Makita

Makita Spare Parts for Bench Grinder GB801

SKU: Makita GB801
€70.08
VAT included

Makita Spare Parts for Bench Grinder GB801

Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair problems for Bench Grinder GB801.
Makita Spare Parts for Bench Grinder GB
  • Makita Spare Parts for Bench Grinder GB
  • Makita Spare Parts for Bench Grinder GB
Makita

Makita Spare Parts for Bench Grinder GB801

SKU: Makita GB801 Condition: New
€70.08
VAT included

Makita Spare Parts for Bench Grinder GB801

Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair problems for Bench Grinder GB801.
settings 36 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
36 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
3
 photo_cameraImage coming soon AL00000057 GRINDSTONE COVER CAP SX GB801 €14.80
5
 photo_cameraImage coming soon AL00000182 FLANGE INTERNAL GB801 €2.19
6
 photo_cameraImage coming soon A-47260 GRINDSTONE 205X19X15.88 GR 60 GB801 €39.39
9
 photo_cameraImage coming soon AL00000064 HEADSET GRINDSTONE SX GB801 €27.73
12
 photo_cameraImage coming soon AL00000008 COVER BASE LAMP GB602 €2.80
18
 photo_cameraImage coming soon AL00000011 COVER BULB GB602 €2.29
19
 photo_cameraImage coming soon AL00000012 LAMP GB602 €5.47
21
 photo_cameraImage coming soon AL00000066 PARA SPARKS SX GB801 €1.88
22
 photo_cameraImage coming soon AL00000016 LENS FOR GB602 €3.71
23
 photo_cameraImage coming soon AL00000015 SUPPORT FOR LENS SX GB602 €2.29
28
 photo_cameraImage coming soon AL00000067 HOLDER LEFT GB801 €2.67
31
 photo_cameraImage coming soon AL00000074 COVER SX GB801 €22.46
33
 photo_cameraImage coming soon AL00000101 BEARING 180204 GB801 €4.58
35
 photo_cameraImage coming soon AL00000171 POWER CABLE GB801 €5.22
38
 photo_cameraImage coming soon AL00000184 HOUSING MOTOR GB801 €7.62
40
 photo_cameraImage coming soon AL00000190 STATOR GB801 €116.02
41
 photo_cameraImage coming soon AL00000191 ARMATURE GB801 €24.54
43
 photo_cameraImage coming soon AL00000069 COVER DX GB801 €22.46
49
 photo_cameraImage coming soon AL00000099 CAPACITOR GB801 €14.80
50
 photo_cameraImage coming soon AL00000141 SWITCH GB602 €5.47
57
 photo_cameraImage coming soon AL00000081 PLATE FOR BATH GB801 €2.67
58
 photo_cameraImage coming soon AL00000080 TRAY X REFRIGERANT GB801 €2.19
59
 photo_cameraImage coming soon AL00000038 HOLDER LENS DX GB602 €2.29
60
 photo_cameraImage coming soon AL00000037 LENS FOR GB602 €3.71
61
 photo_cameraImage coming soon AL00000079 PARA SPARKS DX GB801 €1.88
62
 photo_cameraImage coming soon AL00000085 HOLDER DX GB801 €2.67
63
 photo_cameraImage coming soon AL00000084 HEADSET GRINDSTONE GB801 €27.73
64
 photo_cameraImage coming soon A-47254 GRINDSTONE 205X19X15.88 GR120 GB801 €47.35
66
 photo_cameraImage coming soon AL00000077 GRINDSTONE COVER DX GB801 €14.80
67
 photo_cameraImage coming soon AL00000192 PLATE POWER CABLE €10.34
68
 photo_cameraImage coming soon AL00000076 BASE GB801 €16.72
69
 photo_cameraImage coming soon AL00000062 EXTERNAL FLANGE GB801 €2.19
75
 photo_cameraImage coming soon AL00000087 ALLEN WRENCH The GB801 €1.88
76
 photo_cameraImage coming soon AL00000086 ALLEN WRENCH II GB801 €2.19
80
 photo_cameraImage coming soon AL00000180 CLAMP CABLE GB801 €1.88
81
 photo_cameraImage coming soon AL00000181 FLANGE GB801 €1.88

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Bench Grinder GB801

Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair problems for Bench Grinder GB801.

