Makita Spare Parts for Masonry Saw Dry Cutting 4100KB

SKU: Makita 4100KB
€1.42
VAT included

Makita Spare Parts for Masonry Saw Dry Cutting 4100KB

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for 4100KB 5" Dry Masonry Saw, with Dust Extraction.
Makita Spare Parts for Masonry Saw Dry Cutting 4100KB
  • Makita Spare Parts for Masonry Saw Dry Cutting 4100KB
  • Makita Spare Parts for Masonry Saw Dry Cutting 4100KB
Makita

Makita Spare Parts for Masonry Saw Dry Cutting 4100KB

SKU: Makita 4100KB Condition: New
€1.42
VAT included

Makita Spare Parts for Masonry Saw Dry Cutting 4100KB

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for 4100KB 5" Dry Masonry Saw, with Dust Extraction.
settings 58 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN: Usually Ships in 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Saw
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
58 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 450838-7 HANDLE COVER €0.12 Not available for order
2
 photo_cameraImage coming soon 650248-0 SWITCH SGES115C-3 €0.12 Not available for order
3
 photo_cameraImage coming soon 424585-6 DUST PROTECTION HOOD €0.12 Not available for order
4
 photo_cameraImage coming soon 654532-5 TERMINAL BLOCK 6E / 1DS €1.32
5
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
7
 photo_cameraImage coming soon 911263-2 HEAD SCREW CILIND. €1.32
9
 Cord Guard JN1601 for Angle Grinder Makita 9015B 682540-6 Cord Guard JN1601 for Angle Grinder Makita 9015B €2.50
10
 photo_cameraImage coming soon 687124-5 CORD CLAMP MT953 €1.32
11
 photo_cameraImage coming soon 141726-6 MOTOR CASE €0.12 Not available for order
12
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
13
 Capacitor for Angle Grinder Makita GA4530 645200-1 Capacitor for Angle Grinder Makita GA4530 €2.65
14
 photo_cameraImage coming soon 424634-9 SPONGE €0.12 Not available for order
15
 Carbon Brushes CB-303 for Belt Sander Makita 9920X 191963-2 Carbon Brushes CB-303 for Belt Sander Makita 9920X €8.30
16
 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C 643750-0 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C €2.03
17
 photo_cameraImage coming soon 599095-3 FIELD 220V €0.12 Not available for order
18
 photo_cameraImage coming soon 450839-5 DEFLECTOR €0.12 Not available for order
19
 photo_cameraImage coming soon 266038-7 SCREW M5 X 70 €3.84
20
 photo_cameraImage coming soon 213262-3 O-RING 18 4100R €2.59
21
 photo_cameraImage coming soon 253192-6 FLAT WASHER 14 €1.40
22
 photo_cameraImage coming soon 211395-8 BEARING 608LLU €0.12 Not available for order
23
 photo_cameraImage coming soon 681644-1 INSULATED WASHER for 9227CB €2.74
24
 photo_cameraImage coming soon 513769-2 ARMATURE 240V COMPLETE €0.12 Not available for order
25
 photo_cameraImage coming soon 240109-8 FAN 70 €0.12 Not available for order
26
 Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €8.63
27
 photo_cameraImage coming soon 226695-3 GEAR 17 €0.12 Not available for order
28
 photo_cameraImage coming soon 961002-0 RETAINING RING S6 €1.24
29
 photo_cameraImage coming soon 144781-7 GEAR BOX 4100KB €27.92
30
 photo_cameraImage coming soon 251586-9 SCREW M6 4100KB €0.00 Not available for order
31
 photo_cameraImage coming soon 213444-7 RING 30 €0.12 Not available for order
32
 photo_cameraImage coming soon 226696-1 GEAR 44 €0.12 Not available for order
33
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.32
34
 photo_cameraImage coming soon 911223-4 HEAD SCREW CILIND. M5X16 €1.44
35
 photo_cameraImage coming soon 135948-8 BEARING BOX €4.14
36
 Bearing 6201DD NSK for Powertools Makita 211129-9 Bearing 6201DD NSK for Powertools Makita €8.63
37
 photo_cameraImage coming soon 325603-2 POST €0.12 Not available for order
38
 photo_cameraImage coming soon 285858-0 BEARING RETENTION 19-33 €0.12 Not available for order
39
 photo_cameraImage coming soon 213279-6 RING 18 X MT582 €0.00 Not available for order
40
 photo_cameraImage coming soon 253397-8 CUP WASHER 15 4100KB €5.90
41
 photo_cameraImage coming soon 224423-0 INNER FLANGE 36 €0.12 Not available for order
42
 photo_cameraImage coming soon 224424-8 OUTER FLANGE 36 €0.12 Not available for order
43
 photo_cameraImage coming soon 266510-9 SCREW M6x18 €0.12 Not available for order
44
 photo_cameraImage coming soon 257982-9 RING RETAINING X HS6101 €0.00 Not available for order
45
 photo_cameraImage coming soon 271443-5 LEVER 49 100KB €2.20
46
 photo_cameraImage coming soon 264103-6 NUT M6 €0.00 Not available for order
47
 photo_cameraImage coming soon 253111-2 FLAT WASHER 6 X 9803 €1.22
48
 photo_cameraImage coming soon 161775-7 BASE 4100KB €5.90
49
 photo_cameraImage coming soon 252103-8 LOCKNUT X JR3020 €1.32
50
 photo_cameraImage coming soon 266515-9 SCREW M5 €0.12 Not available for order
51
 photo_cameraImage coming soon 416741-2 JOINT VACUUM X X SG1250 / 2 €5.75
52
 O-Ring 35 for Demolition Hammers Makita HR 4501-10-11C 213460-9 O-Ring 35 for Demolition Hammers Makita HR 4501-10-11C €3.29
53
 Dust Guard Right Side for Mansory Saw Makita 4100KB 458035-9 Dust Guard Right Side for Mansory Saw Makita 4100KB €4.57
54
 photo_cameraImage coming soon 213005-3 RING 5 €0.00 Not available for order
55
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
56
 photo_cameraImage coming soon 458605-4 LH POWDER COVER €0.12 Not available for order
57
 photo_cameraImage coming soon 233267-7 SPRING COMPRESSION X 7 AN621 €1.96
58
 WASHER 6 X HM1303 941151-9 WASHER 6 X HM1303 €3.66
59
 photo_cameraImage coming soon 265658-4 SCREW M6x26 €0.12 Not available for order
60
 photo_cameraImage coming soon 347305-0 PLATE €0.12 Not available for order
61
 photo_cameraImage coming soon 126911-2 DUST COVER 4100KB €0.12 Not available for order

