPERC.INTERR.FORM / HP2010N €2.53
61
 Carbon Brushes for Stonecutter Makita HK0500 191904-8 Carbon Brushes for Stonecutter Makita HK0500 €15.20
62
 photo_cameraImage coming soon 911143-2 SCREW M4FOR22 €1.40
63
 photo_cameraImage coming soon 253192-6 FLAT WASHER 14 €1.40
64
 photo_cameraImage coming soon 211033-2 BEARING 608LB €9.89
65
 photo_cameraImage coming soon 681613-2 INSULATION WASHER €1.29
66
 Rubber Pin for Hammer SDS-Max Makita HR4000C 263002-9 Rubber Pin for Hammer SDS-Max Makita HR4000C €1.47
68
 photo_cameraImage coming soon 321914-3 CRANK JOINT HR2000 €15.18
69
 photo_cameraImage coming soon 153160-8 CRANK SHAFT COMPLETE HR2000 €54.98
70
 Retaining Ring R32 for Powertools Makita 962151-6 Retaining Ring R32 for Powertools Makita €1.43
71
 photo_cameraImage coming soon 211204-1 BALL BEARING 6002 HR2010 €13.31
72
 photo_cameraImage coming soon 911218-7 HEAD SCREW CILIND. M5x14 €1.54
73
 photo_cameraImage coming soon 342633-8 BELT HR2510 / 2000 €4.77
74
 photo_cameraImage coming soon 315145-4 GRIP BASE HR2210/HR1600 HR1800 €6.81
76
 photo_cameraImage coming soon 924216-2 BUTTERFLY SCREW M5X15 €1.36
77
 photo_cameraImage coming soon 273496-0 GRIP 37 HR2510 / 2000 €12.88
81
 Change Ring Cover for Rotary Hammer Makita HR2000 415076-8 Change Ring Cover for Rotary Hammer Makita HR2000 €6.83
82
 photo_cameraImage coming soon 322517-6 Roller 7 Hr2000 (tib136) Hr160 Hr2400 €2.06
83
 photo_cameraImage coming soon 216009-4 BALL 7.1 €1.39
84
 photo_cameraImage coming soon 257172-4 Ring 20 Hr2000 (tib136) Hr160d Hr2400 €5.89
400
 photo_cameraImage coming soon 181573-3 BIT GREASE HR2400 €5.57
402
 photo_cameraImage coming soon 321144-6 DEPTH GAUGE €4.43
407
 photo_cameraImage coming soon 421342-3 DUST CUP 5 €4.06

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Rotary Hammer HR2000

Makita genuine spare parts or replacement parts for to repair Rotary Hammer SDS-PLUS HR2000.

Fix Your Rotary Hammer SDS-PLUS HR2000. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Rotary Hammer and the respective parts of the code.
Makita HR2000

