Makita

Makita Spare Parts for Mixer UT120

SKU: Makita UT120
€5.01
VAT included

Makita Spare Parts for Mixer UT120

Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Mixer UT120.

Fix Your Power Tool. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.

Makita Spare Parts for Mixer UT120
  • Makita Spare Parts for Mixer UT120
  • Makita Spare Parts for Mixer UT120
Makita

Makita Spare Parts for Mixer UT120

SKU: Makita UT120 Condition: New
€5.01
VAT included

Makita Spare Parts for Mixer UT120

Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Mixer UT120.

Fix Your Power Tool. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 48 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
48 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon EE7132A240 MOTOR HOUSING COVER UT120 €11.04
2
 photo_cameraImage coming soon EE80201267 SCREW 4.8 X 45 X DBM080 €1.93
3
 photo_cameraImage coming soon EE7731B100 ARMATURE X UT120 €222.29
4
 photo_cameraImage coming soon 210024-0 BEARING HR5001C €5.08
5
 photo_cameraImage coming soon EE80201333 RETAINING RING 28 X DBM080 €1.22
6
 photo_cameraImage coming soon EE80201196 HOLDERS X DBM080 €11.04
7
 Carbon Brushes for Mixers UT120-1400-1401 7132A22S Carbon Brushes for Mixers UT120-1400-1401 €22.00
8
 photo_cameraImage coming soon EE80201385 WASHER X DBM080 €1.22
9
 photo_cameraImage coming soon EE80201180 SCREW 4 X 12 X DBM080 €1.22
11
 photo_cameraImage coming soon EE80201305 LOCKING RING 10 X UT120 €1.22
12
 photo_cameraImage coming soon EE83000036 LOOP 22 X 2.5 X DBM080 €1.22
13
 photo_cameraImage coming soon EE80701005 MAGNET SLEEVE UT120 €11.04
14
 photo_cameraImage coming soon 211142-7 BEARING 6001LLB X GD0800C €11.39
15
 photo_cameraImage coming soon EE77318610 END SHIELD OF GEARING UT120 €76.80
16
 photo_cameraImage coming soon EE77318400 GEAR HOUSING COMPLETE UT120 €93.36
17
 photo_cameraImage coming soon EE74010470 INTERMEDIATE WHEEL UT120 €28.54
18
 photo_cameraImage coming soon EE7731C490 PINION SHAFT UT120 €45.34
19
 photo_cameraImage coming soon EE80201252 SCREW 2.9 X 13 X DBM080 €1.22
20
 photo_cameraImage coming soon EE77314187 CONNECTING ROD UT120 €3.70
21
 photo_cameraImage coming soon 211251-2 BEARING 6003LLB X DA6301 €14.49
22
 photo_cameraImage coming soon EE7731C420 PWORK SPINDLE UT120 €50.78
24
 photo_cameraImage coming soon 211256-2 BEARING X AM4024LG €12.69
25
 photo_cameraImage coming soon EE7731C430 SPINDLE WHEEL UT120 €62.37
26
 photo_cameraImage coming soon EE80200507 WASHER 17 X UT120 €1.22
30
 Potentiometer Handle for Mixer Makita UT120 EE80901001 Potentiometer Handle for Mixer Makita UT120 €6.55
31
 Potentiometer Holder for Mixer Makita UT120 EE80901005 Potentiometer Holder for Mixer Makita UT120 €2.63
32
 photo_cameraImage coming soon EE80601132 CONTROLLER 240V UT120 €141.86
33
 photo_cameraImage coming soon EE80900170 MOTOR HOUSING UT120 €40.84
34
 photo_cameraImage coming soon EE7731B150 STATOR - FIELD UT120 €76.80
35
 photo_cameraImage coming soon EE80201266 SCREW 3.9 X 60 X UT120 €1.93
36
 photo_cameraImage coming soon EE7132A140 BAFFLE X UT120 €5.01
37
 photo_cameraImage coming soon EE80200051 HANDLE UT120 €69.71
38
 photo_cameraImage coming soon EE80201303 WASHER 6 X UT120 €1.22
39
 photo_cameraImage coming soon EE80201209 SCREW M 6 X 12 X UT120 €1.22
41
 photo_cameraImage coming soon EE80900101 HANDLE COVER UT120 €16.72
42
 photo_cameraImage coming soon EE83000004 SAVE CABLE X DBM080 €3.70
44
 photo_cameraImage coming soon EE80201270 SCREW 4.2 X 13 X DBM080 €1.22
45
 photo_cameraImage coming soon EE71540330 CLAMP Cable tie X DBM080 €1.93
46
 Potentiometer for Mixer Makita UT120 EE80500020 Potentiometer for Mixer Makita UT120 €16.64
47
 Switch for Mixer Makita UT120 EE80600507 Switch for Mixer Makita UT120 €17.00
48
 photo_cameraImage coming soon EE80500010 CAPACITOR X UT120 €7.49
49
 photo_cameraImage coming soon EE80201280 SCREW 4.8 X 22 X UT120 €1.22
50
 photo_cameraImage coming soon EE80201271 SCREW 4.2 X 16 X UT120 €1.22
51
 photo_cameraImage coming soon EE77316186 CONNECTING CORD B UT120 €5.01
52
 photo_cameraImage coming soon EE80200582 PIN 4 X DBM080 €1.22
53
 photo_cameraImage coming soon EE80201284 SCREW 4.8 X 55 X UT120 €1.93
54
 photo_cameraImage coming soon EE77324620 GASKET UT120 €2.99
55
 photo_cameraImage coming soon 212075-9 NEEDLE BEARING 1010 HR4010C €3.70

