Makita

Makita Spare Parts for Metal Shear JS1601

SKU: Makita JS1601
€79.10
VAT included

Makita Spare Parts for Metal Shear JS1601

Makita genuine spare parts or replacements parts for to fix Makita JS1601 Metal Shear.
Makita Spare Parts for Blechschere JS1601
  • Makita Spare Parts for Blechschere JS1601
  • Makita Spare Parts for Blechschere JS1601
Makita

Makita Spare Parts for Metal Shear JS1601

SKU: Makita JS1601 Condition: New
€79.10
VAT included

Makita Spare Parts for Metal Shear JS1601

Makita genuine spare parts or replacements parts for to fix Makita JS1601 Metal Shear.
settings 60 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
51 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
Pos. Item Price Buy
1
 photo_cameraImage coming soon 266091-3 SPECIAL SCREW 4 X 50 €1.32
2
 photo_cameraImage coming soon 922147-9 SCREW M4x25 €1.36
3
 photo_cameraImage coming soon 961011-9 RETAINING RING E4 €1.44
4
 photo_cameraImage coming soon 346131-4 PLATE SLIDE DX X JS1000 €2.06
5
 photo_cameraImage coming soon 343480-0 SLIDE PLATE SX JS1660 €1.74
7
 photo_cameraImage coming soon 792533-6 BLADE SIDE JS1660 €44.52
9
 photo_cameraImage coming soon 251951-2 ALLEN SCREW M5x10 €1.36
10
 photo_cameraImage coming soon 261065-9 WASHER TEFLON 7XJS1650 €1.34
12
 photo_cameraImage coming soon 792534-4 BLADE CENTRAL JS1660 €64.02
14
 photo_cameraImage coming soon 261065-9 WASHER TEFLON 7XJS1650 €1.34
15
 photo_cameraImage coming soon 267010-2 FLAT WASHER 5 XJS1650 €1.33
16
 photo_cameraImage coming soon 267010-2 FLAT WASHER 5 XJS1650 €1.33
19
 photo_cameraImage coming soon 331329-6 JOINT X JS1650 €12.92
21
 photo_cameraImage coming soon 140506-7 HOUSING ROD X JS1601 €51.89
22
 photo_cameraImage coming soon 325727-4 LOCK JS1660 €5.09
24
 photo_cameraImage coming soon 266085-8 SCREW M6x10 X 5143R €1.93
25
 photo_cameraImage coming soon 256733-7 PIN 7 X JS1650 €2.94
26
 photo_cameraImage coming soon 961012-7 RETAINING RING E6 €2.17
27
 photo_cameraImage coming soon 211027-7 BEARING 627ZZ X UH5570 €2.19
28
 photo_cameraImage coming soon 253133-2 PLAIN WASHER 7 €1.40
29
 photo_cameraImage coming soon 331273-7 ROD X JS1650 €16.59
30
 Ball Bearing 6000 ZZ for CUT-OFF Machine Makita 2414EN 211480-7 Ball Bearing 6000 ZZ for CUT-OFF Machine Makita 2414EN €8.05
31
 photo_cameraImage coming soon 325948-8 ECCENTRIC X JS1601 €9.72
32
 photo_cameraImage coming soon 325949-6 SCREW X JS1601 €11.32
33
 photo_cameraImage coming soon 227731-8 GEAR 40 X JS1601 €8.61
34
 Bearing 696ZZ FOR Angle Grinder Makita GA4530 210033-9 Bearing 696ZZ FOR Angle Grinder Makita GA4530 €3.35
35
 photo_cameraImage coming soon 442161-4 SEAL X JS1601 €1.34
36
 photo_cameraImage coming soon 140507-5 CASING ING. X JS1601 €5.73
37
 Ball Bearing 608DDW for Jigsaw Makita 4327 210005-4 Ball Bearing 608DDW for Jigsaw Makita 4327 €5.44
38
 photo_cameraImage coming soon 240076-7 FAN FOR 56 9554NB €2.27
39
 photo_cameraImage coming soon 517674-5 ARMATURE X JS1000 €42.15
40
 Armature Washer for Angle Grinder Makita GA4530 681636-0 Armature Washer for Angle Grinder Makita GA4530 €2.34
41
 Ball Bearing 607 ZZ for Impact Drill Maktek MT601 210062-2 Ball Bearing 607 ZZ for Impact Drill Maktek MT601 €4.41
42
 Ball Bearing Protection for Angle Grinder Makita GA4530 421868-5 Ball Bearing Protection for Angle Grinder Makita GA4530 €2.00
43
 Baffle for Angle Grinder Makita GA4530 450796-7 Baffle for Angle Grinder Makita GA4530 €1.50
44
 photo_cameraImage coming soon 452073-3 DISTANCE X JS1601 €2.54
45
 photo_cameraImage coming soon 623549-9 STATOR FOR JS1000 €14.68
46
 photo_cameraImage coming soon 266004-4 SCREW 4x70 €1.87
47
 photo_cameraImage coming soon 266492-5 SCREW M4X25-9527PB 9528PB €2.47
48
 Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 643839-4 Carbon Brushe Holder for Angle Grinders Makita GA4530-4534-5034 €3.18
49
 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 194722-3 Carbon Brushes for Angle Grinders Makita GA4530-4534-5034 €5.37
50
 photo_cameraImage coming soon 450795-9 HOUSING MOTOR GA4530 €10.14
52
 Switch Lever for Angle Grinder Makita GA4530 450797-5 Switch Lever for Angle Grinder Makita GA4530 €6.55
54
 Lever Switch Spring for Angle Grinder Makita 9554NB 233121-5 Lever Switch Spring for Angle Grinder Makita 9554NB €1.30
55
 Switch for Angle Grinders Makita GA4530-34-5034 650560-8 Switch for Angle Grinders Makita GA4530-34-5034 €8.23
56
 photo_cameraImage coming soon 687682-1 CLAMP Cable tie X JS1000 €2.95
57
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
58
 photo_cameraImage coming soon 638739-1 CAPACITOR X JS1000 €3.75
59
 photo_cameraImage coming soon 682566-8 CORD GUARD X HR2450 €2.15
61
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
62
 Rear Cover for Angle Grinder Makita GA4530 450794-1 Rear Cover for Angle Grinder Makita GA4530 €6.55

