Makita

Makita Spare Parts for Rotary Hammer Drill HR160D

SKU: Makita HR160D
€1.46
VAT included

Makita Spare Parts for Rotary Hammer Drill HR160D

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for HR160D Rotary Hammer Drill.
Makita Spare Parts for Rotary Hammer Drill HR160D
  • Makita Spare Parts for Rotary Hammer Drill HR160D
  • Makita Spare Parts for Rotary Hammer Drill HR160D
Makita

Makita Spare Parts for Rotary Hammer Drill HR160D

SKU: Makita HR160D Condition: New
€1.46
VAT included

Makita Spare Parts for Rotary Hammer Drill HR160D

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for HR160D Rotary Hammer Drill.
settings 61 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
61 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
6
 photo_cameraImage coming soon 931302-2 NUT M6 HR4000C €1.46
7
 Screw M5 X 35 for Angle Grinder Makita GA9050R 266012-5 Screw M5 X 35 for Angle Grinder Makita GA9050R €2.01
8
 photo_cameraImage coming soon 150822-9 Gear Housing Hr160dw Hr2400 Hr2400 €56.04
10
 photo_cameraImage coming soon 211323-3 BALL BEARING 6904 €21.53
11
 photo_cameraImage coming soon 231954-2 Ring Spring 25 Hr2400/hr160dwh Hr2400 €1.41
12
 photo_cameraImage coming soon 267110-8 Ring Washer 31 Hr2400 Hr2400 €5.14
14
 photo_cameraImage coming soon 226260-8 Spur Gear 46 Hr2400/hr160dwh Hr2400 €35.77
17
 photo_cameraImage coming soon 134813-8 Tool Holder Assy Hr2400/hr160 Hr2400 €193.58
19
 photo_cameraImage coming soon 267105-1 FLAT WASHER HR2400 €3.14
21
 photo_cameraImage coming soon 226288-6 Spur Gear 49 Hr160dwh Hr160d €28.32
22
 photo_cameraImage coming soon 211022-7 CUSCINETTO 607ZZ X AH3655 €5.14
23
 photo_cameraImage coming soon 253186-1 FLAT WASHER 7 X 420S €1.38
24
 photo_cameraImage coming soon 219007-7 Swash Bearing 9 Hr2400 Hr2400 €102.90
26
 photo_cameraImage coming soon 322652-0 Clutch Hr2400/hr160dwh Hr2400 €32.75
27
 photo_cameraImage coming soon 213720-9 GASKET 67 €3.41
28
 photo_cameraImage coming soon 322721-7 Cam Shaft Hr160dwh Hr160d €44.86
29
 photo_cameraImage coming soon 226259-3 Spur Gear 10 Hr2400/hr160dwh Hr2400 €35.77
31
 photo_cameraImage coming soon 415372-4 Change Lever Hr2400/hr160dwh Hr2400 €4.43
32
 photo_cameraImage coming soon 213265-7 O-RING 17 HR2400 €1.44
33
 photo_cameraImage coming soon 231288-3 Compression Spring 6 Hr2400/hr Hr2400 €3.85
35
 photo_cameraImage coming soon 251392-2 PAN HEAD SCREW M4 €1.41
36
 photo_cameraImage coming soon 265715-8 Wing Screw M6x40 Hr2400 €5.94
38
 photo_cameraImage coming soon 213063-9 GASKET 10 X HR2000 €5.24
39
 photo_cameraImage coming soon 323723-6 Impact Bolt Hr160dw Hr2400 €5.94
40
 photo_cameraImage coming soon 262038-5 Rubber Ring 17 Hr2000/hr160dwh Hr2400 €2.69
41
 photo_cameraImage coming soon 321915-1 Idler Hr2000/hr160dwh Hr2400 €18.98
42
 photo_cameraImage coming soon 267109-3 Special Washer 13.5 Hr240 Hr2400 €6.64
43
 photo_cameraImage coming soon 231953-4 Ring Spring 23 Hr2400/hr160dwh Hr2400 €1.41
44
