Makita

Makita Electric Trimmer UR3502 Parts

SKU: Makita UR3502
€5.43
VAT included

Makita Spare Parts for Electric Trimmer UR3502

Repair your Electric Trimmer UR3502!
Guaranteed original spare parts and discounted prices await you. Ensure optimal performance for your tool with authentic and long-lasting parts. Don't compromise on quality, choose reliability for your Makita!
Makita Electric Trimmer UR3502 Parts
  • Makita Electric Trimmer UR3502 Parts
  • Makita Electric Trimmer UR3502 Parts Drawing
Makita

Makita Electric Trimmer UR3502 Parts

SKU: Makita UR3502 Condition: New
€5.43
VAT included

Makita Spare Parts for Electric Trimmer UR3502

Repair your Electric Trimmer UR3502!
Guaranteed original spare parts and discounted prices await you. Ensure optimal performance for your tool with authentic and long-lasting parts. Don't compromise on quality, choose reliability for your Makita!
settings 100 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
100 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon YA00000497 POWER CABLE UR3502 €5.28
2
 photo_cameraImage coming soon YA00000516 CORD GUARD UR3502 €1.43
3
 photo_cameraImage coming soon YA00000660 MOTOR CASE FOR UR3502 €46.15
4
 photo_cameraImage coming soon YA00000562 FAN HOUSING LEFT UR3502 €2.14
5
 photo_cameraImage coming soon YA00000514 RUBBER X UR3502 €1.43
6
 photo_cameraImage coming soon YA00000618 SCREW 4x14 €1.43
7
 photo_cameraImage coming soon YA00000547 CABLE PRESS BOARD UR3502 €1.43
8
 photo_cameraImage coming soon YA00000501 TERMINAL SET UR3502 €1.43
9
 photo_cameraImage coming soon YA00000619 PCB CONTOL BOARD UR3502 €46.15
10
 photo_cameraImage coming soon YA00000499 INDUCTANCE X UR3502 €5.28
11
 photo_cameraImage coming soon YA00000554 SWITCH LEVER €1.43
12
 photo_cameraImage coming soon YA00000513 SPRING €1.43
13
 photo_cameraImage coming soon YA00000498 CAPACITOR X UR3502 €1.43
14
 photo_cameraImage coming soon YA00000555 SWITCH X UR3502 €3.95
15
 photo_cameraImage coming soon YA00000539 SPACER €1.43
16
 photo_cameraImage coming soon YA00000525 BUTTON €1.43
17
 photo_cameraImage coming soon YA00000511 COMPRESSION SPRING €1.43
18
 photo_cameraImage coming soon YA00000620 FRONT HANDLE CPL. UR3502 €17.13
19
 photo_cameraImage coming soon YA00000621 SCREW €1.43
20
 photo_cameraImage coming soon YA00000564 FRONT HANDLE UR3502 €13.06
21
 photo_cameraImage coming soon YA00000563 HANDLE SUPPORT €4.56
22
 photo_cameraImage coming soon YA00000622 NUT M5 €1.43
23
 photo_cameraImage coming soon YA00000623 INSULATING PLATE €2.14
24