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Metal Shear JS1601

Makita genuine spare parts or replacements parts for to fix Makita JS1601 Metal Shear.

In the following table, look for the model of the Blenchschere and the respective parts of the code.
Makita JS1601 Metal Shear

Makita JS1601 Metal Shear Spare Parts
# Part Num. Description
1 266091-3 SPECIAL SCREW 4 X 50
2 922147-9 SCREW M4x25
3 961011-9 RETAINING RING E4
4 346131-4 PLATE SLIDE DX X JS1000
5 343480-0 SLIDE PLATE SX JS1660
6 343481-8 PLATE BLADE JS1660
7 792533-6 BLADE SIDE JS1660
9 251951-2 ALLEN SCREW M5x10
10 261065-9 WASHER TEFLON 7XJS1650
11 253338-4 WASHER 7 X JS1650
12 792534-4 BLADE CENTRAL JS1660
13 253338-4 WASHER 7 X JS1650
14 261065-9 WASHER TEFLON 7XJS1650
15 267010-2 FLAT WASHER 5 XJS1650
16 267010-2 FLAT WASHER 5 XJS1650
17 256155-1 PIN 5 X JS1650
18 256155-1 PIN 5 X JS1650
19 331329-6 JOINT X JS1650
20 423118-4 COP.ANTIPOLVERE XJS1650
21 140506-7 CASING ROD X JS1601
22 325727-4 LOCK JS1660
23 252083-8 NUT ESAG.M4-7 X JS1650
24 266085-8 SCREW M6x10 X 5143R
25 256733-7 PIN 7 X JS1650
26 961012-7 RETAINING RING E6
27 211027-7 BEARING 627ZZ X UH5570
28 253133-2 PLAIN WASHER 7
29 331273-7 ROD X JS1650
30 211480-7 BEARING 6000ZZ
31 325948-8 ECCENTRIC X JS1601
32 325949-6 SCREW X JS1601
33 227731-8 GEAR 40 X JS1601
34 210033-9 BEARING 696ZZ X 2107FK
35 442161-4 SEAL X JS1601
36 140507-5 CASING ING. X JS1601
37 210005-4 BALL BEARING 608 DDW
38 240076-7 FAN 56 X 9554NB
39 517674-5 ARMATURE X JS1000
40 681636-0 INSULATION WASHER
41 210062-2 BEARING 607ZZ X MT601
42 421868-5 RING RUBBER X 9554NB
43 450796-7 BAFFLE FOR GA4530
44 452073-3 DISTANCE X JS1601
45 623549-9 STATOR FOR JS1000
46 266004-4 SCREW 4x70
47 266492-5 SCREW M4x25-9527PB 9528PB
48 643839-4 BRUSH GA4530
49 194722-3 CARBON BRUSHES CB 459 X GA4530
50 450795-9 CASING MOTOR GA4530
51 418016-5 KEY SWITCH X MT952
52 450797-5 LEVER SWITCH GA4530
53 868086-8 LABEL JS1601
54 233121-5 SPRING COMPRESSION 4 X 9554NB
55 650560-8 SWITCH DPX 2110-R 9554NB
56 687682-1 CLAMP Cable tie X JS10
57 265995-6 SCREW M4X18 X 6408 / 6221DW
58 638739-1 CAPACITOR X JS1000
59 682566-8 PASS CABLE X HR2450
61 265995-6 SCREW M4X18 X 6408 / 6221DW
62 450794-1 BACK COVER GA4530
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita JS1601
12 Items

Specific References

New

Download

Diagram Makita JS1601

Diagram Makita JS1601

Download (643.88KB)