 photo_cameraImage coming soon 322720-9 Striker Hr160dwh Hr160d €24.36
45
 Seal 16 O-R for Cylinder Stonecutter HK0500 213214-4 Seal 16 O-R for Cylinder Stonecutter HK0500 €2.51
46
 photo_cameraImage coming soon 316450-2 Piston Cylinder Hr2400/hr160dw Hr2400 €68.88
48
 photo_cameraImage coming soon 267104-3 FLAT WASHER 12 X HR2400 €2.15
50
 photo_cameraImage coming soon 689028-7 Radiating Plate Hr160dwh Hr160d €7.58
51
 photo_cameraImage coming soon 911013-5 SCREW M3X10 €1.40
52
 photo_cameraImage coming soon 651911-8 Switch Tg503bflb-1 Hr160dwh Hr160d €113.16
54
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
57
 Switch for Battery Clamp for Cordless Drills Makita 6317DWDE-6271-6281-8271 DWAE 643918-8 Switch for Battery Clamp for Cordless Drills Makita 6317DWDE-6271-6281-8271 DWAE €8.40
58
 photo_cameraImage coming soon 344121-1 PLATE X 6221DW €3.14
59
 photo_cameraImage coming soon 415499-0 Switch Lever Hr160dwh Hr160d €3.14
60
 photo_cameraImage coming soon 421495-8 Dust Cover Hr160dwh Hr160d €3.85
61
 photo_cameraImage coming soon 182672-4 Motor Housing Set Hr160dwh Hr160d €56.04
62
 photo_cameraImage coming soon 263024-9 PIN RUBBER 4 X 6916DW €2.86
63
 photo_cameraImage coming soon 263014-2 RUBBER PIN 4 €1.42
64
 photo_cameraImage coming soon 819063-3 MAKITA LABEL X BFL300F €1.40
65
 photo_cameraImage coming soon 322517-6 Roller 7 Hr2000 (tib136) Hr160 Hr2400 €2.06
66
 photo_cameraImage coming soon 154404-9 Change Ring Comp Hr2000/hr160d Hr2400 €44.42
66
 Chuck Ring for Power Scraper Makita HK0500 323724-4 Chuck Ring for Power Scraper Makita HK0500 €14.74
67
 photo_cameraImage coming soon 286234-1 Cap 37 Hr2000 Hr160dw Hr2400 €12.57
67
 Cap 31 for Power Scraper Makita HK0500 286265-0 Cap 31 for Power Scraper Makita HK0500 €2.02
68
 photo_cameraImage coming soon 232190-3 LEAF SPRING 26 BHR200S/HR2430 €3.14
68
 Leaf Spring for Stonecutter Makita HK0500 232192-9 Leaf Spring for Stonecutter Makita HK0500 €4.54
69
 photo_cameraImage coming soon 344574-4 Spring Guide Hr160dw Hr2400 €2.08
70
 Change Ring Cover for Rotary Hammer Makita HR2000 415076-8 Change Ring Cover for Rotary Hammer Makita HR2000 €6.83
70
 photo_cameraImage coming soon 416410-5 CHUCK COVER, HR2412 €2.68
71
 photo_cameraImage coming soon 213068-9 O Ring 10 Hr2000 Tib136 Hr2400 €1.39
71
 Compression Spring 38 for Rotary Hammer Makita HR3000C 233203-3 Compression Spring 38 for Rotary Hammer Makita HR3000C €3.27
72
 photo_cameraImage coming soon 233202-5 COMPRESSION SPRING 20 HR160DW €1.57
73
 photo_cameraImage coming soon 216009-4 BALL 7.1 €1.39
73
 Steel Ball 7 mm for Hammers Makita 216022-2 Steel Ball 7 mm for Hammers Makita €1.47
74
 photo_cameraImage coming soon 257172-4 Ring 20 Hr2000 (tib136) Hr160d Hr2400 €5.89
1002
 photo_cameraImage coming soon 414938-7 Battery Cover Uc120dw/Vr250dw €1.80

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Rotary Hammer Drill HR160D

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for HR160D Rotary Hammer Drill.

