Makita

Makita Spare Parts for Mixer UT1401

SKU: Makita UT1401
€4.42
VAT included

Makita Spare Parts for Mixer UT1401

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UT1401.

- Two speed
- Soft start
- Constant speed under load
- Double handle
Makita Spare Parts for Mixer UT1401
  • Makita Spare Parts for Mixer UT1401
  • Makita Spare Parts for Mixer UT1401
Makita

Makita Spare Parts for Mixer UT1401

SKU: Makita UT1401 Condition: New
€4.42
VAT included

Makita Spare Parts for Mixer UT1401

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UT1401.

- Two speed
- Soft start
- Constant speed under load
- Double handle
settings 55 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
55 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 80900093 BACK COVER €15.11
2
 photo_cameraImage coming soon 80201267 SCREW 4,8X45 €1.67
3
 photo_cameraImage coming soon 7132A100 ARMATURE €154.61
4
 photo_cameraImage coming soon 80410011 BEARING 608 2Z €10.01
5
 photo_cameraImage coming soon 80201333 RING 28 / 1.2 €1.67
6
 photo_cameraImage coming soon 80201196 BRUSHES HOLDER €17.09
7
 Carbon Brushes for Mixers UT120-1400-1401 7132A22S Carbon Brushes for Mixers UT120-1400-1401 €22.00
8
 photo_cameraImage coming soon 80201385 WASHER B4 €1.67
9
 photo_cameraImage coming soon 80201180 SCREW M4X12 €1.67
11
 photo_cameraImage coming soon 80201320 RING 11 / 1.0 €1.67
12
 photo_cameraImage coming soon 83000036 RING 22X2,5 €1.38
14
 photo_cameraImage coming soon 80410031 BEARING 6001 2Z €18.56
15
 photo_cameraImage coming soon 77M3161U HOLDER €88.81
16
 photo_cameraImage coming soon 77M3140U GEAR BOX €72.52
17
 photo_cameraImage coming soon 7132A470 GEAR €39.46
18
 photo_cameraImage coming soon 7132H500 POST 11/17 Z €64.96
20
 photo_cameraImage coming soon 80201442 SCREW 50X40 €2.12
21
 photo_cameraImage coming soon 80410061 BEARING 6005 2RS €28.44
22
 photo_cameraImage coming soon 77M31420 POST THREAD €64.96
23
 photo_cameraImage coming soon 80200601 KEY €1.38
24
 photo_cameraImage coming soon 80410130 BEARING 6203 2RS €25.15
25
 photo_cameraImage coming soon 71323430 GEAR €72.52
26
 photo_cameraImage coming soon 80200504 WASHER 15 / 22X0,2 €1.38
27
 photo_cameraImage coming soon 80201322 RING 15/1 €1.38
30
 photo_cameraImage coming soon 71223460 POST 13Z €60.02
31
 photo_cameraImage coming soon 80200602 KEY A5X5X28 €3.69
32
 photo_cameraImage coming soon 7132H440 GEAR 34 / 40Z €53.44
33
 photo_cameraImage coming soon 80900403 HOUSING MOTOR €60.02
34
 photo_cameraImage coming soon 7132A150 STATOR €109.37
35
 photo_cameraImage coming soon 80201266 SCREW 3,9X60 €2.12
36
 photo_cameraImage coming soon 80900286 BAFFLE €6.89
37
 photo_cameraImage coming soon 80201277 TX SCREW 5X20 €1.38
38
 photo_cameraImage coming soon 77M31590 HANDLE €79.76
39
 photo_cameraImage coming soon 83000051 RUBBER HV1305 €3.69
40
 photo_cameraImage coming soon 80900000 STOPPER €5.00
41
 photo_cameraImage coming soon 80900098 GRIP INT. €28.26
42
 photo_cameraImage coming soon 83000004 SLEEVE €5.61
43
 photo_cameraImage coming soon 80600060 POWER CABLE €30.89
44
 photo_cameraImage coming soon 80201270 SCREW 4,2X13 €1.67
45
 photo_cameraImage coming soon 85000020 CLAMP FIXED CABLE €2.58
46
 photo_cameraImage coming soon 80600510 SWITCH €53.75
47
 photo_cameraImage coming soon 80600306 DISTANCE €1.67
48
 photo_cameraImage coming soon 80500010 CAPACITOR €12.28
51
 photo_cameraImage coming soon 80600072 CABLE €8.44
52
 photo_cameraImage coming soon 80200582 PIN 4X12 €1.67
53
 photo_cameraImage coming soon 80201280 SCREW 4,8X22 €1.67
54
 photo_cameraImage coming soon 80201302 WASHER 5 €1.67
55
 photo_cameraImage coming soon 80201103 SCREW M5x14 €1.67
56
 photo_cameraImage coming soon 82000507 SEAL €5.90
57
 photo_cameraImage coming soon 80900119 COVER €4.58
58
 photo_cameraImage coming soon 7132H540 SHIFT LEVER €43.41
60
 photo_cameraImage coming soon 80201340 RING 26 / 1.2 €1.38
61
 photo_cameraImage coming soon 80430029 WHEAT €4.09
62
 photo_cameraImage coming soon 7132H545 STUD €11.66
63
 photo_cameraImage coming soon 80200577 PIN 3m6X10 €1.38

