Makita Spare Parts for Pressure Washer HW151
€22.84
VAT included
Makita Spare Parts for Pressure Washer HW151
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pressure Washer HW151.
Makita Spare Parts for Pressure Washer HW151
€22.84
VAT included
Makita Spare Parts for Pressure Washer HW151
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pressure Washer HW151.
settings
161 spare parts
description
4 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
161 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Page 3
zoom_in View exploded
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Page 4
zoom_in View exploded
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Makita Spare Parts for Pressure Washer HW151
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pressure Washer HW151.In the following table, look for the model of Pressure Washer and the respective parts of the code.
| Pressure Washer HW151 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 609580020 | CASING HW140 |
| 2 | 609360760 | ADJUSTMENT KNOB PRESSURE |
| 3 | 609580230 | LOWER CASING HW151 |
| 4 | 609320570 | SCREW HW140 M5X100 |
| 5 | 609580070 | FRONT FRAME HW140 |
| 6 | 609060200 | SCREW HW140 4,8x16 |
| 7 | 609580250 | HOLDER ACCESSORIES HW140 |
| 8 | 609580270 | FOOT HW140 |
| 9 | 609580040 | BAFFLE HW140 |
| 10 | 609580260 | BRACKET PUMP HW140 |
| 11 | 609550331 | WASHER HW151 |
| 12 | 609320350 | SCREW M6X12 HW151 |
| 13 | 609580060 | BACK FRAME HW140 |
| 14 | 609480650 | WASHER HW140 5,3x10x1 |
| 15 | 609480640 | NUT HW140 |
| 16 | 609580370 | GUARD HW140 |
| 17 | 609180080 | AXIS WHEELS HW140 |
| 18 | 609680890 | WASHER HW140 12,5X48X2,5 |
| 19 | 609580280 | WHELL 175mm HW140 |
| 20 | 609680880 | WASHER HW140 |
| 21 | 609580170 | COVER MAKITA HW140 |
| 22 | 609580050 | HOLDER ACCESSORIES HW140 |
| 23 | 609580010 | BASE HW140 |
| 24 | 609900220 | KNOB HW140 |
| 25 | 609180330 | RUBBER HW140 |
| 26 | 609180130 | TANK HW140 |
| 27 | 609000230 | FILTER HW140 |
| 28 | 609580190 | CAP HW140 |
| 29 | 609580300 | HOSE HW140 6x9x55 |
| 30 | 609050037 | SCREW HW140 6x40 |
| 31 | 609050019 | KNOB HW140 |
| 32 | 609360090 | HOLDER ACCESSORIES HW140 |
| 33 | 609580290 | HOSE HW140 6x9x45 |
| 34 | 609000110 | SCREW 3,5X16 HW140 |
| 35 | 609440190 | DETERGENT REGULATOR HW140 |
| 36 | 609600100 | HOLDER CABLE HW140 |
| 37 | 609100300 | SCREW 5X16 HW140 |
| 38 | 609589000 | BASE HW140 |
| Pag.2 | ||
| 1 | 609900120 | NIPPLE 3/8" HW140 |
| 2 | 609740290 | RING 14 HW140 |
| 3 | 609901060 | INJECTOR HW140 |
| 4 | 609800560 | RING 8,73 HW140 |
| 5 | 609080091 | SPRING HW140 |
| 6 | 609901070 | NON-RETURN VALVE HW140 |
| 7 | 609460430 | RING HW140 |
| 8 | 609344850 | HEAD HW151 |
| 9 | 609349055 | VALVE HW151 |
| 10 | 609344770 | SPACER VALVE HW151 |
| 11 | 609465720 | RING HW151 9,75X1,78 |
| 12 | 609344800 | CAP HW151 |
| 13 | 609344790 | STOP HW151 |
| 14 | 609850850 | SCREW M6X30 HW151 |
| 15 | 609620301 | CAP 1/8"G HW151 |
| 16 | 609500280 | ELBOW 3/4" GAS HW151 |
| 17 | 609342701 | SLEEVE HW151 |
| 18 | 609600180 | RING HW151 |
| 19 | 609460151 | PISTON HW151 |
| 20 | 609021900 | PISTON HW151 |
| 21 | 609080190 | RING HW151 |
| 22 | 609600180 | RING HW151 |
| 23 | 609080401 | RING HW151 |
| 24 | 609820510 | RING 10 HW140 |
| 25 | 609740290 | RING 14 HW140 |
| 26 | 609344870 | PISTON GUIDE HW151 |
| 27 | 609343450 | STOP SPRING HW151 |
| 28 | 609460190 | SPRING HW151 |
| 29 | 609980220 | STOP SPRING HW151 |
| 30 | 609500550 | PIN HW151 2,6x15 |
| 31 | 609344881 | CAP HW151 |
| 32 | 609980740 | CAP HW140 |
| 33 | 609060120 | NUT M6 HW151 |
| 34 | 609344940 | MANOMETER FITTING HW151 |
| 35 | 609040476 | MANOMETER HW151 |