In the following table, look for the model of Rotary Hammer and the respective parts of the code.
Makita HR160D
Makita HR160D Rotary Hammer Drill
# Part Num. Description
5 273634-4 Grip 33 Hr160dwh Hr160d
6 931302-2 Hex Full Nut M6 Lf1000/Dst111
7 266012-5 Pt Screw 5x35
8 150822-9 Gear Housing Hr160dw Hr2400 Hr2400
10 211323-3 Ball Bearing 6904llu Hr2000/hr Hr4011c
11 231954-2 Ring Spring 25 Hr2400/hr160dwh Hr2400
12 267110-8 Ring Washer 31 Hr2400 Hr2400
14 226260-8 Spur Gear 46 Hr2400/hr160dwh Hr2400
17 134813-8 Tool Holder Assy Hr2400/hr160 Hr2400
19 267105-1 Narrow Washer 29 Hr2400 Hr2811ft
20 857521-1 Name Plate Hr160dwh Hr160d
21 226288-6 Spur Gear 49 Hr160dwh Hr160d
22 211022-7 Ball Bearing 607zz
23 253186-1 Thin Washer 7 Hr160D/Lf1000
24 219007-7 Swash Bearing 9 Hr2400 Hr2400
26 322652-0 Clutch Hr2400/hr160dwh Hr2400
27 213720-9 O Ring 67 Ga7050/Ga9050/
28 322721-7 Cam Shaft Hr160dwh Hr160d
29 226259-3 Spur Gear 10 Hr2400/hr160dwh Hr2400
31 415372-4 Change Lever Hr2400/hr160dwh Hr2400
32 213265-7 O Ring 17 Hr2400/Hr160dwh
33 231288-3 Compression Spring 6 Hr2400/hr Hr2400
35 251392-2 Pan Hd Screw M4x11 Hr2430
36 265715-8 Wing Screw M6x40 Hr2400
38 213063-9 O Ring 10 Hr2000/hr160dwh/hr24 Hr2430
39 323723-6 Impact Bolt Hr160dw Hr2400
40 262038-5 Rubber Ring 17 Hr2000/hr160dwh Hr2400
41 321915-1 Idler Hr2000/hr160dwh Hr2400
42 267109-3 Special Washer 13.5 Hr240 Hr2400
43 231953-4 Ring Spring 23 Hr2400/hr160dwh Hr2400
44 322720-9 Striker Hr160dwh Hr160d
45 213214-4 O Ring 16
46 316450-2 Piston Cylinder Hr2400/hr160dw Hr2400
48 267104-3 Flat Washer 12 Btd043/063/103
49 629685-9 Dc Motor Hr160dwh Hr160d
50 689028-7 Radiating Plate Hr160dwh Hr160d
51 911013-5 Pan Hd Screw M3x10 Dsd180
52 651911-8 Switch Tg503bflb-1 Hr160dwh Hr160d
54 265995-6 Pt Screw 4X18 Uh4570/55/65/55
57 643918-8 Battery Holder
58 344121-1 Set Plate Hr160dwh/6831dw/6942 Hr160d
59 415499-0 Switch Lever Hr160dwh Hr160d
60 421495-8 Dust Cover Hr160dwh Hr160d
61 182672-4 Motor Housing Set Hr160dwh Hr160d
62 263024-9 Rubber Pin 4
63 263014-2 Rubber Pin 4
64 819063-3 Label/Makita 500
65 322517-6 Roller 7 Hr2000 (tib136) Hr160 Hr2400
66 154404-9 Change Ring Comp Hr2000/hr160d Hr2400
66 323724-4 Chuck Ring Hr160dw Hr2400
67 286265-0 Cap 31 Hr160dw/hr2410/2420 Hr2430
67 286234-1 Cap 37 Hr2000 Hr160dw Hr2400
68 232190-3 Leaf Spring 26 Bhr200s/hr2430 Hr3000c
68 232192-9 Leaf Spring 26 Hk0500/hr2400/ Hr2400
69 344574-4 Spring Guide Hr160dw Hr2400
70 416410-5 Chuck Cover Hr160dw/hr2410/242 Hr2430
70 415076-8 Change Ring Cover Hr2000 (tib1 Hr2420
71 233203-3 Compression Spring 38 Hr160dw Hr3000c
71 213068-9 O Ring 10 Hr2000 Tib136 Hr2400
72 233202-5 Compression Spring 20 Hr160dw Hr2400
73 216009-4 Steel Ball 7.1
73 216022-2 Steel Ball 7.0 M3601/M8701
74 257172-4 Ring 20 Hr2000 (tib136) Hr160d Hr2400
1002 414938-7 Battery Cover Uc120dw/Vr250dw
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita HR160D
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Drawing Makita HR160D

Drawing Makita HR160D

Download (138.24KB)

