Makita Cordless Chainsaw UC002G Parts

Name: Makita Cordless Chainsaw UC002G Parts
Brand: Makita
SKU: Makita UC002G
Availability: InStock

SKU: Makita UC002G

€5.43

VAT included

Makita Cordless Chainsaw UC002G Spare Parts

Fix Your Cordless Chainsaw UC002G. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee

84 spare parts

Page 1 View exploded Usually Ships in: 7/10 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
A09	Image coming soon	191B36-3 BATTERY BL4025 SET	€228.68
A11	Image coming soon	191C10-7 INTERCHANGEABLE ADAPTER	€71.77
A08	Image coming soon	191E07-8 DC40RA FAST CHARGER DC40RA 40V MAX	€178.44
A01	Image coming soon	191G14-3 GUIDE BAR 10 SET	€22.27
A04-1	Image coming soon	191H00-0 CHAIN LOOP 90PX-1,1MM 3/8"40 LINKS	€14.84
F02	Image coming soon	191H00-0 CHAIN LOOP 90PX-1,1MM 3/8"40 LINKS	€14.84
F03	Image coming soon	191H08-4 250 mm (10") Saw Chain, 3/8" LP, .050"	€20.90
A12	Image coming soon	191J81-6 KIT ENERGY 40VmaxBL4025 2,5Ax2+DC40RA	€531.52
A13	Image coming soon	191J97-1 KIT ENERGY 40VmaxBL4040 4Ax2+DC40RA	€656.34
F04	Image coming soon	191V90-7 SPROCKET 6 SET	€9.89
F07	Image coming soon	195923-6 ROUND FILE 4.5 SET	€25.01
F09	Image coming soon	198457-8 CHAIN EDGER SET	€24.86
A04	Image coming soon	199075-5 SAW CHAIN SET	€26.80
F10	Image coming soon	199075-5 SAW CHAIN SET	€26.80
C10	Image coming soon	263005-3 PIN RUBBER 6	€1.32
A02-1	Image coming soon	458501-6 GUIDE BAR CASE	€6.78
A02	Image coming soon	458501-6 GUIDE BAR CASE	€6.78
D10	Image coming soon	630B63-0 DC40RA (BULK) FAST CHARGER	€147.41
C11	Image coming soon	688131-1 FILTER LINE X MT240	€1.40
C10	Image coming soon	688131-1 FILTER LINE X MT240	€1.40
A05	Image coming soon	782023-7 WRENCH 13-16	€3.37
F07-1	Image coming soon	D-70954 FILE HOLDER SET 4.5MM(11/64")	€11.42
001	Image coming soon	413979-0 FRONT HANDLE	€5.13
002	Image coming soon	122A77-2 TANK CAP ASSEMBLY	€14.34
003	Image coming soon	213080-9 RING 29.5 PS32CTLC	€5.43
004		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
006	Image coming soon	141G07-0 SWITCH CIRCUIT COMPLETE	€18.98
007	Image coming soon	266420-0 SCREW 5PER20 HR2800	€1.44
008	Image coming soon	183U56-5 HOUSING SET	€56.02
009	Image coming soon	232713-7 TORSION SPRING 10	€1.40
010	Image coming soon	413987-1 CATCH LEVER	€2.08
011	Image coming soon	650011-1 SWITCH C3JR-4BM-PAND3	€28.31
012	Image coming soon	632L49-0 SWITCH UNIT	€10.07
013	Image coming soon	459282-5 SWITCH LEVER	€1.30
014	Image coming soon	632L48-2 SWITCH UNIT	€17.02
015	Image coming soon	620F70-5 620265-4	€181.26
016	Image coming soon	652031-1 SCREW M3x6	€1.40
017	Image coming soon	632S63-8 TERMINAL UNIT	€9.89
019	Image coming soon	422467-6 CAP	€1.44
020	Image coming soon	422764-0 OIL TUBE 3-85	€2.69
021	Image coming soon	911113-1 SCREW M4X10 X LS1013	€1.47
022		142156-4 Oil Pump for Electric Chainsaw Makita UC3041A	€24.95
