Makita

Makita Spare Parts for Die Grinder GS6000

SKU: Makita GS6000
€14.77
VAT included

Makita Spare Parts for Die Grinder GS6000

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Die Grinder GS6000.
Makita Spare Parts for Die Grinder GS6000
  • Makita Spare Parts for Die Grinder GS6000
  • Makita Spare Parts for Die Grinder GS6000
Makita

Makita Spare Parts for Die Grinder GS6000

SKU: Makita GS6000 Condition: New
€14.77
VAT included

Makita Spare Parts for Die Grinder GS6000

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Die Grinder GS6000.
settings 40 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
40 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 424549-0 PROTECTION INSULATION €13.04
5
 photo_cameraImage coming soon 266046-8 SCREW M5x50 HR2010 €2.74
8
 photo_cameraImage coming soon 224583-8 EXTERNAL FLANGE €11.56
9
 photo_cameraImage coming soon 224457-3 FLANGE INTERNAL €16.59
10
 photo_cameraImage coming soon 961060-6 RETAINING RING S20 €2.50
11
 photo_cameraImage coming soon 285824-7 RETAINING BEARING €2.94
12
 photo_cameraImage coming soon 211306-3 BALL BEARING 6204DD €10.72
16
 photo_cameraImage coming soon 211256-2 BEARING X AM4024LG €12.69
17
 photo_cameraImage coming soon 257253-4 RING 17 €1.34
19
 Seal 53 for Demolition Hammer MAKITA HM1200 213656-2 Seal 53 for Demolition Hammer MAKITA HM1200 €1.46
21
 photo_cameraImage coming soon 213487-9 RING 31 X AF550H €1.79
22
 Bearing 6201DD NSK for Powertools Makita 211129-9 Bearing 6201DD NSK for Powertools Makita €8.41
23
 Retaining Ring R32 for Powertools Makita 962151-6 Retaining Ring R32 for Powertools Makita €1.43
25
 photo_cameraImage coming soon 517889-4 ARMATURE €77.49
26
 photo_cameraImage coming soon 681657-2 INSULATION WASHER GA9050R €1.79
27
 photo_cameraImage coming soon 210059-1 BEARING 6000 HR2010 €11.29
28
 photo_cameraImage coming soon 421490-8 RUBBER RING 26 X 1805B €6.36
29
 photo_cameraImage coming soon 266038-7 SCREW M5 X 70 €3.84
30
 photo_cameraImage coming soon 451480-7 BAFFLE PLATE GA9050R €1.79
31
 photo_cameraImage coming soon 523424-8 STATOR €38.86
32
 photo_cameraImage coming soon 140222-1 MOTOR HOUSING X GA9050R €14.31
33
 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 643710-2 Brushes Holder Cap for Angle Grinders Makita GA7020-GA9020-9069 €2.01
34
 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders 191957-7 Carbon Brushes CB-204 Makita for Hammers and Angle Grinders €9.15
36
 photo_cameraImage coming soon 188848-1 REAR HANDLE €8.61
37
 Capacitor for Angle Grinder Makita GA9020 645088-9 Capacitor for Angle Grinder Makita GA9020 €1.50
38
 photo_cameraImage coming soon 688131-1 FILTER LINE X MT240 €1.40
39
 Switch for Angle Grinder Makita GA9020 2200 W 650102-8 Switch for Angle Grinder Makita GA9020 2200 W €31.96
40
 Srew M4X14 for Hammers Makita HR4001C-HR4010C 266192-7 Srew M4X14 for Hammers Makita HR4001C-HR4010C €1.46
41
 photo_cameraImage coming soon 687169-3 STRAIN RELIEF HP1620 €1.46
42
 Cord Guard JN1601 for Angle Grinder Makita 9015B 682540-6 Cord Guard JN1601 for Angle Grinder Makita 9015B €2.72
45
 photo_cameraImage coming soon 265999-8 4X25 SCREW €1.47
46
 photo_cameraImage coming soon 346655-0 SIDE PROTECTION ANT. €6.69
47
 photo_cameraImage coming soon 924316-8 BUTTERFLY SCREW M6x15 €1.34
48
 photo_cameraImage coming soon 942151-2 WASHER 6 €3.66
49
 photo_cameraImage coming soon 941151-9 WASHER 6 X HM1303 €3.66
53
 photo_cameraImage coming soon 922422-3 HEXAGON BOLT M8x16 €1.42
54
 photo_cameraImage coming soon 165715-7 SIDE PROTECTION POST. €12.92
55
 photo_cameraImage coming soon 213017-6 RING 6 AN621 €1.79
56
 photo_cameraImage coming soon 346656-8 COLLAR €1.34
57
 photo_cameraImage coming soon 252105-4 NUT M8X13 €1.29

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Die Grinder GS6000

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Die Grinder GS6000.

In the following table, look for the model of the Die Grinder and the respective parts of the code.
Makita GS6000

Die Grinder GS6000
# Part Num. Description
1 424549-0 PROTECTION INSULATION
3 123200-6 CAP WHEEL
5 266046-8 SCREW M5x50 HR 2010
6 256180-2 PIN 3
8 224583-8 EXTERNAL FLANGE
9 224457-3 FLANGE INTERNAL
10 961060-6 RETAINING RING S20
11 285824-7 RETAINING BEARING
12 211306-3 BALL BEARING 6204DD
13 318961-3 GEAR BOX
14 268161-4 PIN 5 X TD020D
15 326252-8 SHAFT 5
16 211256-2 BEARING X AM4024LG
17 257253-4 RING 17
18 227766-9 GEAR 47
19 213656-2 SEAL 53 X HM1200
20 318962-1 COVER GEAR BOX
21 213487-9 RING 31 X AF550H
22 211129-9 BALL BEARING NSK 6201DD
23 962151-6 RETAINING RING R32
24 240143-8 FAN 80
25 517889-4 ARMATURE
26 681657-2 INSULATING WASHER X GA9050R
27 210059-1 BEARING 6000 HR2010
28 421490-8 RUBBER RING 26 X 1805B
29 266038-7 SCREW M5 X 70 HP2030
30 451480-7 BAFFLE GA9050R
31 523424-8 STATOR
32 140222-1 CASING MOT. X GA9050R
33 643710-2 PLUG BRUSH XHM1500
34 191957-7 CARBON BRUSHES CB-204 (201.202)
36 188848-1 REAR HANDLE
37 645088-9 CONDENSER GA9020
38 688131-1 FILTER LINE X MT240
39 650102-8 SWITCH TG08-1200-011
40 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
41 687169-3 CLAMP cable tie HP1620
42 682540-6 SLEEVE JN1601
45 265999-8 SCREW 4X25
46 346655-0 SIDE PROTECTION ANT.
47 924316-8 BUTTERFLY SCREW M6x15
48 942151-2 WASHER 6 4101R
49 941151-9 WASHER 6 X HM1303
50 213005-3 RING 5
51 922452-4 SCREW M8x30
52 951125-2 ELASTIC PIN 4-32
53 922422-3 HEXAGON BOLT M8x16
54 165715-7 SIDE PROTECTION POST.
55 213017-6 RING 6 X AN621
56 346656-8 COLLAR
57 252105-4 NUT M8X13

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita GS6000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita GS6000

Diagram Makita GS6000

Download (275.77KB)