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Mixer UT120

Fix Your Mixer UT120. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Mixers and the respective parts of the code.
Makita UT120

Mixer Makita UT120
# Part Num. Description
1 EE7132A240 MOTOR HOUSING COVER UT120
2 EE80201267 SCREW 4.8 X 45 X DBM080
3 EE7731B100 ARMATURE X UT120
4 210024-0 BALL BEARING X HR5001C
5 EE80201333 LOCKING RING 28 X DBM080
6 EE80201196 BRUSH HOLDER DBM080
7 7132A22S CARBON BRUSHE SET DBM080 (2PCS)
8 EE80201385 WASHER X DBM080
9 EE80201180 SCREW 4 X 12 X DBM080
11 EE80201305 LOCKING RING 10 X UT120
12 EE83000036 O-RING 22 X 2.5 X DBM080
13 EE80701005 MAGNET SLEEVE UT120
14 211142-7 BALL BEARING 6001LLB X GD0800C
15 EE77318610 END SHIELD OF GEARING UT120
16 EE77318400 GEAR HOUSING COMPLETE UT120
17 EE74010470 INTERMEDIATE WHEEL UT120
18 EE7731C490 PINION SHAFT UT120
19 EE80201252 SCREW 2.9 X 13 X DBM080
20 EE77314187 CONNECTING ROD UT120
21 211251-2 BALL BEARING 6003LLB X DA6301
22 EE7731C420 PWORK SPINDLE UT120
24 211256-2 BALL BEARING X AM4024LG
25 EE7731C430 SPINDLE WHEEL UT120
26 EE80200507 WASHER 17 X UT120
30 EE80901001 HANDLE UT120
31 EE80901005 COVER PLATE UT120
32 EE80601132 CONTROLLER 240V UT120
33 EE80900170 MOTOR HOUSING UT120
34 EE7731B150 STATOR - FIELD UT120
35 EE80201266 SCREW 3.9 X 60 X UT120
36 EE7132A140 BAFFLE X UT120
37 EE80200051 HANDLE UT120
38 EE80201303 WASHER 6 X UT120
39 EE80201209 SCREW M 6 X 12 X UT120
41 EE80900101 HANDLE COVER UT120
42 EE83000004 CORD GUARD DBM080
44 EE80201270 SCREW 4.2 X 13 X DBM080
45 EE71540330 STRAIN RELIEF DBM080
46 EE80500020 POTENTIOMETER X UT120
47 EE80600507 SWITCH X UT120
48 EE80500010 CAPACITOR X UT120
49 EE80201280 SCREW 4.8 X 22 X UT120
50 EE80201271 SCREW 4.2 X 16 X UT120
51 EE77316186 CONNECTING CORD B UT120
52 EE80200582 PIN 4 X DBM080
53 EE80201284 SCREW 4.8 X 55 X UT120
54 EE77324620 GASKET UT120
55 212075-9 NEEDLE BEARING 1010 HR4010C
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita UT120
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Makita UT120

Diagram Makita UT120

Download (332.91KB)