023	Image coming soon	422765-8 OIL TUBE 3-109	€2.69
024	Image coming soon	231975-4 SPRING TUBE OIL X DCS230T	€1.47
025	Image coming soon	452666-6 PLUG OIL PIPE PS32CTLC	€1.32
026	Image coming soon	911218-7 HEAD SCREW CILIND. M5x14	€1.54
027	Image coming soon	961011-9 RETAINING RING E4	€1.44
028	Image coming soon	226884-0 WORM GEAR	€1.44
029	Image coming soon	413904-1 MOTOR HOUSING	€6.63
030	Image coming soon	652093-9 PAN HEAD SCREW M2X5	€1.40
031	Image coming soon	620F73-9 SENSOR UNIT	€35.76
032	Image coming soon	652069-6 M3x6 SCREW	€1.43
033	Image coming soon	629A85-9 STATOR	€28.31
034	Image coming soon	413980-5 BAFFLE PLATE	€2.69
035		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
036	Image coming soon	210026-6 BALL BEARING 696ZZ	€3.83
037	Image coming soon	519710-3 ROTOR ASSY	€61.62
038	Image coming soon	210059-1 BEARING 6000 HR2010	€11.29
039	Image coming soon	911118-1 M4PER12 SCREW	€2.74
040	Image coming soon	413907-5 FRONT HAND GUARD RETAINER	€3.13
041	Image coming soon	141E58-1 FRONT HAND GUARD COMPLETE	€9.89
042	Image coming soon	232714-5 COMPRESSION SPRING 3	€1.40
043	Image coming soon	313212-9 PS32CTLC GUIDE	€1.47
045	Image coming soon	183U56-5 HOUSING SET	€56.02
047	Image coming soon	422466-8 GROMET	€1.44
048	Image coming soon	227620-7 DRIVE GEAR	€2.03
049	Image coming soon	227634-6 STRAIGHT BEVEL GEAR 14	€3.83
050	Image coming soon	347517-5 TENSION SLIDE	€2.14
051	Image coming soon	327317-9 ADJUST SCREW	€2.77
052		227496-2 Tensioner Screw Gear for Chainsaw Makita UC3551A	€6.00
053	Image coming soon	281222-3 HOOK	€1.32
054	Image coming soon	347514-1 HOOK SUPPORT	€1.44
055	Image coming soon	347516-7 CHAIN CATCHER	€1.44
056		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
057		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
058	Image coming soon	346809-9 SPIKE BUMPER EA3700T/PS-3700T	€2.14
059	Image coming soon	141E60-4 LINK PLATE COMPLETE	€6.63
060	Image coming soon	232452-9 COMPRESSION SPRING 7	€1.24
061	Image coming soon	347864-4 BRAKE BAND	€4.43
062	Image coming soon	413981-3 HOUSING R COVER	€3.84
063		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
064	Image coming soon	162979-4 BRAKE DRUM	€9.89
065	Image coming soon	213060-5 O-RING 10	€1.27
066	Image coming soon	191V90-7 SPROCKET 6 SET	€9.89
067	Image coming soon	961013-5 RING RITEGNOXJN3200	€2.03
068	Image coming soon	347533-7 GUIDE PLATE L	€1.44
069	Image coming soon	266905-6 H.L. SOCKET HEAD BOLT M5X12	€1.32
070		266007-8 Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030	€2.03
071	Image coming soon	347534-5 GUIDE PLATE R	€1.44
072	Image coming soon	136573-8 SPROCKET COVER ASS'Y	€18.98
073	Image coming soon	162494-8 FRANGE NUT COMPLETE	€6.00
074	Image coming soon	413986-3 NUT COVER	€1.92
076	Image coming soon	422310-9 CHIP GUIDE	€1.32
077	Image coming soon	324616-0 TIE X DCS230T - PS220TH	€3.95