 photo_cameraImage coming soon YA00000624 SCREW M6X20 €1.43
25
 photo_cameraImage coming soon YA00000541 SHOULD BELT RING €2.76
26
 photo_cameraImage coming soon YA00000521 RUBBER SLEEVE €5.28
27
 photo_cameraImage coming soon YA00000519 SPONGE SLEEVE €2.14
28
 photo_cameraImage coming soon YA00000625 SCREW €1.43
29
 photo_cameraImage coming soon YA00000560 REAR COVER UR3502 €3.95
30
 photo_cameraImage coming soon YA00000626 MOTOR €179.92
31
 photo_cameraImage coming soon YA00000627 NUT M6 €1.43
32
 photo_cameraImage coming soon YA00000507 FAN UR3502 €2.14
33
 photo_cameraImage coming soon YA00000538 STATOR SCREW €1.43
34
 photo_cameraImage coming soon YA00000523 ELASTIC WASHER €1.43
35
 photo_cameraImage coming soon YA00000524 WASHER €1.43
36
 photo_cameraImage coming soon YA00000531 SLEEVE €1.43
37
 photo_cameraImage coming soon YA00000526 REAR SUPPORT €5.28
38
 photo_cameraImage coming soon YA00000505 UR3502 STATOR €41.57
39
 photo_cameraImage coming soon YA00000431 BEARING 608 €3.23
40
 photo_cameraImage coming soon YA00000628 ARMATURE UR3502 €87.61
41
 photo_cameraImage coming soon YA00000430 BEARING €5.28
42
 photo_cameraImage coming soon YA00000629 UR3502 FRONT SUPPORT €19.53
43
 photo_cameraImage coming soon YA00000489 CARBON BRUSCH ASS'Y €7.79
44
 Makita UR3502 Carbon Brush Set YA00001194 Makita UR3502 Carbon Brush Set €4.06
45
 photo_cameraImage coming soon YA00000502 BRUSH HOLDER UR3502 €1.43
46
 photo_cameraImage coming soon YA00000503 BRUSH HOLDER SUPPORT UR3502 €1.43
47
 photo_cameraImage coming soon YA00000630 SCREW M4X12 €1.43
48
 photo_cameraImage coming soon YA00000483 SHAFT €33.68
50
 photo_cameraImage coming soon YA00000550 UR3502 TRANSMISSION SHAFT €14.76
51
 photo_cameraImage coming soon YA00000481 ROD UR3502 €57.65
52
 photo_cameraImage coming soon YA00000528 SLEEVE €1.43
53
 photo_cameraImage coming soon YA00000553 ROD CONNECTOR €3.95
54
 photo_cameraImage coming soon YA00000480 UR3502 GEAR BOX €87.61
55
 photo_cameraImage coming soon YA00000468 RETAINER RING UR3502 €1.43
56
 photo_cameraImage coming soon YA00000434 RETAINER RING C €1.43
57
 photo_cameraImage coming soon YA00000471 BEARING 6900 €4.56
58
 photo_cameraImage coming soon YA00000440 WASHER €1.43
59
 photo_cameraImage coming soon YA00000442 GEAR €10.18
60
 photo_cameraImage coming soon YA00000548 UR3502 GEAR BOX €13.06
61
 photo_cameraImage coming soon YA00000460 SCREW €1.43
63
 photo_cameraImage coming soon YA00000542 WASHER €1.43
64
 photo_cameraImage coming soon YA00000470 BEARING 629Z €5.28
65
 photo_cameraImage coming soon YA00000443 GEAR €10.18
