Makita Spare Parts for Electric Breaker HM1317C

Name: Makita Spare Parts for Electric Breaker HM1317C
Brand: Makita
SKU: Makita HM1317C
Availability: InStock

SKU: Makita HM1317C

€328.45

VAT included

Makita Spare Parts for Electric Breaker HM1317C

Makita original spare parts for to replace broken parts for to fix HM1317C 1-3/16″ : 30mm Hex Shank – Electric Breaker.

Ripara il tuo Electric Breaker, tutti i pezzi di ricambio sono fornibili per una rapida consegna. I nostri ricambi sono ricambi originali e sono dotati di una garanzia completa.

104 spare parts

Page 1 View exploded Usually Ships in: 7/10 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	266512-5 SET BOLT M10X142	€6.36
2	Image coming soon	163506-0 SIDE HANDLE	€32.08
3	Image coming soon	451331-4 HANDLE BASE	€1.88
4	Image coming soon	451331-4 HANDLE BASE	€1.88
5	Image coming soon	252654-1 THUMB NUT M10	€4.17
6	Image coming soon	253194-2 WASHER 5 X HM1303	€1.40
7	Image coming soon	922221-3 Screw M5X16 X HM1303	€3.41
12	Image coming soon	324099-4 TOOL RETAINER	€39.66
13	Image coming soon	331866-0 TOOL HOLDER	€272.09
14	Image coming soon	266011-7 HEX. SOCKET HEAD BOLT M8X35	€2.48
15	Image coming soon	233309-7 COMPRESSION SPRING 17	€2.77
16	Image coming soon	324135-6 RETAINER SLEEVE	€7.28
17	Image coming soon	213720-9 GASKET 67	€3.41
18	Image coming soon	262150-1 URETHAN RING	€7.28
19	Image coming soon	267401-7 FLAT WASHER 24	€10.72
20	Image coming soon	257782-7 SLEEVE 43	€21.06
21	Image coming soon	213569-7 O-RING 45 X AN621	€1.25
22	Image coming soon	213192-8 X-RING 36	€6.36
23	Image coming soon	213150-4 O-RING 36	€2.45
24	Image coming soon	325682-0 IMPACT BOLT	€35.07
25	Image coming soon	325683-8 WASHER 30	€12.33
26	Image coming soon	424206-0 RUBBER RING 36	€12.33
27	Image coming soon	325684-6 SHOULDER RING 32	€16.23
28	Image coming soon	318458-2 BARREL	€83.76
29	Image coming soon	325685-4 STRIKER	€18.53
30	Image coming soon	213193-6 O-RING 42	€2.91
31	Image coming soon	233977-6 RING SPRING 55	€1.88
32	Image coming soon	331870-9 CYLINDER 52	€172.18
33	Image coming soon	451168-9 SHOULDER SLEEVE	€3.60
34	Image coming soon	234111-1 COMPRESSION SPRING 66	€13.93
35	Image coming soon	265367-5 BOLT M 8 X 40 X HM 1500	€2.91
36	Image coming soon	451169-7 WEIGHT GUIDE	€2.45
37	Image coming soon	331867-8 COUNTER WEIGHT	€18.53
38	Image coming soon	451169-7 WEIGHT GUIDE	€2.45
39	Image coming soon	234111-1 COMPRESSION SPRING 66	€13.93
40	Image coming soon	331868-6 SLIDE SLEEVE	€13.93
41	Image coming soon	233977-6 RING SPRING 55	€1.88
42	Image coming soon	213569-7 O-RING 45 X AN621	€1.25
43	Image coming soon	213569-7 O-RING 45 X AN621	€1.25
44	Image coming soon	256238-7 PIN 12 X HM1303	€5.67
45	Image coming soon	213193-6 O-RING 42	€2.91
46	Image coming soon	318459-0 PISTON	€35.07
47	Image coming soon	213569-7 O-RING 45 X AN621	€1.25
48	Image coming soon	451164-7 CONNECTING ROD	€4.86
50	Image coming soon	213806-9 GASKET 90 XHR2510	€4.72
51	Image coming soon	318462-1 GEAR COVER	€49.30
53	Image coming soon	227709-1 HELICAL GEAR 47	€44.02
54	Image coming soon	211306-3 BALL BEARING 6204DD	€10.72
56	Image coming soon	267166-1 WASHER 14 X HM0860C	€1.88
57	Image coming soon	226156-3 GEAR COMPLETE 31-43	€90.65
58	Image coming soon	212159-3 CONROD HOUSING 1412 X HM1214C	€4.86
