Makita original spare parts for to replace broken parts for to fix Wall Chaser 125 mm Makita SG1250.
Fix Your Wall Chaser. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Makita original spare parts for to replace broken parts for to fix Wall Chaser 125 mm Makita SG1250.
Fix Your Wall Chaser. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Shipping and delivery information will be available shortly.
Makita original spare parts for to replace broken parts for to fix Wall Chaser 125 mm Makita SG1250.
Fix Your Wall Chaser. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Groover and the respective parts of the code.
| Makita SG1250 Wall Chaser | ||
| # | Part Num. | Description |
| 1 | 265995-6 | TAPPING SCREW 4X18 |
| 2 | 183692-1 | HANDLE SET |
| D10 | INC. 48 | |
| 3 | 265995-6 | TAPPING SCREW 4X18 |
| 4 | 911263-2 | PAN HEAD SCREW M5X40 |
| 5 | 687113-0 | COVER |
| 6 | 651418-4 | SWITCH ST115A-40 |
| 6-1 | 651418-4 | SWITCH ST115A-40 |
| 7 | 632945-0 | SWITCH BLOCK |
| 8 | 687052-4 | STRAIN RELIEF |
| 9 | 265995-6 | TAPPING SCREW 4X18 |
| 10 | 682566-8 | CORD GUARD 10 |
| 11 | 665883-1 | POWER SUPPLY CORD 1.0-2-5.0 |
| 12 | 413076-2 | BAFFLE PLATE |
| 13 | 259039-2 | SELF LOCK 6 |
| 14 | 688117-5 | MAGNET SLEEVE |
| 15 | 267756-0 | WAVE WASHER 6 |
| 16 | 421738-8 | LABYRINTH RUBBER RING 22 |
| 16-1 | 422750-1 | LABYRINTH RUBBER RING 22 |
| 17 | 626503-2 | FIELD 220-240V |
| 17-1 | 621C19-0 | FIELD 220-240V |
| 18 | 417237-6 | INSULATION COVER |
| 19 | 344871-8 | RETAINER |
| 20 | 266258-3 | TAPPING SCREW 4X70 |
| 21 | 210027-4 | BALL BEARING 627DDW |
| 22 | 253823-7 | FLAT WASHER 7 |
| 23 | 681656-4 | INSULATION WASHER |
| 24 | 515208-8 | ARMATURE ASS'Y 220-240V |
| D10 | INC. 21-23,25 | |
| 25 | 240033-5 | FAN 57 |
| 26 | 253084-9 | FLAT WASHER 12 |
| 27 | 317359-1 | GEAR HOUSING COVER |
| 28 | 211142-7 | BALL BEARING 6001LLB |
| 29 | 961052-5 | RETAINING RING (EXT) S-12 |
| 30 | 233901-9 | LOCK SPRING 12 |
| 31 | 253052-2 | FLAT WASHER 12 |
| 32 | 227429-7 | SPIRAL BEVEL GEAR 9 |
| 32-1 | 227A58-2 | SPIRAL BEVEL GEAR 9 |
| 33 | 253077-6 | FLAT WASHER 6 |
| 34 | 961002-0 | RETAINING RING S-6 |
| 35 | 417186-7 | SWITCH LEVER |
| 36 | 417813-6 | SWITCH KNOB |
| 37 | 819080-3 | MAKITA LABEL |
| 37-1 | 819080-3 | MAKITA LABEL |
| 38 | 183740-6 | MOTOR HOUSING |
| D10 | INC. 37 | |
| 38-1 | 418512-3 | MOTOR HOUSING |
| 38-2 | 183740-6 | MOTOR HOUSING |
| D10 | INC. 37 | |
| 39 | 643760-7 | BRUSH HOLDER |
| 40 | 266256-7 | TAPPING SCREW PT3X10 |
| 41 | 191978-9 | A.C. CARBON BRUSH CB-318 |
| 42 | 417183-3 | REAR COVER |
| 43 | 265995-6 | TAPPING SCREW 4X18 |