66
 photo_cameraImage coming soon YA00000465 WOODRUUF KEY €1.43
67
 photo_cameraImage coming soon YA00000552 SHAFT €10.18
68
 photo_cameraImage coming soon YA00000469 BEARING 6002-2RS €6.11
69
 photo_cameraImage coming soon YA00000467 RING €1.43
70
 photo_cameraImage coming soon YA00000515 SLEEVE €1.43
71
 photo_cameraImage coming soon YA00000441 OIL SEAL €2.14
73
 photo_cameraImage coming soon YA00000533 SEAL €1.43
74
 photo_cameraImage coming soon YA00000459 SCREW €1.43
75
 photo_cameraImage coming soon YA00000458 SCREW €1.43
76
 photo_cameraImage coming soon YA00000461 NUT €1.43
77
 photo_cameraImage coming soon YA00000446 SCREW €1.43
78
 photo_cameraImage coming soon YA00000546 PROTECTION €14.76
79
 photo_cameraImage coming soon YA00000631 SCREW €1.43
80
 photo_cameraImage coming soon YA00000632 SCREW €1.43
81
 photo_cameraImage coming soon YA00000540 FLANGE €6.81
82
 Dolmar ET-110C Nylon Head YA00000681 Dolmar ET-110C Nylon Head €17.41
83
 photo_cameraImage coming soon YA00000477 UR3502 HEAD COVER €8.74
84
 photo_cameraImage coming soon YA00000556 UR3502 HEAD COVER €7.79
85
 photo_cameraImage coming soon YA00000532 BUSH X NYLON WIRE €1.43
86
 photo_cameraImage coming soon YA00000535 NUT €3.23
87
 photo_cameraImage coming soon YA00000466 SPRING €1.43
88
 photo_cameraImage coming soon YA00000510 GASKET €1.43
89
 photo_cameraImage coming soon YA00000679 NYLON WIRE REEL €7.79
90
 photo_cameraImage coming soon YA00000635 NYLON LINE €2.76
91
 photo_cameraImage coming soon YA00000680 HEAD BASE €4.56
92
 photo_cameraImage coming soon YA00000636 CPL PROTECTION €13.06
93
 photo_cameraImage coming soon YA00000637 SCREW €1.43
94
 photo_cameraImage coming soon YA00000638 SCREW €1.43
95
 photo_cameraImage coming soon YA00000545 PROTECTION €8.74
96
 photo_cameraImage coming soon YA00000439 BLADE €2.76
97
 photo_cameraImage coming soon YA00000622 NUT M5 €1.43
98
 photo_cameraImage coming soon YA00000472 BLADE PROTECTION €1.43
100
 photo_cameraImage coming soon YA00000639 SUSPENDER €7.79
103
 photo_cameraImage coming soon YA00000640 SCREW M5X10 €1.43
104
 photo_cameraImage coming soon YA00000641 SCREW €1.43
105
 photo_cameraImage coming soon YA00000656 SCREW ST4.2 €1.43
106
 photo_cameraImage coming soon YA00000660 MOTOR CASE FOR UR3502 €46.15
107
 photo_cameraImage coming soon YA00000561 HOUSING RIGHT FAN €2.14
108
 photo_cameraImage coming soon YA00000514 RUBBER X UR3502 €1.43
109
 photo_cameraImage coming soon YA00000630 SCREW M4X12 €1.43
110
 photo_cameraImage coming soon YA00000657 SCREW M3 €1.43