You might also like

Carbon Brushes Makita for Angle Grinders 9554-9555-9557
Makita SKU: 194074-2
Carbon Brushes Makita for Angle Grinders 9554-9555-9557
Carbon Brushes Makita for Angle Grinders 9554-9555-9557 Genuine spare part Makita,  Carbon Brushe Set CB-325 for Angle Grinders 9554HN - 9554HNG - 9554NB - 9555NB - 9557HN - 9557HNG - 9557HP - 9557NB -...
Last items in stock €4.19
Details
Ring 16 O-Ring for Hammers Makita
Valex s.p.a. SKU: 213227-5
Ring 16 O-Ring for Hammers Makita
Ring 16 O-Ring for Hammers Makita Genuine spare Makita, O-Ring for Hammers SDS Plus and Stonecutter,  BHR202RFE - BHR240RFE  -  HK0500 -  HR2020 -  HR2450 -  HR2470F and compatible. Part for the following products: - Cordless rotary...
Last items in stock €4.19
Details
Carbon Brushes Makita for Sanders BO4555-4556-4565-4566
Makita SKU: 191962-4
Carbon Brushes Makita for Sanders BO4555-4556-4565-4566
Carbon Brushes Makita for Sanders BO4555-4556-4565-4566 Genuine Parts Makita, Carbon Brushes for: Jigsaws 4304 - 4305 - 4306 - 4340 - 4341 - 4350 - 4351, for Drills 6310 -  6408 - 6824, for Sanders  BO4555 - 4556 - 4565 - 4566 Part...
AVAILABLE €7.53
Details
Armature for Hammer 18 mm Makita HR1830 Sale
Makita SKU: 515649-8
Armature for Hammer 18 mm Makita HR1830
Armature for Hammer 18 mm Makita HR1830 Genuine spare part Makita, Armature 240V for Rotary Hammer SDS PLUS 18 mm Makita HR1830 For the Following Items : -  HR1830 - ROTARY HAMMER SDS+18MM 2 FUNCTIONS - Code : 515649-8
Last items in stock €41.89
Details
Armature for Hammer 20mm Makita HR2300 Sale
Makita SKU: 515354-7
Armature for Hammer 20mm Makita HR2300
Armature for Rotary Hammer 20mm Makita HR2300 Genuine spare part Makita, Armature for SDS PLUS Rotary Hammer 20 mm 720 W Makita HR2300. Part for the Following Items : -  HR2300 - ROTARY HAMMER SDS+ 23MM 2 FUNC. - Code : 515354-7
AVAILABLE €46.94
Details
Steel Ball 7 mm for Hammers Makita
Makita SKU: 216022-2
Steel Ball 7 mm for Hammers Makita
Steel Ball 7 mm for Hammers Makita Genuine spare part Makita, Steel Ball 7 mm diameter for Hammers SDS Plus and Cordless, BHR162RFE - BHR200SFE - BHR240RFE - BHR241RFE - BHR261DP1 - DHR263Z - HR1830 -  HR2420 - HR2611FT....
build View Spare Parts
Stator for Hammer 18 mm Makita HR1830 -10%
Makita SKU: 633624-3
Stator for Hammer 18 mm Makita HR1830
Stator for Hammer 18 mm Makita HR1830 Genuine spare part Makita, Stator (FIELDS) 240V for SDS PLUS Hammers 18 mm Makita HR1830. Part for the following products: -  HR1830 - ROTARY HAMMER SDS+18MM 2 FUNZ - Code : 633624-3
AVAILABLE €14.98 €16.64
Details
Carbon Brushes CB-325 for Angle Grinder Makita 9554NB
Makita SKU: 194074-2
Carbon Brushes CB-325 for Angle Grinder Makita 9554NB
Carbon Brushes CB-325 for Angle Grinder Makita 9554NB Original spare part Makita for Angle Grinder, Carbon Brushes for 9554HN - 9554HNG - 9554NB - 9555NB - 9555NB - 9557HN - 9558HN - 9564H Part for the following products: - ANGLE...
AVAILABLE €4.19
Details
Bearing for Angle Grinder Makita 9524NB
Makita SKU: 211012-0
Bearing for Angle Grinder Makita 9524NB
