Makita Spare Parts for Belt Sander 9920

SKU: Makita 9920
€0.12
VAT included

Makita Spare Parts for Belt Sander 9920

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Belt Sander 9920.

Makita Spare Parts for Belt Sander 9920
  • New
  • Out-of-Stock
  • Makita Spare Parts for Belt Sander 9920
  • Makita 9920 Drawing
Makita

Makita Spare Parts for Belt Sander 9920

SKU: Makita 9920 Condition: New
€0.12
VAT included

Makita Spare Parts for Belt Sander 9920

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Belt Sander 9920.

settings 74 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Sander
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
74 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
A01
 photo_cameraImage coming soon 122591-2 DUST BAG €16.56
F17-1
 photo_cameraImage coming soon 193055-3 BELT SANDER STAND €103.55
C10
 photo_cameraImage coming soon 212043-2 BALL BEARING TLA810Z HR201 €6.70
C21
 photo_cameraImage coming soon 214101-0 BEARING 12 €3.11
C20
 photo_cameraImage coming soon 214116-7 SPONGE SHEET 30-47 €2.50
C10
 photo_cameraImage coming soon 214116-7 SPONGE SHEET 30-47 €2.50
C10
 photo_cameraImage coming soon 226519-3 PLANE BEARING 12 €12.22
E02
 photo_cameraImage coming soon 344848-3 STRAP WASHER €1.32
C10
 photo_cameraImage coming soon 410602-8 FASTENER €2.65
C20
 photo_cameraImage coming soon 413012-8 SPONGE SHEET 30-47 €1.24
C10
 photo_cameraImage coming soon 453974-8 Makita Latch €5.89
C10
 photo_cameraImage coming soon 643708-9 BRUSH HOLDER 5X11 GA5020/ €3.70
E03
 photo_cameraImage coming soon 645105-5 NOISE SUPPRESSOR/CONDENSOR 64 €4.87
C10
 photo_cameraImage coming soon 654020-2 RING TERMINAL 94 €1.32
C21
 photo_cameraImage coming soon 654501-6 CONNECTOR P-1.25 €1.32
C20
 photo_cameraImage coming soon 654502-4 CONNECTOR P-2 €1.32
A03
 photo_cameraImage coming soon 821551-8 CONNECTOR PLASTIC CASE (TYPE3) €56.50
A06
 photo_cameraImage coming soon 837877-8 INNER TRAY €10.88
1
 photo_cameraImage coming soon 651284-9 SWITCH SGEL115CDY-6 €12.22
2
 photo_cameraImage coming soon 151743-8 MOTOR HOUSING COMPL. 9920 €57.57
3
 photo_cameraImage coming soon 654532-5 TERMINAL BLOCK 6E / 1DS €1.32
4
 photo_cameraImage coming soon 417049-7 FRONT HANDLE HT2256D €7.67
5
 photo_cameraImage coming soon 266173-1 SCREW PT 5X30 €1.32
6D
 photo_cameraImage coming soon 665890-4 POWER SUPPLY CORD 1.0-2-4.0 €22.06
8A
 photo_cameraImage coming soon 687052-4 CLAMP cable clamp X 6408 €1.92
9
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
10
 photo_cameraImage coming soon 211088-7 BALL BEARING 6000-9527PB 9528PB €7.67
11
 photo_cameraImage coming soon 681649-1 INSULATING WASHER 9403 €1.32
12B
 photo_cameraImage coming soon 523404-4 STATOR 220 X 9920 €46.06
13
 photo_cameraImage coming soon 266056-5 SCREW M 5 X 45 X JR3060T €2.65
14-1
 photo_cameraImage coming soon 643515-0 Holder cap 7-11 €1.21
14
 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C 643750-0 Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C €2.03
15
 Carbon Brushes CB-303 for Belt Sander Makita 9920X 191963-2 Carbon Brushes CB-303 for Belt Sander Makita 9920X €8.30
16B
 photo_cameraImage coming soon 513339-7 ARMATURE 9920 €105.80
17
 photo_cameraImage coming soon 417050-2 VANE X 9920 €3.11
18
 photo_cameraImage coming soon 240026-2 FAN X 9920 €3.83
19
