Makita

Makita Spare Parts for Circular Saw DHS630Z

SKU: Makita DHS630Z
€84.96
VAT included

Makita Spare Parts for Circular Saw DHS630Z

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Circular Saw DHS630Z.
Makita Spare Parts for Circular Saw DHS630Z
  • Makita Spare Parts for Circular Saw DHS630Z
  • Makita Spare Parts for Circular Saw DHS630Z
Makita

Makita Spare Parts for Circular Saw DHS630Z

SKU: Makita DHS630Z Condition: New
€84.96
VAT included

Makita Spare Parts for Circular Saw DHS630Z

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Circular Saw DHS630Z.
settings 88 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
88 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 141237-1 COVER HANDLE X BHS63 €62.06
2
 photo_cameraImage coming soon 644808-8 X-TERMINAL BLS713 BHP451 €6.27
3
 photo_cameraImage coming soon 419664-3 LEVER BCS550R €2.58
4
 photo_cameraImage coming soon 650631-1 SWITCH X-BUC250 BSS610 €16.65
5
 photo_cameraImage coming soon 231469-9 SPRING 4 X 6811DW €1.40
6
 photo_cameraImage coming soon 419665-1 LEVER SWITCH BCS550R €2.58
7
 photo_cameraImage coming soon 620257-3 REGULATOR €34.22
8
 photo_cameraImage coming soon 231469-9 SPRING 4 X 6811DW €1.40
9
 photo_cameraImage coming soon 140984-1 HOUSING MOT. X BHS630 €62.06
10
 Pt Screw M4X18 for Rotary Hammer Makita HR4000C 265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C €1.46
12
 photo_cameraImage coming soon 643889-9 SUPPORT BRUSH SX X BHS630 €4.25
13
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.46
14
 photo_cameraImage coming soon 452787-4 COVER POST. X BHS630 €8.71
15
 photo_cameraImage coming soon 643941-3 PLUG BRUSH X 5621RDW €4.43
16
 photo_cameraImage coming soon 194435-6 CHARCOALS CB-441 €5.13
17
 photo_cameraImage coming soon 643882-3 SUPPORT BRUSH DX X BHS630 €4.25
18
 photo_cameraImage coming soon 911258-5 SCREW M5x35 4101R €2.58
19
 photo_cameraImage coming soon 266026-4 SCREW M4 X 12 €2.74
20
 photo_cameraImage coming soon 452790-5 SUPPORT X BHS630 €5.36
21
 photo_cameraImage coming soon 452789-0 COVER CAP DISC X BHS630 €15.38
22
 photo_cameraImage coming soon 266292-3 SCREW 4 X 65 X BJR240 €2.08
23
 photo_cameraImage coming soon 638571-3 STATOR MAGNET PERMAN.BSS61 €12.69
24
 photo_cameraImage coming soon 452785-8 Deflector X BHS630 €5.36
25
 photo_cameraImage coming soon 266026-4 SCREW M4 X 12 €2.74
26
 photo_cameraImage coming soon 331947-0 PIPE 6 X BHS630 €4.25