59	Image coming soon	262157-7 NYLON RING 14	€1.88
60	Image coming soon	212159-3 CONROD HOUSING 1412 X HM1214C	€4.86
61	Image coming soon	267166-1 WASHER 14 X HM0860C	€1.88
62	Image coming soon	424207-8 SEAL RING	€1.88
63	Image coming soon	140056-2 CRANK HOUSING COMPLETE	€309.61
64	Image coming soon	211373-8 BALL BEARING 6205	€14.77
65	Image coming soon	331871-7 CRANK SHAFT	€18.53
66	Image coming soon	331869-4 COUNTER SHAFT	€74.57
67	Image coming soon	212264-6 NEEDLE ROLLER BEARING 1813	€16.23
68	Image coming soon	325686-2 SHOULDER WASHER 8	€2.45
69	Image coming soon	213809-3 O RING 87	€2.91
70	Image coming soon	268240-8 PIN 10	€1.88
71	Image coming soon	140057-0 BEARING BOX COMPLETE	€32.08
72	Image coming soon	961004-6 RETAINING RING S8	€3.76
73	Image coming soon	213261-5 O-RING 17X9207SPC	€4.22
74	Image coming soon	265844-7 HEX. SOCKET HEAD BOLT M6X20	€1.40
75	Image coming soon	211032-4 BEARING X 1902	€5.87
77	Image coming soon	443127-7 FILTER X HM1203C	€1.40
78	Image coming soon	213758-4 O RING 74	€2.91
79	Image coming soon	451166-3 CRANK CAP COVER	€4.17
81	Image coming soon	451167-1 REAR COVER	€23.81
83	Image coming soon	331855-5 SEALING SCREW HM1214C	€1.88
84	Image coming soon	211249-9 BALL BEARING 6302LLU HM1203C	€12.69
85	Image coming soon	267397-2 WASHER 15 X HM1203C	€1.40
86	Image coming soon	240003-4 FAN X 2702	€5.13
87		517788-0 Armature for Demolition Hammer AVT Makita HM1317C	€161.99
88		681642-5 Armature Washer for Demolition Hammers Makita HR 4501-10-11C	€13.30
89	Image coming soon	210059-1 BEARING 6000 HR2010	€12.89
90	Image coming soon	451107-9 WASHER GUIDE X HM1214C	€2.45
91	Image coming soon	267809-5 WAVE WASHER 19 FOR HM1202	€1.35
92	Image coming soon	451111-8 BAFFLE PLATE X HM1214C	€3.60
93	Image coming soon	266044-2 SCREW PT.5X60	€6.04
94		636333-3 Stator for Demolition Hammer Makita HM1317C	€41.89
95	Image coming soon	451117-6 MOTOR HOUSING X HM1214C	€21.06
96		632D00-2 Carbon Brushes Holder Makita for Hammers HM 1203C-1213C-1214C-1317C	€15.80
97		195844-2 Carbon Brushes Makita for Hammers HM-HR	€11.59
98		265995-6 Pt Screw M4X18 for Rotary Hammer Makita HR4000C	€1.46
99	Image coming soon	158986-3 CONTROLLER COVER COMP. HM1214C	€12.33
100	Image coming soon	263027-3 RUBBER PIN 4 HM0860C	€1.70
101	Image coming soon	651423-1 SWITCH X 3706	€14.34
102		265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW	€1.46
103	Image coming soon	687169-3 STRAIN RELIEF HP1620	€1.46
104		265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW	€1.46
106		682560-0 Power Cord Protection for Angle Grinder Makita 1800-2000-2200W	€3.18
107		620230-3 Speed Controller for Demolition Hammer Makita HM1317C	€97.43
109	Image coming soon	232209-8 FLAT SPRING HM0860C	€1.70
110	Image coming soon	451112-6 SLIDE LEVER HM1214C	€3.60
111	Image coming soon	263027-3 RUBBER PIN 4 HM0860C	€1.70
112	Image coming soon	451105-3 LENS FOR HM1214C	€2.45
113	Image coming soon	451118-4 REAR HANDLE X HM1214C	€39.66
114		265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW	€1.46
115	Image coming soon	451106-1 SWITCH LEVER HM1214C	€2.91
116		265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW	€1.46
119	Image coming soon	451119-2 HANDLE COVER X HM1214C	€21.06
120		265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW	€1.46