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita Cordless Chainsaw UC002G Spare Parts

Fix Your Cordless Chainsaw UC002G. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.

MAKITA UC002G 25cm CORDLESS CHAIN SAW 115MM Spare Parts
#	Part Num.	Description
001	413979-0	FRONT HANDLE
002	122A77-2	TANK CAP ASSEMBLY
D10		INC. 3
003	213080-9	O RING 29.5
004	266326-2	TAPPING SCREW 4X18
005	8041P2-4	UC002G MODEL NO. LABEL
006	141G07-0	SWITCH CIRCUIT COMPLETE
C10	810D46-0	SWITCH LABEL
007	266420-0	TAPPING SCREW 5X20
007-1	265C57-8	TAPPING SCREW 5X20
008	183U56-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
D10		INC. 19,45
008-1	1831C9-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
D10		INC. 19,45
009	232713-7	TORSION SPRING 10
009-1	232867-0	TORSION SPRING 10
010	413987-1	CATCH LEVER
010-1	141V70-3	LOCK OFF LEVER COMPLETE
011	650011-1	SWITCH C3JR-4BM-PAND3
012	632L49-0	SWITCH UNIT
013	459282-5	SWITCH LEVER
014	632L48-2	SWITCH UNIT
015	620F70-5	CONTROLLER
C10	688131-1	LINE FILTER
015-1	620P50-1	CONTROLLER
C11	688131-1	LINE FILTER
016	652031-1	PAN HEAD SCREW M3X6
017	632S63-8	TERMINAL UNIT
018	8110T7-9	UC002G SERIAL NO. LABEL
019	422467-6	CAP
020	422764-0	OIL TUBE 3-85
021	911113-1	PAN HEAD SCREW M4X10 WITH
		WR
022	142156-4	OIL PUMP COMPLETE
023	422765-8	OIL TUBE 3-109
024	231975-4	SPRING
025	452666-6	NIPPLE
026	911218-7	PAN HEAD SCREW M5X14
027	961011-9	STOP RING E-4
028	226884-0	WORM GEAR
029	413904-1	MOTOR HOUSING
030	652093-9	PAN HEAD SCREW M2X5
030-1	652119-7	PAN HEAD SCREW M2X6
031	620F73-9	SENSOR UNIT
032	652069-6	FLAT HEAD SCREW M3X6
033	629A85-9	STATOR
034	413980-5	BAFFLE PLATE
034-1	413V76-4	BAFFLE PLATE
035	266326-2	TAPPING SCREW 4X18
036	210026-6	BALL BEARING 696ZZ
037	519710-3	ROTOR ASSY
D10		INC. 36,38
038	210059-1	BALL BEARING 6000DDW
039	911118-1	PAN HEAD SCREW M4X12
040	413907-5	FRONT HAND GUARD RETAINER
041	141E58-1	FRONT HAND GUARD COMPLETE
C10	8042N8-4	CAUTION LABEL
042	232714-5	COMPRESSION SPRING 3
043	313212-9	HAND GUARD GUIDE
044	8110T4-5	UC002G NAME PLATE
045	183U56-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
D10		INC. 8,19
045-1	1831C9-5	HOUSING SET
C10	263005-3	RUBBER PIN 6
D10		INC. 8,19
046	8012U4-2	XGT LOGO LABEL
047	422466-8	GROMET
048	227620-7	DRIVE GEAR 14
049	227634-6	STRAIGHT BEVEL GEAR 14
050	347517-5	TENSION SLIDE
051	327317-9	ADJUST SCREW
052	227496-2	STRAIGHT BEVEL GEAR 14
053	281222-3	HOOK
054	347514-1	HOOK SUPPORT
054-1	347D19-5	HOOK SUPPORT
055	347516-7	CHAIN CATCHER
056	266326-2	TAPPING SCREW 4X18
057	266326-2	TAPPING SCREW 4X18
058	346809-9	SPIKE BUMPER
059	141E60-4	LINK PLATE COMPLETE
060	232452-9	COMPRESSION SPRING 7
061	347864-4	BRAKE BAND
062	413981-3	HOUSING R COVER
063	266326-2	TAPPING SCREW 4X18
064	162979-4	BRAKE DRUM
065	213060-5	O RING 10
066	191V90-7	SPROCKET 6 SET
067	961013-5	STOP RING E-7
068	347533-7	GUIDE PLATE L
069	266905-6	H.L. SOCKET HEAD BOLT M5X12
070	266007-8	TAPPING SCREW BIND PT 3X10
071	347534-5	GUIDE PLATE R
072	136573-8	SPROCKET COVER ASS'Y
D10		INC. 70,71,73,74,76
073	162494-8	FLANGE NUT COMPLETE
074	413986-3	NUT COVER
076	422310-9	CHIP GUIDE
077	324616-0	HOSE CLAMP
A01	191G14-3	GUIDE BAR 10 SET
A02	458501-6	GUIDE BAR CASE
A02-1	458501-6	GUIDE BAR CASE
A03	199897-3	OIL VESSEL SET
A04	199075-5	SAW CHAIN SET
A04-1	191H00-0	SAW CHAIN 10 SET
A05	782023-7	WRENCH 13-16
A07	412393-7	BATTERY COVER
A07-1	412393-7	BATTERY COVER
A08	191E07-8	DC40RA FAST CHARGER
D10	630B63-0	DC40RA (BULK) FAST CHARGER
A09	191B36-3	BATTERY BL4025 40V MAX 2,5AH
A11	191C10-7	INTERCHANGEABLE ADAPTER
A12	191J81-6	KIT ENERGY 40VmaxBL4025 2,5Ax2+DC40RA
A13	191J97-1	KIT ENERGY 40VmaxBL4040 4Ax2+DC40RA
E01	8039U0-8	CAUTION TAG
E02	8040V6-2	SOUND LABEL
F02	191H00-0	SAW CHAIN 10 SET
F03	191H08-4	SAW CHAIN 10 SET
F04	191V90-7	SPROCKET 6 SET
F06	195093-1	CHAIN OIL SET
F07	195923-6	ROUND FILE 4.5 SET
F07-1	D-70954	FILE HOLDER SET 4.5MM(11/64")
F08	196205-9	SAW CHAIN SET
F09	198457-8	CHAIN EDGER SET
F09-1	D-70948	FILE HOLDER SET 4.0MM(5/32")
F10	199075-5	SAW CHAIN SET
E01	8032W7-6	CAUTION TAG