27
 photo_cameraImage coming soon 266020-6 SCREW M4 X 12 €1.46
28
 photo_cameraImage coming soon 272270-3 LEVER 39 BHS630 €2.58
29
 photo_cameraImage coming soon 210023-2 9910/11 BEARING €7.16
30
 photo_cameraImage coming soon 519288-6 ARMATURE BHS630 €45.35
31
 photo_cameraImage coming soon 241869-5 FAN 55 €5.94
32
 photo_cameraImage coming soon 210051-7 BEARING 609LLB €5.36
33
 photo_cameraImage coming soon 344681-3 LOCKING SHAFT X 5621RDW €4.25
34
 photo_cameraImage coming soon 233117-6 COMPRESSION SPRING 6 X GA7010C €1.32
35
 photo_cameraImage coming soon 266458-5 SCREW M 6 X 18 X 4131 €2.58
36
 photo_cameraImage coming soon 224421-4 EXTERNAL FLANGE 28 X BHS630 €13.15
37
 photo_cameraImage coming soon 224417-5 FLANGE INT. 28 X BHS630 €13.15
38
 photo_cameraImage coming soon 257938-2 RETAINING RING WR-26 €2.58
39
 photo_cameraImage coming soon 267127-1 FLAT WASHER 26 9046 €2.58
40
 photo_cameraImage coming soon 452791-3 HEADSET PROTECTION BHS630 €15.38
41
 photo_cameraImage coming soon 231874-0 SPRING TENSION 4 X BHS630 €2.58
42
 photo_cameraImage coming soon 345470-9 RING THICKNESS X BCS550R €2.58
43
 photo_cameraImage coming soon 326410-6 SPINDLE BHS630 €7.04
44
 photo_cameraImage coming soon 911128-8 SCREW M4x16 X HR4000C €2.74
45
 photo_cameraImage coming soon 140983-3 BEARING BOX X BHS630 €6.36
46
 photo_cameraImage coming soon 442141-0 SEAL X BHS630 €2.58
47
 photo_cameraImage coming soon 210069-8 BEARING 6900DDW X BCS550R €6.48
48
 photo_cameraImage coming soon 285847-5 RETAINING CUSC.14-23 X BCS5 €4.68
49
 photo_cameraImage coming soon 257284-3 RING 10 X BHS630 €3.14
50
 photo_cameraImage coming soon 227791-0 GEAR 24 €6.48
51
 photo_cameraImage coming soon 961006-2 RETAINING RING S10 €1.32
52
 photo_cameraImage coming soon 262155-1 RUBBER RING 10 X BHS630 €2.58
53
 photo_cameraImage coming soon 267369-7 WASHER 11 X BHS630 €2.58
54
 Bearing for Angle Grinder Makita 9524NB 211012-0 Bearing for Angle Grinder Makita 9524NB €8.23
55
 photo_cameraImage coming soon 227717-2 GEAR 17 X BHS630 €15.38
56
 photo_cameraImage coming soon 226676-7 GEAR 39 X BHS630 €13.15
57
 photo_cameraImage coming soon 253823-7 ROND. FLAT 7 X JS1600 €2.40
58
 photo_cameraImage coming soon 264064-0 NUT M6 X BHS630 €5.36
59
 photo_cameraImage coming soon 266229-0 SCREW M 5X8 X KP312S €1.29
60
 photo_cameraImage coming soon 141002-8 HEADSET DISC BHS630 €45.35
61