| 44 | 631492-8 | CONTROLLER |
| 45 | 643760-7 | BRUSH HOLDER |
| 46 | 266256-7 | TAPPING SCREW PT3X10 |
| 48 | 183692-1 | HANDLE SET |
| D10 | INC. 2 | |
| 49 | 233071-4 | COMPRESSION SPRING 4 |
| 50 | 224577-3 | LOCK NUT 14-45 |
| 51 | 331661-8 | SPACER 3 |
| 52 | 331662-6 | SPACER 6 |
| 53 | 257732-2 | SLEEVE 14 |
| 54 | 224298-7 | INNER FLANGE 42 |
| 54-1 | 224415-9 | INNER FLANGE 42 |
| 55 | 324393-4 | SPINDLE |
| 56 | 415300-9 | LABYRINTH RING |
| 57 | 265490-6 | HEX. SOCKET HEAD BOLT M4X16 |
| 58 | 317570-5 | BEARING BOX |
| 58-1 | 318302-3 | BEARING BOX |
| 59 | 213673-2 | O RING 52 |
| 60 | 211129-9 | BALL BEARING 6201DDW |
| 61 | 285841-7 | BEARING RETAINER |
| 62 | 227430-2 | SPIRAL BEVEL GEAR 35 |
| 62-1 | 227A59-0 | SPIRAL BEVEL GEAR 35 |
| 63 | 256459-1 | PIN |
| 64 | 213048-5 | O RING 6 |
| 65 | 153381-2 | GEAR HOUSING COMPLETE |
| 65-1 | 153718-3 | GEAR HOUSING COMPLETE |
| 65-2 | 153488-4 | GEAR HOUSING COMPLETE |
| 66 | 233072-2 | COMPRESSION SPRING 8 |
| 67 | 417236-8 | PIN CAP |
| 67-1 | 418067-8 | PIN CAP |
| 68 | 266257-5 | TAPPING SCREW 4X28 |
| 69 | 961011-9 | STOP RING E-4 |
| 70 | 257227-5 | RING 6 |
| 71 | 961014-3 | STOP RING E-8 |
| 72 | 153685-2 | BLADE CASE COMPLETE |
| C10 | 816397-5 | SCALE LABEL |
| 73 | 324392-6 | SHOULDER SHAFT |
| 74 | 231655-2 | TORSION SPRING 11 |
| 75 | 266040-0 | TAPPING SCREW CT 4X25 |
| 76 | 418390-1 | DUST COVER |
| 77 | 850945-0 | NAME PLATE SG1250 |
| 78 | 416741-2 | ELBOW |
| 79 | 213423-5 | O RING 30 |
| 80 | 183718-9 | COVER |
| D10 | INC. 83 | |
| 81 | 922466-3 | HEX.SOCKET HEAD BOLT M8X45 |
| 82 | 961006-2 | RETAINING RING S-10 |
| 83 | 819064-1 | MAKITA MARK |
| 84 | 317723-6 | BASE |
| 85 | 922487-5 | HEX. SOCKET HEAD BOLT M8X65 |
| 86 | 941201-0 | FLAT WASHER 8 |
| 87 | 223145-9 | CAM |
| 88 | 417665-5 | FRONT GRIP |
| 90 | 252185-0 | SQUARE NUT M6 |
| 91 | 344391-2 | BIT HOLDER |
| 92 | 922251-4 | HEX. SOCKET HEAD BOLT M5X30 |
| 93 | 941201-0 | FLAT WASHER 8 |
| 94 | 922462-1 | HEX. SOCKET HEAD BOLT M8X40 |
| 95 | 345364-8 | INDICATOR |
| 96 | 942151-2 | SPRING WASHER 6 |
| 97 | 257731-4 | SLEEVE 7 |
| 98 | 251897-2 | SCREW M6X33 |
| 99 | 253310-6 | THIN WASHER 10 |
| 100 | 267783-7 | WAVE WASHER 10 |
| 101 | 253310-6 | THIN WASHER 10 |
| A01 | A-80438 | D.WHEEL 125X22.23 |
| A02 | 782407-9 | LOCK NUT WRENCH 35 |
| A03 | 783204-6 | HEX. WRENCH 6 |
| A04 | 824709-8 | PLASTIC CARRYING CASE |
| C10 | 417059-4 | LATCH |
| C20 | 819143-5 | MAKITA LABEL |
| C30 | 418889-6 | HANDLE |
| A04-1 | 824709-8 | PLASTIC CARRYING CASE |
| C10 | 163455-1 | LATCH |
| C20 | 419360-3 | HANDLE |