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Spare Parts for Electric Trimmer UR3502

Makita genuine spare parts replacement parts for to repair Electric Trimmer UR3502.

In the following table, look for the model of Trimmer and the respective parts of the code.
Makita UR3502

UR3502 - ELECTRIC GRASS TRIMMER
# Part Num Description
1 YA00000497 POWER CABLE UR3502
2 YA00000516 CABLE SLEEVE UR3502
3 YA00000660 MOTOR CASE FOR UR3502
4 YA00000562 LEFT FAN CASE FOR UR3502
5 YA00000514 RUBBER FOR UR3502
6 YA00000618 4x14 SCREW
7 YA00000547 CABLE CLAMP UR3502
8 YA00000501 TERMINAL UR3502
9 YA00000619 PRINTED CIRCUIT BOARD UR3502
10 YA00000499 INDUCTION FOR UR3502
11 YA00000554 SWITCH LEVER
12 YA00000513 SPRING
13 YA00000498 CAPACITATOR FOR UR3502
14 YA00000555 SWITCH FOR UR3502
15 YA00000539 SPACER
16 YA00000525 BUTTON
17 YA00000511 COMPRESSION SPRING
18 YA00000620 FRONT HANDLE COMPLETE UR3502
19 YA00000621 SCREW
20 YA00000564 UR3502 FRONT HANDLE
21 YA00000563 HANDLE SUPPORT
22 YA00000622 M5 NUT
23 YA00000623 INSULATION PLATE
24 YA00000624 M6X20 SCREW
25 YA00000541 BRACE RING
26 YA00000521 RUBBER SLEEVE
27 YA00000519 SPONGE SLEEVE
28 YA00000625 SCREW
29 YA00000560 UR3502 REAR COVER
30 YA00000626 UR3502 MOTOR ASSEMBLY
31 YA00000627 M6 NUT
32 YA00000507 UR3502 FAN
33 YA00000538 STATOR SCREW
34 YA00000523 SPRING WASHER
35 YA00000524 WASHER
36 YA00000531 SOCKET
37 YA00000526 REAR SUPPORT
38 YA00000505 UR3502 STATOR
39 YA00000431 608 BEARING
40 YA00000628 UR3502 ARMATURE
41 YA00000430 BEARING
42 YA00000629 UR3502 FRONT SUPPORT
43 YA00000489 UR3502 BRUSH ASSEMBLY
44 YA00001194 CARBON BRUSHE SET PACK 2PCS
45 YA00000502 BRUSH HOLDER UR3502
46 YA00000503 BRUSH HOLDER SUPPORT UR3502
47 YA00000630 M4X12 SCREW
48 YA00000483 SHAFT
50 YA00000550 DRIVE SHAFT UR3502
51 YA00000481 ROD UR3502
52 YA00000528 SOCKET
53 YA00000553 ROD CONNECTOR
54 YA00000480 GEAR BOX UR3502
55 YA00000468 RETAINING RING UR3502
56 YA00000434 RETAINING RING C
57 YA00000471 BEARING 6900
58 YA00000440 WASHER
59 YA00000442 GEAR
60 YA00000548 GEAR BOX UR3502
61 YA00000460 SCREW
63 YA00000542 WASHER
64 YA00000470 BEARING 629Z
65 YA00000443 GEAR
66 YA00000465 KEY
67 YA00000552 SHAFT
68 YA00000469 BEARING 6002-2RS
69 YA00000467 RING
70 YA00000515 SOCKET
71 YA00000441 OIL SEAL
73 YA00000533 GASKET
74 YA00000459 SCREW
75 YA00000458 SCREW
76 YA00000461 NUT SELF-LOCKING
77 YA00000446 SCREW
78 YA00000546 GUARD
79 YA00000631 SCREW
80 YA00000632 SCREW
81 YA00000540 FLANGE
82 YA00000681 NYLON HEAD ET-110C UR3502
83 YA00000477 HEAD COVER UR3502
84 YA00000556 HEAD COVER UR3502
85 YA00000532 NYLON WIRE BUSHING
86 YA00000535 NUT
87 YA00000466 SPRING
88 YA00000510 SEAL
89 YA00000679 NYLON WIRE SPOOL
90 YA00000635 NYLON WIRE
91 YA00000680 HEAD BASE
92 YA00000636 CPL PROTECTION
93 YA00000637 SCREW
94 YA00000638 SCREW
95 YA00000545 GUARD
96 YA00000439 BLADE
97 YA00000622 M5 NUT
98 YA00000472 BLADE PROTECTION
100 YA00000639 STRAP
101 YA00000473
102 YA00000438 Key
103 YA00000640 M5X10 SCREW
104 YA00000641 SCREW
105 YA00000656 ST4.2 SCREW
106 YA00000660 MOTOR CASING FOR UR3502
107 YA00000561 RH FAN CASING
108 YA00000514 RUBBER FOR UR3502
109 YA00000630 M4X12 SCREW
110 YA00000657 M3 SCREW
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita UR3502
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita UR3502 Parts Drawing

Makita UR3502 Parts Drawing

Download (481.32KB)

You might also like

Makita UR3502 Carbon Brush Set
Makita SKU: YA00001194
Makita UR3502 Carbon Brush Set
Makita UR3502 Carbon Brush Set Genuine part Makita, Carbon Brushes Pack 2 Pcs for Elecric Grass Trimmer UR3502. Part for the following products: -  UR3502 ELECTRIC GRASS TRIMMER - Code : YA00001194
Usually Ships in: 7/10 Business Days Approx. €4.06
Details
Dolmar ET-110C Nylon Head
Makita SKU: YA00000681
Dolmar ET-110C Nylon Head
Dolmar Nylon Head for Trimmer ET-110C Genuine part Dolmar, Nylon Head for Electric Grass Trimmer ET-110C. Part for the following products: -  Trimmer Dolmar ET-110C -  Trimmer Makita UR3502 - Code : YA00000681
Last items in stock €17.41
Details
Comments (0)