| 36 | 609344890 | CAP HW151 |
| 37 | 609480480 | RING 4,48 HW140 |
| 38 | 609460180 | GASKET 15X25X5 HW151 |
| 39 | 609770260 | RING HW151 |
| 40 | 609344750 | PISTON GUIDE HW151 |
| 41 | 609260440 | SEAL WATER HW151 |
| 42 | 609344760 | SEAL OIL HW151 |
| 43 | 609344050 | BODY PUMP HW151 |
| 44 | 609260050 | BUSH HW151 |
| 45 | 609040710 | RING HW151 |
| 46 | 609344060 | BACK COVER HW151 |
| 47 | 609260780 | SCREW M5X25 HW151 |
| 48 | 609880840 | RING HW151 |
| 49 | 609343900 | CAP OIL HW151 |
| 50 | 609880111 | KEY HW151 |
| 51 | 609341070 | BALL BEARING HW151 |
| 52 | 609480890 | RING RETAINING HW140 |
| 53 | 609111120 | RING HW151 |
| 54 | 609341080 | OIL SEAL HW151 17x47x7 |
| 55 | 609340060 | ROD HW151 |
| 56 | 609340080 | PIN HW151 |
| 57 | 609340070 | HOUSING PISTON HW151 |
| 58 | 609260460 | OIL SEAL HW151 |
| 59 | 609600180 | RING HW151 |
| 60 | 609341010 | WASHER HW151 |
| 61 | 609342740 | PISTON HW151 |
| 62 | 609341020 | WASHER HW151 |
| 63 | 609850670 | SCREW M6X35 HW151 |
| 64 | 609340170 | ECCENTRIC SHAFT HW151 |
| 65 | 609120680 | RING HW140 3,69x1,78 |
| 66 | 609600180 | RING HW151 |
| 67 | 609022040 | ROD TSS HW151 |
| 68 | 609021630 | SPRING HW151 6X19X1 |
| 69 | 609021650 | WASHER HW151 |
| 70 | 609260820 | RING HW151 |
| 71 | 609344830 | FITTING HW151 |
| 72 | 609042580 | KIT TSS HW151 |
| 73 | 609560520 | SPRING HW140 |
| 74 | 609250280 | BALL HW140 |
| 75 | 609480480 | RING 4,48 HW140 |
| 76 | 609982520 | HOSE FITTING HW140 |
| 77 | 609349285 | PUMP CPL. HW151 |
| 78 | 609349204 | HEAD CPL HW151 |
| 79 | 609042579 | KIT VALVE HW151 |
| 80 | 609082130 | FILTRO ACQUA HW140/102/111 |
| 81 | 609040086 | MANICOTTO HW140 |
| 82 | 609344970 | RING 3/4" GAS HW151 |
| Pag.3 | ||
| 1 | 609260300 | FAN HW151 |
| 2 | 609340350 | OIL SEAL HW151 |
| 3 | 609260760 | SCREW M5X20 HW151 |
| 4 | 609340320 | HOUSIG FAN HW151 |
| 5 | 609340340 | BALL BEARING HW151 20x47x14 |
| 6 | 609269100 | CLAMP |
| 7 | 609340780 | GASKET HW151 |
| 8 | 609341832 | BOX CLAMP VIP |
| 9 | 609261560 | SCRE W3,9X16 HW151 |
| 10 | 609263520 | CAPACITOR HW151 |
| 11 | 609340280 | CLAMP HW140 |
| 12 | 609261560 | SCRE W3,9X16 HW151 |
| 13 | 609342040 | CAP FAN HW151 |
| 14 | 609340660 | GROMMET 10mm HW151 |
| 15 | 609340650 | GROMMET 6,5mm HW151 |
| 16 | 609340640 | CLAMP HW151 |
| 17 | 609760450 | POWER CABLE HW140 |
| 18 | 609909209 | SWITCH HW140 |
| 19 | 609029752 | BOX TSS HW151 |
| 20 | 609022200 | COLLAR HW140 |
| 21 | 609044476 | ENGINE 1,7HP HW151 |
| Pag.4 | ||
| 1 | 609580310 | HIGH PRESSURE TUBE HW151 |
| 2 | 609600260 | FITTING HW140 |
| 3 | 609820510 | RING 10 HW140 |
| 4 | 609470390 | WASHER HW140 5,5X15X1,5 |
| 5 | 609580330 | SCREW HW140 M5X40 |
| 6 | 609580150 | HOLDER SX HW140 |
| 7 | 609100300 | SCREW5X16 HW140 |
| 8 | 609480890 | RETAINING RING HW140 |
| 9 | 609600220 | FITTING HW140 |
| 10 | 609390080 | RING 11,91 HW140 |
| 11 | 609580340 | BOLT HW140 |
| 12 | 609580160 | INNER HOLDER HW140 |
| 13 | 609480640 | NUT HW140 |
| 14 | 609360230 | REEL SX HW140 |
| 15 | 609380420 | RETAINING RING HW140 |
| 16 | 609083550 | HOSE HW140 |
| 17 | 609580120 | SPACER REEL HW140 |
| 18 | 609021780 | SCREW HW140 3,9X32 |
| 19 | 609580350 | PIN LEVER REEL HW140 |
| 20 | 609580130 | HOOK HW140 |
| 21 | 609580140 | HOLDER DX HW140 |
| 22 | 609360360 | SCREW M5X10 HW140 |
| 23 | 609360150 | HANDLE HW140 |
| 24 | 609580080 | HANDLE HW140 |
| 25 | 609580180 | UPPER HANDLE HW140 |
| 26 | 609580090 | LOWER HANDLE HW140 |
| 27 | 609042581 | REEL HOSE CPL HW140 |
| 501 | 609041154 | GUN |
| 502 | 609040551 | LANCE+HEAD |
| 503 | 609040167 | LANCE+HEAD ROTOPOWER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