Shipping and delivery information will be available shortly.

Makita Spare Parts for Masonry Saw Dry Cutting 4100KB

MAKITA Original spare parts

at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for 4100KB 5" Dry Masonry Saw, with Dust Extraction.

In the following table, look for the model of Dustless Cutter and the respective parts of the code.
Makita 4100KB

4100KB 5" Dry Masonry Saw, with Dust Extraction
# Part Num. Description
1 450838-7 HANDLE COVER
2 650248-0 SWITCH SGES115C-3
3 424585-6 DUST PROTECTION HOOD
4 654532-5 CLAMP 1P
5 265995-6 * SCREW M4X18 X 6408 / 6221DW
7 911263-2 CYLINDER HEAD SCREW M5x40
9 682540-6 SLEEVE JN1601
10 687124-5 MT953 CABLE CLAMP
11 141726-6 MOTOR CASE
12 265995-6 * SCREW M4X18 X 6408 / 6221DW
13 645200-1 CAPACITOR
14 424634-9 SPONGE
15 191963-2 CARBON BRUSHES CB-303
16 643750-0 CARBON BRUSH HOLDER CAP
17 599095-3 FIELD 220V
18 450839-5 DEFLECTOR
19 266038-7 SCREW M5 X 70 HP2030
20 213262-3 GASKET 18 4100R
21 253192-6 FLAT WASHER 14
22 211395-8 BEARING 608LLU
23 681644-1 INSULATING WASHER X 9227CB
24 513769-2 ARMATURE 240V COMPLETE
25 240109-8 FAN 70
26 211092-6 BALL BEARING 629DD
27 226695-3 GEAR 17
28 961002-0 RETAINING RING S6
29 144781-7 GEAR BOX 4100KB
30 251586-9 SCREW M6 4100KB
31 213444-7 RING 30
32 226696-1 GEAR 44
33 961052-5 RETAINING RING S12
34 911223-4 CYLINDER HEAD SCREW M5X16
35 135948-8 BEARING BOX
36 211129-9 BALL BEARING 6201DD NSK
37 325603-2 POST
38 285858-0 BEARING RETENTION 19-33
39 213279-6 RING 18 X MT582
40 253397-8 CUP WASHER 15 4100KB
41 224423-0 INNER FLANGE 36
42 224424-8 OUTER FLANGE 36
43 266510-9 SCREW M6x18
44 257982-9 LOCKING RING X HS6101
45 271443-5 LEVER 49 100KB
46 264103-6 NUT M6
47 253111-2 FLAT WASHER 6 X 9803
48 161775-7 BASE 4100KB
49 252103-8 NUT X JR3020
50 266515-9 SCREW M5
51 416741-2 JOINT X ASPIRATOR X SG1250 / 2
52 213460-9 GASKET 35 HK / HR1800 / HM12
53 458035-9 DUST GUARD RIGHT SIDE
54 213005-3 RING 5
55 265995-6 * SCREW M4X18 X 6408 / 6221DW
56 458605-4 LH POWDER COVER
57 233267-7 COMPRESSION SPRING 7 X AN621
58 941151-9 WASHER 6 X HM1303
59 265658-4 SCREW M6x26
60 347305-0 PLATE
61 126911-2 DUST COVER 4100KB
