August Summer Clousure
Makita

Makita Spare Parts for Finishing Sander M9203

SKU: Makita M9203
€0.12
VAT included

Makita Spare Parts for Finisching Sander M9203 180w

Makita original replacement parts for to replace broken parts for to fix Finishing Sander M9203 180w

Makita Spare Parts for Finishing Sander M9203
  • New
  • Out-of-Stock
  • Makita Spare Parts for Finishing Sander M9203
  • Makita M9203 Drawing
Makita

Makita Spare Parts for Finishing Sander M9203

SKU: Makita M9203 Condition: New
€0.12
VAT included

Makita Spare Parts for Finisching Sander M9203 180w

Makita original replacement parts for to replace broken parts for to fix Finishing Sander M9203 180w

settings 36 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

Machine Type: Sander
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
36 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
2
 photo_cameraImage coming soon 451927-1 TOP COVER MT923 €6.32
3
 Rubber Pin for Hammer SDS-Max Makita HR4000C 263002-9 Rubber Pin for Hammer SDS-Max Makita HR4000C €1.32
4
 photo_cameraImage coming soon 194968-1 CARBON BRUSHES CB-64(56,57) €2.31
5
 Brushes Support for Orbital Sander Makita BO4901 643552-4 Brushes Support for Orbital Sander Makita BO4901 €2.65
6
 photo_cameraImage coming soon 654532-5 TERMINAL BLOCK 6E / 1DS €1.32
7
 photo_cameraImage coming soon 424086-4 SWITCH COVER MT923 €1.24
8
 photo_cameraImage coming soon 651527-9 INTERRUTTORE PER BO4555 €3.83
9
 photo_cameraImage coming soon 645228-9 CAPACITOR MT924 €1.28
10
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
11
 photo_cameraImage coming soon 687124-5 CORD CLAMP MT953 €1.32
13
 photo_cameraImage coming soon 682502-4 CABLE SLEEVE 8/85 €2.65
14
 photo_cameraImage coming soon 456555-7 MOTOR HOUSING €24.95
16
 photo_cameraImage coming soon 593739-7 STATOR MT923 €24.95
17
 photo_cameraImage coming soon 266560-4 SCREW 4x40 HS300D €1.32
18
 photo_cameraImage coming soon 210062-2 BEARING 607ZZ X MT601 €2.03
19
 photo_cameraImage coming soon 681670-0 INSULATION WASHER X JR180D €1.32
20
 photo_cameraImage coming soon 515799-9 ARMATURE MT923 €33.57
21
 FLAT WASHER 10 6221DW 253180-3 FLAT WASHER 10 6221DW €2.03
22
 photo_cameraImage coming soon 211087-9 BALL BEARING 6200DDW €8.63
23
 photo_cameraImage coming soon 451928-9 BOX BEARING MT923 €6.00
24
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
25
 FLAT WASHER 10 6221DW 253180-3 FLAT WASHER 10 6221DW €2.03
26
 photo_cameraImage coming soon 241677-4 FAN 68 MT923 €4.87
27
 photo_cameraImage coming soon 213983-7 RING 4 BO4555 €1.32
28
 photo_cameraImage coming soon 318151-8 FOOT BO4555 €1.32
29
 photo_cameraImage coming soon 424023-8 BUSH DUST BO4555 €1.32
30
 photo_cameraImage coming soon 213983-7 RING 4 BO4555 €1.32
31
 photo_cameraImage coming soon 266427-6 SCREW 4X12 MT923 €1.32
32
 photo_cameraImage coming soon 324873-0 MT923 LEVER PAPER €1.32
33
 photo_cameraImage coming soon 267239-0 WASHER 7 MT923 €1.24
34
 photo_cameraImage coming soon 451930-2 BOX INTAKE MT923 €4.44
35
 photo_cameraImage coming soon 213315-8 RING 19 X BO3700 €1.32
36
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
37
 photo_cameraImage coming soon 423470-0 SPONGE RING MT923 €1.24
38
 photo_cameraImage coming soon 451929-7 BASE MT923 €14.64
39
 Seal 53 for Demolition Hammer MAKITA HM1200 213656-2 Seal 53 for Demolition Hammer MAKITA HM1200 €1.32
40
 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 211228-7 Ball Bearing 6202DD for Demolition Hammer Makita HM1800 €8.63
41
 photo_cameraImage coming soon 318622-5 ECCENTRIC MT923 €5.16
42
 Screw M 4x12 for Cordless Drill Makita 6830 - 6831DWA 912117-6 Screw M 4x12 for Cordless Drill Makita 6830 - 6831DWA €1.32
43
 Pad Plate for Orbital Sander Maktec MT923 140441-9 Pad Plate for Orbital Sander Maktec MT923 €6.00
44
 photo_cameraImage coming soon 266427-6 SCREW 4X12 MT923 €1.32

Shipping and delivery information will be available shortly.

Makita Spare Parts for Finisching Sander M9203 180w

Makita original replacement parts for to replace broken parts for to fix Finishing Sander M9203 180w

In the following table, look for the model of the Drill and the respective parts of the code.
Finishing Sander M9203

Makita Finishing Sander M9203
# Part Num. Description
1 265995-6 SCREW M4X18
2 451927-1 TOP COVER MT923
3 263002-9 RUBBER PIN 4
4 194968-1 CARBON BRUSHES CB-64(56,57)
5 643552-4 BRUSH HOLDER
6 654532-5 CONNECTOR 1P
7 424086-4 SWITCH COVER MT923
8 651527-9 SWITCH FOR BO4555
9 645228-9 CAPACITOR MT924
10 265995-6 SCREW M4X18
11 687124-5 STRAIN RELIEF MT953
12 665383-1 xxxxxx
13 682502-4 CABLE SLEEVE 8/85 6408
14 456555-7 MOTOR HOUSING
15 852B68-2 xxxxxx
16 593739-7 STATOR MT923
17 266560-4 SCREW 4X40 HS300D
18 210062-2 BEARING 607ZZ X MT601
19 681670-0 INSULATING WASHER
20 515799-9 ARMATURE MT923
21 253180-3 FLAT WASHER 10 X 6221DW
22 211087-9 BALL BEARING 6200DDW NSK
23 451928-9 BEARING BOX MT923
24 265995-6 SCREW M4X18
25 253180-3 FLAT WASHER 10 X 6221DW
26 241677-4 FAN 68 MT923
27 213983-7 O RING 4 BO4555
28 318151-8 FOOT BO4555
29 424023-8 DUST PROOF BUSH BO4555
30 213983-7 O RING 4 BO4555
31 266427-6 SCREW 4X12 MT923
32 324873-0 CLAMP LEVER MT923
33 267239-0 WASHER 7 MT923
34 451930-2 DUST NOZZLE MT923
35 213315-8 O RING 19 X BO3700
36 265995-6 SCREW M4X18
37 423470-0 SPONGE RING MT923
38 451929-7 BASE MT923
39 213656-2 O RING 53 X HM1200
40 211228-7 BALL BEARING 6202DD
41 318622-5 CAM MT923
42 912117-6 SCREW M4X12
43 140441-9 PAD
44 266427-6 SCREW 4X12 MT923
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita M9203

Data sheet

Machine Type
Sander

Specific References

New

Download

Makita M9203 Drawing

Makita M9203 Drawing

Download (503.92KB)