Page 2 Usually Ships in: 7/10 BUSINESS DAYS

Pos.		Item	Price
999		195103-4 Service Pack for Demolition Hammer Makita HM1317C	€29.44
1000		181490-7 Grease Gr.30 for SDS-Max Hammer Makita HR4002	€7.72
1001		824897-1 Makita Carrying Case for HM1317C	€199.53
1002		198993-4 Makita Grease Vessel for Bit 100 ml	€10.49
1003	Image coming soon	A-31485 Rammer, 30 mm Hex shank, Ø 200 mm	€134.74
1004	Image coming soon	D-15285 BULL POINT 400	€32.48
1005		D-15300 Makita Cold Chisel 30x400 mm	€32.48
1006		P-05549 Makita Bull Point 30x400 mm	€34.34
1007		P-05555 Makita Hex Rammer 255x200mm	€142.94
1008		P-05561 Makita Bull Point Chisel 30x700mm	€52.71
1009		P-05583 Makita Bull Flat Chisel 30x700mm	€55.93
1010		P-13518 Makita Spoon Chisel 115x400mm	€91.40
1011	Image coming soon	162271-8 LATCH	€2.12

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Electric Breaker HM1317C

Makita genuine spare parts or replaciments parts for to repair HM1317C 1-3/16″ : 30mm Hex Shank – Electric Breaker.

In the following table, look for the model of the Hammer and the respective parts of the code.