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference Makita UC002G

Available 6 Items

Data sheet

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]

Specific References

Condition New

Download

Makita UC002G Parts Diagram

Download (534.14KB)

Makita SKU: 142156-4

Oil Pump for Electric Chainsaw Makita UC3041A

Oil Pump for Electric Chainsaw Makita UC3041A Genuine parts Makita, Oil Pump for Electric Chainsaws UC3041A - UC3541A - UC3551A - UC4051A - ES2136TLC - ES2141TLC - DUC252Z - DUC353Z. Parts for the following products: - ES2136TLC -...

AVAILABLE €24.95

Details

Makita SKU: 227496-2

Tensioner Screw Gear for Chainsaw Makita UC3551A

Makita UC3551A Spiral Bevel Gear Genuine parts Makita, Tensioner Screw Spiral Bevel Gear for Chainsaws UC3551A - UC4051A - ES2141TLC - ES2136TLC - DUC252Z - AS3726. Parts for the following products: - AS3625LGE - CHAINSAW 25CM...

Usually Ships in: 7/10 Business Days Approx. €6.00

Details

Makita SKU: 326310-0

Tensioner Screw Pin for Chainsaw Makita UC3551A

Tensioner Screw Pin for Chainsaw Makita UC3551A Genuine parts Makita, Tensioner Screw Pin for Chainsaws UC3551A - UC4051A - ES2141TLC - ES2136TLC - DUC252Z - AS3726. Parts for the following products: - AS3726 - Chain Saw 18VX2 DOLMAR...

on 7/10 Business Days Approx €1.32

Details

Makita SKU: 142235-8

Sprocket Cover Nut Complete for Electric Chainsaw Makita UC3041A

Sprocket Cover Nut Complete for Electric Chainsaw Makita UC3041A Genuine parts Makita, Sprocket Cover Nut Complete for Electric Chaisaws UC3041A - UC3541A - UC4041A - Dolmar ES34TLC - ES39TLC Parts for the following products: - AS3726...

AVAILABLE €10.07

Details

Makita SKU: 266326-2

Strain Relief Screw M4x16 for Angle Grinder Makita GA4530

Strain Relief Screw M4x16 for Angle Grinder Makita GA4530 Genuine part Makita, Strain Relief Special Screw M4x16 for Angle GrinderS GA4530 - GA4530R - GA4534 - GA5034 - Plate Joiner PJ7000. Parts for the following...

AVAILABLE €1.27

Details

Comments (0)

Cart (0)

Subcategories

Subcategories

Subcategories

Power Tools Spare Parts

Garden Spare Parts

Air Compressor Spare Parts

Protezione & Edilizia

Impianti & Utensili

Casa & Giardino

Makita Cordless Chainsaw UC002G Parts

Makita Cordless Chainsaw UC002G Spare Parts

Makita Cordless Chainsaw UC002G Parts

Makita Cordless Chainsaw UC002G Spare Parts

Makita Cordless Chainsaw UC002G Spare Parts

Data sheet

Specific References

Download

Makita UC002G Parts Diagram

You might also like

Products

News

Notes

Our company