 photo_cameraImage coming soon 210023-2 9910/11 BEARING €4.87
20
 Motor Cover for Belt Sander MAKITA 9920X 417048-9 Motor Cover for Belt Sander MAKITA 9920X €17.02
22
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
23
 photo_cameraImage coming soon 417051-0 COVER HANDLE X 9920 €6.32
24
 photo_cameraImage coming soon 417052-8 COVER BELT X 9920 €5.16
25
 photo_cameraImage coming soon 252153-3 HEX NUT 9910/11 €1.32
26
 Drive Belt for Belt Sander MAKITA 9920X 225084-9 Drive Belt for Belt Sander MAKITA 9920X €6.70
27
 Fan with Gear for Belt Sander MAKITA 9920X 241663-5 Fan with Gear for Belt Sander MAKITA 9920X €22.06
28
 photo_cameraImage coming soon 251815-0 KNOB SCREW M6 €1.92
29
 photo_cameraImage coming soon 253707-9 WASHER P.16 99B / 6000R / 8410B €1.32
30
 photo_cameraImage coming soon 231225-7 SPRING 16 99 B / 9924DB €10.85
30-1
 photo_cameraImage coming soon 232573-7 COMP. SPRING 16, 9900B €1.32
31
 photo_cameraImage coming soon 266050-7 SCREW 4X30 PT €1.32
32
 photo_cameraImage coming soon 931402-8 NUT M8 €1.32
33
 photo_cameraImage coming soon 222156-1 PULLEY X 9920 €12.96
34
 photo_cameraImage coming soon 317273-1 COVER GEAR 9920 €10.64
35
 Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €8.63
35-2
 Bearing 629DD FOR Angle Grinder Makita GA4530 211092-6 Bearing 629DD FOR Angle Grinder Makita GA4530 €8.63
36
 photo_cameraImage coming soon 226520-8 GEAR TWISTED X 9920 €12.96
37
 photo_cameraImage coming soon 151755-1 GEAR TWISTED X 9920 €24.95
39
 photo_cameraImage coming soon 151747-0 FRAME COMPLETE X 9920 €129.54
40
 photo_cameraImage coming soon 211088-7 BALL BEARING 6000-9527PB 9528PB €7.67
41
 photo_cameraImage coming soon 162217-4 REAR ROLLER 9920 €24.95
42
 photo_cameraImage coming soon 252154-1 NUT ESAG. 9910/11 €1.32
43
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.32
44
 photo_cameraImage coming soon 323931-9 SHAFT ROLL ANT. X 9920 €5.16
45
 photo_cameraImage coming soon 253922-5 WASHER 12 9401/02 / 99B €2.03
46
 photo_cameraImage coming soon 151753-5 SHAFT ROLL ANT. CPL. X 9920 €29.04
47
 photo_cameraImage coming soon 344823-9 LEVER X 9920 €3.83
48
 photo_cameraImage coming soon 267731-6 WASHER X 9910/11 €1.32
49
 photo_cameraImage coming soon 265059-6 SCREW 9910/11 €2.03
50
 photo_cameraImage coming soon 416417-1 WHEEL X 9910/11 €12.03
51
 photo_cameraImage coming soon 233249-9 SPRING COMPRESSION 7 X 9920 €1.32
52
 photo_cameraImage coming soon 151744-6 ARM ROLLER X ANT. X 9920 €17.02
53
 photo_cameraImage coming soon 267746-3 SOCKET X 9920 €2.65
54
 photo_cameraImage coming soon 233250-4 SPRING OF COMPRESSION 12 X9920 €1.32
55
 photo_cameraImage coming soon 266034-5 SCREW CT 4X16 €1.32
56
 photo_cameraImage coming soon 344822-1 PROTECTION COVER X 9920 €10.07
57
 photo_cameraImage coming soon 911116-5 SCREW M4X12 X AM4024LG €1.32
60A
 photo_cameraImage coming soon 631380-9 CONTROL X 9920 €51.58
64
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
65
 photo_cameraImage coming soon 266034-5 SCREW CT 4X16 €1.32
66
 photo_cameraImage coming soon 266034-5 SCREW CT 4X16 €1.32
67
 photo_cameraImage coming soon 266034-5 SCREW CT 4X16 €1.32
78
 Cord Guard JN1601 for Angle Grinder Makita 9015B 682540-6 Cord Guard JN1601 for Angle Grinder Makita 9015B €2.50
781
 Power Cord Guard 10/90 for for Makita Power Tools 682505-8 Power Cord Guard 10/90 for for Makita Power Tools €2.65