HM1317C ELECTRIC BREAKER Pag.1
#	Part Num.	Description
1	266512-5	SET BOLT M10X142
2	163506-0	SIDE HANDLE
3	451331-4	HANDLE BASE
4	451331-4	HANDLE BASE
5	252654-1	THUMB NUT M10
6	253194-2	FLAT WASHER 5
7	922221-3	HEX. SOCKET HEAD BOLT M5X16
12	324099-4	TOOL RETAINER
13	331866-0	TOOL HOLDER
14	266011-7	HEX. SOCKET HEAD BOLT M8X35
15	233309-7	COMPRESSION SPRING 17
16	324135-6	RETAINER SLEEVE
17	213720-9	O RING 67
18	262150-1	URETHAN RING
19	267401-7	FLAT WASHER 24
20	257782-7	SLEEVE 43
21	213569-7	O RING 45
22	213192-8	X-RING 36
23	213150-4	O-RING 36
24	325682-0	IMPACT BOLT
25	325683-8	WASHER 30
26	424206-0	RUBBER RING 36
27	325684-6	SHOULDER RING 32
28	318458-2	BARREL
29	325685-4	STRIKER
30	213193-6	O-RING 42
31	233977-6	RING SPRING 55
32	331870-9	CYLINDER 52
33	451168-9	SHOULDER SLEEVE
34	234111-1	COMPRESSION SPRING 66
35	265367-5	HEX. SOCKET HEAD BOLT M8X40
36	451169-7	WEIGHT GUIDE
37	331867-8	COUNTER WEIGHT
38	451169-7	WEIGHT GUIDE
39	234111-1	COMPRESSION SPRING 66
40	331868-6	SLIDE SLEEVE
41	233977-6	RING SPRING 55
42	213569-7	O RING 45
43	213569-7	O RING 45
44	256238-7	PIN 12
45	213193-6	O-RING 42
46	318459-0	PISTON
47	213569-7	O RING 45
48	451164-7	CONNECTING ROD
49	268241-6	PIN 6
50	213806-9	O RING 90
51	318462-1	GEAR COVER
52	266499-1	H.S HEAD BOLT M6X30 WITH GM
53	227709-1	HELICAL GEAR 47
54	211306-3	BALL BEARING 6204LLB
56	267166-1	FLAT WASHER 14
57	226156-3	GEAR COMPLETE 31-43
58	212159-3	NEEDLE CAGE 1412
59	262157-7	NYLON RING 14
60	212159-3	NEEDLE CAGE 1412
61	267166-1	FLAT WASHER 14
62	424207-8	SEAL RING
63	140056-2	CRANK HOUSING COMPLETE
64	211373-8	BALL BEARING 6205LLU
65	331871-7	CRANK SHAFT
66	331869-4	COUNTER SHAFT
67	212264-6	NEEDLE ROLLER BEARING 1813
68	325686-2	SHOULDER WASHER 8
69	213809-3	O RING 87
70	268240-8	PIN 10
71	140057-0	BEARING BOX COMPLETE
72	961004-6	RETAINING RING S-8
73	213261-5	O RING 17
74	265844-7	HEX. SOCKET HEAD BOLT M6X20
75	211032-4	BALL BEARING 608ZZ
76	962112-6	RETAINING RING R-22
77	443127-7	FILTER
78	213758-4	O RING 74
79	451166-3	CRANK CAP COVER
81	451167-1	REAR COVER
82	266499-1	H.S HEAD BOLT M6X30 WITH GM
83	331855-5	SEALING SCREW
84	211249-9	BALL BEARING 6302LLU
85	267397-2	FLAT WASHER 15
86	240003-4	FAN 80
87	517788-0	ARMATURE ASSEMBLY 220-240V
88	681642-5	INSULATION WASHER
89	210059-1	BALL BEARING 6000DDW
90	451107-9	WASHER GUIDE
91	267809-5	WAVE WASHER 19
92	451111-8	BAFFLE PLATE
93	266044-2	TAPPING SCREW 5X60
94	636333-3	FIELD 220-240V
95	451117-6	MOTOR HOUSING
96	632D00-2	BRUSH HOLDER UNIT
97	195844-2	CARBON BRUSH SET CB-175
98	265995-6	TAPPING SCREW 4X18
99	158986-3	CONTROLLER COVER COMPLETE
100	263027-3	RUBBER PIN 4
101	651423-1	SWITCH
102	265995-6	TAPPING SCREW 4X18
103	687169-3	STRAIN RELIEF
104	265995-6	TAPPING SCREW 4X18
105	692623-4	POWER SUPPLY CORD 1.5-2-4.0
106	682560-0	CORD GUARD 10
107	620230-3	CONTROLLER
108	266834-3	H.S.H.BOLT M4X18 WITH GM
109	232209-8	LEAF SPRING
110	451112-6	SLIDE LEVER
111	263027-3	RUBBER PIN 4
112	451105-3	LENS
113	451118-4	HANDLE
114	265995-6	TAPPING SCREW 4X18
115	451106-1	SWITCH LEVER
116	265995-6	TAPPING SCREW 4X18
117	266499-1	H.S HEAD BOLT M6X30 WITH GM
118	867300-9	HM1317C NAME PLATE
119	451119-2	HANDLE COVER
120	265995-6	TAPPING SCREW 4X18
Accessories Pag.2
999	195103-4	HAMMER SERVICE KIT
1000	181490-7	HAMMER GREASE 30G
1001	824897-1	PLASTIC CARRYING CASE
1002	198993-4	Grease vessel for bit 100 ml
1003	A-31485	Rammer, 30 mm Hex shank, Ø 200 mm
1004	D-15285	BULL POINT 400
1005	D-15300	Cold Chisel 30 x 400 mm
1006	P-05549	Bull point 30 x 400 mm
1007	P-05555	Hex Spade Chisel Bit
1008	P-05561	30 x 700mm Bull Point Chisel Bit
1009	P-05583	30 x 700mm Flat Chisel Bit
1010	P-13518	Spoon chisel
1011	162271-8	LATCH

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference Makita HM1317C

Available 12 Items

Data sheet

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]

Specific References

Condition New

Download

Makita HM1317C Drawing

Download (436.81KB)

Makita SKU: 651922-3

Switch for Polisher Makita SA7000

Switch for Polisher Makita SA7000 Genuine part Makita, Switch for Polisher SA7000 - Mitre Saw 2414B - 2414EN-NB - Planes Makita 4304 - 4304T - 4306 - Circular Saws Makita 5017RKB - 5603R - RK - 5703R - RK - 5705RK Part for the...

Last items in stock €32.80

Cart (0)

Subcategories

Subcategories

Subcategories

Power Tools Spare Parts

Garden Spare Parts

Air Compressor Spare Parts

Protezione & Edilizia

Impianti & Utensili

Casa & Giardino

Makita Spare Parts for Electric Breaker HM1317C

Makita Spare Parts for Electric Breaker HM1317C

Makita Spare Parts for Electric Breaker HM1317C

Makita Spare Parts for Electric Breaker HM1317C

Makita Spare Parts for Electric Breaker HM1317C

Data sheet

Specific References

Download

Makita HM1317C Drawing

You might also like
