We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Cordless Rotary Hammer Drill DHR164Z.
In the following table, look for the model of the Cordless Rotary Hammer Drill and the respective parts of the code.
| Cordless Rotary Hammer Drill DHR164Z | ||
| # | Part Num. | Description |
| 1 | 286263-4 | CAP 35 X HR2020 |
| 2 | 233940-9 | SPRING RING 19 FOR HR2432 |
| 3 | 419220-9 | CHUCK COVER X HR1830 |
| 4 | 257241-1 | RING 21 X HR2020 |
| 5 | 345187-4 | GUIDE WASHER X HR2020 |
| 6 | 233916-6 | SPRING 21-29 X HR2020 |
| 7 | 921923-8 | SCREW M 8 X 120 X HR2020 |
| 8 | 417911-6 | BASE HANDLE X HR1830 |
| 9 | 158057-6 | HANDLE 36 CPL HR2230 |
| 10 | 266048-4 | SCREW M 4 X 40 X 4334D |
| 11 | 162242-5 | CPL CHANGE LEVER X HR1830 |
| 12 | 233459-8 | COMPRESSION SPRING 3 HR1830 |
| 13 | 455413-4 | BUTTON |
| 14 | 213278-8 | RING 13 X HR2020 |
| 15 | 213535-4 | OIL SEAL 25 |
| 16 | 211375-4 | BALL BEARING 6805LLB 6221D |
| 17 | 211012-0 | BEARING X 9524NB |
| 18 | 154840-9 | GEAR BOX HR1830 |
| 19 | 961135-1 | RING RING W25 |
| 20 | 267304-5 | WASHER 25 HR1830 |
| 21 | 233457-2 | COMPRESSION SPRING 25 HR1830 |
| 22 | 331707-0 | GEAR 46 HR1830 |
| 26 | 154843-3 | TOOL HOLDER HR1830 |
| 27 | 216022-2 | BAL 7 |
| 28 | 213183-9 | RING 13 HR1830 |
| 29 | 324611-0 | IMPACT BOLT HR1830 |
| 30 | 257275-4 | RING 11 HR1830 |
| 31 | 233942-5 | SPRING RING 22 |
| 32 | 267175-0 | FLAT WASHER 24 6914DW |
| 33 | 345681-6 | FLANGE HR1830 |
| 34 | 324613-6 | STRIKER X HR1830 |
| 35 | 213182-1 | RING 14 X HR1830 |
| 36 | 331708-8 | PISTON HR1830 |
| 37 | 267130-2 | SPRING WASHER 9 HR2410 |
| 38 | 324612-8 | PISTON PIN X HR1830 |
| 39 | 267130-2 | SPRING WASHER 9 HR2410 |
| 40 | 227152-4 | GEAR 10 HR1830 |
| 41 | 331706-2 | CLUTCH CAM HR1830 |
| 42 | 219019-0 | SWASH BEARING 9 HR1830 |
| 43 | 226623-8 | GEAR 22 FOR BHR162 |
| 44 | 423346-1 | SEAL RING X HR1830 |
| 45 | 233458-0 | COMPRESSION SPRING 32 HR1830 |
| 46 | 268147-8 | PIN 4 HR1830 |
| 47 | 443123-5 | FELT 4X3 FOR HR1830 |
| 48 | 345645-0 | CHANGE PLATE HR1830 |
| 49 | 233460-3 | COMPRESSION SPRING 3 HR1830 |
| 50 | 345654-9 | STOPPER PLATE FOR HR1830 |
| 51 | 211012-0 | BEARING X 9524NB |
| 52 | 154841-7 | INNER HOUSING X HR1830 |
| 53 | 213953-6 | RING 24 HR2430 |
| 54 | 619182-3 | ARMATURE FOR BHP162 |
| 55 | 911011-9 | SCREW M3X10 |
| 57 | 638446-6 | YOKE UNIT BHR162 |
| 58 | 632D97-1 | BRUSH HOLDER |
| 59 | 419457-8 | CHANGE LEVER FOR BHR162 |
| 61 | 424128-4 | COVER CAP FOR BHR202R |
| 63 | 643929-3 | CAP BRUSH X 6213 / 6203DW |
| 64 | 191971-3 | CARBON BRUSH CB-430 |
| 65 | 632D93-9 | SWITCH |
| 67 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 68 | 183A24-8 | HOUSING |
| 69 | 620366-8 | LIGHT CIRCUIT |
| 71 | 643867-9 | BATTERY TERMINAL BJR141 |
| 72 | 689098-6 | HEAT SINK X 6503D |
