Makita Spare Parts for Hammer HR5000K
Fix Your Hammer HR5000K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Hammer and the respective parts of the code.
| Hammer HR5000K |
| # |
Part Num. |
Description |
| 1 |
254231-5 |
KEY 4 |
| 2 |
316068-9 |
BARREL X HR5000K |
| 3 |
213707-1 |
GASKET 65 X HR1800 |
| 4 |
214653-1 |
PLANE BEARING 52 X HR5000K |
| 5 |
267044-5 |
FLAT WASHER 52 HR5000K |
| 6 |
221380-3 |
GEAR 41 HR5000K |
| 7 |
323751-1 |
STRIKER HR5000 |
| 8 |
213481-1 |
O-RING 32 X HR5000 |
| 10 |
213481-1 |
O-RING 32 X HR5000 |
| 12 |
256120-0 |
PIN 10 |
| 13 |
323750-3 |
PISTON X HR5000 |
| 14 |
414218-1 |
CRANK CAP HM1200 |
| 15 |
213754-2 |
GASKET 71 X HM1200 |
| 16 |
315419-3 |
ROD X HM1200 |
| 17 |
212208-6 |
NEEDLE BEARING 1516 |
| 18 |
153176-3 |
CRANK SHAFT COMPLETE HR5000K |
| 19 |
254001-2 |
KEY 4 |
| 20 |
254001-2 |
KEY 4 |
| 21 |
962251-2 |
RING R52 |
| 22 |
211327-5 |
BALL BEARING HM1202C |
| 23 |
213656-2 |
GASKET 53 X HM1200 |
| 24 |
157868-6 |
CRANK HOUSING COMPLETE HR5000K |
| 25 |
221761-1 |
GEAR 41 X HR5000K |
| 26 |
221957-4 |
GEAR 24 HR5000K |
| 27 |
212113-7 |
NEEDLE BEARING 1212 |
| 28 |
263005-3 |
RUBBER PIN 6 |
| 29 |
421690-0 |
GASKET 113 HR5000K |
| 30 |
157867-8 |
GEAR HOUSING HR5000K |
| 31 |
253787-5 |
WASHER 16 X HR5000K |
| 32 |
210004-6 |
BALL BEARING 638 |
| 33 |
253865-1 |
WASHER 8 HR5000K / HR3850 |
| 34 |
231446-1 |
SPRING 12 X HR5000K |
| 35 |
150009-3 |
GEAR HR5000K |
| 36 |
253310-6 |
WASHER 10 56DW / HR3850B |
| 37 |
153174-7 |
GEAR X HR5000K |
| 38 |
212359-5 |
NEEDLE BEARING 2216 |
| 39 |
212011-5 |
NEEDLE BEARING 609 |
| 40 |
961011-9 |
STOP RING E4 |
| 41 |
213055-8 |
GASKET 10 XHR3850 / B |
| 42 |
322187-1 |
CHANGE SHAFT X HR5000K |
| 43 |
342786-3 |
PLATE X HR3850 / B |
| 44 |
216002-8 |
BALL BEARING 4.8 |
| 45 |
231317-2 |
SPRING 3 X HR3850 / B |
| 46 |
410331-3 |
CHANGE LEVER HR3850 / B |
| 47 |
941052-1 |
FLAT WASHER 4 |
| 48 |
922126-7 |
SCREW M4X16 HR5000K / 3850B |
| 49 |
942101-7 |
SPRING WASHER 5 |
| 50 |
922212-4 |
SCREW M5X12 |
| 51 |
322157-0 |
IMPACT BOLT X HR5000K |
| 52 |
267043-7 |
FLAT WASHER 43 HR5000K |
| 53 |
211469-5 |
BALL BEARING 6907 |
| 54 |
252119-3 |
NUT M34.8-41 HR5000K |
| 55 |
213471-4 |
GASKET 31.5 HR5000K |
| 56 |
213419-6 |
GASKET 30 HR5000K |
| 57 |
213663-5 |
GASKET 55 X HR5000K |
| 58 |
331132-5 |
PIN X HR5000K |
| 59 |
322861-1 |
TOOL HOLDER HR5000K |
| 60 |
231281-7 |
SPRING 15 NEW HM1300 |
| 62 |
252046-4 |
HEXAGON NUT M8 XHM1300 |
| 63 |
922451-6 |
BOLT M8X30 |
| 64 |
152396-6 |
CYLINDER LINER 40 X HR5000K |
| 65 |
213459-4 |
GASKET 32 X HR3850B |
| 66 |
211129-9 |
BALL BEARING 6201DD NSK |
| 67 |
213160-1 |
OIL SEAL 14 XHR3850 / B |
| 68 |
241634-2 |
FAN 94 X HR3850 / B |
| 69 |
514888-7 |
ARMATURE X HR5000K |
| 70 |
681646-7 |
INSULATION RING HM1200 / 3612BR |
| 71 |
211087-9 |
BALL BEARING 6200DDW NSK |
| 72 |
213406-5 |
GASKET 30 58NB / SB / HM1200 |
| 73 |
911280-2 |
SCREW M5X55 |
| 75 |
524833-4 |
STATOR X HR5000K |
| 78 |
159054-5 |
MOTOR HOUSING HR5000K |
| 79 |
643650-4 |
BRUSH HOLDER CAP |
| 80 |
181048-2 |
CARBON BRUSH CB-155 (CB-161) |
| 81 |
284055-5 |
REAR COVER HM1200 / HR3850 |
| 83 |
922221-3 |
SCREW M5X16 X HM1303 |
| 84 |
922376-4 |
SCREW M6X55 |
| 85 |
941151-9 |
WASHER 6 X HM1303 |
| 87 |
416061-4 |
HANDLE X HR5000 / K |
| 88 |
151768-2 |
HOLDER CPL HR5000 |
| 89 |
265439-6 |
SCREW M8X150 X HM1100C |
| 90 |
252640-2 |
GRIP KNOB M8 X |
| 94 |
922316-2 |
BOLT M6 X 14 |
| 96 |
343754-9 |
PLATE XHR3850 / HR5000K |
| 97 |
922341-3 |
SCREW M6X25 |
| 99 |
421265-5 |
DUST COVER HR3850 / B |
| 100 |
911126-2 |
SCREW M4X16 |
| 101 |
651145-3 |
SWITCH C3D-H-MS |
| 102 |
931301-4 |
HEXAGON NUT M6 |
| 103 |
942151-2 |
WASHER 6 4101R |
| 104 |
941151-9 |
WASHER 6 X HM1303 |
| 105 |
263002-9 |
RUBBER PIN 4 |
| 107 |
685725-3 |
SPONGE X UH3000 |
| 108 |
263002-9 |
RUBBER PIN 4 |
| 109 |
321210-9 |
HANDLE PIN HR3850 / B |
| 110 |
182077-8 |
HANDLE CPL XHM1200 / K |
| 111 |
682505-8 |
CORD GUARD 10/90 |
| 113 |
687001-1 |
CABLE CLAMP |
| 114 |
911133-5 |
SCREW M4X18 |
| 116 |
911243-8 |
SCREW M5X25 HR2010 |
| 117 |
262051-3 |
RUBBER RING 9-6 XHR3850 |
| 118 |
262052-1 |
RUBBER RING 9-3 XHR3850 |
| 119 |
257636-8 |
SLEEVE X HR3850 |
| 120 |
134887-9 |
HANDLE TYPE NEW HR5000 |
| 121 |
134499-8 |
CLUTCH CPL HR5000K |
| 122 |
654020-2 |
TERMINAL RING 94 |
| 999 |
193285-6 |
SERVICE KIT HR5000K |