Shipping and delivery information will be available shortly.

Makita Spare Parts for Belt Sander 9920

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Belt Sander 9920.

In the following table, look for the model of the Belt Sander and the respective parts of the code.
Makita 9920

 Makita Belt Sander 9920
# Part Num. Description
1 651284-9 SWITCH SGEL115CDY-6
2 151743-8 MOTOR HOUSING COMPLETE
C10 643708-9 BRUSH HOLDER 5-11
3 654532-5 TERMINAL BLOCK 1P
4 417049-7 FRONT GRIP
5 266173-1 TAPPING SCREW 5X30
6D 665890-4 POWER SUPPLY CORD 1.0-2-4.0
78 682540-6 CORD GUARD 9.3-90
781 682505-8 CORD GUARD 10-90
8A 687052-4 STRAIN RELIEF
9 265995-6 TAPPING SCREW 4X18
10 211088-7 BALL BEARING 6000DDW
11 681649-1 INSULATION WASHER
12B 523404-4 FIELD ASS'Y 230-240V
C10 654020-2 RING TERMINAL
C20 654502-4 CONNECTOR P-2
C21 654501-6 CONNECTOR P-1.25
13 266056-5 TAPPING SCREW 5X45
14 643750-0 BRUSH HOLDER CAP 7-11
14-1 643515-0 HOLDER CAP 7-11
15 191963-2 CARBON BRUSH CB-303
16B 513339-7 ARMATURE ASS'Y 230-240V
D10 INC. 10,11,18,19
17 417050-2 BAFFLE PLATE
18 240026-2 FAN 75
19 210023-2 BALL BEARING 627DDW
20 417048-9 MOTOR COVER
21 819001-5 MAKITA LABEL
22 265995-6 TAPPING SCREW 4X18
23 417051-0 HANDLE COVER
24 417052-8 BELT COVER
25 252153-3 HEX. NUT M6-10
26 225084-9 SYNCHRO BELT 6-330
27 241663-5 FAN 76
28 251815-0 SCREW M6X25
29 253707-9 FLAT WASHER 16
30 231225-7 COMPRESSION SPRING 16
30-1 232573-7 COMPRESSION SPRING 16
31 266050-7 TAPPING SCREW 4X30
32 931402-8 HEX. NUT M8
33 222156-1 PULLEY 9.5-46.0
34 317273-1 GEAR COVER
35 211092-6 BALL BEARING 629DDW
35-1 210078-7 BALL BEARING 629DDW
35-2 211092-6 BALL BEARING 629DDW
36 226520-8 HELICAL GEAR 10
37 151755-1 HELICAL GEAR 39 COMPLETE
C10 226519-3 HELICAL GEAR 39
38 852053-3 NAME PLATE 9920
39 151747-0 FRAME COMPLETE
C10 212043-2 NEEDLE BEARING 810
C20 214116-7 PLANE BEARING 12
C21 214101-0 PLANE BEARING 12
C30 344828-9 PLATE
40 211088-7 BALL BEARING 6000DDW
41 162217-4 DRIVING ROLLER
42 252154-1 HEX. NUT M8-13
43 961052-5 RETAINING RING (EXT) S-12
44 323931-9 TENSION ROLLER SHAFT
45 253922-5 CUP WASHER 12
46 151753-5 TENSION ROLLER COMPLETE
C10 214116-7 PLANE BEARING 12
C20 413012-8 SPONGE SHEET 30-47
47 344823-9 LEVER
48 267731-6 CUP WASHER 4
49 265059-6 SHOULDER SCREW M4
50 416417-1 ROLLER
51 233249-9 COMPRESSION SPRING 7
52 151744-6 TENSION ROLLER ARM COMPLETE
53 267746-3 CUP WASHER 17
54 233250-4 COMPRESSION SPRING 12
55 266034-5 TAPPING SCREW CT 4X16
56 344822-1 SAFETY COVER
57 911116-5 PAN HEAD SCREW M4X12
60A 631380-9 CONTROLLER
61A1 193198-1 CARBON PLATE
64 265995-6 TAPPING SCREW 4X18
65 266034-5 TAPPING SCREW CT 4X16
66 266034-5 TAPPING SCREW CT 4X16
67 266034-5 TAPPING SCREW CT 4X16
A01 122591-2 DUST BAG ASS'Y
C10 410602-8 FASTENER
A02 794239-2 ABRASIVE BELT 76X610 WA80
A02-1 D-67169 ABRASIVEBELT WOOD 76X610
E01-1 193200-0 CORK RUBBER PLATE SET
E02 344848-3 STRAP WASHER
E03 645105-5 NOISE SUPPRESSOR
F17-1 193055-3 BELT SANDER STAND
A03 821551-8 CONNECTOR PLASTIC CASE (TYPE3)
C10 453974-8 LATCH
A04 803F05-3 9920J INDICATION LABEL
A05 803F06-1 9920J PLASTIC CASE LABEL
A06 837877-8 INNER TRAY
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita 9920

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
Machine Type
Sander
MORE INFO:
[email protected]

Specific References

New

Download

Makita 9920 Drawing

Makita 9920 Drawing

Download (665.74KB)

