Fix Your Power Planer 170 mm 1806B. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of Power Planer and the respective parts of the code.
| Planer Makita 1806B | ||
| # | Part Num. | Description |
| 2 | 645006-7 | CAPACITOR X LS1013 |
| 3 | 682540-6 | CORD GUARD JN1601 |
| 4 | 911156-3 | HEAD SCREW CILIND. M4X30 |
| 6 | 911213-7 | SCREW M5X12 |
| 7 | 181151-9 | IMPUGNAT.COMPLETA |
| 8 | 911251-9 | HEAD SCREW CILIND. M5x30 |
| 9 | 156414-2 | HOUSING MOTOR 1805B |
| 10 | 911133-5 | SCREW M4X18 |
| 11 | 687031-2 | RELIEF X 3901 |
| 12 | 911103-4 | HEAD SCREW CILIND. M4X6 |
| 13 | 651034-2 | SWITCH X 5014 / 16B |
| 14 | 911226-8 | HEAD SCREW CILIND. M5X18 |
| 15 | 281007-7 | HOOK |
| 19 | 271249-1 | KNOB 62 |
| 20 | 253004-3 | FLAT WASHER 13 |
| 21 | 911156-3 | HEAD SCREW CILIND. M4X30 |
| 22 | 410149-2 | CONVOGL.TRUCCIOLI |
| 23 | 911206-4 | HEAD SCREW CILIND. M5x10 |
| 24 | 285011-8 | COVER BEARING 38 |
| 25 | 911206-4 | HEAD SCREW CILIND. M5x10 |
| 26 | 142892-2 | FRAME |
| 27 | 423094-2 | SEAL |
| 28 | 231233-8 | SPRING 24 |
| 29 | 315575-9 | BASE FRONT |
| 30 | 265484-1 | BOLT M6x18 |
| 31 | 187675-3 | ROLLER PLATE (2pcs) |
| 32 | 341376-9 | WASHER 10 |
| 33 | 263002-9 | PIN RUBBER 4 |
| 34 | 211087-9 | BALL BEARING 6200DDW |
| 35 | 911256-9 | SCREW M5x35 |
| 36 | 643650-4 | PLUG BRUSH HOLDER |
| 37 | 181044-0 | CARBON BRUSHE SET CB 153 |
| 38 | 251212-0 | SCREW M5X13 |
| 39 | 161132-9 | ROLLER |
| 40 | 341377-7 | WASHER 12 |
| 41 | 211107-9 | BEARING 6201 |
| 42 | 523025-2 | STATOR |
| 44 | 211061-7 | BALL BEARING 6000DDX 6221 |
| 45 | 681646-7 | ROND.ISOL.HM1200 / 3612BR |
| 46 | 513388-4 | ARMATURE |
| 48 | 222007-8 | PULLEY 6-23L |
| 49 | 911263-2 | HEAD SCREW CILIND. M5x40 |
| 50 | 152214-8 | ENGINE HOLDER |
| 51 | 341384-0 | WASHER 26 |
| 52 | 211106-1 | BEARING 6201 |
| 53 | 213102-5 | DUST WASHER 12 |
| 54 | 263005-3 | PIN RUBBER 6 |
| 55 | 263005-3 | PIN RUBBER 6 |
| 56 | 157024-8 | BOX ROLLER |
| 57 | 911123-8 | HEAD SCREW CILIND. M4x14 |
| 58 | 222006-0 | PULLEY 6-30 |
| 59 | 225042-5 | BELT 6-304 |
| 60 | 343301-6 | BELT COVER |
| 61 | 911206-4 | HEAD SCREW CILIND. M5x10 |
| 63 | 421490-8 | RUBBER RING 26 X 1805B |
| 500 | D-63666 | KNIVES 170mm (2pz) |
