Makita Spare Parts for Angle Grinder GA9061R

SKU: Makita GA9061R
€36.83
VAT included

Makita Spare Parts for Angle Grinder GA9061R

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9061R.
Makita Spare Parts for Angle Grinder GA9061R
  • Makita Spare Parts for Angle Grinder GA9061R
  • Makita Spare Parts for Angle Grinder GA9061R
Makita

Makita Spare Parts for Angle Grinder GA9061R

SKU: Makita GA9061R Condition: New
€36.83
VAT included

Makita Spare Parts for Angle Grinder GA9061R

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9061R.
settings 43 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
43 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
4
 photo_cameraImage coming soon 143485-8 GEAR BOX €26.25
5
 photo_cameraImage coming soon 456238-9 GA9060 DEFLECTOR €2.00
6
 photo_cameraImage coming soon 252194-9 NUT M8 GA9020 €1.79
7
 photo_cameraImage coming soon 227652-4 GEAR 13 €5.58
8
 Ball Bearing 6301DD for Angle Grinders Makita 211132-0 Ball Bearing 6301DD for Angle Grinders Makita €13.46
9
 photo_cameraImage coming soon 262085-6 RUBBER RING 38 9079S €1.42
10
 Washer 20 for Angle Grinder Makita GA9020 267299-2 Washer 20 for Angle Grinder Makita GA9020 €1.27
11
 photo_cameraImage coming soon 962211-4 RETAINING RING R42 €3.13
12
 photo_cameraImage coming soon 513448-2 ARMATURE ASS'Y 220V €62.45
13
 photo_cameraImage coming soon 240161-6 FAN 86 €7.29
14
 photo_cameraImage coming soon 681630-2 WASHER 9029-9029SF. €2.90
15
 photo_cameraImage coming soon 211087-9 BALL BEARING 6200DDW €8.75
17
 photo_cameraImage coming soon 621779-6 STATOR 240V €50.50
18
 photo_cameraImage coming soon 266044-2 SCREW PT.5X60 €6.04
21
 photo_cameraImage coming soon 456240-2 MOTOR HOUSING €26.25
22
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
23
 photo_cameraImage coming soon 143950-7 COVER BRUSH DX €4.89
24
 photo_cameraImage coming soon 197129-2 CARBON BRUSH CB-218 €4.54
26
 photo_cameraImage coming soon 143949-2 COVER BRUSH SX €3.78
27
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
30
 Capacitor for Angle Grinder Makita GA9020 645088-9 Capacitor for Angle Grinder Makita GA9020 €1.50
31
 photo_cameraImage coming soon 620588-0 REGULATOR €32.91
33
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
35
 photo_cameraImage coming soon 682573-1 CORD ARMOR 10 X GA9010C €3.41
36
 photo_cameraImage coming soon 632F79-5 SWITCH €20.78
37
 photo_cameraImage coming soon 687169-3 STRAIN RELIEF HP1620 €1.46
38
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
39
 photo_cameraImage coming soon 183C62-2 HANDLE €12.24
41
 photo_cameraImage coming soon 213026-5 RING 7 X GA9010C €2.64
43
 photo_cameraImage coming soon 211032-4 BEARING X 1902 €5.87
44
 Ext DIN471 Circlip-15 for Makita Power Tools 961055-9 Ext DIN471 Circlip-15 for Makita Power Tools €1.47
46
 photo_cameraImage coming soon 346981-7 RING C33 €3.28
47
 photo_cameraImage coming soon 346982-5 RING C29 €3.28
48
 photo_cameraImage coming soon 326640-9 SLEEVE €8.14
50
 photo_cameraImage coming soon 227654-0 GEAR 54 €26.25
51
 photo_cameraImage coming soon 911128-8 SCREW M4x16 X HR4000C €2.74
52
 photo_cameraImage coming soon 285742-9 BEARING CHAIN 59 €1.56
54
 photo_cameraImage coming soon 211377-0 BEARING 6905LLB X BHR200 €9.33
55
 photo_cameraImage coming soon 213760-7 SEAL 78 HR2010 €2.69
56
 photo_cameraImage coming soon 143515-5 BEARING BOX €24.03
57
 photo_cameraImage coming soon 265541-5 SCREW M6X22 GA9020 €1.79
58
 photo_cameraImage coming soon 326641-7 SHAFT €7.29
59
 Cover Disc for Angle Grinder Makita GA9020 122891-0 Cover Disc for Angle Grinder Makita GA9020 €36.84
60
 Inner Flange 42 for Angle Grinder Makita 9524NB 224490-5 Inner Flange 42 for Angle Grinder Makita 9524NB €2.94
61
 photo_cameraImage coming soon 224485-8 NUT 14-45 €3.28

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Angle Grinder GA9061R

Distribution and Sale at attractive prices of Makita Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA9061R.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita GA9061R

Angle Grinder GA9061R
# Part Num. Description
1 456247-8 BUTTON PIN
2 234391-9 SPRING COMPRESSION 8
3 251489-7 SCREW 5X30
4 143485-8 GEAR BOX
5 456238-9 GA9060 DEFLECTOR
6 252194-9 NUT M8 FOR GA9020
7 227652-4 GEAR 13
8 211132-0 BALL BEARING 6301DD
9 262085-6 RUBBER RING 38 9079S
10 267299-2 WASHER 20 FOR GA9020
11 962211-4 RETAINING RING R42
12 513448-2 ARMATURE ASS'Y 220V
13 240161-6 FAN 86
14 681630-2 WASHER X 9029-9029SF.
15 211087-9 BALL BEARING 6200DDW NSK
16 456239-7 PLATE
17 621779-6 STATOR 240V
18 266044-2 SCREW PT.5X60
21 456240-2 MOTOR HOUSING
22 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
23 143950-7 COVER BRUSH DX
24 197129-2 CARBON BRUSH CB-218
25 643715-2 BRUSH HOLDER
26 143949-2 COVER BRUSH SX
27 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
30 645088-9 CAPACITOR FOR GA9020
31 620588-0 REGULATOR
32 251489-7 SCREW 5X30
33 265995-6 SCREW M4X18 X 6408 / 6221DW
35 682573-1 CORD GUARD 10 X GA9010C
36 632F79-5 SWITCH
37 687169-3 CABLE CLAMP HP1620
38 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
39 183C62-2 HANDLE
41 213026-5 RING 7 X GA9010C
42 256571-7 PIN 7
43 211032-4 BEARING X 1902
44 961055-9 RETAINING RING S15
45 346980-9 BALANCER
46 346981-7 RING C33
47 346982-5 RING C29
48 326640-9 SLEEVE
49 213859-8 RING 19
50 227654-0 GEAR 54
51 911128-8 SCREW M4X16 X HR4000C
52 285742-9 BEARING CHAIN 59
53 253725-7 WASHER 17
54 211377-0 BEARING 6905LLB X BHR200
55 213760-7 GASKET 78 HR2010
56 143515-5 BEARING BOX
57 265541-5 SCREW M6X22 FOR GA9020
58 326641-7 SHAFT
59 122891-0 SPARK GUARD FOR GA9020
60 224490-5 INTERNAL FLANGE 42
61 224485-8 NUT 14-45