Bearing for Angle Grinder Makita 9524NB Genuine spare Makita, Ball Bearing 606 2Z for Angle Grinder 9524NB. Part for the following products: - CIRCULAR SAW 165 MM 5604R - CIRCULAR SAW 165 MM-18V 2.2Ah Ni-MH 5621RDWBE - KEYLESS DRILL...
AVAILABLE €8.23
Details
Spring 21-29 for 20 mm Hammer Makita HR2020
Makita SKU: 233916-6
Spring 21-29 for 20 mm Hammer Makita HR2020
Spring 21-29 for 20 mm Hammer Makita HR2020 Original spare Makita, 21-29 Spring for 20 mm Hammerdrill SDS Plus 710 W Makita HR2020. Part for the following products: - Hammer SDS-PLUS 18MM 1830 - Hammer 24MM 750W 2450 - Hammer 720W...
AVAILABLE €3.18
Details
Ring 21 for Chuck Hammer Makita HR2020
Makita SKU: 257241-1
Ring 21 for Chuck Hammer Makita HR2020
Ring 21 for Chuck Hammer Makita HR2020 Genuine part Makita, Ring 21 for Hammers HR1830 - HR2020 - HR2230 - BHR162-202-240-241-261-262RFE - DHR164Z. Parts for the following products: - BHR162RFE - Cordless Hammer 14.4V LITHIUM BATTERY...
AVAILABLE €3.31
Details
Ball Bearing Protection for Angle Grinder Makita GA4530
Makita SKU: 421868-5
Ball Bearing Protection for Angle Grinder Makita GA4530
Ball Bearing Protection for Angle Grinder Makita GA4530 Genuine part Makita, Rubber Ring Ball Bearing Protection for Angle Grinder GA4530 - GA4530R - GA4534 - GA5034 - 9554HN - 9554HNG - 9554NB - 9555NB. Parts for the following...
AVAILABLE €2.00
Details
Stator for Hammer 20-24 mm Makita HR2020-HR2440
Makita SKU: 633488-5
Stator for Hammer 20-24 mm Makita HR2020-HR2440
Stator for Hammer 20-24 mm Makita HR2020-HR2440 Genuine parts Makita, 240V Stator (FIELD) for Hammers SDS-PLUS 20-24mm Makita HR2020 - HR2432 - HR2440 - HR2450 - HR2450F - HR2450FT - HR2450X.  Part for the following products: - HR2020...
AVAILABLE €16.00
Details
Armature for Hammer 24mm Makita HR2440 Sale
Makita SKU: 515668-4
Armature for Hammer 24mm Makita HR2440
Armature for Hammer 24mm Makita HR2440 Genuine spare part Makita, 220-230 V Armature for SDS PLUS Hammers 24 mm 780 W HR2440 - HR2450 - HR2450F - HR2450FT - HR2450X. Part for the following products: - HR2440 - HAMMER 24MM SDS-PLUS...
AVAILABLE €67.13
Details
Cover Cap Bits for Rotary Hammer MAKITA HR2020
Makita SKU: 286263-4
Cover Cap Bits for Rotary Hammer MAKITA HR2020
Cover Cap Bits for Rotary Hammer MAKITA HR2020 Original parts Makita, Cover Cap for Rotary Hammers BHR162RFE - BHR202RFE - BHR240RFE - BHR241RFE - BHR243RFE - BHR261DP1 - BHR261TDP1 - BHR262RDE - BHR262TRDE - DHR164Z - DHR165Z -...
Last items in stock €4.86
Details
Elastic Ring 19 for HAMMER Makita HR2020
Makita SKU: 233940-9
Elastic Ring 19 for HAMMER Makita HR2020
Elastic Ring 19 for HAMMER Makita HR2020 Genuine spare Makita, Elastic Ring 19 for Hammers HK1820 - HR1830 - HR2020 - HR2230 - HR2432 - HR2440 - HR2450 - HR2450F - HR2450FT - HR2450X - HR2460 - HR2470 - HR2470F - HR2470FT - HR2610T -...
AVAILABLE €1.50
Details
Cap 31 for Power Scraper Makita HK0500
Makita SKU: 286265-0
Cap 31 for Power Scraper Makita HK0500
Cap 31 for Power Scraper Makita HK0500 Genuine spare part Makita, Cap 31 for SDS-PLUS Power Scraper HK0500. Part for the following products: -  HK0500 - POWER SCRAPER SDS-PLUS - Code : 286265-0
Usually Ships in: 7/10 Business Days Approx. €2.02
Details
Comments (0)