Makita HR2000 Corded 3/4'' Rotary Hammer Drill
# Part Num. Description
1 231935-6 RING SPRING 26 HR2000
2 267022-5 SPECIAL WASHER 13.5 HR200 5PK HR2000
3 262038-5 RUBBER RING 17 HR2000
4 321915-1 RUBBER RING 17 HR2000/HR160DWH
6 213063-9 O RING 10 HR2000/HR160DWH/HR24
7 213063-9 O RING 10 HR2000/HR160DWH/HR24
8 322516-8 TOOL HOLDER HR2000 (TIB136)*
11 213068-9 O RING 10 HR2000 TIB136
12 221924-9 SPUR GEAR 39 HR2000
13 231408-9 COMPRESSION SPRING 35 HR2000
15 231936-4 RING SPRING 30.5 HR3000C/HR200
16 213418-8 OIL SEAL 28 HR2000
17 211323-3 BALL BEARING 6904
18 157611-3 GEAR HOUSING COMPLETE HR2000
20 154404-9 CHANGE RING COMP HR2000/HR160D
21 286234-1 CAP 37 HR2000 HR160DW - CT44-1
22 261067-5 WASHER 28 HR2000
25 321911-9 STRIKER HR2000 / 8015DW
26 213214-4 O RING 16 HR1800/HR160DWH/HR2/ 2000
27 331282-6 PISTON CYLINDER HR2000
28 321916-9 PISTON JOINT HR2000/HR160DWH
29 342962-9 WASHER HR2000
31 342962-9 WASHER HR2000
32 442087-0 GEAR HOUSING PACKING
33 157612-1 GEAR HOUSING COVER COMPLETE H
35 213407-3 O RING 26 3901/4101RH
36 211061-7 BALL BEARING 6000DD 6221DW
37 213112-2 OIL SEAL 12 HR2000
38 241832-8 FAN 62 HR2000
39 515128-6 ARMATURE HR2000
41 925183-4 PAN HEAD SCREW M4X55 6820
42 528147-3 FIELD ASSY 220V HP2010N / HR2000
46 651470-2 SWITCH STE 210N-1 DOUBLE HR200
47 213105-9 O RING 11 HR2000/6835DWA/6833 43 / 65SB / HP201N
48 682504-0 CORD GUARD 10/85 HP1641/BO5031/HP163
50 687001-1 STRAIN RELIEF 4157KB/6820V
51 911133-5 PAN HD SCREW M4X18
52 685722-9 SPONGE SHEET RP1110C/8406/3620 4302C
54 150315-6 HANDLE COVER COMPLETE HR2000
55 911124-6 PAN HD SCREW M4X14 HM1301
56 643605-9 BRUSH HOLDER HR2000
58 651256-4 SWITCH SGEL106CV-1A 240V JR300
59 411900-3 SWITCH SGEL106CV-1A 220V JR300 / HP2010N
60 911276-3 PAN HD SCREW M5X55 5703R
61 191904-8 CARBON BRUSH / AUTO CUT CB-113 (116,118)
62 911143-2 PAN HEAD SCREW M4X22
63 253192-6 THIN WASHER 14 6013B/6822
64 211033-2 BALL BEARING 608LB 9217SPC/904 HR2010
65 681613-2 INSULATION WASHER JN / JS32 / 4301BV
66 263002-9 RUBBER PIN 4 GA7050/9050/PC500
67 923456-9 CAP SQ NECK BOLT A Q.S.T. M8X35 HR2210
68 321914-3 CRANK JOINT HR2000
69 153160-8 CRANK SHAFT COMPLETE HR2000
70 962151-6 RETAINING RING R-32 BPJ141/81
71 211204-1 BALL BEARING 6002 HR2010
72 911218-7 PAN HEAD SCREW M514
73 342633-8 BELT HR2510 / 2000
74 315145-4 GRIP BASE HR2210/HR1600 HR1800
76 924216-2 WING SCREW M5X15
77 273496-0 GRIP 37 HR2510 / 2000
81 415076-8 CHANGE RING COVER HR2000 (TIB1)
82 322517-6 ROLLER 7 HR2000 (TIB136) HR160
83 216009-4 STEEL BALL 7.1
84 257172-4 RING 20 HR2000 (TIB136) HR160D
400 181573-3 GREASE VESSEL 93G
401 182617-2 STEEL CARRYING CASE
401 824608-4 PLASTIC CARRYING CASE
402 321144-6 DEPTH GAUGE
407 421342-3 DUST CUP 5

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HR2000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita HR2000

Diagram Makita HR2000

Download (260.27KB)

Tech Info CT44-1

Tech Info CT44-1

Download (182.1KB)