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Mixer UT1401

MAKITA Original spare parts

 at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UT1401.

- Two speed
- Soft start
- Constant speed under load
- Double handle

In the following table, look for the model of the Mixers and the respective parts of the code.
Makita UT1401

Mixer Makita UT1401
# Part Num. Description
1 80900093 BACK COVER
2 80201267 SCREW 4,8X45
3 7132A100 ARMATURE
4 80410011 BEARING 608 2Z
5 80201333 RING 28 / 1.2
6 80201196 BRUSHES HOLDER
7 7132A22S CARBON BRUSHES X DBM080 (2PCS)
8 80201385 WASHER B4
9 80201180 SCREW M4X12
11 80201320 RING 11 / 1.0
12 83000036 RING 22X2,5
14 80410031 BEARING 6001 2Z
15 77M3161U HOLDER
16 77M3140U GEAR BOX
17 7132A470 GEAR
18 7132H500 POST 11/17 Z
20 80201442 SCREW 50X40
21 80410061 BEARING 6005 2RS
22 77M31420 POST THREAD
23 80200601 KEY
24 80410130 BEARING 6203 2RS
25 71323430 GEAR
26 80200504 WASHER 15 / 22X0,2
27 80201322 RING 15/1
30 71223460 POST 13Z
31 80200602 KEY A5X5X28
32 7132H440 GEAR 34 / 40Z
33 80900403 HOUSING MOTOR
34 7132A150 STATOR
35 80201266 SCREW 3,9X60
36 80900286 BAFFLE
37 80201277 TX SCREW 5X20
38 77M31590 HANDLE
39 83000051 RUBBER HV1305
40 80900000 STOPPER
41 80900098 GRIP INT.
42 83000004 SLEEVE
43 80600060 POWER CABLE
44 80201270 SCREW 4,2X13
45 85000020 CLAMP FIXED CABLE
46 80600510 SWITCH
47 80600306 WASHER
48 80500010 CAPACITOR
51 80600072 CABLE
52 80200582 PIN 4X12
53 80201280 SCREW 4,8X22
54 80201302 WASHER 5
55 80201103 SCREW M5x14
56 82000507 SEAL
57 80900119 COVER
58 7132H540 SHIFT LEVER
60 80201340 RING 26 / 1.2
61 80430029 WHEAT
62 7132H545 STUD
63 80200577 PIN 3m6X10

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita UT1401
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita UT1401

Diagram Makita UT1401

Download (285.98KB)