In the following table, look for the model of the Bench Grinder and the respective parts of the code.
Makita GB801
Bench Grinder GB801
# Part Num. Description
1 AL00000144 SCREW M5X51 GB801
2 AL00000107 SCREW M5X55 GB801
3 AL00000057 GRINDSTONE COVER CAP SX GB801
4 AL00000058 NUT M16 SX GB801
5 AL00000182 FLANGE INTERNAL GB801
6 A-47260 GRINDSTONE 205X19X15.88 GR 60 GB801
7 AL00000111 M5x12 screw GB801
8 AL00000132 WASHER 5 GB602
9 AL00000064 HEADSET GRINDSTONE SX GB801
10 AL00000114 SCREW M4X6 GB602
11 AL00000065 STOPS CABLE GB801
12 AL00000008 COVER BASE LAMP GB602
13 AL00000009 NUT GB602
14 AL00000013 BULB GB602
15 AL00000010 CLAMP CABLE GB602
16 AL00000104 SCREW M4X10 GB602
17 AL00000105 SCREW M4x30 GB602
18 AL00000011 COVER BULB GB602
19 AL00000012 LAMP GB602
20 AL00000121 NUT M5 GB602
21 AL00000066 PARA SPARKS SX GB801
22 AL00000016 LENS FOR GB602
23 AL00000015 HOLDER FOR LENS SX GB602
24 AL00000127 WASHER 6 GB602
25 AL00000133 SPRING WASHER 6 GB602
26 AL00000119 SCREW M6x30 GB801
27 AL00000014 KNOB GB602
28 AL00000067 HOLDER LEFT GB801
29 AL00000128 WASHER 8 GB602
30 AL00000118 SCREW M8x10 GB602
31 AL00000074 COVER SX GB801
32 AL00000073 CORRUGATED WASHER GB801
33 AL00000101 BEARING 180204 GB801
34 AL00000026 STOPS CABLE GB602
35 AL00000171 POWER CABLE GB801
36 AL00000103 SCREW M4X8 GB602
37 AL00000131 SPRING WASHER GB602
38 AL00000184 HOUSING MOTOR GB801
39 AL00000022 COMPASS GB602
40 AL00000190 STATOR GB801
41 AL00000191 ARMATURE GB801
42 AL00000135 PIN 3X8 GB602
43 AL00000069 COVER DX GB801
44 AL00000126 WASHER 5 GB602
45 AL00000068 SCREW M5X142 GB801
46 AL00000146 WASHER 4 GB602
47 AL00000122 Dad0 M8 GB602
48 AL00000029 HOLDER X CAPACITOR GB602
49 AL00000099 CAPACITOR GB801
50 AL00000141 SWITCH GB602
51 AL00000031 CIRCUIT BREAKER GB602
52 AL00000120 NUT M4 GB602
53 AL00000134 WASHER 4 GB602
54 AL00000112 SCREW M5X45 GB801
55 AL00000130 WASHER 5 GB801
56 AL00000083 FOOT RUBBER GB801
57 AL00000081 PLATE FOR BATH GB801
58 AL00000080 TRAY X REFRIGERANT GB801
59 AL00000038 HOLDER LENS DX GB602
60 AL00000037 LENS FOR GB602
61 AL00000079 PARA SPARKS DX GB801
62 AL00000085 HOLDER DX GB801
63 AL00000084 HEADSET GRINDSTONE GB801
64 A-47254 GRINDSTONE 205X19X15.88 GR120 GB801
65 AL00000078 NUT M16 GB801
66 AL00000077 GRINDSTONE COVER DX GB801
67 AL00000192 PLATE POWER CABLE
68 AL00000076 BASE GB801
69 AL00000062 EXTERNAL FLANGE GB801
73 AL00000115 SCREW M5x10 GB602
74 AL00000108 SCREW M4X8 GB602
75 AL00000087 ALLEN WRENCH The GB801
76 AL00000086 ALLEN WRENCH II GB801
80 AL00000180 CLAMP CABLE GB801
81 AL00000181 FLANGE GB801
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita GB801
12 Items

Specific References

New

Download

Diagram Makita GB801

Diagram Makita GB801

Download (271.2KB)