You might also like

Carbon Brushes for Stonecutter Makita HK0500
Makita SKU: 191904-8
Carbon Brushes for Stonecutter Makita HK0500
Carbon Brushes for Power Scraper Makita HK0500 Makita genuine spare part, Carbon Brushe Set for to repair Power Scraper HK0500 Part for the following Items: - Power Scraper Makita HK0500 - JigSaw - 4302C - ...
Last items in stock €15.20
Details
Steel Ball 7 mm for Hammers Makita
Makita SKU: 216022-2
Steel Ball 7 mm for Hammers Makita
Steel Ball 7 mm for Hammers Makita Genuine spare part Makita, Steel Ball 7 mm diameter for Hammers SDS Plus and Cordless, BHR162RFE - BHR200SFE - BHR240RFE - BHR241RFE - BHR261DP1 - DHR263Z - HR1830 -  HR2420 - HR2611FT....
build View Spare Parts
Oil Seal for Hammer SDS-Max Makita HR4000C
Makita SKU: 213112-2
Oil Seal for Hammer SDS-Max Makita HR4000C
Oil Seal for Hammer SDS-Max Makita HR4000C Original spare Makita, Oil seal 12x26x6 mm for Hammers SDS-Max Makita HR4000C - HR 2000 - HR 2010 - HR 2400. Parts for the following products: - DEMOLITION HAMMER HR 2000 - DEMOLITION HAMMER...
AVAILABLE €7.72
Details
Bearing for Angle Grinder Makita 9524NB
Makita SKU: 211012-0
Bearing for Angle Grinder Makita 9524NB
Bearing for Angle Grinder Makita 9524NB Genuine spare Makita, Ball Bearing 606 2Z for Angle Grinder 9524NB. Part for the following products: - CIRCULAR SAW 165 MM 5604R - CIRCULAR SAW 165 MM-18V 2.2Ah Ni-MH 5621RDWBE - KEYLESS DRILL...
AVAILABLE €8.23
Details
Stator for Percussion Drills Makita HP2010N/HR2000 Sale
Makita SKU: 528147-3
Stator for Percussion Drills Makita HP2010N/HR2000
Stator for Percussion Drills Makita HP2010N/HR2000 Genuine part Makita, Stator (FIELD) 230v for Percussion Drill Makita HP2010N - Rotary Hammer HR2000 Part for the following products: - Percussion Drill Makita HP2010N/HR2000 - Rotary...
AVAILABLE €53.67
Details
Seal 16 O-R for Cylinder Stonecutter HK0500
Makita SKU: 213214-4
Seal 16 O-R for Cylinder Stonecutter HK0500
Seal 16 O-R for Cylinder Stonecutter HK0500 Genuine part Makita, Seal 16 O-Ring cylinder for Hammers HR1800/2000 and Stonecutter HK0500. Parts for the following products: - 8015DW - 10.8V HAMMER - 8015DW - 10.8V HAMMER - HK0500 -...
AVAILABLE €2.51
Details
Retaining Ring R32 for Powertools Makita
Makita SKU: 962151-6
Retaining Ring R32 for Powertools Makita
Retaining Ring R32 for Powertools Makita Genuine part Makita, Retaining Ring R32 for Powertools Makita. Parts for the following products: - Angle Grinder115 mm 710w-9554 NB - Angle Grinder115 mm 840w-9557 HN - Angle Grinder115 mm...
AVAILABLE €1.43
Details
Retaining Ring for Stonecutter Makita HK0500
Valex s.p.a. SKU: 231979-6
Retaining Ring for Stonecutter Makita HK0500
Retaining Ring for Stonecutter Makita HK0500 Genuine spare Makita, Retaining Ring for Stonecutter HK0500 - Rotary Hammers BHR200SF - BHR200SFE - BHR200SFEP - BHR200SJEP - BHR200WAE - HR2010 - HR2400 - HR2413 Part for the following...
AVAILABLE €4.19
Details
Leaf Spring for Stonecutter Makita HK0500
Makita SKU: 232192-9
Leaf Spring for Stonecutter Makita HK0500
Leaf Spring for Stonecutter Makita HK0500 Genuine spare part Makita, Leaf Spring for Stonecutter SDS-PLUS HK0500 Part for the following products: - HK0500 - STONECUTTER SDS-PLUS - HR160DWA - ROTARY HAMMER 16MM 12V-2,0AH - HR160DWAE -...
on 7/10 Business Days Approx €4.54
Details
Ball Bearing 6000DD NSK for Cordless Drill Makita 6221DW
Makita SKU: 211061-7
Ball Bearing 6000DD NSK for Cordless Drill Makita 6221DW
Ball Bearing 6000DD NSK for Cordless Drill Makita 6221DW Genuine part Makita, Ball Bearing 6201LLB NSK for Cordless Drills 6221DW - 6075DW - 6012DWK - 6075DW - 6095DW. Parts for the following products: - 1805B - PLANER 155 MM - 1806B...
AVAILABLE €8.69
Details
Change Ring Cover for Rotary Hammer Makita HR2000
Makita SKU: 415076-8
Change Ring Cover for Rotary Hammer Makita HR2000
Change Ring Cover for Rotary Hammer Makita HR2000 Original replacement part Makita, Change Ring Cover for Rotary Hammer Electronic HR2000. Parts for the following products: - HR2000 - ROTARY HAMMER ELECTRONIC - Code: 415076-8
Last items in stock €6.83
Details
Ball Bearing 609 2RS for Pruning Scissor Makita 4604DW
Makita SKU: 211051-0
Ball Bearing 609 2RS for Pruning Scissor Makita 4604DW
Ball Bearing 609 2RS for Pruning Scissor Makita 4604DW Genuine replacement part Makita, Ball Bearing 609 2RS for Pruning Scissor 24V 4604DW. Part for the following products: -  4604DW - PRUNING SCISSOR 24V MAKITA - Code : 211051-0
on 7/10 Business Days Approx €11.19
Details
Comments (0)