 photo_cameraImage coming soon 262511-5 RUBBER REDUCTION X HM1300 €3.18
62
 photo_cameraImage coming soon 265115-2 SCREW M 5 X BHS630 €2.58
63
 photo_cameraImage coming soon 452786-6 BOX X BHS630 €6.48
64
 photo_cameraImage coming soon 452788-2 COVER X BHS630 €5.36
65
 photo_cameraImage coming soon 266042-6 SCREW 4X20 X 2107FK €2.74
66
 photo_cameraImage coming soon 631694-6 CIRCUIT FOR LIGHT BSS610 €19.84
67
 photo_cameraImage coming soon 961014-3 RETAINING RING E-8 €1.46
68
 photo_cameraImage coming soon 272260-6 LEVER 55 X BHS630 €4.25
69
 photo_cameraImage coming soon 265595-2 SCREW M6 X 85 X BHS630 €8.71
70
 photo_cameraImage coming soon 253804-1 WASHER 6 X LS1013 €1.40
71
 photo_cameraImage coming soon 346477-8 SOCKETS X BHS630 €3.69
72
 photo_cameraImage coming soon 318245-9 DEPTH DRIVING 'BHS630 €8.71
73
 photo_cameraImage coming soon 346477-8 SOCKETS X BHS630 €3.69
74
 photo_cameraImage coming soon 922137-2 SCREW ESAG. INC. 4X20 €2.58
75
 photo_cameraImage coming soon 345876-1 DRIVING BACK BHS630 €2.58
76
 photo_cameraImage coming soon 252126-6 NUT M4-7 X BHS630 €1.47
78
 photo_cameraImage coming soon 961012-7 RETAINING RING E6 €2.17
79
 photo_cameraImage coming soon 453165-1 LEVER LOCK BHS630 €2.58
80
 photo_cameraImage coming soon 265571-6 SCREW M6x10 BHS630 €3.69
81
 photo_cameraImage coming soon 233596-8 SPRING TORSION 11 BHS630 €2.58
83
 photo_cameraImage coming soon 265072-4 SCREW M 5 X BHS630 €2.58
84
 photo_cameraImage coming soon 345590-9 DRIVING ANGLE BHS630 €4.25
87
 photo_cameraImage coming soon 252103-8 LOCKNUT X JR3020 €3.18
96
 photo_cameraImage coming soon 265708-5 SCREW M6 X 20 X LS1040 €2.69
97
 photo_cameraImage coming soon 942151-2 WASHER 6 €3.66
98
 photo_cameraImage coming soon 941151-9 WASHER 6 X HM1303 €3.66
99
 photo_cameraImage coming soon 266039-5 SCREW M6X6 €2.00
100
 photo_cameraImage coming soon 310511-0 BASE BHS630 €39.90
101
 photo_cameraImage coming soon 266039-5 SCREW M6X6 €2.00
103
 photo_cameraImage coming soon 266208-8 SCREW M6 X 8 X LS0714FL €1.29
104
 photo_cameraImage coming soon 911109-2 SCREW M4X8 X 4304T-4305T €1.34
105
 photo_cameraImage coming soon 450333-7 UPPER GUIDE BHS630 €2.58
106
 photo_cameraImage coming soon 265708-5 SCREW M6 X 20 X LS1040 €2.69
107
 photo_cameraImage coming soon 942151-2 WASHER 6 €3.66
108
 photo_cameraImage coming soon 941151-9 WASHER 6 X HM1303 €3.66
109
 photo_cameraImage coming soon 254031-3 WOODRUF 3 €2.58