You might also like

Abrasive Belt Set Makita 76x475 mm
Einhell Italia s.r.l. SKU: Makita P-37166
Abrasive Belt Set Makita 76x475 mm
Abrasive Belt Set Makita 76x475 mm Makita 76x475 Abrasive Belt Set Sive: 76x457 mm - 1 grit 40 - 1 grit 80 - 1 grit 120 - Code: P-37166
AVAILABLE €8.77
Details
Abrasives Tapes for Sanding Belt mm 100x620
VARO-VIC.VAN ROMPUY SKU: KRT244003 - 004 - 005
Abrasives Tapes for Sanding Belt mm 100x620
Abrasives Tapes for Sanding Belt mm 100x620 Abrasive paper tape used for the levigaturabo color removal on large surfaces. - Packaging: 3 pcs - Available grits: gr. 40 - 60 - 80 - Code: KRT244003 - KRT244004 - KRT244005
AVAILABLE €9.36
Details
Abrasives Tapes for Sanding Belt mm 100x620
VARO-VIC.VAN ROMPUY SKU: KRT242003 - 004 - 005
Abrasives Tapes for Sanding Belt mm 75x533
Abrasives Tapes for Sanding Belt mm 75x533 Abrasive paper tape used for the levigaturabo color removal on large surfaces. - Packaging: 3 pcs - Available grits: gr. 40 - 60 - 80 - Code: KRT242003 - KRT242004 - KRT242005
AVAILABLE €8.89
Details
Abrasives Tapes for Sanding Belt mm 100x620
VARO-VIC.VAN ROMPUY SKU: KRT242503 - 504 - 505 - 507
Abrasives Tapes for Sanding Belt mm 100x560
Abrasives Tapes for Sanding Belt mm 100x560 Abrasive paper tape used for the levigaturabo color removal on large surfaces. - Packaging: 3 pcs - Available grits: gr. 40 - 60 - 80 - 120 - Code: KRT242503 - KRT242504 - KRT242505 -...
AVAILABLE €8.77
Details
Fan with Gear for Belt Sander MAKITA 9920X
Makita SKU: 241663-5
Fan with Gear for Belt Sander MAKITA 9920X
Fan with Gear for Belt Sander MAKITA 9920X Genuine replacement part  Makita, Fan with Belt Gear for Belt Sander MAKITA 9902 - 9903 - 9920X - 9404X. Parts for the following products: - 9404X - BELT SANDER 100X610MM - 9902 - BELT SANDER...
AVAILABLE €22.06
Details
Drive Belt for Belt Sander MAKITA 9920X
Makita SKU: 225084-9
Drive Belt for Belt Sander MAKITA 9920X
Drive Belt for Belt Sander MAKITA 9920X Genuine replacement part Makita, Drive Belt for Belt Sander MAKITA 9902 - 9903 - 9404X - 9920X. Parts for the following products: - 9404X - BELT SANDER 100X610MM - 9902...
AVAILABLE €6.70
Details
Bearing 629DD FOR Angle Grinder Makita GA4530
Makita SKU: 211092-6
Bearing 629DD FOR Angle Grinder Makita GA4530
Bearing 629DD FOR Angle Grinder Makita GA4530 Genuine part Makita, Ball Bearing 629DD for Angle Grinders GA4530 - GA4530R - GA4534 - GA5034 - GA9000 - 9541-9542. Parts for the following products: - GA4530 - ANGLE GRINDER 115MM -...
AVAILABLE €8.63
Details
Rubber Cork Board for Belt Sander MAKITA 9920X
Makita SKU: 423313-6
Rubber Cork Board for Belt Sander MAKITA 9920X
Rubber Cork Board for Belt Sander MAKITA 9920X Genuine parts Makita, Rubber Cork Board for Belt Sander MAKITA 9920X. Parts for the following products: -  Belt Sander MAKITA 9920X - Code: 423313-6
AVAILABLE €4.86
Details
Carbon Plate for Belt Sander MAKITA 9920X
Makita SKU: 423316-0
Carbon Plate for Belt Sander MAKITA 9920X
Carbon Plate for Belt Sander MAKITA 9920X Genuine parts Makita, Carbon Plate for Belt Sander MAKITA 9920X. Parts for the following products: -  Belt Sander MAKITA 9920X - Code: 423316-0
AVAILABLE €7.56
Details
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C
Makita SKU: 643750-0
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C
Carbon Brush Holder Cap for Hammer Makita HM1100 - HM1100C Genuine part MAKITA, Carbon Brush Holder Cap for Hammers HM1100 - HM1100C - Angle Grinder  GA6021C - GA6020 - Circular Saw 5703R. Parts for the following products: - 2107FK -...
AVAILABLE €2.03
Details
Motor Cover for Belt Sander MAKITA 9920X
Makita SKU: 417048-9
Motor Cover for Belt Sander MAKITA 9920X
Motor Cover for Belt Sander MAKITA 9920X Genuine replacement part  Makita, Motor Cover for Belt Sander MAKITA 9920X - 9404X. Part for the following products: - 9404X - BELT SANDER 100X610MM - 9920X - LBELT SANDER 76X610MM - Code:...
AVAILABLE €17.02
Details
Comments (0)
No customer reviews for the moment.