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Circular Saw DHS630Z

Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Circular Saw DHS630Z.

In the following table, look for the model of the Circular Saw and the respective parts of the code.
Makita DHS630Z
CIRCULAR SAW DHS630Z
# Part Num. Description
1 141237-1 COVER HANDLE X BHS63
2 644808-8 TERMINAL X BLS713 BHP451
3 419664-3 LEVER BCS550R
4 650631-1 SWITCH X-BUC250 BSS610
5 231469-9 SPRING 4 X 6811DW
6 419665-1 LEVER SWITCH BCS550R
7 620257-3 REGULATOR
8 231469-9 SPRING 4 X 6811DW
9 140984-1 HOUSING MOT. X BHS630
10 265995-6 SCREW M4X18 X 6408 / 6221DW
12 643889-9 SUPPORT BRUSH SX X BHS630
13 265995-6 SCREW M4X18 X 6408 / 6221DW
14 452787-4 COVER POST. X BHS630
15 643941-3 PLUG BRUSH X 5621RD
16 194435-6 CHARCOALS CB-441
17 643882-3 SUPPORT BRUSH DX X BHS630
18 911258-5 SCREW M5x35 4101R
19 266026-4 SCREW M4 X 12
20 452790-5 SUPPORT X BHS630
21 452789-0 COVER CAP DISC X BHS630
22 266292-3 SCREW 4 X 65 X BJR240
23 638571-3 STATOR MAGNET PERMAN.BSS61
24 452785-8 DEFLETTORE X BHS630
25 266026-4 SCREW M4 X 12
26 331947-0 PIPE 6 X BHS630
27 266020-6 SCREW M4 X 12
28 272270-3 LEVER 39 BHS630
29 210023-2 BEARING 9910/11
30 519288-6 ARMATURE BHS630
31 241869-5 FAN 55
32 210051-7 BEARING 609LLB
33 344681-3 LOCKING SHAFT X 5621RDW
34 233117-6 SPRING COMP. 6 X GA7010C
35 266458-5 SCREW M 6 X 18 X 4131
36 224421-4 EXTERNAL FLANGE 28 X BHS630
37 224417-5 FLANGE INT. 28 X BHS630
38 257938-2 RETAINING RING WR-26
39 267127-1 FLAT WASHER 26 9046
40 452791-3 HEADSET PROTECTION BHS630
41 231874-0 SPRING TENSION 4 X BHS630
42 345470-9 RING THICKNESS X BCS550R
43 326410-6 SPINDLE BHS630
44 911128-8 SCREW M4x16 X HR4000C
45 140983-3 BEARING BOX X BHS630
46 442141-0 SEAL X BHS630
47 210069-8 BEARING 6900DDW X BCS550R
48 285847-5 RETAINING CUSC.14-23 X BCS550R
49 257284-3 RING 10 X BHS630
50 227791-0 GEAR 24
51 961006-2 RETAINING RING S10
52 262155-1 RUBBER RING 10 X BHS630
53 267369-7 WASHER 11 X BHS630
54 211012-0 BEARING X 9524NB
55 227717-2 GEAR 17 X BHS630
56 226676-7 GEAR 39 X BHS630
57 253823-7 ROND. FLAT 7 X JS1600
58 264064-0 NUT M6 X BHS630
59 266229-0 SCREW M 5X8 X KP312S
60 141002-8 HEADSET DISC BHS630
61 262511-5 REDUCTION RUBBER X HM1300
62 265115-2 SCREW M 5 X BHS630
63 452786-6 BOX X BHS630
64 452788-2 COVER X BHS630
65 266042-6 SCREW 4X20 X 2107FK
66 631694-6 CIRCUIT FOR LIGHT BSS610
67 961014-3 RETAINING RING E-8
68 272260-6 LEVER 55 X BHS630
69 265595-2 SCREW M6 X 85 X BHS630
70 253804-1 WASHER 6 X LS1013
71 346477-8 SOCKETS X BHS630
72 318245-9 DEPTH DRIVING 'BHS630
73 346477-8 SOCKETS X BHS630
74 922137-2 SCREW ESAG. INC. 4X20
75 345876-1 DRIVING BACK BHS630
76 252126-6 NUT M4-7 X BHS630
77 256480-0 PIN 6-7 BSS611R
78 961012-7 RETAINING RING E6
79 453165-1 LEVER LOCK BHS630
80 265571-6 SCREW M6x10 BHS630
81 233596-8 SPRING TORSION 11 BHS630
82 256480-0 PIN 6-7 BSS611R
83 265072-4 SCREW M 5 X BHS630
84 345590-9 DRIVING ANGLE BHS630
87 252103-8 NUT X JR3020
96 265708-5 SCREW M6 X 20 X LS1040
97 942151-2 WASHER 6 4101R
98 941151-9 WASHER 6 X HM1303
99 266039-5 SCREW M6X6
100 310511-0 BASE BHS630
101 266039-5 SCREW M6X6
103 266208-8 SCREW M6 X 8 X LS0714FL
104 911109-2 SCREW M4X8 X 4304T-4305T
105 450333-7 UPPER GUIDE BHS630
106 265708-5 SCREW M6 X 20 X LS1040
107 942151-2 WASHER 6 4101R
108 941151-9 WASHER 6 X HM1303
109 254031-3 WOODRUF 3
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase.All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita DHS630Z
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita DHS630Z

Diagram Makita DHS630Z

Download (890.96KB)

You might also like

Bearing for Angle Grinder Makita 9524NB
Makita SKU: 211012-0
Bearing for Angle Grinder Makita 9524NB
Bearing for Angle Grinder Makita 9524NB Genuine spare Makita, Ball Bearing 606 2Z for Angle Grinder 9524NB. Part for the following products: - CIRCULAR SAW 165 MM 5604R - CIRCULAR SAW 165 MM-18V 2.2Ah Ni-MH 5621RDWBE - KEYLESS DRILL...
AVAILABLE €8.23
Details
Comments (0)
